Honeywell Inncom E527 User manual

7 March 2018
CONFIDENTIAL
INNtool Support Material: Wiring 24VAC
E527/X47 4G 24VAC Wiring Guide
Disclaimer
This document contains information that is the proprietary and confidential property of INNCOM by Honeywell. By acceptance hereof, each recipient
agrees to use the information contained herein only for the purpose anticipated by INNCOM by Honeywell, and not to disclose to others, copy or
reproduce, any part hereof without the written consent of INNCOM by Honeywell. The recipient agrees to return this document to INNCOM by
Honeywell immediately upon request.
•DISCONNECT POWER BEFORE BEGINNING INSTALLATION. ELECTRICAL HAZARD: Can cause electrical shock or equipment damage.
•Must be installed by a trained , experienced technician.
•See device specific product guides for load specifications.
Table of Contents
1. WIRING GUIDE 24VAC X47 (“A3” OPTION)............................................................................................................ 2
2. THERMOSTAT WIRE CONNECTIONS: ....................................................................................................................... 3
3. SYSTEM SPECIFIC WIRING GUIDES........................................................................................................................ 4
4. LOW VOLTAGE WIRING........................................................................................................................................... 5
5. FIELD SIDE WIRING ............................................................................................................................................... 6
6. DOCUMENT INFORMATION ..................................................................................................................................... 7

© INNCOM by Honeywell - 2 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
1. Wiring Guide 24VAC X47 (“A3” option)
See detailed wiring guides for specific system types on the following page.
X47
2
1
3
2
1
3
4
5
2X5 MOLEX CONNECTOR
(MALE)
P/N 62-1464.R
7
10
1
2
9
3
8
4
5
6
ORG - LOW FAN
VIO - FAN POWER
GRY - VALVE POWER
WHT - HEAT / REV VLV
YEL - COOL / COMP
BRN - MED / W2
BLU - HIGH FAN
BLK - COMMON
RED - 24VAC
GRN - EARTH GND FC2
FC1
FC9
FC8
FC7
FC6
FC5
FC4
FC3
FC10
FC11
FC12
FC13
FC14
FC15
ORG - S5
GRN - IN2
YEL - IN1
RED - DC OUT
BRN - COMMON
1 2 3
123 4 5
6 7 8 9
10
GND
1
2
3
ANG OUT-1
ANG OUT-2
FC22
FC23
FC24
N/C
FC21
1
2
3
1
2
3
FC20 GND
FC19 10k NTC
N/C
FC18
FC17 GND
FC16 10k NTC

© INNCOM by Honeywell - 3 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
2. Thermostat wire connections:
HVAC INTERFACE LOW VOLTAGE INTERFACE
Connection
Color
Function
Connection
Color
Function
FC1
Green
EARTH GROUND
FC11
Brown
DC GROUND
FC2
Red
24 VAC POWER
FC12
Red
DC OUT
FC3
Black
24 VAC COMMON
FC13
Orange
S5 BUS
FC4
Blue
HIGH FAN RELAY
FC14
Yellow
INPUT 1
FC5
Brown
MED FAN RELAY/ HEAT RELAY(STAGE 2)
FC15
Green
INPUT 2
FC6
Yellow
COMPRESSOR CONTACTOR
FC7
White
HEAT RELAY(STAGE 1)/ REVERSING VALVE
FC8
Grey
24 VAC VALVE POWER
FC9
Violet
24 VAC FAN POWER
FC10
Orange
LOW FAN RELAY
FIELD SIDE INTERFACE
Connection
Color
Function
FC16
Orange
10K NTC (REMOTE THERMISTOR INPUT)
FC17
Red
GROUND
FC18
Brown
NO CONNECTION
FC19
Orange
10K NTC (REMOTE THERMISTOR INPUT)
FC20
Red
GROUND
FC21
Brown
NO CONNECTION
FC22
Orange
ANALOG OUTPUT-2
FC23
Red
ANALOG OUTPUT-1
FC24
Brown
GROUND

© INNCOM by Honeywell - 4 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
3. System Specific Wiring Guides
Generic Single Stage Heat/Cool
Unused Fan Outputs
GL – LOW FAN
ORG
BRN
BLU
FC5
FC4
FC10
*Unused fan outputs in any HVAC Type shall be tied to FC10
Heat Pump North (HpO)-Single Stage Heat
Heat Pump North (HpO)-Two Stages Heat
Heat Pump South (HpB)-Single Stage Heat
Heat Pump South (HpB)-Two Stages Heat
2 Pipe Change-Over
2 Pipe Change-Over with Back-up Electric Heat
Cool Only System
Heat Only System
R – 24VAC
C – COMMON
Y – COOL
W – HEAT
GH – HIGH FAN*
G2 –MED FAN*
GL – LOW FAN
ORG
VIO
GRY
WHT
YEL
BRN
BLU
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC5
FC4
FC3
FC10
ORG
VIO
GRY
WHT
YEL
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC3
FC10
R – 24VAC
C – COMMON
Y – COMPRESSOR
O – REV VALVE
GH – HIGH FAN*
GM –MED FAN*
GL – LOW FAN
BRN
BLU
FC5
FC4
ORG
VIO
GRY
WHT
YEL
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC3
FC10
R – 24VAC
C –COMMON
Y –COMPRESSOR
B –REV VALVE
GH –HIGH FAN*
GM – MED FAN*
GL –LOW FAN
BRN
BLU
FC5
FC4
ORG
VIO
GRY
WHT
YEL
BRN
BLU
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC3
FC10
R – 24VAC
C – COMMON
Y – VALVE
GH – HIGH FAN*
GL – LOW FAN
GM – MED FAN*
N/C
FC5
FC4
ORG
VIO
GRY
WHT
YEL
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC3
FC10
R – 24VAC
C – COMMON
Y – COMPRESSOR
B – REV VALVE
GH – HIGH FAN*
W2 - HEAT2
GL – LOW FAN
BRN
BLU
FC5
FC4
ORG
VIO
GRY
WHT
YEL
BRN
BLU
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC3
FC10
R – 24VAC
C – COMMON
Y – VALVE
GH – HIGH FAN*
GL – LOW FAN
GM – MED FAN*
W2 – ELECTRIC HEAT
FC5
FC4
ORG
VIO
GRY
WHT
YEL
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC3
FC10
R – 24VAC
C – COMMON
Y – COMPRESSOR
O – REV VALVE
GH – HIGH FAN*
W2 - HEAT2
GL – LOW FAN
BRN
BLU
FC5
FC4
R – 24VAC
C – COMMON
Y - COOL VALVE
N/C
GH – HIGH FAN*
G2 – MED FAN*
GL – LOW FAN
ORG
VIO
GRY
WHT
YEL
BRN
BLU
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC5
FC4
FC3
FC10
R – 24VAC
C – COMMON
N/C
W – HEAT VALVE
GH – HIGH FAN*
G2 – MED FAN*
GL – LOW FAN
ORG
VIO
GRY
WHT
YEL
BRN
BLU
BLK
RED
EARTH GROUND
GRN
FC2
FC1
FC9
FC8
FC7
FC6
FC5
FC4
FC3
FC10

© INNCOM by Honeywell - 5 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
4. Low Voltage Wiring
Door Contact Only
Window Contact Only
Closed Door=Closed Contact
FC11
FC12
FC13
FC14
DOOR CONTACT
FC15
Closed Window=Closed Contact
FC11
FC12
FC13
FC14
WINDOW
CONTACT
FC15
Door & Window Contact
Window Contact & PIR Sensor
FC11
FC12
FC13
FC14
DOOR CONTACT
WINDOW
CONTACT
FC15
FC11
FC12
FC13
FC14
WINDOW
CONTACT
Alarm + -TMP
INNCOM
PIR
SENSOR
FC15
Door Contact & PIR Sensor
PIR Sensor Only
FC11
FC12
FC13
FC14
DOOR CONTACT
Alarm + -TMP
INNCOM
PIR
SENSOR
FC15
FC11
FC12
FC13
FC14
INNCOM
PIR
SENSOR
Alarm + -TMP
FC15
If Multiple Window Contacts in Series
If Multiple PIR Sensors in Series
FC11
FC X
WINDOW
CONTACT WINDOW
CONTACT
Alarm + -TMP
FC11
FC12
FC X
INNCOM
PIR
SENSOR
Alarm + -TMP
INNCOM
PIR
SENSOR
S5 Bus
FC11
FC12
FC13
S5 BUS:
TO OTHER S5
ROOM DEVICES

© INNCOM by Honeywell - 6 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
5. Field Side Wiring
Variable Fan connection using ANG OUT-1
Variable Fan connection using ANG OUT-2
FC22
FC23
FC24
FAN
Powered by
others
Variable Control
GND
ANG OUT-1
ANG OUT-2
0-10V
GND
FC22
FC23
FC24
FAN
Powered by
others
Variable Control
GND
0-10V
ANG OUT-1
ANG OUT-2
GND
Heat/Cool Valve connection using ANG OUT-1
Heat/Cool Valve connection using ANG OUT- 2
FC22
FC23
FC24 0-10V
Powered by
others
GND
ANG OUT-1
ANG OUT-2
GND
VALVE
Remote Thermistor
FC22
FC23
FC24
VALVE
0-10V
Powered by
others
GND
ANG OUT-1
ANG OUT-2
GND
FC17
FC16
GND
10k NTC

© INNCOM by Honeywell - 7 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
6. Document Information Author
Jasmeet Talwar
INNCOM by Honeywell
277 West Main Street
Niantic, CT 06357
[phone]
File
Source:
$:/FO_100_INNtool/Documents/Wiring Guides/INNtool_E527_24VAC_Wiring_Diagram.doc
Distribution:
T:\FTP\Eng_Data\Hotels\FO_100_INNtool\Documents\Wiring Guides\INNtool_E527_24VAC_Wiring_Diagram.pdf
Version
2017/12/05 Version 3.2
