Honeywell Evohome User manual

evohome
User Guide

Getting the most from evohome

evohome is easy to use. It’s simple
to make permanent or temporary
changes to your heating schedule,
and to make other adjustments.
Explore your evohome to find out
what you can do, and use this simple
guide to help you master some of the
more common actions.
Getting the most from evohome
1evohome User Guide

2 Getting the most from evohome

More control, more comfort
With evohome, you’ll discover ways to
manage your heating more effectively – and
make savings on your heating bills.
s Honeywell Zoning Technology - Delivering
heat into your home, in the right place, at the
right temperature and at the right time gives
the perfect balance of comfort and control,
whilst not wasting energy or money.
s Access via Mobile devices : Enabling control
whether you are relaxing at home or the other side
of the world, evohome can be accessed via your
mobile device anytime you choose. (optional)
s Intelligent controls that are simple to use :
A clear and simple to use touch screen
interface provides access to your Smart
Honeywell evohome Controller
Monday 27 April
Living room
21˚ 18˚ 15˚
18˚ 17˚ 23˚
Quick actions
21˚ 18˚ 17˚
19˚45˚ 17˚ 23˚
Kitchen Bedroom 2
Dining roomHot water Bedroom 1 Bathroom
12:03
SETTINGS SCHEDULE
Getting the most from evohome
3evohome User Guide

4 Getting the most from evohome

Working with zones
A zone can be one room or a number of rooms.
For example you might want to link all of your
bedrooms as one zone and control them as one
unit. Or if you have several radiators in one room
or open space, they can be grouped into a zone
so you don’t need to control them individually.
Getting the most from evohome
5evohome User Guide

6 Getting the most from evohome

Access evohome from Anywhere
The evohome smartphone or tablet app lets you
control your heating wherever you are. So, if you’re
away from home and need to turn your heating off
or on, or up or down, you are always in control.
To manage evohome with your mobile device
you’ll need a Honeywell Internet Gateway
device. If this isn’t in the pack you bought, visit
evohome.honeywell.com to find out more.
s Connect your Remote Access Gateway
to the evohome Controller – follow the
instructions in the installation guide
s Set up a mobile user account − go to
mytotalconnectcomfort.com and
follow the instructions there
s Download the app – visit the Apple app
store, or Google Play for Android phones
Getting the most from evohome
7evohome User Guide

SCHEDULE
MONDAY
Living room 18˚ 21˚
18˚ 21˚
18˚ 21˚
18˚ 21˚
18˚ 21˚
Dining room
Kitchen
Bedroom 1
Bedroom 2
00:00 06:00 12:00 18:00 00:00
more rooms DAYS WEEKS
12:03
Monday 27 April
Living room
21˚ 18˚ 15˚
18˚ 17˚ 23˚
Quick actions
21˚ 18˚ 17˚
19˚45˚ 17˚ 23˚
Kitchen Bedroom 2
Dining roomHot water Bedroom 1 Bathroom
12:03
SETTINGS SCHEDULE
I want to set up a new heating
schedule for the first time
1Press SCHEDULE
2Press any of the zone names
3Use the Wizard
1
2
You can also press
the EDIT SCHEDULE
button in any of
the zone override
screens
Living with evohome
8 Living with evohome

SCHEDULE
MONDAY
12:03
06:30
21.0˚
08:00
18.0˚
18:00
21.0˚
22:30
16.0˚
COPYWIZARD
18˚ 21˚
00:00 06:00 12:00 18:00 24:00
I want to change the heating
schedule for a room or zone
1Press SCHEDULE
2Press the name of the zone
you want to change
3Press Edit manually
4Press the part of the schedule you want to
change then use the up and down arrows
to change the time or temperature
4
You can also press
the EDIT SCHEDULE
button in any of
the zone override
screens
9evohome User Guide

LIVINGROOM – OVERRIDE
MONDAY
12:03
EDIT SCHEDULE
Set
MAKE
PERMANENT
18˚ 21˚
00:00 06:00 12:00 18:00 24:00
Until
18.0˚ 18 00:
I want to increase or reduce the
temperature for a zone
1On the home screen press the ‘tile’ for that zone
2Use the up and down arrows to
change the time or temperature
If you want, you can make these new
settings permanent for that zone.
2
Living with evohome
10 Living with evohome

QUICK ACTIONS
Touch once to quickly enable an Action
Touch & hold to enable with a timed duration
12:03
ECONOMY
Reduce all room temps by 3˚
AWAY
All rooms set to 15˚
DAY OFF
Use Saturday’s schedule today
HEATING OFF
All rooms set to OFF
CUSTOM
Use custom heating schedule
I want to turn the temperature
down a little throughout my home
1Press Quick Actions
2Press ECONOMY
This lowers the temperature in
all zones by 3 degrees.
2
You can also set the
ECONOMY Quick
Action for between
1 and 24 hours by
pressing and holding
the button to set the
timer
11evohome User Guide

QUICK ACTIONS
Touch once to quickly enable an Action
Touch & hold to enable with a timed duration
12:03
ECONOMY
Reduce all room temps by 3˚
AWAY
All rooms set to 15˚
DAY OFF
Use Saturday’s schedule today
HEATING OFF
All rooms set to OFF
CUSTOM
Use custom heating schedule
I want to turn the heating down
while I am away from home for
more than a day
1Press Quick Actions
2Press AWAY
This lowers the temperature in all zones to 15
degrees. When you’re back you can cancel
the action by pressing it on the home screen.
2
You can also set the
AWAY Quick Action
for between 1 and 99
days by pressing and
holding the button to
set the timer
Living with evohome
12 Living with evohome

QUICK ACTIONS
Touch once to quickly enable an Action
Touch & hold to enable with a timed duration
12:03
ECONOMY
Reduce all room temps by 3˚
AWAY
All rooms set to 15˚
DAY OFF
Use Saturday’s schedule today
HEATING OFF
All rooms set to OFF
CUSTOM
Use custom heating schedule
… have a day off and stay at home
3Press Quick Actions
4Press DAY OFF
This action is useful if you’re staying at home
on a day when you would normally be out.
4
You can also set the
AWAY Quick Action
for between 1 and 99
days by pressing and
holding the button to
set the timer
13evohome User Guide

QUICK ACTIONS
Touch once to quickly enable an Action
Touch & hold to enable with a timed duration
12:03
ECONOMY
Reduce all room temps by 3˚
AWAY
All rooms set to 15˚
DAY OFF
Use Saturday’s schedule today
HEATING OFF
All rooms set to OFF
CUSTOM
Use custom heating schedule
…turn the heating off in every zone
5Press Quick Actions
6Press HEATING OFF
To return to the normal schedule just cancel the
action by pressing it on the home screen.
6
Living with evohome
14 Living with evohome

The settings menu lets you manage
your evohome Controller and
personalise your settings
s Device settings – change the date, time and
language, control your display settings and
set a security passcode (default 0000)
s Room settings – change the name of a
room, change the display order of rooms
on the home screen, or reset a room
schedule to the original settings
s Quick actions – personalise the settings
used by the quick action functions
The settings menu
15evohome User Guide

evohome Controller batteries
The evohome Controller uses rechargeable
batteries which should not need to be
replaced. If the batteries need to be charged
place the evohome Controller back on a
powered Table Stand or Wall Bracket.
If necessary, replace with AA 1.2V Ni-MH 2000-
2400mAh batteries only.
Replacing the Radiator
Controller (HR92) batteries
FACEPLATEMAIN UNIT
Batteries
16 Living with evohome

evohome User Guide

evohome
Honeywell Control Systems Ltd.
Skimped Hill Lane,
Bracknell
Berkshire
RG12 1EB
www.honeywelluk.com
evohome is designed to convert a system with single zone
pipework into a multi zone system, resulting in optimal control
and comfort combined with maximum energy saving.
For more information on Smart Heat Zoning for your home, visit:
www.evohome.honeywell.com
50040746-201 A
© 2013 Honeywell International Inc.
