Honeywell Digital Round T8775C User manual

Honeywell
T8775A,CTheDigitalRoundTM
Non-Programmable
Thermostats
® U.S. Registered Trademark
Patents Pending
© 2004 Honeywell International Inc.
All Rights Reserved 69-1679ES--1

SYSTEM
SWiTCH_\
(T8 F75C
SELECTS
COOL, OFF/HEAT
iNDiCATORS
THAT SHOW
THERMOSTAT HAS
CALLED FOR
HEATING
OR COOLmNG _
DiGiTAL DISPLAY
DISPLAYS ROOM
OR SET TEMPERATURE
BACKLJGHT SUTTON
(T8775C ONLY)
SELECTS
ON/AUTO
ROOM
TEMPERATURE
iNDiCATOR
SHOWS THAT THE
CURRENTROOM
TEMPERATURE
IS DISPLAYED
SETTING
mNDICATOR
SHOWS THAT THE
CURRENT
TEMPERATURE
SETTING IS DISPLAYED
DIAL
DISPLAYS AND ADJUSTS
TEIViPE RATU RE SETTING/TURNS
BACKLIGHT ON M19470
Fig. 1. T8775 Thermostat (features and operation).
69-1679ES--1 2

Setting SYSTEMand FANSwitches (T8775Conly)
System and Fan settings are controlled by using SYSTEM and
FAN switches located on the top of the thermostat (see Fig. 1).
IMPORTANT
Do not operate the T8775C in cooling mode when the
outdoor temperature is below 50°F (10°C), or damage to
compressor could result.
SETTHESYSTEMSWITCH:
Heat: The thermostat controls your heating system.
Off: Both heating and cooling systems are off.
Cool: The thermostat controls your cooling system.
SETTHE FANSWITCH:
Auto: Normal setting for most homes. The fan only runs with
the heating and cooling system.
On: The fan runs continuously. Use for improved air
circulation.
OperatingYour Thermostat
NOTE: Batteries are not required because the temperature set-
ting is held permanently in memory.
3 69-1679ES--1

BacklitDisplay
The backIight can be turned on by turning the dial, or by
pushing the backlight button as shown in Fig. 1.
DisplayTemperature Setting
NOTE: Your temperature setting can be set anywhere from
40°F to 90°F (4°C to 32°C) in heating and 45°F to 99°F
(7°C to 37°C) in cooling (T8775C only).
Turn the dial one click to display
the current temperature setting.
A _1_indicator points to Set
when the temperature setting is
displayed. If a change to the
temperature setting is not made
within five seconds, the mode
will switch to the room
temperature display.
A _1_indicator points to Room
when the room temperature is
displayed.
69-1679ES--1 4

AdjustTemperature Setting
To lower the temperature setting, turn the dial
counterclockwise.
To raise the temperature setting, turn the dial clockwise.
Troubleshooting Guide
CAUTION
Equipment Damage Hazard.
Can cause permanent damage to compressor or
other equipment.
Do not operate cooling when outside temperature is
below 50°F (10°C).
Allow compressor to remain off for five minutes before
restarting.
See equipment manufacturer instructions.
Heatingor cooling does not comeon.
Make sure that the SYSTEM switch on the thermostat is set to
Heat or Cool (T8775C only).
5 69-1679ES--1

In heating, make sure the temperature setting is above the
room temperature and the flame _ is present in the display.
In cooling, make sure the temperature setting is below the
room temperature and a solid snowflake _,_ is present in the
display (T8775C only).
NOTE: If a call for cooling is made before the compressor has
been off for five minutes, or if a power interruption
occurs while the compressor is running, the thermostat
will go into a five-minute delay to protect the compres-
sor. The snowflake _,_ will flash during this delay.
Check the system fuse or circuit breaker and replace or reset if
necessary.
Check for air movement at the register.
If you have questions concerning this thermostat, call Honeywell
Customer Care at 1-800-468-1502.
69-1679ES--1 6

7 69-1679ES--1

Honeywell
Automation and Control Solutions
HoneywelI InternationaI inc. Honeywell Limited-HoneyweII Limitee
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario
Printed in U.S.A. on recycled M1V 4Z9
paper containing at least 10%
post-consumer paper fibers.
69-1679ES--1 J.S. Rev 6-04 w,_vhoneyweit.com/yourhome
