Lyric™ C2 Wi-Fi Security Camera
USER MANUAL
Before you begin
Read these instructions carefully. Failure to follow these instructions may damage
the product or cause it to not function as intended.
Download the Lyric app
To setup and use your new security
camera, search for Honeywell Lyric
in the App Store or Google Play.
GET IT ON
Lyric

ii
Need help?
If you need help at any point during the installation and setup of the
Wi-Fi Security Camera, please contact Honeywell Lyric Support:
Web: YourHome.Honeywell.com
Email: [e-mail]
Phone: [phone]

iii
Contents
Welcome • 1
Camera overview • 2
Placement • 3
With stand • 3
Without stand • 3
Installation • 4
Download the Honeywell Lyric app • 4
Launch the Lyric app • 4
Connect the power cord • 4
Connect • 5
Connect to mobile device • 5
Connect to Wi-Fi • 5
Status LEDs • 6
Operation • 7
Remove/replace the stand • 7
Lyric app experience • 7
Reset • 7
SD card • 7

iv
App overview • 8
Livestreaming • 9
Configure alerts • 10
Select alert notification type • 10
Select alert recipients • 11
Review clips • 11
Camera settings • 12
Turn the LED on and o • 14
Turn the microphone on and o • 14
Motion detection • 15
Sound detection • 16
Smoke or carbon monoxide alarm detection • 17
Baby cry detection • 17
Delete a camera • 18

v
Set up detection zones • 20
Geofencing setup • 19
App settings and account info • 22
Manage messages • 23
Firmware update • 24
Frequently Asked Questions • 25
Specifications • 33
FCC Regulations • 34
Warranty • 36

vi

1
Welcome
Congratulations on your purchase of Honeywell’s Lyric™ C2 Wi-Fi
Security Camera. You can monitor visitors, pets, and family
yourself—anytime, anywhere.
What’s in the box?
You should find:
• Honeywell Lyric C2 Wi-Fi Security Camera
• Optional mounting screws
• Power cord and adapter
• 8 GB microSD Card
Download the app
You need the Lyric app and an
account to set up and use your new
camera.
Search for Honeywell Lyric in the
App Store or Google Play.
After downloading, follow the instructions in the app.
See “Frequently Asked Questions” on page 25 for any questions
regarding installation and operation of your Lyric camera.
GET IT ON
Lyric

2
Camera overview
LED
indicator
Camera
lens
Power
cord
Stand/wall
mount
Backplate
and rubber
feet Reset hole
SD card and slot

3
Placement
With stand
Place the camera in a desired location
for viewing and recording.
Without stand
You can also mount the camera directly
to the wall without the stand.

4
Installation
Launch the Lyric app
4 Launch the Lyric app.
5 Select the Security Camera to install, then create an
account (if necessary), or sign in to your Lyric account.
6 Follow the instructions in the Lyric app to name the
camera and its location.
Download the Honeywell Lyric app
Note: Have your Wi-Fi password available and confirm your
router is dual-band and communicates at 2.4/5 GHz before
installation.
1 Make sure Bluetooth is enabled on your mobile device.
2 Search for Honeywell Lyric in the App Store or Google
Play.
3 Download the Honeywell Lyric app.
Connect the power cord
7 Plug the power cord’s micro USB end into the camera.
8 Plug the power cord’s USB end into the wall
outlet adapter, and plug your camera into a
power outlet.
9 Wait until the LED on the camera blinks blue
(about 1 minute), then press NEXT.
Note: If the LED turns solid red, it means the
connection mode timed out. Unplug the camera
and plug it back in, and wait for the LED to blink blue.
GET IT ON
Lyric
Lyric Water Leak &
Freeze Detector
Lyric C2 Wi-Fi
Camera
Lyric Round
Select a device to install
100%8:08 AM
Add New Device

5
Connect
Connect to Wi-Fi
Be sure you are on the same Wi-Fi network you wish to
connect your camera to.
1 Choose your Wi-Fi network from the list. Press NEXT.
2 Enter your Wi-Fi password, if necessary. Press DONE.
Note: The camera will beep during some steps in this
process, which is normal.
NEXT
NEXT
2.7-5.9 in
Connect to mobile device
1 Enable Bluetooth on your mobile device.
2 The app will look for the camera.
• For one camera, it will connect
automatically.
• For more than one camera, the
app will prompt you to select one
camera at a time. Each camera has a
unique Media Access Control (MAC)
ID printed on the back. The MAC ID
is a unique identifier assigned to the
camera. Use that ID to select the camera you want to connect.
3 A QR code will display in the app as shown in the image above. To connect your
camera to the app, hold your mobile device to display the QR code approximately
3-6inches (7-15cm) from the camera lens.
4 The camera LED turns purple and the camera beeps
when the mobile connection is complete.

6
Status LEDs
During Wi-Fi connection and camera operation, the LED shows the status of
the camera.
LED Camera state
During installation
Blinking Blue Powered up. Ready to begin setup.
Solid Blue Connected to App. Ready to complete setup.
Solid Red (for
2seconds)
Setup timed out, or connection failed. The LED will
then turn solid purple. Unplug camera, plug it back
in, and restart the process.
Solid Purple QR Code scan complete.
See “Connect to Wi-Fi” on page 5.
Blinking Green Connecting to Wi-Fi network.
Solid Green Connected to Wi-Fi network.
During operation
Blinking Green Connecting to Wi-Fi network.
Solid Green Connected to Wi-Fi and operating.
Blinking Red Not connected to Wi-Fi.

7
Operation
Remove/replace the stand
The C2 Camera snaps in and out of its stand. When replacing the camera, be
sure to thread the power cord through the hole in the base of the stand.
Lyric app experience
When you launch the application, live video from your camera is displayed.
If you have multiple cameras, a list of them is displayed.
Select a camera from the list to view live video from that
camera.
Reset
If your Wi-Fi connection fails or you need to connect to a
dierent Wi-Fi network, insert one end of a paperclip into
the reset hole. Press and hold it for 10seconds until you
hear a chirp. Then re-start the connection process. This
erases the SD card, but clips remain in the cloud unless you
delete them during your subscription period.
SD card
The camera comes with an encrypted 8GB SD card installed. It stores images
if the camera’s connection to the cloud is lost. You can replace it with any
compatible SDcard, up to 64GB.

8
App overview
These are the controls available during livestream.
Camera on/o
Press to turn the
camera on or o. Motion/sound detector
Press to turn the motion or
sound detection alerts on or
o during livestream.
Snapshot control
Press to take pictures during
livestream. Images are saved
to mobile device’s photos.
Video clips
When the camera detects motion or sound, it records
a clip. Those clips are listed in chronological order
here. Swipe up to see the list of clips, then swipe up or
down to see the full list. Press a clip to watch it.
Clips are saved to the cloud and are available for the
length of time determined by your subscription level.
Push to Talk
Press and hold
to speak out of
the camera.
Release to stop.

9
Livestreaming
You can use your security camera to get a live look-in wherever
you place the camera. The camera has a 145° field of view and
will only show you what is within that range of view in the
direction you point the camera. Place the camera so you can
see what you want to monitor.
Each livestream session lasts 90 seconds. When one livestream
session ends, you can start a new one if you like. Use the Push
to Talk button to talk to someone through the camera.
Livestreams are not saved to the SD card, and are not
uploaded to your cloud storage. By default, livestreams are in
HD. If data limits are a concern, change this setting to Auto or
Low, or only use livestreaming when you need to. See “Video
quality” on page 13.
In 1080p / 2Mbps / 30 fps Mode:
Minimum bandwidth required for 1080p Full HD live streaming: 2.048Mbps
Minimum bandwidth required for successful motion and audio detection and clip upload:
1.867Mbps
In 1080p / 1Mpbs/ 15fps Mode:
Minimum bandwidth required for 720p HD live streaming: 1.024Mbps
Minimum bandwidth required for successful motion & audio detection & clip upload:
1.693Mbps
Intelligent Sound Detection
The C2 camera is designed to identify the sounds of a smoke or CO alarm, as well as a
baby’s cry. It will then notify you that those sounds were detected, and not just any sound.
For more information, see page 17.

10
Configure alerts
When the camera detects a sound or
motion, it sends an alert to the app.
1 Press the Alerts icon when a red bubble
appears.
2 The Alerts are displayed with the Alert
type and the date/time stamp.
3 Press an alert to view the 30-second
video clip.
4 Swipe left, then press Dismiss to remove
the Alert.
5 To dismiss all Alerts, press Edit, then
press DISMISS ALL.
Select alert notification type
1 Press the side menu button on the home
screen.
2 Press Alerts and Notifications.
3 Select the notification type you want
to set (Camera Status, Motion Event, or
Sound Event).
4 Choose to turn on or o the following
types of notifications:
• Camera Status ON/OFF alert -
displayed in the Alerts list.
• Push Notification - displayed on your
mobile device.
• Email Notification - sent via email

11
Select alert recipients
You can choose multiple people to have access to the camera and receive Alerts.
1 Press the side menu button on the home
screen.
2 Press Manage Users.
3 Press Add User at the bottom of the
app.
4 Enter the email address of the person
you want to add to the camera then
press SEND.
Review clips
1 Swipe up from the bottom of the home
screen to show clips.
2 Press a clip to watch it.
3 Press FILTER to sort the clips, then
select a filter type (All, New, Viewed,
Downloaded).

12
Camera settings
Camera settings can be controlled in the app. You can set up things like night mode, use
Lyric’s Geofencing capability, and turn on Motion or Sound Detection, and other settings.
1 Press the side menu button on the
home screen.
2 Press the camera you want to change
the settings on. Look for the name you
gave the camera when installed.
3 To change the camera mode, press
Camera Mode.
4 Press a setting for the camera mode:
• Manual - turn the camera on or o
using the app.
• Geofencing - the camera turns on
when you leave the area, and turns
o when you return.
5 To change the night vision settings,
press Night Vision.
6 Press a setting for night vision:
• Auto - the camera adjusts its
settings automatically.
• On - night vision is always on.
• O - night vision is always o.

13
Video quality
You can change the quality of your video stream. This will help limit data use on your
mobile device.
1 Press the side menu button on the
home screen.
2 Press the camera you want to change
the settings on. Look for the name you
gave the camera when installed.
3 Press Video Quality.
4 Press a setting for video quality:
• Auto - the camera adjusts its
settings automatically.
• Low - lower quality video that uses
less data or bandwidth (VGA).
• High - higher quality video that
uses more data or bandwidth
(1080p HD).

14
Turn the LED on and o
If you want to turn the camera’s LED o (or back on), it is easy to do using the app.
1 Press the side menu button on the
home screen.
2 Press the camera you want to change
the settings on. Look for the name you
gave the camera when installed.
3 Use the Camera LED switch to turn the
LED on or o.
Turn the microphone on and o
If you want to turn the camera’s
microphone o (or back on), it is easy to
do using the app.
1 Press the side menu button on the
home screen.
2 Press the camera you want to change
the settings on. Look for the name you
gave the camera when installed.
3 Use the Camera Microphone switch to
turn the microphone on or o.
