Hoover HPW2C-ZA User manual

Version 1.0
Power
Wash
2000W
Car
User Guide
HPW2C-ZA
hoover.za.com

32
Contents
Machine Overview
General Safety Information
Operation
Maintenance
FAQs
Warranty
Other Information
Notes
3
4
8765
9
11
10
Unit
Accessories
Handle
Trigger Handle Storage
Wheel
Water Outlet
On/Off Switch
Power Cord and Pressure
Hose Storage Hook
Water Inlet and
Connector (already
installed)
Solution Intake Tube
Pressure Hose
Trigger Handle
Lance
Car Brush
Jet Nozzle (pink nib)
Turbo Nozzle
Solution Nozzle (white
nib)
Nozzle Cleaning Tool
1
9
2
10
3
11
4
12
5
13
15
6
14
16
7
8
1
7
2
8
3
4
9
13
10
14
11
15
12
16
5
6
MACHINE OVERVIEW
CONTENTS
2
12
13

4 5
FOR HOUSEHOLD USE ONLY.
This pressure washer is intended for household use only and NOT for commercial or industrial use.
1. This Pressure washer is for outdoor use only.
2. It is your responsibility to check the suitability of the surface to be cleaned. Hoover cannot be held
responsible for damage caused.
3. Keep fingers, hair and loose clothing from moving parts and openings whilst using the pressure washer.
4. When using your pressure washer the recommended working distance between the nozzle and surface
area or object to be cleaned is 30cm.
5. This appliance can only be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
6. Only recommend the use of genuine accessories and solution to be used with this pressure washer. The
use of non-branded accessories and solution will invalidate your warranty.
7. Don’t leave the pressure washer unattended or running when not in use for more than 5 minutes without
depressing the trigger.
8. Don’t use this pressure washer if it has been dropped, damaged or immersed in water.
9. Don’t use pressure washer if the power cord or plug is damaged.
10. Don’t handle the plug of the pressure washer with wet hands.
11. Don’t use the pressure washer without supply hose (minimum length 7.5m) in place and unwind the
hose fully from reel.
12. Don’t use the pressure washer without the water filter in place.
13. Don’t pull or carry this pressure washer by the power cord. Don’t use the power cord as a handle, pull
the power cord around corners or sharp edges or close a door over the power cord. Don’t unplug pressure
washer by pulling on the power cord.
14. Don’t aim the pressure washer at people, animals, plants, electrical components, wires, or the pressure
washer itself.
15. Don’t use the pressure washer on electrical components, damaged/delicate paint surfaces, tyres,
engines/motors.
16. Don’t use the pressure washer with incorrect voltage as this may result in damage or injury to the user.
The correct voltage is listed on the rating label.
17. Always wear suitable clothing footwear and eye protection whilst using the pressure washer.
18. Always connect the water supply, remove the lance and squeeze the trigger to run water through the
machine before switching the power on.
19. Always use a suitable hose connector to match the coupling on the pressure washer with a non-return
valve at tap end of the supply hose.
20. Always unplug the pressure washer before cleaning or carrying out any maintenance.
21. Always turn off and unplug the pressure washer before disconnecting or connecting the hose, after use
always wrap the pressure hose and power cord around the storage clips provided.
22. Always release any built up pressure in the handle prior to disconnecting the hose and ensure water
inlet filter is clean prior to storage in a cool dry place.
23. Use only CE approved 13amp extension cords with RCD, non-approved extension cords may
overheat. Care should be taken to arrange the extension cord as it could be a trip hazard.
24. Always make sure the power/extension cord is fully unwound and prevent the power/extension cord
from getting wet during use.
25. Always replace the fuse in the plug with a 13amp fuse. Always protect the power cable from heated
surfaces or near open flames.
26. Always carry the pressure washer by the handle.
27. Always check water hose and accessories are not damaged, broken or worn before use.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
Attach both wheels
and push until they
click into place.
Attach the hose connector
to water inlet by turning
clockwise until tight.
Slot the handle in to the
top of the machine and
insert the 2 screws, turn
clockwise to tighten.
Align the pressure hose and
cord storage hook onto the
back of the machine and
secure with 2 screws.
Assembling your pressure washer
Preparing your pressure washer for use
Always make sure the pressure washer and water supply is off before connecting or disconnecting the hose and
accessories.
Push the pressure hose firmly
to the water outlet and turn
the pressure hose collar
clockwise until tight.
Whilst firmly pushing the lance
into the trigger handle turn
clockwise to lock into position.
A trigger safety lock is located
underneath the handle. The safety lock
should always be in LOCKED position
before connecting/disconnecting the
pressure hose to the trigger handle.
To remove the lance from the trigger
handle firmly push and twist the lance
anti-clockwise. When unlocked pull to
remove.
To connect pressure hose to trigger
handle, press the pressure hose release
button and push pressure hose to lock
into position. Gently pull the pressure
hose to check the connection.
TIP: After connecting pressure
hose, lance and accessories
check they are securely fitted and
lock in place before turning on.
IMPORTANT: Always make sure the trigger safety lock is in the LOCKED position when not in use or
connecting/disconnecting the pressure hose.
Always check water hose, pressure hose, lance and accessories are not damaged broken or worn before use.
Please read General Safety Information at the beginning before use.
LOCKED
UNLOCKED
OPERATION
GENERAL SAFETY INFORMATION

7
6
Make sure water supply
is not connected. Firmly
push the water hose
pipe with suitable
connector onto the water
inlet to lock into position.
Connect water hose pipe
to a suitable water supply
and turn water on.
Before plugging the
machine in, press the
unlock safety button on
the trigger handle and
squeeze the trigger
until water starts to flow
through the nozzle.
IMPORTANT: Always use an RCD (Residual Current Device) adaptor when using this pressure washer.
WARNING: Don’t leave the pressure washer running when not in use, or more than 5 minutes to prevent overheating.
Before switching the machine on, the trigger handle must be squeezed to release water and to remove any airlocks in
the machine or pressure hose. Always release any build up pressure in the handle prior to disconnecting the hose.
Connect the power
cord to the mains
supply via an
RCD adaptor.
Push the ‘I’ switch to
turn on. The machine
will run for a few
seconds then stop
but no water will be
released.
Squeeze the trigger on
the trigger handle to
release a high pressured
water jet, and start
cleaning.
WARNING:
Don’t aim the pressure washer di-
rectly at people, animals, plants,
electrical components, wires or
the pressure washer itself.
Push ‘O’ switch to
turn off.
WARNING:
Never use the turbo nozzle on
cars, tyres and engines.
To attach the jet/solution
nozzle. Fit the lance
with a firm push and twist
clockwise to lock into
place.
The jet nozzle has a wider spray and is ideal for use on surfaces areas such
as cars, garden furniture, decking and boats.
To attach the turbo
nozzle, fit the lance with
a firm push and twist
clockwise to lock into
place.
Using your accessories
The turbo nozzle has a more concentrated spray and is ideal for use on very dirty surfaces, patios or masonry.
As it is not fitted with a pressure regulator it is not suitable for use on delicate or painted surfaces.
Hold down the release button on the
lance, push the jet nozzle and lance
firmly together until you hear an audible
CLICK. Release the button and gently pull
the jet nozzle to make sure it is locked
securely before use.
Hold down the release button on the lance,
push the turbo nozzle and lance firmly together
until you hear an audible CLICK. Release
the button and gently pull the turbo nozzle to
make sure it is locked secure before use.
Squeeze the trigger on the
trigger handle to release a
high pressured water jet,
and start cleaning.
Squeeze the trigger on the trigger
handle to release a high pressured
water jet, and start cleaning.
IMPORTANT: Always make sure the machine is switched off and the safety button on the trigger handle is
LOCKED before connecting/disconnecting the lance, nozzle or accessories.
OPERATION
OPERATION

98
Unhook the solution tube and
insert into the solution bag.
Solution only dispensed with
the trigger handle, lance and
solution nozzle, or car/out-
door/rotary brush if supplied.
Switch the machine on
and squeeze trigger
to dispense the water
and solution mix.
After use rinse the pressure
washer to prevent blockages.
Inset the solution tube into a
bucket of fresh water (Max
40 C), turn the machine on and
squeeze the trigger for 1 minute.
Using solution with your pressure washer
IMPORTANT: When using solution make sure you follow the dilution instructions and use Hoover solution only.
Solution can only be used with the trigger handle, lance and solution nozzle, or car/outdoor/rotary brush if supplied.
Solution CANNOT be used with the jet and turbo nozzles.
WARNING:
Always make sure the pressure washer is switched OFF before
connecting/disconnecting the pressure hose, lance, accessories or solution
bag.
To access water filter
unscrew water inlet
connector and remove.
Always store tools, power cord and pressure hose into allocated storage slots.
STORAGE
To remove water filter, pinch
the inner water filter tab
with pliers and gently pull.
Water filter can be rinsed
under running water
periodically.
IMPORTANT: Always rinse fresh water through your pressure washer and accessories for 1 minute after using
solution to prevent blockages.
IMPORTANT: Before storing your machine always make sure no water remains in the pressure washer or hose/
accessories to prevent frost damage. Keep in a dry place above zero degrees and out of the reach of children.
Removing a blockage in the lance and nozzles
To remove the lance from
trigger handle firmly push
and twist the lance anti-
clockwise, when unlocked
pull to remove.
To remove the nozzles press the
nozzle release button and pull.
Insert the nozzle cleaning
tool into the end of lance
and nozzles to remove
any dirt or debris.
WARNING: Before carrying out any maintenance
make sure the machine is switched off and unplugged.
Attach the car brush to the
trigger handle. Firmly push
the car brush and trigger
handle together, turn clock-
wise to lock into position.
Switch on the pressure washer
and squeeze the trigger to
release water spray or water
and detergent mix.
To remove the brush from the
trigger handle firmly push and
twist the lance anti-clockwise
to unlock. Pull to remove.
Using the car brush (included in selected models only, see ‘Included with
your machine’)
IMPORTANT: When using your pressure washer the recommended working distance between the nozzle and
surface area or object to be cleaned is 30cm.
IMPORTANT: After connecting the pressure hose, lance and accessories check they are securely fitted and locked
in place before switching on.
IMPORTANT: Always release any pressure build up in the handle prior to disconnecting the hose and accessories .
IMPORTANT: Don’t use if the lance and accessories are damaged, broken or worn.
IMPORTANT: Always check brushes are clean and free from grit/hard debris before use.
MAINTENANCE
OPERATION

Is there an accessory missing?
• Check the ‘This pack contains’ panel on the box to make sure the part is included with your machine.
Why won’,’t my pressure washer turn on?
• Make sure the on/off switch is set to the ‘I’ position.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with a 13amp fuse.
• Check if your RCD has been tripped, if it has tripped, reset it.
• The power cord maybe damaged.
Why won’,’t the water/solution dispense?
• The pump may have stopped, make sure the on/off switch is set to the ‘I’ position and check the plug
fuse.
• The pump may have stopped. This may be because of overheating due to poor water supply. Check the
water flow rate to your water supply.
• Hose may be blocked or kinked, check for leaks in the hose and clear any blockages. Straighten out the
hose to ensure no kinks and check the hose pipe connections to the tap and water inlet.
• There may be an air lock. To unlock the trigger safety lock, squeeze the trigger to release water before
the machine is switched on.
• Check assembly of solution application bottle Go to the ‘Operation’ pages. Nozzle/accessory may be
blocked, clear any blockages and clean nozzle Go to the ‘Maintenance’ page.
Why won’,’t my pressure washer reach operating pressure?
• Hose may be blocked or kinked, check for leaks in the hose and clear any blockages. Straighten out the
hose to ensure no kinks and check the hose pipe connections to the tap and water inlet.
• Nozzle may be blocked, clear any blockages and clean nozzle.
Go to the ‘Maintenance’ page.
• Remove and clean the water inlet filter Go to the ‘Maintenance’ page.
• Check the water flow rate to your water supply.
10 11
WARRANTY
FAQs
Please affix proof of purchase/receipt here
In the event of a claim under warranty this receipt must be produced.
WARRANTY
1. Home of Living Brands (Pty) Limited warrants to the original purchaser of this product (“the
customer”) that this product will be free of defects in quality and workmanship which under normal
personal, family or household use and purpose may manifest within a period of 1 (one) year from
the date of purchase )”warranty period”).
2. Where the customer has purchased a product and it breaks, is defective or does not work
properly for the intended purpose, the customer must notify the supplier from whom the customer
bought the product (“the supplier”) thereof within the warranty period. Any claim in terms of this
warranty must be supported by a proof of purchase. If proof of purchase is not available, then
repair, and/or service charges may be payable by the customer to the supplier.
3. The faulty product must be taken to the supplier’s service centre to exercise the warranty.
4. The supplier will refund, repair, or exchange the product in terms of this warranty subject to
legislative requirements. This warranty shall be valid only where the customer has not broken
the product himself, or used the product for something that it is not supposed to be used for. The
warranty does not include and will not be construed to cover products damaged as a result of
disaster, misuse, tamper, abuse or any unauthorised modification or repair of the product.
5. This warrant will extend only to the product provided at the date of the purchase and not to any
expendables attached or installed by the customer.
6. If the customer requests that the supplier repairs the product and the product breaks or fails
to work properly within 3 (three) months of the repair and not as a result of misuse, tampering or
modification by or on behalf of the customer, then the supplier may replace the product or pay a
refund to the customer.
7. The customer may be responsible for certain costs where the products returned are not in the
original packaging, or if the packaging is damaged. This will be deducted from any refund paid
to the customer.
HOME OF LIVING BRANDS (PTY) LTD (JOHANNESBURG)
JOHANNESBURG
CAPE TOWN
DURBAN
TEL NO. [phone]
TEL NO. [phone]
TEL NO. [phone]
www.hoover.za.com

Service & Help
If you have queries or concerns about using your Hoover Pressure Washer, please visit hoover.za.com
Technical Specification
Name: Pressure Washer
Wattage: 2000w
Voltage: 220-240~50Hz
Max Pressure: 140 bar
Working Pressure: 100 bar
Flow Rate: 430L/Hr
Subject to technical change without notice.
Consumables
For information on spares and accessories, please visit hoover.za.com
The use of genuine Hoover spare parts helps to maintain optimised performance
and validates your guarantee.
EEC Statement of Compliance
Manufacturer/EEC importer: Hoover, hereby on our own responsibility, declare that the
HPW series is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
The new hose-sets supplied with the appliance are to be used and the old hose-sets should not be
re-used to connect to the water mains
12 13
NOTES
OTHER INFORMATION

15
NOTES
14 NOTES

HPW2C-ZA
hoover.za.com
