Honeywell 10X User manual

Document 800-06705 - Rev A - 12/10
10X True Day/Night PTZ Dome
Mini PTZ Dome Camera
HDT HDTX
User Guide

2
Revisions
Issue Date Revisions
A 6/10 New document.
12/10 This version is for Ver. 1.5 firmware.

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
3
Important Notice
The Mini PTZ Dome Camera only supports Pelco-D protocol.
When Mini PTZ Dome of Pelco-D protocol is controlled by a Honeywell RapidEye or Fusion Series DVR, please use
Focus Near and Focus Far buttons instead of OSD operation buttons in DVR’s user interface to select or close OSD
menu items.
When Mini PTZ Dome of Pelco-D protocol is controlled by a Honeywell RapidEye Series DVR, please run pattern / swing
/ group functions only in the OSD menu.
When Mini PTZ Dome of Pelco-D protocol is controlled by a Honeywell HREP Series DVR, programming of pattern /
swing / group functions is only available in the DVR’s local user interface and not in the network web client.
The Privacy Zone mask function setting is reserved.

4
Contents
1 Introduction ………………………………………………………………………………………………….. 11
Features ………………………………………………………………………………………………………. 11
Parts List …………………………..………………………………………………………………………….. 13
Main Part Description ………………………………………………………………………………………... 14
2 Installation …………………………………………………………………………………………………… 15
DIP Switch Setup …………………………………………………………………………………………….. 15
In-Ceiling Mount Installation ………………………………………………………………………………… 18
Installation with Surface Mount Bracket …………………………………………………………………… 19
Installation with Ceiling Mount Bracket ……………………………………………………………………. 20
Installation with Wall Mount Bracket ……………………………………………………………………….. 22
Wiring and Cabling …………………………………………………………………………………………... 23
3 Operation …………………………………………………………………………………………………….. 25
Check Points before Operation …………………………………………………………………………….. 25
OSD Menu ……………………………………………………………………………………………………. 26
Reserved Preset (Hot Keys) ………………………………………………………………………………... 26
Preset …………………………………………………………………………………………………………. 27
Swing ………………………………………………………………………………………………………….. 27
Pattern ………………………………………………………………………………………………………… 28
Group ………………………………………………………………………………………………………….. 29
Other Functions ………………………………………………………………………………………………. 30
OSD Display ………………………………………………………………………………………………….. 31
4 OSD Menu ……………………………………………………………………………………………………. 32
Quick Programming Guide ………………………………………………………………………………….. 32
Main Menu ……………………………………………………………………………………………………. 32
Display Setup ………………………………………………………………………………………………… 33
Camera Setup ………………………………………………………………………………………………... 34
Motion Setup …………………………………………………………………………………………………. 37
Preset Setup ………………………………………………………………………………………………….. 39
Swing Setup ………………………………………………………………………………………………….. 41
Pattern Setup …………………………………………………………………………………………………. 42
Group Setup ………………………………………………………………………………………………….. 43
System Initialize ……………………………………………………………………………………………… 45
Appendix A Specifications …………………………………………………………………………………….. 46
Appendix B Dimensions ………………………………………………………………………………………... 48
Contents

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
5
Figures
Figure 1-1 Parts Overview ..…….....……………………………………………………………………………. 13
Figure 2-1 Location of DIP Switch ……………………………………………………………………………… 14
Figure 2-2 Terminal Resistor Setup for Multi-Drop Connections ..………………………………………... 16
Figure 2-3 Typical Connection Diagram ……………………………………………….................................. 22
Figure 2-4 Connection of RS-485 Communication ……………………………………………….................. 23
Figure 3-1 OSD Display in Main Screen ……………………………………………….................................. 31

6
Tables
Table 1-1 Example of Preset Parameters .……………………………………………………………………. 10
Table 2-1 Example of Camera ID Setup ….…………………………………………………………………... 14
Table 2-2 Communication Protocol Setup ….………………..……………………………………………... 15
Table 2-3 Pin Description of Main Cable ……………………………………............................................... 22
Table 2-4 Power Consumption ………………………………………………............................................... 22
Table 4-1 Factory Default Setting ………………………………………………........................................... 47
Tables

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
7
Warnings and Safeguards
Explanation of Warnings
WARNING! The exclamation point in an octagon is a WARNING.
Failure to take or avoid a specific action could result in physical harm
to a person or irreparable damage to equipment.
Caution The lightning flash with arrowhead symbol within an equilateral triangle
alerts the user to the presence of un-insulated dangerous voltage within
the enclosure of the product that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
Caution The exclamation point in an equilateral triangle is a Caution.
Failure to take or avoid a specified action could result in loss of data or
damage to equipment and may contain important operating and
maintenance servicing information.

8
FCC Compliance
Information to User: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his expense.
Caution Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Canadian Compliance Statement
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada
European Compliance Statement
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measure.
Warnings and Safeguards

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
9
Important Safety Instructions
BEFORE OPERATING OR INSTALLING THE UNIT, READ AND FOLLOW ALL
INSTRUCTIONS. After Installation, retain the safety and operating instructions for future
reference.
1. HEED WARNINGS – Follow all warnings on the unit and in the operating instructions.
2. ATTACHMENTS / ACCESSORIES - Use only the attachments/accessories specified by
the manufacturer.
3. INSTALLATION
•Installation should only be performed by qualified personnel in accordance
with the manufacturer’s instructions and local codes. Improper installation can
lead to serious injury and/or damage to the equipment.
•Do not install near heat sources such as radiators, heat registers, or stoves, or
other heat-producing devices (such as amplifiers).
•Unless otherwise indicated by the manufacturer, the unit is designed for
indoor use only and must not be exposed to rain or moisture.
•Do not install in extremely hot or humid locations, in areas subject to dust or
mechanical vibrations, or where radiation or strong electromagnetic signals
are present.
4. POWER SOURCE - This unit should be operated only from the type of the power source
indicated on the marking label.
5. HANDLING
•Do not disassemble or tamper with the unit.
•Do not drop the unit or subject it to shock or vibration.
•Take special care that you do not scratch the dome cover when cleaning the
unit.
6. SERVICING
•Refer all servicing to qualified service personnel.
•Use only replacement parts specified by the manufacturer. Using
unauthorized parts may result in fire, electric shock, or other hazards.

10
Warranty and Service
Subject to the terms and conditions listed on the Product Warranty Card, during the
warranty period Honeywell will repair or replace, at its sole option, free of charge, any
defective products returned prepaid.
In the event you have a problem with any Honeywell Video Systems product, please call
Customer Service for assistance or to request a Return Merchandise Authorization
(RMA) number. Be sure to have the model number, serial number, and the nature of the
problem available for the technical service representative.
In the U.S.A. and Canada, call 1.800.796.2288.
Prior authorization must be obtained for all returns, exchanges, or credits. Items shipped
to Honeywell without a clearly identified Return Merchandise Authorization (RMA)
number may be refused.
WEEE (Waste Electrical and Electronic Equipment). Correct
disposal this product (applicable in the European Union and the other
European countries with separate collection systems). This product
should be disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures.
Warranty and Service

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
11
Introduction
Features
Powerful Zoom Camera & Setup Options
zSony 1/4 inch Interline Transfer CCD image sensor
z10x optical zoom/digital zoom (maximum 100x zoom magnification)
zTrue Day/Night (TDN) capability
zAuto-focus, manual focus, semi-auto focus modes available
zMultiple setup options using On-Screen Display (OSD)
Powerful Pan/Tilt Functions
zHigh-speed pan/tilt motion up to 360° per second
zVector Drive technology allows faster time to target view.
zMicro-Stepping Control technology provides sharp focus and natural-looking video at high zoom
magnifications with zoom-proportional pan/tilt movement.
Preset, Pattern, Swing, Group and More…
zMaximum 127 presets are programmable with Pelco-D protocol.
zEach preset can have its own parameter values independently from the other presets.
For an example, refer to the below table.
Table 1-1 Example of Preset Parameter
Preset No. White
Balance
Auto
Exposure ••• Label Remarks
Preset 1 Parameter A Parameter 3 “ENTRANCE”
Preset 2 Parameter C Parameter 5 “WAREHOUSE”
Preset 3 Parameter V Parameter 2 “OFFICE”
•••
Preset 95 −−−−Reserved for OSD Menu
•••
Preset 128 Parameter K Parameter 9 “TERRACE”

12
zMaximum 8 sets of Swing are programmable. The Swing function causes the camera to move
repetitively between two preset positions at programmed speeds.
zMaximum 4 Patterns are programmable. The Pattern function causes the camera to memorize the
path (curve path) created by the controller joystick and to duplicate it as closely as possible.
zMaximum 8 sets of Groups are programmable. The Group function causes the camera to memorize a
combination of Presets, Patterns and/or Swings and to run them repetitively in sequence. A Group can
consist of up to 20 Preset/Pattern/Swing functions.
Pan/Tilt/Zoom (PTZ) Control
zUp to 255 cameras can be connected to a single controller using an RS-485 communication
connection.
zCamera firmware supports Pelco-D control protocol.
On-Screen Display (OSD) Menu
zOSD menu is provided to display the status of camera and to configure the functions interactively.
zInformation displayed on screen includes camera ID, pan/tilt angle, direction, and presets.
Reserved Presets (Hot Keys)
zMost camera setup options can be set up easily and directly with the reserved presets (Hot Keys),
without entering the OSD menu. For more information, refer to “Reserved Presets (Hot Keys)” in this
manual.
Introduction

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
13
Parts List
Product & Accessories
zMain Body, Surface Mount Bracket
and In-Ceiling Plate
zDefault Accessories
[ Main Cable, Rubber Gasket, Screws: Tapping M4×25,
Machine M3×6, Machine M3×8, Machine M4×50, M4 Nut ]
Brackets (Optional)
zWall Mount Bracket
[ Screws : Machine M3×8, Hex Lag #14×50 ]
zCeiling Mount Bracket
[ Screws : Machine M3×8, Tapping M4×25 ]
Mounts Description
zHDTW 10×True Day/Night PTZ Wall Mount Bracket
zHDTC 10×True Day/Night PTZ Ceiling Mount Bracket

14
Main Part Description
Figure 1-1 Parts Overview
zDome Cover To protect the dome cover from scratches and dust, do not remove the
protective vinyl from the dome cover until the installation is complete.
zDome Cover Lock-up
Screw
Used to lock up the dome cover after attaching the dome cover to the
main body.
zDome Cover Assembly
Stud
Used to line up the stud on the main body and the stud on the dome cover
when attaching the dome cover to the main body.
zDIP Switch Used to set up camera IDs and protocols.
zSurface Mount Bracket
and Mounting Screw Hole
Used for surface mount type, wall mount type and ceiling mount type.
They are not used for in-ceiling mount type.
zMain Connector Used for the power wire, the video cable and the RS-485 communication
cable connection.
Surface Mount Bracke
t
Mounting Screw Hole
Dome Cover
Assembly Stud
DIP Switch
Main Connector
Dome Cover Lock-up Screw
Dome Cover
Introduction

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
15
Installation
DIP Switch Setup
Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol.
Figure 2-1 Location of DIP Switch
Camera ID Setup
zID numbers of cameras are set up with binary numbers. See the
examples shown below.
Table 2-1 Example of Camera ID Setup
Pin 1 2 3 4 5 6 7 8
Digit Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7
Binary Value 1 2 4 8 16 32 64 128
ex) DIP Switch
Value=5
ON OFF ON OFF OFF OFF OFF OFF
ex) DIP Switch
Value =10
OFF ON OFF ON OFF OFF OFF OFF
Pelco-D Camera ID = DIP Switch Value
Range: 1~255
ON
ON
12345678

16
Communication Protocol Setup
zThe camera ID range is “1~255”. Camera ID must not be “0”!
zThe factory default of the camera ID is “1”.
zMatch the camera ID with the Cam ID setting of your DVR or controller
to control the camera.
zIf you are connecting a single camera to a controller, and the cable you
are using to connect the camera to the controller is so long that the
camera is out of control, terminate the camera. When connecting more
than one camera to a single controller, terminate the last camera on
the communication line. The last camera means the camera farthest in
cable length from the controller.
zNote that the total length of the communication cable between a
controller and the camera(s) on the same communication line must be
less than 4,000 feet (1,200 meters).
ON
ON
1234
Installation
zSelect an appropriate protocol using one of the following DIP switch
combinations.
Table 2-2 Communication Protocol Setup
Switch Mode
Protocol
P0
(Pin 1)
P1
(Pin 2)
P2
(Pin 3)
OFF OFF OFF PELCO-D, 2400 bps
ON OFF OFF PELCO-D, 9600 bps
Others Reserved
zMatch the camera protocol with the camera protocol in the setting of
your DVR or controller to control the camera.
zAdjust the DIP switch after turning off the camera. If you changed the
camera protocol by changing the DIP switch, the change will be
effective after you reboot the camera.
zThe factory default protocol is “Pelco-D, 2400 bps”.

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
17
Terminal Resistor Setup
T
he terminal resistor is used in the following cases:
zCase 1: The control cable length between a camera and a
controller is very long (1:1 Connection)
If the communication cable length is over 300m with one shielded
twisted pair cable or CAT5 cable (this distance may vary when using
different impedance cables), the electrical signal will bound in the
terminal point. This reflected signal causes distortion of original signal.
Accordingly, the camera can be out of control. In this case, the
terminal resistor on the camera must be set to ON.
zCase 2: Multiple cameras are connected to a controller.
The terminal resistor of the camera furthest away from the controller
must be set to ON. Do not turn on the terminal resistor of all the
cameras on the same communication cable (see Figure 2-2).
[Note] : If the terminal resistor is set to ON at the camera dome, it must
also be set to ON at the controller/DVRs. Some controllers/DVRs
having built-in impedance matching may not have a terminal resistor
switch. Please refer to your controller/DVR user's manual.
Figure 2-2 Terminal Resistor Setup for Multi-Drop Connection
Controller
Terminal Resistor ON
RS-485
Terminal Resistor
OFF
Terminal Resistor
OFF
Terminal Resistor
ON
#1 #2 #n
ON
ON
1234

18
In-Ceiling Mount Installation
cRemove the ceiling tile from the ceiling and attach
the Guide Pattern to the ceiling tile. Then cut a hole
whose diameter is 116 mm and three holes for
M4x30 on the ceiling tile.
dInstall the main body with the In-Ceiling Plate, the
three screws (M4x50) and the three nuts (M4).
Then install the ceiling tile to the ceiling and
connect the main cable to the main port.
eAlign the dome cover stud with the stud on the main
body and slightly push the dome cover to the
ceiling tile.
fTurn the dome cover clockwise and install the dome
cover lock-up screw. Then remove the protective
vinyl from the dome cover. (Machine M3×6)
Important Notice
zBefore starting the installation, make sure that the camera ID and protocol are set up properly.
Installation

Mini PTZ Dome Camera User Guide
Document 800-06705 - Rev A - 12/10
19
Installation with Surface Mount Bracket
cRemove the ceiling tile from the ceiling and cut a
hole whose diameter is 30-40mm on the ceiling tile
to pass the wires and cables through to the upside
of the ceiling. (In case of wiring and cabling through
the ceiling tile only)
dPrepare the surface mount bracket. Pull the main
cable for the system as below. Attach the surface
mount bracket to the mounting surface. (Tapping
M4×25)
eConnect the main cable to the ports and install the
main body. (Machine M3×8)
fAlign the dome cover stud with the stud on the main
body and slightly push the dome cover to the
ceiling. Turn the dome cover clockwise and install
the dome cover lock-up screw. Then remove the
protective vinyl from the dome cover. (Machine
M3×6)
Important Notice
zBefore starting the installation, make sure that the camera ID and protocol are set up properly.
zWhen the wiring access hole on the side of the surface mount bracket is not used, make sure that the hole is
properly sealed with the supplied rubber gasket.

20
Installation with Ceiling Mount Bracket
cRemove the ceiling tile from the ceiling and cut a
hole whose diameter is 30—40 mm on the ceiling
tile and attach the ceiling mount bracket on it.
(Tapping M4×25)
dPull the main cable for the system as below. Turn
the bracket adapter on its axis in a clockwise
direction until it stops and then attach the surface
mount bracket. (Machine M3×8)
eConnect the main cable to the ports and install the
main body. (Machine M3×8)
fAlign the dome cover stud with the stud on the main
body and slightly push the dome cover to the
ceiling. Turn the dome cover clockwise and install
the dome cover lock-up screw. Then remove the
protective vinyl from the dome cover. (Machine
M3×6)
Bracket Adapter
Surface Mount
Bracket
Installation
