Honeywell CENTRA LINE WEB-HMI4/C User manual

WEB-HMI4/C, WEB-HMI7/C,
WEB-HMI7/CF, WEB-HMI10/CF,
WEB-HMI16/CF and
WEB-HMI21/CF User’s Manual (SW)
Copyright © 2021 Honeywell GmbH. • All Rights Reserved EN2Z-1077GE51 R0621

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
EN2Z-1077GE51 R0621 2
This page intentionally left blank.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
3 EN2Z-1077GE51 R0621
CONTENTS
DOCUMENT PROCESS .........................................................................................................................................................4
TRADEMARKS.......................................................................................................................................................................4
Software License Advisory .................................................................................4
Trademark Information .......................................................................................4
FIRST AND QUICK START OF DEVICE................................................................................................................................5
First start of the device .......................................................................................5
Configuration of the web client ...........................................................................6
The Settings Page.........................................................................................6
Accessing the System Settings Screen .........................................................6
The Web Browser Settings............................................................................7
Configure the Network interface ....................................................................7
Finish Quick start...........................................................................................8
OPEN THE SYSTEM SETTINGS MENU................................................................................................................................9
Localisation ........................................................................................................9
System ...............................................................................................................10
Logs....................................................................................................................10
To download the log files:..............................................................................10
To view the log files:......................................................................................10
Date & Time .......................................................................................................11
Networks ............................................................................................................11
Services..............................................................................................................11
Management ......................................................................................................12
Display................................................................................................................12
Fonts ..................................................................................................................12
Install additional fonts....................................................................................12
To remove a custom font...............................................................................13
Authentication.....................................................................................................13
Restart................................................................................................................13
Web Browser......................................................................................................13
Exit .....................................................................................................................14
FACTORY RESET ..................................................................................................................................................................15
Create the recovery USB device ........................................................................15
Restore the device from USB.............................................................................15

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
EN2Z-1077GE51 R0621 4
DOCUMENT PROCESS
Table 1. Document process
Version Updated Location Comments
ENG01 2021-05-25 -
- New Document
- New SKU numbers
- Removed “Resetting password”
- Removed “Touchscreen Calibration”
- Removed “Plugin” and changed screenshots.
- Modified “Certificate” and “Certificate’s
Parameters”
TRADEMARKS
Software License Advisory
The information contained in this document is provided for informational purposes
only. While efforts were made to verify the accuracy of the information contained in
this documentation, it is provided 'as is' without warranty of any kind.
Third-party brands and names are the property of their respective owners.
Microsoft®, Win32, Windows®, Windows XP, Windows Vista, Windows 7, Windows
8, Visual Studio are either registered trademarks or trademarks of the Microsoft
Corporation in the United States and other countries. Other products and company
names mentioned herein may be the trademarks of their respective owners.
The example companies, organizations, products, domain names, e-mail
addresses, logo, people, places, and events depicted herein are fictitious. No
association with any real company, organization, product, domain name, e-mail
address, logo, person, place or event is intended or should be inferred.
This document supports software that is proprietary to Honeywell GmbH, Honeywell
Control Systems Ltd. and/or to third party software vendors. Before software
delivery, the end user must execute a software license agreement that governs
software use. Software license agreement provisions include limiting use of the
software to equipment furnished, limiting copying, preserving confidentiality, and
prohibiting transfer to a third party. Disclosure, use, or reproduction beyond that
permitted in the license agreement is prohibited.
Trademark Information
CentraLine and 'close to you' are trademarks of Honeywell Inc.
BACnet and ASHRAE are registered trademarks of American Society of Heating,
Refrigerating and Air-Conditioning Engineers. Microsoft and Windows are registered
trademarks, and Windows Internet Explorer are trademarks of Microsoft
Corporation. Java and other Java-based names are trademarks of Sun
Microsystems Inc. and refer to Sun's family of Java-branded technologies. Mozilla
and Firefox are trademarks of the Mozilla Foundation. Echelon, LON, LonMark,
LonTalk, and LonWorks are registered trademarks of Echelon Corporation.
Tridium, JACE, Niagara Framework, NiagaraAX Framework, Sedona Framework,
and Vykon are registered trademarks, and Workbench, WorkPlaceAX, and
AXSupervisor are trademarks of Tridium Inc. All other product names and services
mentioned in this publication that are known to be trademarks, registered
trademarks, or service marks are the property of their respective owners.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
5 EN2Z-1077GE51 R0621
FIRST AND QUICK START OF DEVICE
First start of the device
After starting up the device for the first time, you are located on the settings page.
Therefore, user need to login to the Setup menu to configure the device. By default,
the username and password are admin.
After entering the configuration menu for the first time, the user is forced to change
the admin password. This password must follow security requirements and must be
remembered all the time to be able to change the configuration of the device.
New password: _____________________________________________________
Confirm the new password in the Confirm Password box. Select Change Password.
The ‘admin’ password will be changed and the device will now reboot.
The new password will be required to change the configuration of the device.
IMPORTANT: DO NOT FORGET THE NEW PASSWORD. A forgotten
password cannot be cleared or reset. If you forget the ‘admin’ password,
contact CentraLine Technical Support.
Wait for the device to reboot and display the Login screen again.
Enter ‘admin’ in the Username box.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
EN2Z-1077GE51 R0621 6
Configuration of the web client
The Settings Page
The settings page is the default start page.
Enter your credentials to open the configuration menu or press Load Homepage on
the write top to access the configuration done in the web browser setup.
If you download a new application, you can force the panel to clear the cache.
Accessing the System Settings Screen
On the HTML5 web application, long press for 5 seconds on the top left corner of
the web panel touchscreen to open the settings page.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
7 EN2Z-1077GE51 R0621
The Web Browser Settings
After entering the configuration menu, you are forwarded to the Web Browser
configuration. To change the web Browser configuration, press the EDIT button on
the right top on the page.
Change the “on start” behavior of the device.
Table 2. Web browser settings
Item Default Description
On Startup
Open settings page
After a restart of the device, the setting
page is displayed
Continue where you left Jump to the application where you left
Open homepage Open the configured Homepage
Homepage https://google.com
Enter here the start page which you want
to load as homepage including http:// or
https://
Configure the Network interface
By default, all network interfaces are configured for DHCP. The ETH0 (which is
located right next to the power connector - refer to the WEB-HMI User’s manual) is
configured as WAN port and should be used to provide the connection to the
required web server.
If you connect the panel to the network using ETH0 and a DHCP server is running,
the Ip-Address is automatically requested from the DHCP server.
If no DHCP server is available or can’t be used on site, the configuration can be
changed to static IP configuration. To configure the network interface, open the
“Network” tab and press the EDIT button on the top right.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
EN2Z-1077GE51 R0621 8
Disabling the DHCP switch will allow you to enter the IP-Address manually. After
you press Save, the manually entered IP address will be used for the device.
NOTE: The device has an internal firewall which blocks all incoming network traffic,
including ICMP ping requests. Therefore, you can’t ping the device to test
the network connectivity.
Finish Quick start
The device is now correctly configured to load the homepage you entered.
Therefore, you can close the setup menu to access the homepage by clicking EXIT
in the System Settings list. Depending on the Web Browser configuration “On
Startup”, the application gets directly opened or you need to press Load Homepage
on the Settings Page.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
9 EN2Z-1077GE51 R0621
OPEN THE SYSTEM SETTINGS MENU
The system settings menu is entered after powering on the device and entering
valid credentials “Username” and “Password” into the login mask.
The main topics of configuration are listed on the left side of the system settings
screen.
WEB BROWSER
Localisation
Setup the language of the device
System
System information, Status and Timers
Logs
Configure logfile generation
Date and Time
Configure the date and time of the device
Network
Configure the network settings of the
Ethernet interfaces
Services
Use to enable the network bridge
Management
Firmware updates and basic FW and
booter configurations
Display
Display setup like colors, timeouts and
touchscreen calibration and more
Fonts
Use to install additional fonts
Authentication
Change passwords or create SSL
certificates
Restart
Restart the main or config OS
Web Browser
Configure the web browser properties like
home page
Exit
Will close the system settings view
Localisation
Use to set the language used for the text in the System Settings screen only. Select
the required language from the listed options.
County Code:
Select from the listed options. Required for WLAN regulatory domain.
System keyboard layout:
Use this option to change the layout of the virtual keyboard according to the
required language. The default keyboard layout is American English.
NOTE: The “Localisation” option does not affect the language of any other web
browser content.

WEB-HMI4/C, WEB-HMI7/C, WEB-HMI7/CF, WEB-HMI10/CF, WEB-HMI16/CF AND WEB-HMI21/CF - USER'S MANUAL (SW)
EN2Z-1077GE51 R0621 10
System
Parameter Description
Info
Provide ‘Device information’ like:
Name
Kernal version
Build date
Hardware code
Total available RAM
Status
Provides device ‘Status’ like:
Free RAM
Uptime
Average CPU Usage
Timers
Provides device “Timers” information like:
System on: Shows how many hours the HMI panel has
been powered.
Backlight on: Shows how many hours the HMI panel
backlight has been powered.
Logs
Persistent log:
Set the persistent log option if you want to maintain the log files saved after a power
reset.
NOTE: The log file manager cyclically fills 3 files of 4Mb.
Save:
Use save button to export a copy of the log files. This option allows the log file(s) to
be saved to an external storage device, e.g. USB device.
NOTE: Log file entries are timestamped with the HMI panel date and time settings.
To download the log files:
1. Access the System Settings screen. Then, select Logs.
2. Select Save. The file system screen is displayed.
3. Insert a USB memory stick into one of the USB ports of the HMI panel.
4. Select the USB device (e.g. usbmemory).
5. Select Save. This will save a file called ‘logs.tar.gz’ to the USB device.
Note: The files are downloaded in a compressed format and will require a
decompression tool (e.g. 7-Zip) in order to view the files.
To view the log files:
1. Access the USB device on a PC and navigate to the ‘logs.tar.gz’ file.
2. Using a suitable tool (e.g. 7-Zip) open the file to reveal a file called logs.tar.
3. Open the ‘logs.tar’ file to view its contents.
