T8011R
Programmable Heat Pump Thermostat
APPLICATION
The T8011R Heat Pump Thermostat provides 24 Vac
control of a two-stage heating and one-stage cooling heat
pump system with manual changeover from heat to cool.
First stage heating and cooling cycle rates are fixed at 3
cph. Second stage heating cycle rate is selectable at
3, 4, 5, 6, 9 or 12 cph. Temperature indication can be set
for °F or °C.
The T8011R Heat Pump Thermostat is powered directly
from the system transformer. Setpoints are held perma-
nently in memory and retained during power outages.
The T8011R TRADELINE® model includes a thermostat,
wallplate and owner’s guide. A 7 3/8 in. (188 mm) x 5 3/4
in. (146 mm) decorator cover plate (for covering wall
marks) is available separately. Order Honeywell part no.
209649A (taupe) or part no. 209649B (white).
MERCURY NOTICE
If this control is replacing a control that contains
mercury in a sealed tube, do not place your old
control in the trash. Dispose of it properly.
Contact your local waste management authority for
instructions regarding recycling and the proper
disposal of a control.
INSTALLATION
When Installing this Product…
1. Read these instructions carefully. Failure to follow
them could damage the product or cause a hazard-
ous condition.
2. Check the ratings given in the instructions and on
the product to make sure the product is suitable for
your application.
3. Installer must be a trained, experienced service
technician.
4. After installation is complete, check out product
operation as provided in these instructions.
CAUTION
Hazardous Voltage
Can damage heating/cooling system.
Disconnect power at furnace or main breaker/fuse
box.
Location
Install the thermostat about 5 ft (1.5m) above the floor in
an area with good air circulation at average temperature.
See Fig. 1. Do not install the thermostat where it can be
affected by:
—drafts or dead spots behind doors and in corners.
—hot or cold air from ducts.
—radiant heat from the sun or appliances.
—concealed pipes and chimneys.
—unheated (uncooled) areas such as an outside wall
behind the thermostat.
Mounting Wallplate to Wall
IMPORTANT
Level for appearance only. The thermostat
functions normally even when not level.
Mount wallplate and the T8011R with the screws provided
(see Fig. 2) as follows:
1. Place the wallplate at the desired location on the
wall.
2. Pull the thermostat wire through the wallplate
entrance hole.
3. Fasten the wallplate to the wall using the anchors
and screws provided.
4. After wiring the wallplate, plug the hole with non-
flammable insulation to prevent drafts from affecting
the thermostat; see Wiring section.
Table 1. Description of T8011R Thermostats.
Model System Changeover System Selection Fan Selection Powering Method
T8011R Heat Pump Manual Cool-Off-Heat-Em. Ht. Auto-On Hardwired
69-1435-1

69-1435–1 2
T8011R PROGRAMMABLE HEAT PUMP THERMOSTAT
5 FEET
[1.5 METERS]
YES
NO
NO
NO
M11338
Fig. 1. Typical location of thermostat.
Fig. 2. Mounting wallplate to wall.
Wiring
IMPORTANT
Use 18-gauge maximum wire for wiring the
T8011R Thermostat.
All wiring must comply with local electrical codes and
ordinances. Disconnect the power supply to prevent
electrical shock or equipment damage.
The shape of the terminals permits insertion of straight or
wraparound wiring connections; either method is accept-
able. A letter code is located near each terminal for
identification. See Fig. 3.
NOTE: To ensure proper mounting of thermostat, restrict
all wiring to the shaded area in the center of the
terminals. See Fig. 4.
Refer to Fig. 5 for typical wiring hookup.
TERMINAL
SCREW
M11334
G
C
R
Y
W1
L
W2
E
B
O
FOR STRAIGHT INSERTION
STRIP 5/16 IN. (8 MM)
FOR WRAPAROUND
STRIP 7/16 IN. (11 MM
)
M12202
WALL WALL
ANCHORS (2)
WALLPLATE
MOUNTING
SCREWS (2)
Fig. 3. Wiring connections.

69-1435–1
3
T8011R PROGRAMMABLE HEAT PUMP THERMOSTAT
Fig. 4. Restrict wiring to shaded area.
KEEP WIRING IN
SHADED AREA
MOUNTING
SCREW HOLE MOUNTING SCREW HOLE
WIRING ENTRANCE
HOLE
M11331
G
C
R
Y
W1
L
W2
E
B
O
L1
(HOT
)
L2
1
1
2
2
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
REMOVE JUMPER, WHEN SUPPLIED, FOR SYSTEMS WITH SEPARATE HEATING COMPRESSOR CONTACTOR (W1 SEPARATE FROM Y).
SYSTEM
SWITCH
HEAT
OFF
COOL
R
W2
L
B
O
Y
EM. HT.
W1
E
AUXILARY
HEAT RELAY
CHANGEOVER
VALVE HEAT
CHANGEOVER
VALVE COOL
COMPRESSOR
CONTACTOR
COMPRESSOR
CONTACTOR
HEAT
FAN RELAY
RELAY
EMERGENCY
HEAT RELAY
G
C
THERMOSTAT
LOGIC
THERMISTOR
SENSOR
POWER
SUPPLY
ON
AUTO
STAGE 2 RELAY
STAGE 1 RELAY
FAN SWITCH
M11333
Fig. 5. T8011R two stage heat, one stage cool wiring diagram with manual changeover.

69-1435–1 4
T8011R PROGRAMMABLE HEAT PUMP THERMOSTAT
Mounting Thermostat To Wallplate
1. Slide SYSTEM switch to the Off position.
2. Engage the tabs at the top of the thermostat and
wallplate.
3. Swing down the thermostat and press the lower
edge of the thermostat onto the wallplate to latch.
See Fig. 6.
Fig. 6. Mounting thermostat to wallplate.
INSTALLER SETUP
Setting °F/°C Indication and Heat Cycle Rate
The following instructions provide the information neces-
sary to change the heating cycle rate to match the heating
equipment and to choose either Fahrenheit (°F) or Celsius
(°C) display.
NOTE: All four steps must be completed to save
changes to the °F/°C indication and the heat
cycle rate.
1. Enter Installer Setup.
a. Use ▲or ▼keys
to set the tempera-
ture setpoint to 52
°F (11°C).
b. Press the ▲and ▼keys simultaneously for
more than two seconds to enter installer
setup.
c. When released the
three-digit
software revision
code displayed.
d. Press the ▲key.
Factory configura-
tion (FC) is
displayed
(A typical example
is shown, but
information
displayed varies
by model. This information is for factory use
only).
Optional System Checkout
When in steps 1c and 1d only, pressing the ▼key can be
used to turn heat or cool outputs on and off. Change the
SYSTEM switch setting to test heat or cool outputs. During
testing, the 5 minute minimum off time is bypassed. No
action takes place If the system switch is in the Off
position.
Examples: System setting at HEAT: If heat is on,
pressing the ▼key turns it off; if heat is off,
pressing the ▼key turns it on.
System setting at COOL: If cool is on,
pressing the ▼key turns it off; if cool is off,
pressing the ▼key turns it on.
NOTE: In installer setup only, each press of the ▲key
momentarily displays 1. Each press of the ▼key
momentarily displays 2. When the keys are
released, these one-digit codes are no longer
displayed.
2. Setting °C or °F.
a. Press the ▲key
again to display
the current setting.
b. Press the ▼key to
change the °C or
°F indication.
M1469
9
DASHED LINES INDICATETABS
ON BACK OFTHERMOSTAT
ENGAGE TABS AT TOP OF THERMOSTAT
WITH SLOTS ON MOUNTING PLATE.
PRESS LOWER EDGE OF
CASE TO LATCH.
A
B
SYSTEM
Cool Off Heat Em Ht
Auto On
FAN
Hold
Select
SYSTEM
Cool Off Heat Em Ht
Auto On
FAN
Hold
Select
EM. HT. AUX. HT.
PM
M12582
A
SET
HT.
M12583
A
M12584
A
M12586
A
M12587
A

69-1435–1
5
T8011R PROGRAMMABLE HEAT PUMP THERMOSTAT
3. Setting Heat Cycle Rate (see Table 2 for cycle rate
options and equipment).
a. Press the ▲key to
display the current
heat cycle rate
setting of 3, 4, 5, 6,
9 or 12 cph.
b. If the desired cycle
rate is displayed,
press the ▲key to
exit the installer
setup.
c. To change the
heat cycle rate,
press the ▼key until your choice of 3, 4, 5, 6,
9 or 12 is displayed.
d. Press the ▲key to
display cooling
algorithm configu-
ration default.
e. Press the ▲key
again to change
cooling algorithm to C1 or C3.
C1 = Standard cooling algorithm.
C3 = Agressive cooling algorithm (can
cause overshooting).
f. Press the ▲key again. Current configuration
(CC) is displayed. A typical example is shown,
but CC varies by
model. (This
information is for
factory use only.)
4. Exit Installer Setup.
a. Press
the ▲
key to
save all
changes
and
return to
normal
operation.
Table 2. Heating Cycle Rate
System Cycles Per Hour
Hydronic Heat, Condensing
Gas Furnacesa
3
Gas or Oil Forced Air 6
Electric Heat 9
Special Applicationsb12
aHigh efficiency furnace (90+).
bRefer to the equipment manufacturer’s Instructions.
NOTE: Stage one heat and cool cycle rates are fixed at
3 cph. Only stage two heat cycle rates are
selectable.
OPERATION
Setting FAN and SYSTEM Switches
Fan and system settings are controlled manually by using
the switches located at the bottom of the
thermostat case. See Fig. 7.
FAN Switch
Fan switch settings are:
On: The fan runs continuously. Use for improved air
circulation and air quality.
Auto: Normal setting for most homes. The fan starts
and stops with the equipment.
Slide the FAN switch in the lower left corner of the
thermostat to select the desired fan setting.
SYSTEM Switch
System switch settings control thermostat operation as
follows:
Cool: The thermostat controls the cooling system.
Off: Both heating and cooling are off.
Heat: The thermostat controls the heating system.
Em. Ht.: The thermostat cycles auxiliary heat (W2) and
emergency heat relay (E) as needed to maintain
setpoint. Terminal L is energized continuously (fault
heat relay is on continuously). Cooling system is off.
Compressor is de-energized.
Slide the SYSTEM switch in the lower right corner of the
thermostat to select the desired system setting.
Fig. 7. Digital Display and System Switches.
SYSTEM
Cool Off Heat Em Ht
Auto On
FAN
T8011
M1470
0
Hold
Select
PM
M12590A
PM
M1469
1
M1469
2
M12589
A
M12588
A
4, 5, 12

69-1435–1 6
T8011R PROGRAMMABLE HEAT PUMP THERMOSTAT
69-1435–1 G.H. Rev. 2-02 Printed in U.S.A.
Setting Current Time and Day
1. To Set Current Time.
a. Press Select twice.
b. Press ▲or ▼to
set current time.
2. To Set Day of Week.
a. Press Select
again.
b. Press ▲or ▼to
set current day.
To use the preprogrammed
time and temperature press Hold to exit the programming
mode.
Setting Time And Temperature
The T8000C is preprogrammed with the time and tem-
perature settings shown in Table 3. For instructions on
programming the thermostat refer to the Owners Guide,
Form No. 69-1143.
Table 3. Preprogrammed Time and
Temperature Settings.
Period Time Heat Setpoint Cool Setpoint
Wake 6:00 AM 70°F (21°C) 78°F (26°C)
Leave 8:00 AM 62°F (17°C) 85°F (29°C)
Return 6:00 PM 70°F (21°C) 78°F (27°C)
Sleep 10:00PM 62°F (17°C) 82°F (28°C)
CHECKOUT
CAUTION
Damage To Compressor Possible.
Operating at too low of an outdoor temperature
may cause compressor damage.
Do not operate cooling if outdoor temperature is
below 50°F (10°C).
Allow compressor to remain off for five minutes
before restarting.
Refer to manufacturer’s recommendations.
Heating
1. Slide the SYSTEM switch to Heat and the FAN
switch to Auto.
2. Press and hold the ▲key to raise the temperature
setting several degrees above the room tempera-
ture; the heating equipment should start.
3. Press the ▼key to lower the temperature setting
below the room temperature. Heating equipment
should stop.
Cooling
1. Slide the SYSTEM switch to Cool and the FAN
switch to Auto.
2. Press the ▼key to lower the temperature setting
several degrees below the room temperature; the
cooling equipment and fan should start.
NOTE: If unit doesn’t start immediately, remember,
the thermostat has a built-in minimum
off-time of five minutes to protect the
compressor.
3. Press the ▲key to raise the temperature setting
above the room temperature. Cooling system should
shut down.
Fan
1. Slide the SYSTEM switch to Off and the FAN switch
to On. The fan should run continuously.
2. Slide the FAN switch to Auto. The system turns the
fan on or off with the equipment.
Make certain all equipment responds correctly to the
thermostat.
Honeywell Limited-Honeywell Limitée
35 Dynamic Drive
Scarborough, Ontario
M1V 4Z9
Automation and Control Solutions
Honeywell
1985 Douglas Drive North
Golden Valley, MN 55422
www.honeywell.com/yourhome
M12592
A
SET
PM
M12591
A
SET
PM
M12593
A
M12594
A
