Hoover Power Wash 1700W Car User manual
Version 1.0
Power
Wash
1700W
Car
User Guide
Pressure Washer
HPW1C-ME
2
1
Contents
Machine Overview
General Safety Information
Operation
Maintenance
FAQs
Other Information
CONTENTS MACHINE OVERVIEW
2
1
8765
9
11
10
Unit
Accessories
Handle
Lance Storage
On/Off Switch
Trigger Handle Storage
Water Outlet
Pressure hose and
power cable storage hook
Nozzle Storage
Detergent Application Bottle
Storage
Water Inlet and Connector
Wheel
Pressure Hose
Trigger Handle
Lance
Car Brush
Jet Nozzle (pink nib)
Turbo Nozzle
Detergent Application Bottle
Nozzle Cleaning Tool
1
1
2
3
4
5
9
2
10
3
11
4
12
5
13
15
6
14
16
17
18
7
8
11
15
12
16
13
17
14
18
6
7
8
9
10
43
3 4
GENERAL SAFETY INFORMATION
FOR HOUSEHOLD USE ONLY.
This pressure washer is intended for household use only and NOT for commercial or industrial use.
1. This Pressure washer is for outdoor use only.
2. It is your responsibility to check the suitability of the surface to be cleaned. Hoover cannot be held
responsible for damage caused.
3. Keep fingers, hair and loose clothing from moving parts and openings whilst using the
pressure washer.
4. When using your pressure washer the recommended working distance between the nozzle
and surface area or object to be cleaned is 30cm.
5. This appliance can only be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children should not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
6. Only recommend the use of genuine accessories and solution to be used with this pressure washer
The use of non-branded accessories and solution will invalidate your warranty.
7. Don’t leave the pressure washer unattended or running when not in use for more than 5 minutes
without depressing the trigger.
8. Don’t use this pressure washer if it has been dropped, damaged or immersed in water.
9. Don’t use pressure washer if the power cord or plug is damaged.
10. Don’t handle the plug of the pressure washer with wet hands.
11. Don’t use the pressure washer without supply hose (minimum length 7.5m) in place and unwind the
hose fully from reel.
12.Don’t use the pressure washer without the water filter in place.
13. Don’t pull or carry this pressure washer by the power cord. Don’t use the power cord as a handle,
pull the power cord around corners or sharp edges or close a door over the power cord.
Don’t unplug pressure washer by pulling on the power cord.
14. Don’t aim the pressure washer at people, animals, plants, electrical components, wires, or the
pressure washer itself.
15. Don’t use the pressure washer on electrical components, damaged/delicate paint surfaces, tyres,
engines/motors.
16. Don’t use the pressure washer with incorrect voltage as this may result in damage or injury to the
user. The correct voltage is listed on the rating label.
17. Always wear suitable clothing footwear and eye protection whilst using the pressure washer.
18. Always connect the water supply, remove the lance and squeeze the trigger to run water through the
machine before switching the power on.
19. Always use a suitable hose connector to match the coupling on the pressure washer with a non-return
valve at tap end of the supply hose.
20. Always unplug the pressure washer before cleaning or carrying out any maintenance.
21. Always turn off and unplug the pressure washer before disconnecting or connecting the hose,
after use always wrap the pressure hose and power cord around the storage clips provided.
22. Always release any built up pressure in the handle prior to disconnecting the hose and ensure water
inlet filter is clean prior to storage in a cool dry place.
23. Use only CE approved 13amp extension cords with RCD, non-approved extension cords may
overheat. Care should be taken to arrange the extension cord as it could be a trip hazard.
24. Always make sure the power/extension cord is fully unwound and prevent the power/extension cord
from getting wet during use.
25. Always replace the fuse in the plug with a 13amp fuse. Always protect the power cable from heated
surfaces or near open flames.
26. Always carry the pressure washer by the handle.
27. Always check water hose and accessories are not damaged, broken or worn before use.
28. Type Y Attachment - Damaged supply cords to be replaced by the manufacturer, service agent
or similarly qualified person to avoid hazard
29. The electric supply connection shall be made by a qualified electrician and comply with
IEC 60364-1
30. Do not direct the jet against yourself or others in order to clean clothes or footwear
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
GENERAL SAFETY INFORMATION
OPERATION 65
Make sure water supply is
not connected. Firmly push
the water hose pipe with
suitable connector onto the
water inlet to lock
into position.
Connect water hose pipe
to a suitable water supply
and turn water on.
Before plugging the
machine in, press the
unlock safety button on
the trigger handle and
squeeze the trigger until
water starts to flow through
the nozzle.
IMPORTANT: Always use an RCD (Residual Current Device) adaptor when using this pressure washer.
WARNING: Don’t leave the pressure washer running when not in use, or more than 5 minutes to prevent overheating.
Before switching the machine on, the trigger handle must be squeezed to release water and to remove any airlocks
in the machine or pressure hose. Always release any build up pressure in the handle prior to disconnecting the hose.
Connect the power cord
to the mains supply via
an RCD adaptor.
Push the ‘I’ switch to turn
on. The machine will run
for a few seconds then
stop but no water will
be released.
Squeeze the trigger
on the trigger handle
to release a high
pressured water jet,
and start cleaning.
WARNING:
Don’t aim the pressure washer
directly at people, animals, plants,
electrical components, wires or the
pressure washer itself.
Push ‘O’ switch to turn off.
OPERATION
Attach both wheels
and push until they
click into place.
Attach the hose connector
to water inlet by turning
clockwise until tight.
Assembling your pressure washer
Preparing your pressure washer for use
Always make sure the pressure washer and water supply is off before connecting or disconnecting the hose and accessories.
Push the pressure hose firmly
to the water outlet and turn the
pressure hose collar clockwise
until tight.
Whilst firmly pushing the lance
into the trigger handle turn
clockwise to lock into position.
A trigger safety lock is located
underneath the handle. The safety
lock should always be in LOCKED
position before connecting/
disconnecting the pressure hose
to the trigger handle.
To remove the lance from the trigger
handle firmly push and twist the lance
anti-clockwise. When unlocked pull
to remove.
To connect pressure hose to trigger
handle, press the pressure hose
release button and push pressure
hose to lock into position.
Gently pull the pressure hose
to check the connection.
IMPORTANT: Always make sure the trigger safety lock is in the LOCKED position when not in use or connecting
/disconnecting the pressure hose.
Always check water hose, pressure hose, lance and accessories are not damaged broken or worn before use.
After connecting pressure hose, lance and accessories check they are securely fitted and locked in place before
turning on.
Please read General Safety Information at the beginning before use.
LOCKED
UNLOCKED
Fill the detergent application
bottle with the diluted detergent
mix. Turn the lid clockwise
to lock.
Push the detergent application
bottle onto the lance fitted with
jet nozzle until you hear an
audible CLICK. Release the
button and gently pull the
turbo nozzle to make sure it
is locked securely before use.
87 OPERATION
Using solution with your pressure washer
IMPORTANT: When using solution make sure you follow the dilution instructions and use Hoover solution only.
Solution can only be used with the trigger handle, lance and solution nozzle, or car/outdoor/rotary brush if supplied.
Solution CANNOT be used with the jet and turbo nozzles.
WARNING:
Always make sure the pressure washer is switched OFF before connecting/disconnecting the pressure hose,
lance, accessories or solution bag.
OPERATION
Attach the car brush to the
trigger handle. Firmly push
the car brush and trigger handle
together, turn clockwise to lock
into position.
Switch on the pressure
washer and squeeze the
trigger to release water spray
or water and detergent mix.
To remove the brush from the
trigger handle firmly push and
twist the lance anti-clockwise
to unlock. Pull to remove.
Using the car brush
(included in selected models only, see ‘Included with your machine’)
Switch the pressure washer
on and squeeze trigger
to dispense the water
and detergent mix.
WARNING:
Never use the turbo nozzle on cars, tyres and engines.
To attach the jet/solution
nozzle. Fit the lance with
a firm push and twist
clockwise to lock into place.
To attach the turbo nozzle,
fit the lance with a firm
push and twist clockwise
to lock into place.
Using your accessories The jet nozzle has a wider spray and isideal for use on surfaces areas such as cars,
garden furniture, decking and boats.
The turbo nozzle has a more concentrated spray and is ideal for use on very dirty surfaces, patios or masonry.
As it is not fitted with a pressure regulator it is not suitable for use on delicate or painted surfaces.
Hold down the release button on the
lance, push the jet nozzle and lance firmly
together until you hear an audible CLICK.
Release the button and gently pull the jet
nozzle to make sure it is locked securely
before use.
Hold down the release button on the lance,
push the turbo nozzle and lance firmly together
until you hear an audible CLICK. Release the
button and gently pull the turbo nozzle to make
sure it is locked secure before use.
Squeeze the trigger on the
trigger handle to release
a high pressured water jet,
and start cleaning.
Squeeze the trigger on the trigger
handle to release a high pressured
water jet, and start cleaning.
IMPORTANT: Always make sure the machine is switched off and the safety button on the trigger handle is LOCKED
before connecting/disconnecting the lance, nozzle or accessories.
109MAINTENANCE
Is there an accessory missing?
• Check the ‘This pack contains’ panel on the box to make sure the part is included with your machine.
Why won’t my pressure washer turn on?
• Make sure the on/off switch is set to the ‘I’ position.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with a 13amp fuse.
• Check if your RCD has been tripped, if it has tripped, reset it.
• The power cord maybe damaged.
Why won’t the water/solution dispense?
• The pump may have stopped, make sure the on/off switch is set to the ‘I’ position and check
the plug fuse.
• The pump may have stopped. This may be because of overheating due to poor water supply.
Check the water flow rate to your water supply.
• Hose may be blocked or kinked, check for leaks in the hose and clear any blockages.
Straighten out the hose to ensure no kinks and check the hose pipe connections to the tap and
water inlet.
• There may be an air lock. To unlock the trigger safety lock, squeeze the trigger to release water
before the machine is switched on.
• Check assembly of solution application bottle Go to the ‘Operation’ pages. Nozzle/accessory
may be blocked, clear any blockages and clean nozzle Go to the ‘Maintenance’ page.
Why won’t my pressure washer reach operating pressure?
• Hose may be blocked or kinked, check for leaks in the hose and clear any blockages.
Straighten out the hose to ensure no kinks and check the hose pipe connections to the tap
and water inlet.
• Nozzle may be blocked, clear any blockages and clean nozzle.
Go to the ‘Maintenance’ page.
• Remove and clean the water inlet filter Go to the ‘Maintenance’ page.
• Check the water flow rate to your water supply.
FAQs
To access water filter
unscrew water inlet
connector and remove.
Always store tools, power cord and pressure hose into allocated storage slots.
Storage
To remove water filter,
pinch the inner water filter
tab with pliers and gently pull.
Water filter can be
rinsed under running
water periodically.
IMPORTANT: Always rinse fresh water through your pressure washer and accessories for 1 minute after using solution
to prevent blockages.
IMPORTANT: Before storing your machine always make sure no water remains in the pressure washer or hose
/accessories to prevent frost damage.
Keep in a dry place above zero degrees and out of the reach of children.
Removing a blockage in the lance and nozzles
To remove the lance from
trigger handle firmly push
and twist the lance
anti-clockwise, when
unlocked pull to remove.
To remove the nozzles press the
nozzle release button and pull.
Insert the nozzle cleaning
tool into the end of lance
and nozzles to remove
any dirt or debris.
WARNING: Before carrying out any maintenance makesure the machine is switched off and unplugged.
11 11
OTHER INFORMATION
Service & Help
If you have queries or concerns about using your Hoover Pressure Washer, please visit www.hoover.ae
Technical Specification
Name: Pressure Washer
Wattage: 1700w
Voltage: 220-240V~50-60Hz
Max Pressure: 130 bar (13,000,000 pascals)
Working Pressure: 90 bar (9,000,000 pascals)
Flow Rate: 6L/min
Subject to technical change without notice.
EEC Statement of Compliance
Manufacturer/EEC importer: Hoover, hereby on our own responsibility, declare that the
HPW series is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
The new hose-sets supplied with the appliance are to be used and the old hose-sets should not
be re-used to connect to the water mains
www.hoover.ae Hoover
:
1700 :
60-50 240-220 :
130 :
90 :
6
.
Hoover : /
: HPW
2006/95/EC :
2004/108/EC :
.
. .
10 9
. " " •
."I" / •
. •
. 13 •
. (RCD) •
. •
/
. "I" / •
. . •
.
. •
.
. . •
/ ."" •
.""
. •
.
."" . •
."" •
. •
8
.
.
.
.
. :
. / :
.
.
.
.
. :
.
.
.
.
7
.Hoover :
.
//
.
:
/
.
.
.
.
. .
)" " )
.
6
:
.
./
.
.
.
.
.
.""
.
.""
.
.
.
/"" :
.
5
.
.
.
.
. )RCD( :
. 5 :
.
.
.)RCD(
"I"
.
.
.
:
.
"O"
.
3
.
.
1.
2.. Hoover .
3.
4.. 30
5. 8
. .
.
6. .
.
7.. 5
8.
9.
10.
11.. (7.5 )
12.
13. .
. .
14.
.
15../ /
16. .
.
17.
18.
19.
.
20.
21.
.
22.
.
23. (RCD) 13
. .
24. / /
25. . 13
.
26.
27.
28Y
29
30
.
4
.
.
.
.
.
.
""
.
..
.
.
. / "" :
.
.
.
LOCKED
UNLOCKED
1
2
1
3
7 6 5 4
8
10
9
2
/
( )
1
9
2
10
3
11
4
12
5
13
15
6
14
16
17
18
7
8
6
7
8
9
10
11
15
12
16
13
17
14
18
1
2
3
4
5
1.0
Power
Wash
1700W
Car
HPW1C-ME
Table of contents
Languages:
Other Hoover Pressure Washer manuals
