Honeywell RTH111 series User manual

Operating
Manual
RTH111 Series
Non-Programmable Thermostat
69-2603ES-01

About your new thermostat
Thermostat features................................... 1
Quick reference to controls....................... 3
Quick reference to display ........................ 4
Operation
Select system setting ................................ 5
Select fan setting ....................................... 6
Adjust the temperature.............................. 7
Compressor protection.............................. 8
Appendices
Battery replacement .................................. 9
Customer assistance ............................... 10
In case of difficulty................................... 11
Limited warranty ...................................... 13
Read and save these instructions.
Need Help?
For assistance with this product please visit http://yourhome.honeywell.com
or call Honeywell Customer Care toll-free at 1-800-468-1502
Table of contents
® U.S. Registered Trademark. Patents pending.
Copyright © 2011 Honeywell International Inc. All rights reserved.
CAUTION: EQUIPMENT
DAMAGE HAZARD.
To prevent possible compressor
damage, do not operate
cooling system when outdoor
temperature is below 50°F (10°C).

RTH111
1 69-2603ES—01
About your new thermostatAbout your new thermostat
Your new Honeywell thermostat has been designed to give you many years of reliable
service and easy-to-use, push-button climate control.
Features
• Displaysambient(measured)temperatureatalltimes
• One-touchaccesstosetpointtemperature
• Built-incompressorprotection
Operating Manual

Operating Manual
69-2603ES—01 2
About your new thermostatThis thermostat is ready to go!
Simply perform the three steps below and the thermostat is in operation:
1. Select system setting: Preset to Off................................To change, see page 5
2. Select fan setting: Preset to Auto...................................To change, see page 6
3. Set the temperature using the
Up or Down buttons....................................................... To change, see pages 7

RTH111
3 69-2603ES—01
About your new thermostat
M32761
Heat Off Cool Auto On
Fan
Quick reference to controls
Up/Down buttons
Press to adjust temperature.
Fan Switch (see page 6)
On: Fan runs continuously.
Auto: Fan runs only when heating
or cooling system is on.
System switch (see page 5)
• Cool: Cooling system control.
• Off: All systems off.
• Heat: Heating system control.

Operating Manual
69-2603ES—01 4
About your new thermostat
Lo
Batt
Set
Cool
77
M32763
On
Quick reference to display screen
Low battery warning
(see page 9)
Temperature
The ambient (measured) temperature
is normally displayed. To view the
setpoint temperature, press the Up
or Down button once. The setpoint
temperature will appear for five
seconds.
System status
Cool on: Cooling system is on.
Heat on: Heating system is on.
WhenCoolOnisflashing,compressor
protection is engaged (see page 8).
Setpoint indicator
Appears when the setpoint
temperature is displayed

RTH111
5 69-2603ES—01
M32761
Heat Off Cool Auto On
Fan
Select the system setting
The SYSTEM switch can be set to control
your heating or cooling system, depend-
ing on the season.
• Cool: Cooling system control.
• Off: All systems are off.
• Heat: Heating system control.
Set SYSTEM switch to control the
heating or cooling system.
CAUTION: EQUIPMENT DAMAGE
HAZARD. To prevent possible
compressor damage, do not operate
cooling system when outdoor
temperature is below 50°F (10°C).

Operating Manual
69-2603ES—01 6
M32761
Heat Off Cool Auto On
Fan
Select the fan setting
Set the FAN switch to Auto or On.
In “Auto” mode (the most commonly used
setting), the fan runs only when the heat-
ing or cooling system is on.
Ifsetto“On,”thefanrunscontinuously.
Set FAN switch to choose whether the fan
runs continuously or only as needed.

RTH111
7 69-2603ES—01
About your new thermostat
M32764
Heat Off Cool Auto On
Fan
Set
Cool
77
On
Adjust the temperature
Press sor tto adjust the temperature.
Note: Make sure the thermostat is set to the
system you want to control (heat or cool).

Operating Manual
69-2603ES—01 8
Built-in compressor protection
This feature helps prevent damage to the
compressor in your air conditioning or heat
pump system.
Damagecanoccurifthecompressoris
restarted too soon after shutdown. This fea-
ture forces the compressor to wait 5 minutes
before restarting.
Duringthewaittime,thedisplaywillflashthe
message CoolOn. When the safe wait time
has elapsed, the message stops flashing and
the compressor turns on.
Message flashes until safe restart
time has elapsed.
Set
Cool
77
M32769
On

RTH111
9 69-2603ES—01
RTHXXXX
M32707
W/
Aux
Not
Used
M32757
Heat Off Cool Auto On
Fan
Battery replacement
Install two fresh AAA batteries when
Lo Batt flashes on the screen. Lo
Batt appears for 60 days before the
batteries are depleted.
Replace batteries once a year, or
when you will be away for more than
a month.
The settings are stored in non-volatile
(permanent) memory and are thus
preserved when the thermostat is
without batteries.
SettheSystemswitchtoOffbeforeremovingthe
batteries.Otherwise,theheating/coolingsystem
could remain activated even when batteries are
removed.
Pull at bottom to
remove thermostat
from wallplate.
Turn thermostat over,
insert fresh AAA alkaline
batteries, then reinstall
thermostat.

Operating Manual
69-2603ES—01 10
RTHXXXX
M32707
W/
Aux
Not
Used
M32757
Heat Off Cool Auto On
Fan
Customer assistance
For assistance with this product, please
visit
http://yourhome.honeywell.com.
OrcallHoneywellCustomerCaretoll-
free at 1-800-468-1502.
To save time, please note your model
number and date code before calling.
Turn thermostat over
to find model number
and date code.
Pull at bottom to
remove thermostat
from wallplate.

RTH111
11 69-2603ES—01
If you have difficulty with your thermostat, please try the following suggestions.
Most problems can be corrected quickly and easily.
Display is blank • Makesurefurnacedoorisclosedsecurely.
• MakesurefreshAAAalkalinebatteriesarecorrectlyinstalled(see
page 9).
Heating or
cooling system
does not respond
• SetsystemswitchtoHeat (see page 5). Make sure the temperature is
set higher than the Inside temperature.
• SetsystemswitchtoCool (see page 5). Make sure the temperature is
set lower than the Inside temperature.
• Wait5minutesforthesystemtorespond.
In case of difficulty

Operating Manual
69-2603ES—01 12
Temperature
settings do not
change
Make sure heating and cooling temperatures are set to acceptable ranges:
• Heat:40°to90°F(4.5°to32°C).
• Cool:50°to99°F(10°to37°C).
“Cool On” is
flashing
•Compressor protection feature is engaged. Wait 5 minutes for the system
to restart safely, without damage to the compressor (see page 8).
“Heat On” is not
displayed
•Set the System switch to Heat, and set the temperature level above the
current room temperature (see page 5).
“Cool On” is not
displayed
•Set the System switch to Cool, and set the temperature level below the
current room temperature (see page 5).
In case of difficulty

RTH111
13 69-2603ES—01
About your new thermostat1-year limited warranty
Honeywell warrants this product, excluding battery, to be free from defects in the workmanship or materials, under normal use
and service, for a period of one (1) year from the date of purchase by the consumer. If at any time during the warranty period the
product is determined to be defective or malfunctions, Honeywell shall repair or replace it (at Honeywell’s option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of purchase, to the place from which you purchased it; or
(ii) call Honeywell Customer Care at 1-800-468-1502. Customer Care will make the determination whether the product should be
returnedtothefollowingaddress:HoneywellReturnGoods,Dock4MN10-3860,1885DouglasDr.N.,GoldenValley,MN55422,
or whether a replacement product can be sent to you.
This warranty does not cover removal or reinstallation costs. This warranty shall not apply if it is shown by Honeywell that the
defect or malfunction was caused by damage which occurred while the product was in the possession of a consumer.
Honeywell’ssoleresponsibilityshallbetorepairorreplacetheproductwithinthetermsstatedabove.HONEYWELLSHALL
NOTBELIABLEFORANYLOSSORDAMAGEOFANYKIND,INCLUDINGANYINCIDENTALORCONSEQUENTIALDAMAGES
RESULTING,DIRECTLYORINDIRECTLY,FROMANYBREACHOFANYWARRANTY,EXPRESSORIMPLIED,ORANYOTHER
FAILUREOFTHISPRODUCT.Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages,so
this limitation may not apply to you.
THISWARRANTYISTHEONLYEXPRESSWARRANTYHONEYWELLMAKESONTHISPRODUCT.THEDURATIONOFANY
IMPLIEDWARRANTIES,INCLUDINGTHEWARRANTIESOFMERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSE,
ISHEREBYLIMITEDTOTHEONE-YEARDURATIONOFTHISWARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. This
warranty gives you specific legal rights, and you may have other rights which vary from state to state.
Ifyouhaveanyquestionsconcerningthiswarranty,pleasewriteHoneywellCustomerRelations,1985DouglasDr,Golden
Valley,MN55422orcall1-800-468-1502.InCanada,writeRetailProductsON15-02H,HoneywellLimited/HoneywellLimitée,35
DynamicDrive,Toronto,OntarioM1V4Z9.

Automation and Control Solutions
Honeywell International Inc.
1985DouglasDriveNorth
GoldenValley,MN55422
HoneywellLimited-HoneywellLimitée
35DynamicDrive
Toronto,OntarioM1V4Z9
http://yourhome.honeywell.com
® U.S. Registered Trademark
© 2011 Honeywell International Inc.
69-2603ES—01M.S.05-11
Printed in U.S.A.

69-2603ES-01
Manual de
funcionamiento
RTH111 Series
Termostato no programable

Índice
Acerca de su nuevo termostato
Características del termostato.................. 1
Rápida referencia de los controles........... 3
Rápida referencia de la pantalla ............... 4
Funcionamiento
Seleccione la configuración del sistema...... 5
Seleccione la configuración
del ventilador............................................... 6
Acerca de su nuevo term .......................... 7
Protección del compresor......................... 8
Apéndices
Reemplazo de la batería............................ 9
Asistencia al cliente................................. 10
Encasodeinconvenientes ..................... 11
Garantía limitada...................................... 13
Lea y guarde estas instrucciones.
®MarcaregistradadelosEE.UU.Patentesentrámite.
© 2011, Honeywell International Inc. Todos los derechos reservados.
¿Necesita asistencia?
Para obtener asistencia relacionada con este producto, visite
http://yourhome.honeywell.com o comuníquese con el número gratuito del
servicio de atención al cliente de Honeywell, llamando 1-800-468-1502
PRECAUCIÓN: PELIGRO DE DAÑO
EN EL EQUIPO.
Para evitar posibles daños en el
compresor, no haga que el termostato
funcione cuando la temperatura
exterior sea inferior a 50 ºF (10 ºC).

RTH111
1 69-2603ES—01
Acerca de su nuevo termostato
Su nuevo termostato ha sido diseñado para brindarle muchos años de funcionamiento
confiable y para brindarle un control climático fácil de usar y con sólo apretar un botón.
Características
• Indicalatemperaturaambiente(medida)entodomomento.
• Unsólobotónpermiteverlatemperaturadelpuntodeajuste.
• Proteccióndelcompresorincorporada.

69-2603ES—01 2
Acerca de su nuevo termostato
Manual de funcionamiento
¡Este termostato está listo para funcionar!
Basta con llevar a cabo las tres etapas siguientes para poner el termostato en marcha:
1. Seleccione la configuración del sistema:
Predetermine la función “Off”................................................. Para cambiar, vea la página 5
2. Seleccione la configuración del ventilador:
Predetermine la función “Auto”.............................................. Para cambiar, vea la página 6
3. Seleccionar la temperatura con
los botones Arriba o Abajo: ............................................ Para cambiar, vea las páginas 7
