Honeywell’s HMLCD19L LCD monitor is designed specifically for the security industry
to provide high resolution display of computer signals and/or composite video. The
combination of robust features, good performance, and exceptional value comes
together to deliver excellent video in a variety of applications. Because they consume
less power, generate less heat, and last longer than convention CRT monitors, LCD
monitors are more cost-effective over long term use.
This 19-inch monitor has a color LCD panel with a thin film transfer (TFT) active
matrix. The monitors automatically adapt to the appropriate input resolution up to
1280 x 1024. The HMLCD19L provides three composite (2 x BNC and 1 x S-Video)
inputs, 1 BNC looping output, and a VGA input to support the use of digital video
recorders (DVRs) and PC applications. This multimode functionality—combined with
a quick panel response time to minimize ghosting in motion video, and high
brightness and contrast ratio—makes the HMLCD19L ideal for applications requiring
a VGA display with composite video capabilities.
The HMLCD19L features a rugged desktop stand and VESA-compliant mounting
holes to easily adapt to different wall and ceiling mounts. These monitors
automatically detect and display the correct video format (NTSC or PAL) and are
powered by an auto-ranging power supply. Adjustments of standard monitor display
parameters are made using user-friendly on-screen menus and front panel controls.
Market Opportunities
With composite and VGA inputs, the HMLCD19L is the perfect choice to pair with
any embedded or PC-based digital video recorder and is a direct replacement for
both CRT and PC monitors. Because the HMLCD19L has a small form factor that
efficiently maximizes the viewing area, it’s perfect for use in confined viewing areas.
Features
www.honeywellvideo.com
HMLCD19L L-Series LCD Monitor
• Resolution, SXGA 1280 x 1024
• Brightness, 300 cd/m2
• Contrast ratio, 500:1
• Fast response time, 8 ms
• Analog RGB (15-pin DB-type) input
• 2 BNC and 1 RCA composite video
inputs
• 1 BNC looping video output
• Two built-in speakers
• Convenient front-panel controls
• Power failure function provides auto
turn-on in case of power failure
• VESA DDC mounting compliant
19-INCH LCD COLOR MONITOR

NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
HMLCD19L L-Series LCD Monitor
L/LS19LCDD/D
November 2007
© 2007 Honeywell International Inc.
Honeywell Security
Honeywell Video Systems
2700 Blankenbaker Pkwy, Suite 150
Louisville, KY 40299
1.800.796.CCTV
www.honeywell.com
www.honeywellvideo.com
SPECIFICATIONS
Ordering
HMLCD19L 19" L-Series LCD monitor, NTSC/PAL, NA power cord
HMLCD19LX 19" L-Series LCD monitor, NTSC/PAL, UK and Continental Europe power cord
Video
Video Standard NTSC / PAL - auto select
Input Signal Video
Composite: 0.6~1 Vp-p @75 ohm
Y: 1.0 Vp-p
C: 0.3 Vp-p
Horizontal Frequency
PC: 31K~81 kHz
Video: 15750 Hz NTSC
(15625 Hz PAL)
Vertical Frequency
PC: 56~75 Hz
Video: 60 Hz NTSC
(50 Hz PAL)
Audio Speaker 2 x 2.0 W / 8 ohm
Resolution SXGA 1280 x 1024
Pixel Type Active Matrix TFT
Pixel Dimension 0.294 x 0.294
Display Colors 16.7 million colors
Brightness 300 cd/m2
Contrast Ratio 500:1
Response Time 8 ms
Display Ratio 4:3
Viewing Angle L/R: 70/70°
U/D: 75/60°
Electrical
Input Voltage 100~240 VAC, 50/60 Hz
Operating Voltage 12 VDC from power supply (included)
Power Consumption 50 W (maximum); <5 W standby
Audio Power 2 x 2W
Audio Input Level -8 dBm
Controls
On Screen Display
(OSD)
Auto Config, Brightness, Contrast,
Color-Temp, Position, Image Quality, Menu
OSD Languages English, French, Italian, Spanish, German,
Traditional Chinese
Front Panel Controls Auto/Enter, Power, Menu, Up, Down
Mechanical
Dimensions
(W x H x D)
16.9" x 16.7" x 6.3"
(430 mm x 425 mm x 160 mm)
Weight Unit: 11.8 lb (5.35 kg)
Shipping:16.0 lb (7.3 kg)
Construction Housing: Hi-impact plastic
Finish: Black matte
Connectors
Video Inputs:
2 x BNC, 1 x RCA,
1 x VGA (15 pin D-sub)
Video out (looping):
1 x BNC
Audio Inputs:
2 x S-Video (L+R, 1 set)
2 x RCA (L+R, 1 set)
1 x PC Audio, Ø 3.5 mm Jack
Power Input:
5.5 x 2.1 mm barrel connector, center positive
Environmental
Temperature Operating: 5° to 104° F (5° to 40° C)
Storage: 4° to 140°F (-20° to 60°C)
Relative Humidity 20% to 85%
Regulatory
Emissions FCC: Part 15, Class B
CE: EN 55022 Class B
Immunity CE: EN 50130-4 6100-4-3
Safety
UL/C-UL: UL60950-1
CE: TUV-GS EN60950-1
CCC: GB4943
Accessories
HMLCDTM Tilting wall mount, VESA standard
HMLCDCM Ceiling mount, VESA standard
HMLCDARM Articulating arm mount, VESA standard
HMLCDFM Fixed wall mount, VESA standard
16.9"
(430 mm)
6.3"
(160 mm)
16.7"
(425 mm)
