Honeywell EVOTOUCH CONTROLLER User manual

evotouch
GB

1
Contents
Glossary 2
actuator 2
binding 2
economy mode 2
heat demand device 2
holiday mode 2
optimisation 2
override 2
period 2
schedule 2
sensor 2
setpoint 2
zone 2
Preface 2
Quick topics 2
Holiday Mode and Economy Mode 3
To set holiday mode 3
To set economy mode 3
Main menu 3
System Overview 3
Operating Mode 3
Zoning Menu 3
Setting Menu 3
Zoning Menu 4
View/Edit Schedule 4
Guided Scheduling 4
Copy Schedule 5
Reset Schedule 5
Zoning Config 5
Zoning Conguration 6
Edit Zone 6
Zone Order 6
Add Zone 6
Delete Zone 7
Setting Menu 8
Time/Date Setting 8
Fault Logbook 8
Language Selection 8
Clean Screen 8
Display Settings 8
Safety information 9
Approvals 9
EMC compliance considerations 9
Product handling 9
Location of device 9
Disclaimer 9
WEEE directive 2002/96/EC
Waste Electrical and Electronic
Equipment directive 9

2
This extended evotouch User Guide provides information about
the user functions available from the Main Menu.
For information about the other user functions of evotouch
please refer to the printed Quick Start User Guide supplied with
evotouch.
Quick topics
The following table gives details of where to nd answers to
common questions about using evotouch:
Topic Answer
I’ve extended my heating system.
How do I dene a new zone?
See Add Zone, page 6.
How do I change the name of a
zone on my evotouch display?
See Edit Zone, page 6.
How do I change the order of
zones on my evotouch display?
See Zone Order, page 6.
How do I change the brightness/
contrast of the evotouch display?
See Display Settings, page 8.
How do I see an overview of the
temperatures in all zones?
See System Overview, page 3.
PrefaceGlossary
actuator
A device for controlling the required temperature of a zone.
binding
The process of establishing a successful wireless connection
between each actuator or sensor, and the evotouch controller.
economy mode
Reduces the temperature settings in all zones by 3°C at a single
button press, to save energy.
heat demand device
A device that can be controlled automatically to suit the demands
of the heating system (e.g. boiler).
The device is controlled depending on the required heat of the
different zones, which will optimise energy usage.
holiday mode
Reduces the temperature while you are away from home,
resuming normal operation on your return.
optimisation
A feature which ensures that the setpoint temperature is reached
at the start time of the period.
override
Manual temperature adjustment of the setpoint for a zone until
next switching point or specied time.
period
A time interval, specied by a start time and end time (start time
of the next period), during which the temperature of a zone is
controlled to a specied setpoint.
schedule
A series of periods dening how the temperature of a zone
should change throughout the day.
sensor
A device for measuring e.g. temperature.
setpoint
A room temperature specied as a target value.
zone
An individual room, or group of rooms, which you can control
independently.

3
Holiday Mode reduces the temperature while you are away from
home, resuming normal operation on your return.
Economy Mode reduces the temperature settings in all zones by
3°C at a single button press, to save energy.
Holiday Mode or Economy Mode are selected from the Home
Screen:
To set holiday mode
• PressHOLIDAY from the Home Screen.
The following screen allows you to set the date and time at which
holiday mode should end:
• SettheEND DATE and END TIME to specify when you return
from holiday, or press PERMANENT to set holiday mode
permanently.
• PressDONE.
The Home Screen shows HOLIDAY:
• PressPress to Change to change the end date or time.
To set economy mode
• PressECONOMY from the Home Screen.
The Home Screen shows ECONOMY ACTIVE:
• PressCANCEL ECONOMY from the Home Screen to cancel
Economy Mode.
Holiday Mode and Economy Mode
Main menu
To display the Main Menu:
• PressMENU from the home screen.
This provides access to the following options:
These are described in greater detail in the following sections.
System Overview
The System Overview screen displays a summary of all the
zones in the system:
Operating Mode
The Operating Mode menu allows you to specify whether the
system heats or not:
Zoning Menu
The Zoning Menu allows you to view, edit, copy, or reset
schedules, and congure zones. For more information see
Zoning Menu, page 4.
Setting Menu
The Setting Menu allows you to set the time, date, and other
settings of evotouch. For more information see Setting Menu,
page 8.

4
Allows you to view, edit, copy, or reset schedules, and congure
zones.
To display the Zoning Menu:
• PressZONING MENU on the Main Menu.
This provides access to the following options:
These are described in greater detail in the following sections.
View/Edit Schedule
You are rst prompted to select the zone to view or edit:
This screen then allows you to edit the periods, add a period, or
delete a period:
For more information see the Quick Start User Guide.
Guided Scheduling
Leads you through a sequence of steps to set up a schedule for
a zone.
You are rst prompted to select the zone to be congured:
• Pressthebuttoncorrespondingtothezoneyouwantto
congure.
The next screen allows you to congure several days with the
same schedule:
• Pressoneormoredaystohighlightthem,tospecifywhich
days are to have the same schedule.
• PressDONE.
To select all the week days or weekend days press WEEK DAYS
or WEEKEND DAYS respectively.
You are then prompted to set the starting time of the rst period:
• SetthetimeandpressNEXT.
You are then prompted to set the temperature for the rst period:
• SetthetemperatureandpressNEXT.
You are then prompted to specify if the zone will be occupied all
day:
• PressYES to leave the heating on all day, or NO to turn the
heating off during the day.
If you specied NO you are prompted to specify when the zone
will become unoccupied:
Zoning Menu

5
• SetthetimeandpressNEXT.
You are then prompted to set the temperature for the zone while
it is unoccupied:
• SetthetemperatureandpressNEXT.
Likewise, you are then given the option of creating a lunchtime
period:
If you press YES you are prompted for the start time (default
12:30), temperature (default 21°), and end time (default 13:30)
for the lunchtime period.
You are then prompted for:
• Thetimethatthezoneagainbecomesoccupiedinthe
evening (default 17:30).
• Theeveningtemperature(default21°).
• Thetimethatthezoneisnolongerusedintheevening
(default 22:30).
• Thenighttimetemperature(default15°).
Finally, the following screen shows a summary of the schedule:
• PressDONE to continue.
The following options are then provided:
• Selecttheappropriateoptiontodofurtherscheduling,or
press DONE to nish.
Copy Schedule
Allows you to copy a schedule between zones.
You are rst prompted to specify the zone you want to copy from:
• Pressthezoneyouwanttocopyfrom.
You are then prompted to specify the zone you want to copy to:
• Pressthezoneyouwanttocopyto.
The following screen summaries what you have selected:
• PressDONE to proceed.
After copying you are given the option of copying to a further
zone.
Reset Schedule
The following menu allows you to select the zone to reset:
• Pressthezoneyouwanttoreset.
You will be prompted to conrm that you want to proceed. The
zone will then be reset to the default schedule with four periods.
Zoning Cong
Allows you to edit, add, and delete zones, and change the
order in which zones are listed on the menus. See Zoning
Configuration, page 6.

6
The Zoning Conguration menu allows you to edit, add, and
delete zones, and change the order in which zones are listed on
the menus.
The following warning is displayed:
• Pressthebuttonfor5seconds,asinstructed.
This provides access to the following options:
NOTE: The ZONE ORDER and DELETE ZONE options are only
available if more than one zone has been created.
The options are described in the following sections.
Edit Zone
You are rst prompted to specify the zone you want to edit:
• Pressthezoneyouwanttoedit.
The following menu is then displayed:
The options are explained in the following table:
Option Description
ADD
ACTUATOR(S)
Prompts you to bind an
actuator to the zone.
ADD ROOM
SENSOR
Prompts you to bind
a room sensor to the
zone.
CHANGE ZONE
NAME
Displays a keyboard
to allow you to edit the
zone name.
TEST RF SIGNAL Sends an RF signal to
test the zone.
Zone Order
Displays the following menu to allow you to specify the order of
the zones:
• Pressthebuttonsintheorderyouwantthezonestobe
arranged on the menus.
As you press each button it will disappear from the screen.
Alternatively, to choose the default order press DEFAULT.
Add Zone
Allows you to add a new zone to the system.
NOTE: This option is not displayed if eight zones have already
been dened.
You are rst prompted to give the zone a name.
The following menu is then displayed to allow you to bind an
actuator and sensor to the zone, and set up the schedule:
For information about programming a schedule see the Quick
Start User Guide.
• PressBINDING MODE to bind devices to the new zone.
You are rst prompted to bind the actuator in the zone:
• PuttheactuatorinBINDmodeandpressBIND:
• WhenasuccessfulresponsehasbeenreceivedpressDONE.
Zoning Conguration

7
The next step is to bind a sensor in the zone.
You are given the option of using the evotouch internal sensor, or
an external room sensor:
If the zone contains the evotouch controller, and you want to use
the internal sensor, press INTERNAL.
Note: Only one zone can be controlled by the internal sensor.
Selecting the internal sensor automatically congures all other
zones to use external sensors.
Otherwise press EXTERNAL and you will be prompted to bind a
room sensor in the zone:
• PresstheBINDbuttononthesensor.
• WhenasuccessfulresponsehasbeenreceivedpressDONE.
You will be returned to the ADD ZONE menu.
Delete Zone
You are rst prompted to specify the zone to be deleted:
• Pressthezoneyouwanttodelete.
You are then prompted to conrm the action:
• PressDONE to delete the selected zone.

8
Allows you to set the time, date, and other settings of evotouch.
It provides the following options:
Time/Date Setting
Allows you to set the time and date:
For more information see the Quick Start User Guide.
Fault Logbook
Displays a log of the most recent faults encountered by the
system:
Language Selection
Allows you to change the language of the user interface:
The currently selected language is shown highlighted.
Clean Screen
Freezes the screen for 30 seconds so you can clean it without
accidentally selecting menu options:
After 30 seconds press DONE to return to the setting menu, or
CLEAN to continue for another 30 seconds:
Display Settings
Allows you to alter the display brightness and contrast, and the
screen timeouts:
• PressMORE to change the timeouts:
Backlight time species how long the display backlight stays on
after the touchscreen has been active.
Time out species how long the current menu remains on the
screen before returning to the standby display.
For the timeout setting the following options are available:
• Pressthetimedurationyouwanttoselect.
Setting Menu

9
Approvals
Conforms to protection requirements of the following directives:
EMC: 2004/108/EC
LVD: 2006/95/EC
R&TTE: 1995/5/EC
EMC compliance considerations
Refer to Code of Practice standards EN61000-5-1 and -2 for
guidance.
Caution: Isolate power supply and make safe before wiring the
unit to prevent electric shock and equipment damage. Installation
should be carried out by a competent person.
Product handling
Care should be taken with the evotouch unit while it is out of its
dock or table-top stand as the unit, particularly the touchscreen
display, may be damaged if the unit is dropped onto a hard
surface.
Location of device
evotouch should be placed in an open space for best
performance as it is a radio frequency device. Leave at least
30cm distance from any metal objects including wall boxes and
at least 1 metre from any other electrical equipment eg. radio,
TV, PC etc. Do not mount onto metal wall boxes.
For the best temperature control performance evotouch should
not be placed near heat or cool sources (e.g. cooker, lamp,
radiator, doorways, windows).
Disclaimer
This product and its associated documentation and packaging
are protected by various intellectual property rights belonging to
Honeywell Inc and its subsidiaries and existing under the laws
of the UK and other countries. These intellectual and property
rights may include patent applications, registered designs,
unregistered designs, registered trade marks, unregistered trade
marks and copyrights.
Honeywell reserves the right to modify this document, product
and functionality without notice. This document replaces any
previously issued instructions and is only applicable to the
product(s) described.
This product has been designed for applications as described
within this document. For use outside of the scope as described
herein, refer to Honeywell for guidance. Honeywell cannot be
held responsible for misapplication or the product(s) described
within this document.
PLEASE RESPECT YOUR ENVIRONMENT!
Take care to dispose of this product and any packaging or
literature in an appropriate way.
WEEE directive 2002/96/EC
Waste Electrical and Electronic
Equipment directive
• Attheendoftheproductlifedisposeofthepackagingand
product in a corresponding recycling centre.
• Donotdisposeoftheunitwiththeusualdomesticrefuse.
• Donotburntheproduct.
• Removethebatteries.
• Disposeofthebatteriesaccordingtothelocalstatutory
requirements and not with the usual domestic refuse.
Manufactured for and on behalf of the
Environmental and Combustion Controls
Division of Honeywell Technologies Sàrl,
ACS-ECC EMEA, Z.A. La Pièce 16,
1180 Rolle, Switzerland by its Authorised
Representative Honeywell Inc.
Honeywell Control Systems Ltd.
ArlingtonBusinessPark,
Bracknell,Berkshire
RG121EB
Technical Help Desk: 08457 678999
www.honeywelluk.com
Safety information

50042753-001 B
© 2009 Honeywell International Inc.
evotouch
