vissonic VIS-PHD1616 User manual

- 1 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
VIS-PHD1616
4K2K HDMI 16x16 Matrix Switcher
User Manual
V1.0 Version

- 2 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
Content
1 Product Overview.............................................................................................................................5
1.1 Product Overview................................................................................................................. 5
1.2 Features................................................................................................................................. 5
1.3 Specification..........................................................................................................................5
1.4 Connection Diagram............................................................................................................. 7
2 Hardware.......................................................................................................................................... 8
2.1 Front panel introduction........................................................................................................8
2.1.1 Display format on the LCD........................................................................................................8
2.1.2 Front panel operation................................................................................................................. 8
2.2Rear pannel introduction........................................................................................................9
3 Control Way................................................................................................................................... 10
3.1 RS232 Control.....................................................................................................................10
3.2 RJ45 TCP/IP Control.......................................................................................................... 11
4 Software...................................................................................................................................... 13
4.1 Switch..................................................................................................................................13
4.2 Keyboard.............................................................................................................................14
4.3 Debug.................................................................................................................................. 15
4.4 demo....................................................................................................................................16
5 Command list................................................................................................................................. 18
5.1 Switching command............................................................................................................18
5.2 Save and call status............................................................................................................. 18
5.3 Enquiry................................................................................................................................18
6 Common Faults and Maintenance................................................................................................. 19

- 3 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
Important note
Warning
In order to ensure the reliable performance of the equipment and the safety of the user, please observe
the following matters during the process of installation, use and maintenance:
◆Please do not use this product in the following places: the place of dust, soot and electric
conductivity dust, corrosive gas, combustible gas; the place exposed to high temperature,
condensation, wind and rain; the occasion of vibration and impact. Electric shock, fire, wrong
operation can lead to damage and deterioration to the product, either;
◆In processing the screw holes and wiring, make sure that metal scraps and wire head will not
fall into the shaft of controller, as it could cause a fire, fault, or incorrect operation;
◆When the installation work is over, it should be assured there is nothing on the ventilated face,
including packaging items like dust paper. Otherwise, this may cause a fire, fault, incorrect
operation for the cooling is not free;
◆Should avoid wiring and inserting cable plug in charged state, otherwise it is easy to cause the
shock, or electrical damage;
◆The installation and wiring should be strong and reliable, contact undesirable may lead to false
action;
◆For a serious interference in applications, should choose shield cable as the high frequency
signal input or output cable, so as to improve the anti-jamming ability of the system.
Attention in the wiring
◆Only after cutting down all external power source, can install, wiring operation begin, or it may
cause electric shock or equipment damage;
◆This product grounds by the grounding wires .To avoid electric shocks, grounding wires and the
earth must be linked together. Before the connection of input or output terminal, please make sure
this product is correctly grounded;
◆Immediately remove all other things after the wiring installation. Please cover the terminals of
the products cover before electrification so as to avoid cause electric shock.
Matters needing attention during operation and maintenance:

- 4 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
◆Please do not touch terminals in a current state, or it may cause a shock, incorrect
operation;
◆Please do cleaning and terminal tighten work after turning off the power supply. These
operations can lead to electric shock in a current
state;
◆Please do the connection or dismantle work of the communication signal cable , the expansion
module cable or control unit cable after turning
off the power supply, or it may cause damage to the equipment, incorrect operation;
◆Please do not dismantle the equipment, avoid damaging the internal electrical component;
◆Should be sure to read the manual, fully confirm the safety, only after that can do program
changes, commissioning, start and stop operation.
Matters needing attention in discarding product:
◆Electrolytic explosion: the burning of electrolytic capacitor on circuit boards may lead to
explosion;
◆Please collect and process according to the classification, do not put into life garbage;
◆Please process it as industrial waste, or according to the local environmental protection
regulations.

- 5 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
1 Product Overview
1.1 Product Overview
VIS-PHD1616 HDMI matrix is professional switcher routs UHD 4Kx2K HDMI
signals from 16 inputs to 16 outputs in need. It support 3D video,
HDCP1.4,HDMI1.4 ,4K at 30Hz and 16 bit color. The control way is included
Rs232,TCP/IP and front panel. It can be widely used in command control center,
multi-screen systems, conference room, high definition medical or education teaching
etc.
1.2 Features
◆High speed switching
◆Resolution is up to 4Kx2K at 30Hz.
◆Support 3D video
◆Support HDMI1.4.
◆Control way is front panel,RS-232,TCP/IP.
◆EDID reading function to fix any compatible problems.
◆Built-in varied of control protocols to work with control system, like
AMX,CRESTRON,VISSONIC.
◆The firmware can be updated by the TCP/IP and be convenient for remote support and OEM
the special features.
◆Input distance is up to 30m(98 feet)
◆；Powerful memory support to preset and call switching mode. With power-down memory
function, with power-off site protection;
◆2U standard housing with rack-mounting design
1.3 Specification
Model
VIS-PHD1616
Specification
Input/output support 16 channels
Input
HDMI

- 6 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
Output
HDMI
Control way
Front panel, RS-232, TCP/IP
Resolution
Up to 4k x 2k（4096×2160 ）
HDMI version
HDMI 1.4，Support 3D TV
HDCP
Compliant to HDCP 1.4
Hot plug and play
Support
Input cable
Up to 30m (98 feet)
Output cable
Up to 15m (50 feet)
HDMI input/output
interface
Type A, 19 pin, female
Power supply
110~220 VAC
Environment
Storage and Work Temperature: -20°~+70°C; humidity:10%~90%
Weight
7KG
Consumption
20W
Dimension (WxDxH)
2U（440mmx333mmx88mm）
Warranty
3 years

- 7 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
1.4 Connection Diagram

- 8 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
2 Hardware
2.1 Front panel introduction
(1) LCD display: Display the button inputs and switching status.
(2) POWER：Power on/off indicator
STATUS ：The indicator is flashing, while the command is executing and. After the
command is executed, the indicator is constantly on.
(3) Number button 0 to 9
(4) Function buttons. Description as bellowing,
AV
Switching button to divide the input and
output number
ALL
Switch the input to all output
SAVE
Save the current status and combine with
number button
LOAD
Load the status and combine with number
button
CANCEL
Cancel the operation
ENTER
Confirm the operation
2.1.1 Display format on the LCD
I N
O U T 1 2 3 4 5 6 7 8 9 A B C D E F G
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
As above picture, the every two number is a channel, IN mean input channel, OUT mean output
channel.IN row will change according to the switching. The OUT row is fixed number.
2.1.2 Front panel operation.
1、one input to one output switch
For example, input 3 switch to output 4, and we need to press the buttons as bellowing,

- 9 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
“3”+“AV” + “4”+“ENTER”（LCD display as bellow picture）；
I N
O U T 1 2 3 4 5 6 7 8 9 A B C D E F G
1 1 1 3 1 1 1 1 1 1 1 1 1 1 1 1
2、one input to all output channel
For example, switch input 2 to all output, we need to press the buttons as bellowing,
“2”+“AV”+“ALL”+“ENTER”（LCD display as bellow picture）
I N
O U T 1 2 3 4 5 6 7 8 9 A B C D E F G
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
3、Save and Load the status
Save the current input and output status, press the button as ：“number” + “SAVE”
Call the status saved before, press the button as：“number” + “LOAD”
Noted: The matrix can save 9 status (number is 1to 9)
2.2Rear panel introduction
（1）Local RS232 loop out for daisy chain connection of multi matrix.
（2）RS-232 serial port for control
（3）TCP/IP control port
（4）Reset button
（5）Power supply jack
（6）HDMI input
（7）HDMI output

- 10 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
3 Control Way
3.1 RS232 Control
The matrix provide the standard RS232 serial port. The user can control the matrix by PC or other controller.
The matrix also provide the RS-232 loop out to transfer the command to other peripherals
Serial port default setting:
Bit rate：9600，Data bit：8 bits，Stop bit：1，No parity bit
RS232 IN port（Connect to the PC）PIN defined as bellowing,
Pin
Signal
Statement
1
-
-
2
TXD
RS-232 protocol，PC send the data
3
RXD
RS-232 protocol, PC receive data.
4
-
-
5
GND
Ground
6
-
-
7
-
-
8
-
-
9
-
-
RS232 LOOP Port (connect to next matrix) pin defined as bellowing,
Pin
Signal
Statement
1
-
-
2
-
-
3
RXD
RS-232 protocol, PC receive data.
4
TXD
RS-232 protocol，PC send the data
5
GND
Ground
6
-
-
7
-
-
8
-
-
9
-
-
RS232 Connection
Link the HDMI matrix to host control computer by using RS-232 cable, when connection is finished, you can
control the matrix with the instructions we provided in the following chapter.

- 11 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
3.2 RJ45 TCP/IP Control
The network port is based on the TCP/IP Network communication protocol and apply the remote control by
Ethernet. The remote user can control the local equipment by Ethernet.
TCP/IP port default setting:
Port no.
1030
IP add.
192.168.0.188 （Static IP; While connecting to routing, the
matrix get the dynamic IP. ）
Subnet Mask
255.255.255.0
Gateway
192.168.0.1
RJ45 two connection ways
1）Cross-wire connection
Directly connect the matrix to host computer by using Cat5/5e cross-wire.
2）Straight wire connection
Connect the matrix to router or switch by using Cat5/5e straight link wire.

- 12 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
Wire line order
In this system, the CAT5/5e cable is used to connect the matrix to network control equipment, each end of the
line is fixed with the RJ-45 connector (commonly known as the crystal head). The standard line order is not
random, the purpose is to ensure the symmetry of the cable connector layout, so that the interference between the
cable and the cable can be offset. Generally, Cat5/5e cable has four twisted pairs which are marked by different
colors.
EIA/TIA 568B and EIA/TIA 568A standard:
EIA/TIA 568B and EIA/TIA 568A standard:
T568A standard
1
2
3
4
5
6
7
8
white
green
green
white
orange
blue
white
blue
orange
white
brown
brown
T568B standard
1
2
3
4
5
6
7
8
white
orange
orange
white
green
blue
white
blue
green
white
brown
brown
Straight wire connection：both ends use T568B standard.
Cross-wire connection：one end use T568A standard, one end use T568B standard.

- 13 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
4 Software
4.1 Switch
(1) Connect to the matrix switcher by RS232.
(2) Connect to the matrix switcher by TCP/IP
(3) Select your operation,
"AV" means switching audio and video
"Video" means switching video
"Audio" means switching audio
"EDID" means read the EDID from input to output
(4) Display executing the command
(5) Input channel number
(6) Output channel number
(7) Press the button to switch/EDID from input to output
For example,
We switch audio/video from input 8 to output 4.
Then we select the and press the button as bellowing picture. The video & audio will
switch from input 8 to output 4, as the command .

- 14 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
4.2 Keyboard
We get the same function as the front panel on the software.
(1) Select your operation "Video","AV","Audio", press input (Up zone) and outputs (down zone) to switch
the signal. Select "EDID" to read the input EDID to outputs. Select "Reboot MATRIX" to confirm/cancel reboot
the matrix switcher.

- 15 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
(2) Select the operation "All" and press the button number N ("1" to "16") to switch the input N to all output.
Select the operation "THROUGH" and press the button number N ("1" to "16") to switch the input N to
corresponding output N.
Select the operation "CLOSE" and press the button number N ("1" to "16") to output N.
(3) Select the operation "LOAD" and press the button number N ("1" to "9") to switch the preset status N.
Select the operation "SAVE" and press the button number N ("1" to "9") to save the current status to preset
status N.
4.3 Debug
Use to send the command directly to the matrix and you can set the "Auto" sending for debug
the matrix.

- 16 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
4.4 demo
The software will auto send the command and switch the inputs to outputs.
As above picture, "Start" is the input start channel, "End" is the input end channel. "Current
Channel" means the current switching executing input channel.
As above picture, "Start" is the output start channel, "End" is the output end channel.
"Current Channel" means the current switching output channel.
Click "start demo”, the switching operation run one input to one output.

- 17 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
from input "START" to output channel "START”, delay time, next output, delay time, until
the "END" output
.…
from input "END" to output channel "END”, delay time, next output, delay time, until the
"END" output

- 18 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
5 Command list
5.1 Switching command
1.One input to one output switch
PC TO Matrix
Function
Matrix to PC
Sample
[X1]V[Y1].
1 video input [X1] switch to output [Y1]
V:[X1]->[Y1]!
1V1.
[X1]V#.
1 video input [X1] switch to corresponding
output [Y1]
[X1] V Through!
1V#.
[X1]#.
1 video and audio input [X1] switch to
corresponding output [Y1]
[X1] A/V Through!
1#.
2. Multi input/output switch
PC TO Matrix
Function
Matrix to PC
Sample
[X1]V[Y1],[Y2].
Video input [X1] switch to output
[Y1], [Y2], [Y3],~[Yn].
V:[X1]->[Y1],[Y2] !
1V1,2,3.
[X1]All.
Audio & video input [X1] switch to all
outputs
[X1]A/V TO All!
1All.
AllV#.
All video channel input [X1], [X2]~
[Xn] switch to corresponding output[Y1],
[Y2]~ [Yn]
All V Through!
AllV#.
All#.
All video & audio channel input [X1],
[X2]~ [Xn] switch to corresponding
output[Y1], [Y2]~ [Yn]
All A/V Through!
All#.
[X1],[X2]V#.
Video input [X1],[X2] switching
corresponding output [Y1],[Y2]
[X1],[X2] V Through!
1,2,3V#.
[X1],[X2]#.
Video & Audio input [X1],[X2]
switching corresponding output [Y1],[Y2]
[X1],[X2] A/V Through!
1,2,3#.
5.2 Save and call status
PC TO Matrix
Function
Matrix to PC
Sample
Save[N].
Save the current input/output status to number
N preset
Save To F[N]!
Save1.
Load[N].
Load the number N preset status to switch
Load From F[N]!
Load1.
5.3 Enquiry
PC TO Matrix
Function
Matrix to PC
Sample
Status[Y1].
Enquiry 1 channel audio & video status
V:[X1]->[X2]！
Status1.
Status.
Enquiry all channel audio & video status
V:[X1]->[X2]！
……
Status.

- 19 - VISSONIC E LE C T R O NICS LIMITED
www.vissonic.com
6 Common Faults and Maintenance
1. Signal interference: the power supply must be connected to the power protection ground, and to
ensure that the input and output devices with the same power protection ground. For the use of
computer communication control users must ensure that the computer used and the device are
connected to the power protection, and the same protection.
2. The serial port cannot control the device: check the control software set the communication port
is connected with the serial port corresponding to the device; check the computer's communication
port is good.
3. There is no corresponding image output when this unit is switched:
(1) Check whether the corresponding input signal. (Available oscilloscope or multimeter to detect)
If there is no signal input, it may be broken or loose input connector, replace the cable can be;
HDMI cable is too long lead to no signal input, you can replace the short cable.
(2) Check whether the corresponding output signal. (Available oscilloscope or multimeter to
detect) If there is no signal output, there may be broken output connector or connector loose,
replace the cable can be; HDMI cable is too long lead to no signal output, can replace the short
cable.
4. Pull, plug video interface, you feel a significant static: Check the equipment power supply
grounding is good ground, according to the correct method of grounding, or easy to damage the
host.
5. LCD screen does not shine, and the button operation No response: the power supply may not be
normal.
(Do not belong to the above situation, may be the internal fault of the equipment, please give the
professional service.)
