Honeywell HMAX082 User manual

HMAX082/HMAX162
Matrix Switcher
HKJMMTP
Keyboards
Owner’s Operation Guide
900.0560 - July 2005 – Rev. 1

ISSUE DATE REVISIONS
01 July 2005 Initial Release
Rev. 1 ii 900.0560
18-July-2005

FCC COMPLIANCE STATEMENT
INFORMATION TO THE USER: This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at
his own expense.
CAUTION: Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada.
USERS OF THE PRODUCT ARE RESPONSIBLE FOR CHECKING AND
COMPLYING WITH ALL FEDERAL, STATE, AND LOCAL LAWS AND
STATUTES CONCERNING THE MONITORING AND RECORDING OF
VIDEO AND AUDIO SIGNALS. HONEYWELL VIDEO SYSTEMS SHALL
NOT BE HELD RESPONSIBLE FOR THE USE OF THIS PRODUCT IN
VIOLATION OF CURRENT LAWS AND STATUTES.
Rev. 1 iii 900.0560
18-July-2005

IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS – All safety and operating instructions should be read before the unit is
operated.
2. RETAIN INSTRUCTIONS – The safety and operating instructions should be retained for future
reference.
3. HEED WARNINGS – All warnings on the unit and in the operating instructions should be adhered
to.
4. FOLLOW INSTRUCTIONS – All operating and use instructions should be followed.
5. CLEANING – Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
6. ATTACHMENTS – Do not use attachments not recommended by the product manufacturer as
they may result in the risk of fire, electric shock, or injury to persons.
7. WATER AND MOISTURE – Do not use this unit near water or in an unprotected outdoor
installation, or any area which is classified as a wet location.
8. ACCESSORIES - Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or adult and
serious damage to the equipment. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the product. Any mounting of
the product should follow the manufacturer’s instructions and should use a mounting
accessory recommended by the manufacturer. Wall or shelf mounting should follow the
manufacturer’s instructions and should use a mounting kit approved by the manufacturer.
9. A product and cart combination should be moved with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart combination to overturn.
10. VENTILATION - Slots and openings in the cabinet and the back or bottom are provided for
ventilation and to ensure reliable operation of the equipment and to protect it from overheating.
These openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. Equipment should never be
placed near or over a radiator or heat register. This product should not be placed in a built-in
installation, such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
11. POWER SOURCES – This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supplied to your home,
consult your product dealer or local power company. For products designed to operate from
battery power or other sources, refer to the operating instructions.
12. GROUNDING OR POLARIZATION – The power supply supplied with this unit may be equipped
with a polarized alternating-current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Rev. 1 iv 900.0560
18-July-2005

IMPORTANT SAFEGUARDS, CONTINUED
13. OVERLOADING – Do not overload outlets and extension cords as this can result in a risk of fire or
electric shock.
14. POWER-CORD PROTECTION – Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them, paying particular attention to
cords and plugs, convenience receptacles, and the point where they exit from the monitor.
15. OBJECT AND LIQUID ENTRY – Never push objects of any kind into this unit through openings as
they may touch dangerous voltage points or short-out parts that could result in a fire or electric
shock. Never spill liquid of any kind on the unit.
16. SERVICING – Do not attempt to service this unit yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.
17. DAMAGE REQUIRING SERVICE – Unplug the unit from the outlet and refer servicing to qualified
service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to
restore the unit to its normal operation.
e. If the unit has been dropped or the enclosure has been damaged.
f. When the unit exhibits a distinct change in performance - this indicates a need for service.
18. REPLACEMENT PARTS – When replacement parts are required, be sure the service technician
has used replacement parts specified by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric shock or other hazards.
19. SAFETY CHECK – Upon completion of any service or repairs to this unit, ask the service
technician to perform safety checks to determine that the unit is in proper operating condition.
20. LIGHTNING AND POWER LINE SURGES – For added protection of this unit during a lightning
storm, or when it is left unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the cable system. This will prevent damage to the unit due to lightning and
power-line surges.
21. HEAT – The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers) that produce heat.
22. INSTALLATION – Do not install the unit in an extremely hot or humid location, or in a place
subject to dust or mechanical vibration. The unit is not designed to be waterproof. Exposure to
rain or water may damage the unit.
Rev. 1 v 900.0560
18-July-2005

IMPORTANT SAFEGUARDS
23. WALL OR CEILING MOUNTING – The product should be mounted to a wall or ceiling only as
recommended by the manufacturer
Rev. 1 vi 900.0560
18-July-2005

EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instruction in the literature
accompanying the product.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: DO NOT INSERT ANY METALLIC OBJECT THROUGH
VENTILATION GRILLS THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: THIS UNIT MUST BE OPERATED WITH A PROPERLY
GROUNDED 3-PIN CONNECTION.
NON-OBSERVANCE OF THIS STANDARD PRACTICE MAY RESULT IN A
STATIC ELECTRICITY BUILD-UP THAT MAY RESULT IN AN ELECTRIC
SHOCK WHEN EXTERNAL CONNECTIONS ARE TOUCHED.
Rev. 1 vii 900.0560
18-July-2005

Notes:
Rev. 1 viii 900.0560
18-July-2005

TABLE OF CONTENTS
SECTION 1: OPERATION......................................................................................................................... 1
1.1 SYSTEM INITIALISATION ................................................................................................................ 1
1.2 JOYSTICK RECALIBRATION ........................................................................................................... 1
1.3 KEYBOARD KEY PRESS OPERATION ............................................................................................ 1
1.4 USER LOG ON................................................................................................................................. 2
1.5 USER LOG OFF ............................................................................................................................... 4
SECTION 2: CAMERA/MONITOR SELECTION ....................................................................................... 5
2.1 MONITOR SELECT .......................................................................................................................... 5
2.1.1 Single Monitor MaxCom Gold Keyboard......................................................................... 5
2.1.2 Multi Monitor MaxCom Gold Keyboard ........................................................................... 5
2.1.3 RS485 and RS232 Keyboard Control.............................................................................. 5
2.2 CAMERA SELECT............................................................................................................................ 6
2.2.1 Selecting by camera number .......................................................................................... 6
2.2.2 Camera Button................................................................................................................. 6
2.3 AUTO-SEQUENCE CONTROL ........................................................................................................ 7
2.3.1 Auto-Sequence On/Off .................................................................................................... 7
2.3.2 Programming Auto-Sequences ....................................................................................... 7
SECTION 3: TELEMETRY FUNCTIONS ................................................................................................... 8
3.0 INTRODUCTION .............................................................................................................................. 8
3.1 SYSTEMS WITH MORE THAN ONE KEYBOARD............................................................................ 8
3.1.1 Controlling cameras ........................................................................................................ 8
3.1.2 Programming Mimic Tours .............................................................................................. 9
3.1.3 Menu Access ................................................................................................................. 10
3.1.4 PC Configuration ........................................................................................................... 10
3.2 PAN AND TILT................................................................................................................................ 10
3.3 TURN 180°..................................................................................................................................... 10
3.4 ZOOM............................................................................................................................................. 10
3.5 FOCUS ........................................................................................................................................... 11
3.6 IRIS................................................................................................................................................. 11
3.7 MANUAL CHANGE OVER (COLOUR TO MONO) ......................................................................... 11
3.8 WASH, WIPE, AND AUXILIARY FUNCTIONS ................................................................................ 11
Rev. 1 ix 900.0560
18-July-2005

TABLE OF CONTENTS, CONTINUED
SECTION 4: PRESETS............................................................................................................................ 13
4.0 DEFINITION.................................................................................................................................... 13
4.1 DEFINING A PRESET..................................................................................................................... 13
4.2 SEEKING A PRESET...................................................................................................................... 13
SECTION 5: TOURS................................................................................................................................ 14
5.0 DEFINTION .................................................................................................................................... 14
5.1 STARTING A TOUR........................................................................................................................ 14
5.2 STOPPING A TOUR ....................................................................................................................... 14
5.3 RESTARTING A TOUR ................................................................................................................... 14
SECTION 6: MIMIC TOURS.................................................................................................................... 15
6.0 DEFINITION.................................................................................................................................... 15
6.1 RECORDING A MIMIC TOUR ........................................................................................................ 15
6.2 PLAYING BACK A MIMIC TOUR .................................................................................................... 15
6.3 STOPPING A MIMIC TOUR............................................................................................................ 16
6.4 RESTARTING A MIMIC TOUR........................................................................................................ 16
SECTION 7: MENU OPTIONS ................................................................................................................ 17
7.0 DESCRIPTION................................................................................................................................ 17
7.1 CAMERAS ...................................................................................................................................... 18
7.1.1 Camera, Preset, and Sector Titles................................................................................. 19
7.1.2 Camera Settings (RapidDomes).................................................................................... 21
7.1.3 Tours.............................................................................................................................. 23
7.1.4 Synchronization (Line-Lock).......................................................................................... 24
7.1.5 Privacy Zones ................................................................................................................ 26
7.1.5.1 Tips for Defining a Preset that is defined as a Privacy Zone............................ 27
7.1.5.2 Defining Presets as Privacy Zones ................................................................... 27
7.1.5.3 Additional Points to Remember about Privacy Zones...................................... 28
7.1.6 Sector Zones ................................................................................................................. 28
7.1.6.1 Defining a Sector Zone..................................................................................... 28
7.1.7 Remote Reset ................................................................................................................ 29
7.2 MONITORS .................................................................................................................................... 31
7.2.1 Auto-Sequence .............................................................................................................. 31
7.2.2 Partitioning..................................................................................................................... 32
7.2.3 Text Brightness .............................................................................................................. 32
Rev. 1 x 900.0560
18-July-2005

TABLE OF CONTENTS, CONTINUED
7.3 SYSTEM ......................................................................................................................................... 33
7.3.1 Time/Date Setting .......................................................................................................... 33
7.3.2 Time/Date Format .......................................................................................................... 34
7.3.3 Monitor Control.............................................................................................................. 34
7.3.4 Universal Sequences..................................................................................................... 35
7.3.5 Language....................................................................................................................... 35
7.3.6 Event Timers .................................................................................................................. 35
7.3.7 Salvo Switching ............................................................................................................. 35
7.4 ALARMS ......................................................................................................................................... 35
7.4.1 System Alarms............................................................................................................... 35
7.4.1.1 System Alarm Settings ..................................................................................... 36
7.4.1.2 System Alarm Actions....................................................................................... 36
7.4.1.3 Contact Tables.................................................................................................. 37
7.4.1.4 Messages.......................................................................................................... 37
7.4.2 Camera Alarms .............................................................................................................. 37
7.4.3 Alarm Properties ............................................................................................................ 37
7.5 SOFTWARE.................................................................................................................................... 38
SECTION 8: SOFTWARE CONFIGURATION UTILITY........................................................................... 39
8.0 INTRODUCTION ............................................................................................................................ 39
8.1 INSTALLING THE SOFTWARE ...................................................................................................... 39
8.1.1 Auto-Run........................................................................................................................39
8.1.2 Manual Installation......................................................................................................... 40
8.2 STARTING THE PROGRAM........................................................................................................... 44
8.2.1 Communicating with the MaxCom Gold ....................................................................... 47
8.2.1.1 Auto Detection Connection .............................................................................. 49
8.2.1.2 Selected Baud Rate Connection ...................................................................... 50
8.2.1.3 End Communication between the PC and the MaxCom Gold.........................51
8.2.1.4 Request Status ................................................................................................. 52
8.2.1.5 Reset Connection ............................................................................................. 52
8.2.1.6 Maxcom References ......................................................................................... 53
8.2.1.7 Display Port Buffer ............................................................................................ 53
8.2.1.8 Clear Output Buffer........................................................................................... 53
8.2.1.9 Clear Port Buffer ............................................................................................... 53
8.3 CONFIGURING THE MAXCOM GOLD .......................................................................................... 54
8.3.1 Opening an Embedded File in the PC Configuration Utility for a Default Configuration54
8.3.2 Transmitting a Default Configuration or Current Configuration from a MaxCom Gold to
the PC Configuration Utility ........................................................................................... 56
8.3.3 Programming Auto-Sequences ..................................................................................... 57
8.3.4 User Privileges ............................................................................................................... 60
8.3.5 Alarms............................................................................................................................ 64
8.3.6 Monitor Partitioning ....................................................................................................... 67
Rev. 1 xi 900.0560
18-July-2005

TABLE OF CONTENTS, CONTINUED
8.3.7 Keyboard Camera Privileges ......................................................................................... 69
8.3.8 Menu Access Rights ...................................................................................................... 72
8.3.9 Settings.......................................................................................................................... 74
8.4 CONFIGURING CAMERAS ............................................................................................................ 77
8.4.1 Camera Setup................................................................................................................ 77
8.4.2 Preset Titles ...................................................................................................................80
8.4.3 Privacy Zones ................................................................................................................ 82
8.4.4 Sector Titles ...................................................................................................................86
8.4.5 Tours.............................................................................................................................. 88
8.4.6 Alarms............................................................................................................................ 92
8.4.7 Contact Tables............................................................................................................... 92
SECTION 9: MAX FLASH UTILITY ......................................................................................................... 93
9.0 INTRODUCTION ............................................................................................................................ 93
9.1 AUTO-RUN..................................................................................................................................... 93
9.2 MANUAL INSTALLATION............................................................................................................... 93
9.3 STARTING THE MAXFLASH PROGRAM ....................................................................................... 96
9.3.1 Transmit ROM from the PC to the MaxCom Gold ......................................................... 97
9.3.2 Receive ROM from the MaxCom Gold to the PC ........................................................ 101
Rev. 1 xii 900.0560
18-July-2005

SECTION 1:
OPERATION
1.1 SYSTEM INITIALISATION
During the initialization phase, if the RapidDomes are initialized at the same time, the
RapidDome will display blanked video until initialization is complete; normal video will
then be displayed.
A start-up screen is displayed on the monitor display for approximately 5 seconds. The
start-up screen shows the MaxCom Gold model (e.g. 8/1, 16/2, etc.), the software
compilation date (e.g. Oct 24 2003), and the software version number (e.g. V01.00).
The keyboards automatically self-calibrate the joystick on power-up. The current
position of the joystick is defined at the centre point.
The keyboard(s) connected to the MaxCom Gold are locked upon power-up. The lock
button on the keyboard is illuminated. A user must log on to the MaxCom Gold at the
keyboard to control the system. Refer to section 1.4 to log on to the system.
1.2 JOYSTICK RECALIBRATION
An operator can re-calibrate the joystick at any time after power-up. Perform the
following procedure to calibrate the joystick.
Press the F6 key and the lock button at the same time.
When powering up any connected keyboards please ensure that the joystick is not
touched or moved for the first five seconds. This allows the joystick to fully self calibrate.
Note: It is important that the operator does not move the joystick during this procedure.
1.3 KEYBOARD KEY PRESS OPERATION
Throughout the manual, reference is made to button (key) presses. If you are instructed
to press a button, it means to press then release the button. If a button must be pressed
and held, it will be specified in the instructions.
Rev. 1 1 900.0560
18-July-2005

1.4 USER LOG ON
In order to operate the MaxCom, a user must be logged on to the unit. To log on to the
MaxCom Gold control system, perform the following procedure at the keyboard.
1. Enter a valid pass code. Please refer to Table 1 for an illustration of the default
passwords and security levels.
For example, to enter pass code 00001,
a. Press 0
b. Press 0
c. Press 0
d. Press 0
e. Press 1.
2. Press lock.
Note: If an invalid pass code is entered, the keyboard sounds a beep.
After a successful log on, the lock key is no longer lit and the user number is
displayed on the upper right side of the monitor. For example, if a user logs on with
pass code 00009, the monitor displays "USER 09". If a user logs on with pass code
65536, the monitor displays "USER 16". If no user is logged on, the monitor displays
"NO USER".
There are sixteen default users defined. Each user has a 5-digit pass code and a
security level. The security levels can be changed using the PC configuration utility.
The default pass codes and security levels are as defined in the following table.
Refer to Table 2 to view the system access for the different security levels. A pass
code with a security level of None can select and control cameras, but cannot
access any of the menus to change cameras, monitors or system parameters.
Table 1. User Pass Code & Security Level
User Pass Code Security Level
1 00001 None
2 00002 None
3 00003 None
4 00004 None
5 00005 Low
6 00006 Low
7 00007 Low
8 00008 Low
9 00009 Medium
10 00010 Medium
Rev. 1 2 900.0560
18-July-2005

Table 1. User Pass Code & Security Level
User Pass Code Security Level
11 00011 Medium
12 00012 Medium
13 28561 High
14 38416 High
15 50625 High
16 65536 High
The table below illustrates the access to features relative to the security level allocated to
a user.
The automatic log out time feature can only be set up via the PC configuration utility.
Table 2. Security Levels
Menu Title Low Medium High
Main N/A – Navigation Only
Camera N/A – Navigation Only
Titles N/A – Navigation Only
Camera Titles ••
Preset Titles ••
Sector Titles ••
Camera Settings ••
Tour Settings ••
Camera Sync ••
Privacy Zones ••
Sector Zones ••
Remote Reset N/A – Navigation Only
Power Up Reset •••
Camera Reset ••
Factory Reset •
Monitor N/A – Navigation Only
Auto Sequence ••
Text Brightness ••
System N/A – Navigation Only
Time/Date
••
Time/Date Format ••
Monitor Control ••
Monitor Display ••
Alarms N/A – Navigation Only
System Alarms N/A – Navigation Only
System Alarm Settings ••
System Alarms Action ••
Alarm Properties ••
Software •••
•Indicates menus that the user can view and edit. All other menus can be viewed, but
not edited.
Rev. 1 3 900.0560
18-July-2005

1.5 USER LOG OFF
To log off the system and lock the controller, perform the following procedure.
1. Press 0
2. Press lock.
The system can be setup so a user is logged out after a period of inactivity. The
automatic log-out time is set using the PC Configuration Utility. The default period is
infinite; i.e. the automatic log out is disabled. Refer to section 8.3.9.
Note: if power is removed from the system, the user is automatically logged off. Upon
power up, the lock button is lit and the user must log back onto the system.
Rev. 1 4 900.0560
18-July-2005

SECTION 2:
CAMERA/MONITOR SELECTION
2.1 MONITOR SELECT
2.1.1 Single Monitor MaxCom Gold Keyboard
The MaxCom Gold displays the video input number that is switched to a monitor on the
top left corner of the monitor display. The Single Monitor MaxCom Gold keyboard has a
dedicated fixed connection to either monitor 1 or monitor 2, depending on the keyboard
port it is connected to. (KBD 1 or KBD2.) Pressing the monitor button will produce an
error beep as the keyboard cannot select a monitor. A right arrow () to the left of the
camera number indicates the monitor is under keyboard control.
2.1.2 Multi Monitor MaxCom Gold Keyboard
The Multi Monitor MaxCom Gold keyboard allows control of either monitor that is
connected to the MaxCom Gold (as long as this has been set up in the menu - see
section 8.3.3). The MaxCom Gold displays the video input number switched to a monitor
on the top left corner of the monitor display. A right arrow () to the left of the camera
number indicates the monitor is being controlled by the keyboard.
To switch the keyboard control to the other monitor in the system, press the monitor
button.
Note: telemetry commands are always sent to the camera that is displayed on the
monitor that is currently being controlled by a keyboard, i.e. showing the next
to the camera title.
2.1.3 RS485 and RS232 Keyboard Control
The MaxCom Gold can be configured so that either an RS485 keyboard or an RS232
keyboard can control one or both monitor outputs. RS485 keyboards are connected to
one of the RJ45 sockets (KBD1 or KBD2) and the RS232 keyboard is connected at the
RS232 CTRL connector.
If an RS232 keyboard has control of a monitor, an asterisk (∗) is displayed to the left of
the camera number on the monitor.
Two keyboards cannot control the same monitor output at the same time. This does not
mean that the operator has to be actively using the keyboard all the time. It just means
the operator can take control of the monitor output at any time. The RS232 keyboard
always has priority over the RS485 keyboard when both keyboards are connected to
the MaxCom Gold and configured to control the same monitor output. If an RS485
keyboard tries to control a monitor output being controlled by an RS232 keyboard, the
message, "RS232 KEYBOARD CONNECTED", is displayed on the monitor being
controlled by the RS232 keyboard (the same monitor the RS485 keyboard is trying to
control), and a long error beep is produced at the keyboard.
Rev. 1 5 900.0560
18-July-2005

2.1.3 RS485 and RS232 Keyboard Control, Continued
The operation is also dependent on the type of RS485 keyboard; whether it is a Single
Monitor type (can control only one monitor output) or a Multi Monitor type (can control
either monitor outputs).
a. Single Monitor Type RS485 Keyboard
If a Single Monitor type RS485 keyboard and an RS232 keyboard are both
connected to the MaxCom Gold, and the RS232 keyboard is controlling the same
monitor output as the RS485, the RS485 keyboard cannot gain control of the
monitor output until the RS232 keyboard is disconnected from the MaxCom Gold.
The "RS232 KEYBOARD CONNECTED" message remains on the monitor display
until the RS232 keyboard is disconnected.
b. Multi Monitor Type RS485 Keyboard
If a Multi Monitor type RS485 keyboard and an RS232 keyboard are both connected
to the MaxCom Gold, the RS485 keyboard can control the monitor output not being
controlled by the RS232 keyboard. If the Multi Monitor type keyboard operator tries
to control the monitor the RS232 keyboard is controlling, the message, "RS232
KEYBOARD CONNECTED", is displayed on the monitor being controlled by the
RS232 keyboard, and a long error beep is produced at the keyboard. The message
remains on the monitor until the RS232 keyboard selects the other monitor output
for control or the RS232 keyboard is disconnected from the system.
2.2 CAMERA SELECT
2.2.1 Selecting by camera number
1. Press the number button(s) that correspond(s) to the camera number. For
example, to select camera 15, press the 1 button, then press the 5 button.
2. Press the camera button.
2.2.2 Camera Button
To sequence numerically between the cameras in the system, repeatedly press the
camera button until the desired camera is displayed.
If a camera is absent from the system, the MaxCom Gold automatically skips (auto-skip)
to the next camera that is present in the system.
Note: See section 2.3.1 for operation while auto-sequence is on.
Rev. 1 6 900.0560
18-July-2005

2.3 AUTO-SEQUENCE CONTROL
The MaxCom Gold has an auto camera-sequencing feature. When turned on, the
MaxCom Gold automatically sequences between the cameras defined in the sequence
on the monitor being controlled by the keyboard. Refer to section 2.3.2 for
programming auto sequences.
Note: If the joystick is moved or a telemetry button is pressed while the keyboard is
auto-sequencing, the auto-sequencing is turned off.
2.3.1 Auto-Sequence On/Off
Pressing the black auto button toggles auto-sequence on and off. When auto-
sequence is on, the black auto button is illuminated.
Note 1: If a user continuously presses the camera button while auto-sequence is on, the
system sequences through only the cameras defined in the sequence. If a camera
defined in the sequence is absent, the MaxCom Gold automatically skips (auto-skip) to
the next camera in the sequence that is present.
Note 2: Auto-sequencing is turned off automatically if the joystick is moved or a
telemetry button is pressed while the monitor under control is auto sequencing. The
black auto button is no longer lit.
Note 3: If a user selects a specific camera (camera number then camera button), auto-
sequencing is turned off and the black auto button is no longer lit.
2.3.2 Programming Auto-Sequences
Camera auto sequences can be programmed by using the MaxCom Gold Menu
Options. Refer to section 7.2.1 to program sequences through the menu options.
Rev. 1 7 900.0560
18-July-2005

SECTION 3:
TELEMETRY FUNCTIONS
3.0 INTRODUCTION
The MaxCom range of keyboards and switchers can control any Honeywell telemetry
receiver. The features that can be used depend on the features that are available on the
RapidDome or telemetry receiver.
Under normal operation, there is no audible beep when pressing the telemetry function
buttons.
When the joystick is used or when telemetry buttons are pressed, commands are sent to
the camera that is selected on the monitor under control.
3.1 SYSTEMS WITH MORE THAN ONE KEYBOARD
If two or more keyboards are being used on a telemetry system, any commands that are
sent to the camera that cause the telemetry LEDs to change on the keyboards will cause
the same telemetry LEDs to change on any other keyboard that has the same camera
selected.
3.1.1 Controlling cameras
Two operators cannot control the same camera at the same time. There are several
situations in which this can occur.
1. If a second operator tries to control a camera already being controlled by another
operator, the message, “CAMERA IN USE”, is displayed on the monitor being
controlled by the second operator and a long error beep is produced at the
keyboard. The message is displayed on the screen until the first operator stops
controlling the camera and does not send any telemetry commands to the camera
for 5 seconds. Once the message is removed, the second operator can control the
camera.
2. If one operator is programming a “mimic tour” in a camera and a second operator
tries to send telemetry to the camera, the message, “CAMERA IN USE”, is displayed
and a long error beep is produced at the keyboard. As soon as the first operator
completes the programming, the message is removed and the second operator can
control the camera. In this case, there is no 5-second delay before handing over
control.
3. If one operator is programming a sector zone for a camera and a second operator
tries to control that camera, the "CAMERA IN USE" message is displayed on the
monitor being controlled by the second operator and a long error beep is produced
at the keyboard. The message is displayed on the screen until the first operator has
completed the programming of the sector zone. In this case, there is no 5-second
delay before handing over control.
Rev. 1 8 900.0560
18-July-2005
