FocusPRO®TH5000 Series
Non-Programmable Digital Thermostat
® U.S. Registered Trademark. Patents pending.
Copyright © 2009 Honeywell International Inc.
All rights reserved.
Installation
Guide
Must be installed by a trained, experienced technician
Read these instructions carefully. Failure to follow these instructions
can damage the product or cause a hazardous condition.
Need Help?
For assistance with this product please visit http://customer.honeywell.com
or call Honeywell Customer Care toll-free at 1-800-468-1502
69-1922EFS-01
This manual covers the following models
• TH5110D:For1Heat/1Coolsystems
• TH5220D:Forupto2Heat/2Coolsystems
• TH5320U:Forupto3Heat/2Coolsystems
(Remove battery holder to find model number)
System Types
• Gas,oil,orelectricheatwithair
conditioning
• Warmair,hotwater,high-
efficiencyfurnaces,heatpumps,
steam,gravity
• Heatonly—two-wiresystems,
three-wire zone valves (Series
20),andnormallyopenzone
valves
• Heatonlywithfan
• Coolonly
• 750mVheatingsystems

Installation Guide
69-1922EFS—01 2
ENGLISH
M29369
M29368
Wallplate installation
1. Separate wallplate from thermostat.
2. Mount wallplate as shown below.
Drill3/16”holesfordrywall.Drill7/32”holesforplaster.
Wallanchors
Wallplate
Wirehole
Mounting screws
CAUTION: ELECTRICAL HAZARD
Can cause electrical shock or equipment damage. Disconnect power before
beginning installation.
MERCURY NOTICE
Ifthisproductisreplacingacontrolthatcontainsmercuryinasealedtube,donot
place the old control in the trash. Contact your local waste management authority for
instructions regarding recycling and proper disposal.
!
Pull here to remove wallplate
from new thermostat.
Remove battery holder.
!
It's easier to grasp the wallplate
and remove it after completely
removing the battery holder.

FocusPRO®TH5000 Series
3 69-1922EFS—01
ENGLISH
M29370
Power options
Keep wires in this
shaded area
Connect Cfor primary AC power
(optional if batteries are installed).
Insert batteries for primary
or backup power.
Remove factory-
installed jumper
only for two-
transformer
systems.
Conventional Terminals:
Rc 24VACpowerfromcooling
transformer
R 24VACpowerfromheating
transformer
W Heat relay (stage 1)
W2 Heat relay (stage 2)
Y Compressor contactor (stage 1)
Y2 Compressor contactor (stage 2)
G Fan relay
C 24VACcommon.For2transformer
systems,usecommonwirefrom
cooling transformer.
Heat Pump Terminals:
Rc 24VACpowerfromcooling
transformer
R 24VACpowerfromheating
transformer
O/B Changeover valve
Y Compressor contactor
Y2 Compressor contactor (stage 2)
-TH5320U only
G Fan relay
Aux Auxiliary heat relay*
E Emergency heat relay*
L Sends output when set to Em. Heat
C 24VACcommon
*Aux and E terminals combined on TH5320U only.
Wiring
Terminal designations
Shaded areas below apply only to TH5320U/TH5220D or as otherwise noted.
TH5110D Rc
Y
W
G
R
C
TH5220D
RcYWGW2Y2 RC
TH5320U
RcYWGW2Y2 RC
TH5110D Rc
Y
O/B
G
R
C
RcYGAuxELR
O
/
B
O
/
B
C
TH5220D
RcYGAux
E
Y2LRC
TH5320U
M29371

Installation Guide
69-1922EFS—01 4
ENGLISH
Wiring
Wiring guide — conventional systems
Shaded areas below apply only to TH5320U/TH5220D or as otherwise noted.
1H/1C System
(1 transformer)
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor
C 24VACcommon[3]
W Heat relay
G Fan relay
Heat-only System
Rc Power [1]
R [R+Rc joined by jumper]
C 24VACcommon[3]
W Heat relay
Heat-only System
(Series 20) [5]
Rc [R+Rc joined by jumper]
R Series20valveterminal“R”[1]
Y Series20valveterminal“W”
C 24VACcommon[3]
W Series20valveterminal“B”
Heat-only System
(normally open zone valve) [5]
Rc [R+Rc joined by jumper]
R Power [1]
Y Normally open zone valve
C 24VACcommon[3]
1H/1C System
(2 transformers)
Rc Power (cooling transformer) [1,2]
R Power (heating transformer) [1,2]
Y Compressor contactor
C 24VACcommon[3,4]
W Heat relay
G Fan relay
Heat-only System
with Fan
Rc Power [1]
R [R+Rc joined by jumper]
C 24VACcommon[3]
W Heat relay
G Fan relay
Cool-only System
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor
C 24VACcommon[3]
G Fan relay
2H/2C System
(1 transformer) [6]
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor (stage 1)
C 24VACcommon[3]
W Heat relay (stage 1)
G Fan relay
W2 Heat relay (stage 2)
Y2 Compressor contactor (stage 2)
2H/2C System
(2 transformers) [6]
Rc Power (cooling transformer)[1,2]
R Power (heating transformer) [1,2]
Y Compressor contactor (stage 1)
C 24VACcommon[3,4]
W Heat relay (stage 1)
G Fan relay
W2 Heat relay (stage 2)
Y2 Compressor contactor (stage 2)
See [notes] below
RcYWGRC
M29372
RcWRC
M29373
RcYWRC
M29374
RcYRC
M29375
RcYWG RC
M29376
RcWG RC
M29377
RcYG RC
M29378
RcYWGW2Y2 RC
M29379
RcYWGW2Y2 RC
M29380
NOTES
Wirespecifications:
Use 18- to 22-gauge thermostat wire.
Shielded cable is not required.
[1] Power supply. Provide disconnect means
and overload protection as required.
[2] Remove jumper for 2-transformer systems.
 [3] Optional24VACcommonconnection.
[4] Common connection must come from
cooling transformer.
[5] InInstallerSetup,setsystemtypeto
Heat Only.
[6] InInstallerSetup,setsystemtypeto
2Heat/2Cool Conventional.
 [7] InInstallerSetup,setchangeovervalveto
O or B.
[8] InInstallerSetup,setsystemtypeto
2Heat/1Cool Heat Pump.
[9] InInstallerSetup,setsystemtypeto
2Heat/2Cool Heat Pump.
[10] InInstallerSetup,setsystemtypeto
3Heat/2CoolHeatPump.
[11] L terminal sends a continuous output when
thermostat is set to Em. Heat. Connect
to Honeywell zoning panels to switch the
panel to Emergency Heat.
[12] Install field jumper between Aux and E if
there is no emergency heat relay.

FocusPRO®TH5000 Series
5 69-1922EFS—01
ENGLISH
M29386
Wiring
Wiring guide — heat pump systems
Shaded areas below apply only to TH5320U/TH5220D or as otherwise noted.
Thermostat mounting
Align the 4 tabs on the wallplate with
slotsonthebackofthethermostat,
then push gently until the thermostat
snaps in place.
Push excess wire back into
the wall opening.
Plug wall opening with
non-flammable insulation.
RcYGRC
M29381
1H/1C Heat
Pump System
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor
C 24VACcommon[3]
O/B Changeover valve [7]
G Fan relay
2H/1C Heat
Pump System
(TH5220D only) [8]
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor
C 24VACcommon[3]
O/B Changeover valve [7]
G Fan relay
Aux Auxiliary heat relay [12]
E Emergency heat relay [12]
L Sends output when set to Em. Heat [11]
2H/1C Heat
Pump System
(TH5320U only) [8]
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor
C 24VACcommon[3]
O/B Changeover valve [7]
G Fan relay
Aux/E Auxiliary/Emergency heat relay
L Sends output when set to Em. Heat [11]
2H/2C Heat
Pump System
(TH5320U only) [9]
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor (stage 1)
C 24VACcommon[3]
O/B Changeover valve[7]
G Fan relay
Y2 Compressor contactor (stage 2)
L Sends output when set to Em. Heat [11]
3H/2C Heat
Pump System
(TH5320U only) [10]
Rc Power [1]
R [R+Rc joined by jumper]
Y Compressor contactor (stage 1)
C 24VACcommon[3]
O/B Changeover valve [7]
G Fan relay
Aux/E Auxiliary/Emergency heat relay
Y2 Compressor contactor (stage 2)
L Sends output when set to Em. Heat [11]
See [notes] on page 4.
RcYGAuxELRC
M29382
RcYGAux
E
LRC
M29383
RcYGY2LRC
M29384
RcYGAux
E
LRC
Y2
M29385

Installation Guide
69-1922EFS—01 6
ENGLISH
10
Done Next
M29387
Tobegin,press and hold the sand FAN
buttons until the display changes.
Function
number Setting
Press s or t to change settings.
Press NEXT to advance to the next function.
Press DONE to exit and save settings.
Installer setup
Follow the procedure below to configure the thermostat to match the installed
heating/coolingsystem,andcustomizefeatureoperationasdesired.
Continued on next page
Setup function Settings & options (factory default in bold)
Shaded areas below apply only to TH5320U/TH5220D or as otherwise noted.
*[Othercyclerateoptions:2,4,6,7,8,10,11or12CPH]
1System type 0 1 heat/1 cool conventional
1 1 heat/1 cool heat pump (no aux. heat)
2 Heatonly—2-wiresystems,3-wirezonevalves(Series20),and
normally open zone valves
3 Heatonlywithfan
4 Cool only
5 2 heat/1 cool heat pump (with aux. heat)
6 2 heat/2 cool conventional
7 2heat/1coolconventional
8 1 heat/2 cool conventional
9 2 heat/2 cool heat pump (no aux. heat) - TH5320U only
10 3heat/2coolheatpump(withaux.heat)-TH5320U only
2Changeover valve
(O/B terminal)
0 Changeover valve (O/B terminal energized in cooling)
1 Changeover valve (O/B terminal energized in heating)
3Fan control
(heating)
0 Gas or oil furnace — equipment controls fan in heating
1 Electricfurnace—thermostatcontrolsfaninheating
5Stage 1 heat cycle
rate (CPH: cycles/hour)*
5 For gas or oil furnaces of less than 90% efficiency
1 For steam or gravity systems
3 Forhotwatersystems&furnaces of over 90% efficiency
9 For electric furnaces
6Stage 2 heat cycle
rate/Auxiliary heat
cycle rate (CPH)*
5 For gas or oil furnaces of less than 90% efficiency
1 For steam or gravity systems
3 Forhotwatersystems&furnaces of over 90% efficiency
9 For electric furnaces
7Auxiliary heat cycle
rate (CPH)*
Only TH5320U
for 3H/2C Heat Pumps
5 For gas or oil furnaces of less than 90% efficiency
1 For steam or gravity systems
3 Forhotwatersystems&furnaces of over 90% efficiency
9 For electric furnaces
8Emergency heat cycle
rate (CPH)*
9 For electric emergency heat
1 For steam or gravity systems
3 Forhotwatersystems&furnaces of over 90% efficiency
5 For gas or oil furnaces of less than 90% efficiency

FocusPRO®TH5000 Series
7 69-1922EFS—01
ENGLISH
10 0
M29388
System test System status
Shaded areas below apply only to TH5320U/TH5220D or as otherwise noted.
Press s / t to turn system on/off.
Press NEXT to advance to next test.
Press DONE to terminate system test.
Test number System status
Tobegin,press and hold the s and t
buttons until the display changes
Installer setup
Setup function Settings & options (factory default in bold)
Shaded areas below apply only to TH5320U/TH5220D or as otherwise noted.
CAUTION: Compressor protection is bypassed during testing. To prevent equipment
damage,avoidcyclingthecompressorquickly
!
10 Heating system 0 Heat and fan turn off.
1 Stage1heatturnson.FanturnsonifSetupFunction1issetto1,
5,9or10ORSetupFunction3issetto1**Seepage6
2 Stage 2 heat turns on
3 Stage3heatturnson-TH5320U only
20 Emergency heating
system
0 Heat and fan turn off
1 Heat and fan turn on
2 Stage 2 heat turns on (auxiliary heat) - TH5220D only
30 Cooling system 0 Compressor and fan turn off
1 Compressor and fan turn on
2 Stage 2 compressor turns on
40 Fan system 0 Fan turns off
1 Fan turns on
9Stage 1 compressor
cycle rate (CPH)
3 Recommended for most compressors
[Othercyclerateoptions:1,2,4,5or6CPH]
10 Stage 2 compressor
cycle rate (CPH)
3 Recommended for most compressors
[Othercyclerateoptions:1,2,4,5or6CPH]
12 Manual/Auto
changeover
0 Manual changeover (Heat/Cool/Off)
1 Auto changeover (Heat/Cool/Auto/Off)
2 Auto changeover only (Auto)
14 Temperature
display
0 Fahrenheit
1 Celsius
15 Compressor
protection
5 Five-minute compressor off time
[Otheroptions:0,1,2,3or4-minuteofftime]
26 Auxiliary heat control 0 Comfort **See page 8
1 Economy
27 Heat temperature
range stops
90 Max. heat temperature setting is 90 °F (32 °C)
[Otheroptions:40°Fto89°F(4.5°Cto31.5°C)]
28 Cool temperature
range stops
50 Min. cool temperature setting is 50 °F (10 °C)
[Otheroptions:51°Fto99°F(10.5°Cto37°C)]
Installer system test

Installation Guide
Honeywell International Inc.
1985 Douglas Drive North
GoldenValley,MN55422
http://customer.honeywell.com
Automation and Control Solutions
® U.S. Registered Trademark.
© 2009 Honeywell International Inc.
69-1922EFS—01M.S.05-09
Honeywell Limited-Honeywell Limitée
35DynamicDrive
Toronto,OntarioM1V4Z9
Printed in U.S.A. on recycled
paper containing at least 10%
post-consumer paper fibers.
Special function
Auxiliary heat control (Setup Function 26):
• Comfort Setting: The thermostat will prioritize comfort over economy depending on heat
pumpperformance,loadconditionsandwhetherthethermostatiscallingfortheheat
pump. Raising the temperature just a few degrees will often activate the auxiliary heat.
• Economy Setting: The thermostat will attempt to reach the temperature setting
without activating the auxiliary heat. The thermostat will wait to activate the auxiliary
heatdependingonheatpumpperformance,loadconditionsandhowmanydegreesthe
temperature setting is changed.
Accessories & replacement parts
Please contact your distributor to order replacement parts.
Part Description Part Number Use With
Battery holder 50000951-001 TH5110D
Batteryholder 50007072-001 TH5320U/TH5220D
Coverplateassembly* 50001137-001 TH5110D
Coverplateassembly* 50002883-001 TH5320U/TH5220D/TH5110D
12packofsmallcoverplates* 50007297-001 TH5110D
12packofmediumcoverplates* 50007298-001 TH5320U/TH5220D/TH5110D
*Use to cover marks left by old thermostats.
Specifications
Temperature Ranges
• Heat:40°to90°F(4.5°to32°C)
• Cool:50°to99°F(10°to37°C)
Operating Ambient Temperature
• 32°to120°F(0°to48.9°C)
Shipping Temperature
• -20°to120°F(-28.9°to48.9°C)
Operating Relative Humidity
• 5%to90%(non-condensing)
Physical Dimensions
TH5220D
• 3-9/16”Hx5-13/16”Wx1-1/2”D
 91mmHx147mmWx38mmD
TH5110D
• 3-7/16”Hx4-1/2”Wx1-5/16”D
 86mmHx114mmWx33mmD
Electrical Ratings
Terminal Voltage(50/60Hz) RunningCurrent
WHeating 20-30Vac 0.02-1.0A
(Powerpile) 750mVDC 100mADC
W2(Aux)Heating 20-30Vac 0.02-0.5A
YCooling 20-30Vac 0.02-1.0A
Y2Cooling 20-30Vac 0.02-1.0A
GFan 20-30Vac 0.02-0.5A
O/BChangeover 20-30Vac 0.02-0.5A
EEmergencyheat 20-30Vac 0.02-1.0A
LOutput 20-30Vac 0.02-0.5A

FocusPRO®Série TH5000
Thermostat numérique non programmable
® Marque de commerce déposée aux É.-U. Brevets en instance.
© 2009 Honeywell International Inc.
Tous droits réservés.
Guide
d’installation
Doit être installé par un technicien expérimenté et qualifié.
Lire attentivement ces instructions. Le manquement à suivre ces instructions
peut entraîner des dommages au produit et causer des conditions dangereuses.
Besoin d’aide?
Pourobtenirdel’assistanceausujetdeceproduit,
consulter le http://customer.honeywell.com ou téléphoner sans frais
au Centre de service à la clientèle de Honeywell au 1-800-468-1502
Ce guide couvre les modèles suivants :
• TH5110D:Pour1systèmedechauffageet1systèmedeclimatisation
• TH5220D:Pour2systèmesdechauffageet2systèmesdeclimatisation
• TH5320D:Pour3systèmesdechauffageet2systèmesdeclimatisation
(Enlever le porte-pile pour trouver le numéro de modèle.)
Types de système
• Chauffageaugaznaturel,
au mazout ou à l’électricité
avec climatiseur
• Fournaisesàgrandrendement
à air chaud ou à eau chaude ;
thermopompes,systèmes
à la vapeur ou gravitaires
• Chauffageseulement–systèmes
àdeuxfils,soupapesdezone
à trois fils (Série 20) soupapes
de zones normalement ouvertes
• Chauffageseulementavec
soufflante
• Climatisationseulement
• Systèmesdechauffagede750mV

69-1922EFS—01 2
Guide d’installation
FRANÇAIS
M29369
M29368
Installation de la plaque murale
1. Séparer la plaque murale du thermostat.
2. Installer la plaque murale tel que décrit
ci-dessous.
Percerdestrousde5mm(3/16po)
dans le placoplâtre.
Ancrages muraux
Plaque murale
Trou du fil Visdemontage
MISE EN GARDE : RISQUE DE CHOC ÉLECTRIQUE
Peut causer un choc électrique ou endommager l’équipement. Couper l’alimentation
avant de commencer l’installation.
REMARQUE À PROPOS DU MERCURE :
Si ce produit sert à remplacer une commande qui contient du mercure dans un tube
scellé,nepasjeterlavieillecommandeauxordures.Consulterl’administrationlocale
de gestion des déchets pour connaître les instructions relatives au recyclage
et à l’élimination.
!
Tirer ici pour enlever la plaque
murale du thermostat neuf.
Retirer le porte-pile.
!
Il est plus facile de saisir la
plaque murale et de l’enlever
après avoir complètement
retiré le porte-pile.
Percerdestrousde5,5mm
(7/32po)silemurestenplâtre.
