INSTALLATION INSTRUCTIONS ADDENDUM
69- 1460- 1
Automation and Control Solutions Automation and Control Solutions
Honeywell Honeywell Limited-Honeywell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario
M1V 4Z9
T8112,T8131,T8132;TD2200,TD2400;
CT2800,CT3200,CT3300,CT3395
Thermostats
CYCLE RATES AND TIME FORMAT
ADJUSTMENT
The adjustment for cycle rates and time format has
changed from the current information in the Installation
Instructions.See Fig.1 and the tables for guidance.
Fig. 1. DIP switch positions.
1
OFF ON
2
3
ON
1
M1482
9
2
3
Heating System DIP Switch Position
Fuel
Switch
Position
Warm air furnace 1 - On 2 - On F
Hot water or high
efficiency warm air
furnace
1 - Off 2 - On F
Electric furnace 1 - On 2 - Off E
Temperature Display DIP Switch Position
Display °F 3 - On
Display °C 3 - Off
