Landa PGHW4-3000 User manual

PRESSURE WASHERS
®
OPERATOR’S MANUAL
LANDA, INC. ■ 4275 N.W. Pacific Rim Blvd. ■ Camas, WA 98607 ■ USA
For technical assistance or the Landa Dealer nearest you, call 800-LANDA-4-U (800-526-3248) or [phone]
or consult our web page at www.landa.com
■PGHW4-3000 ■PGHW4-4000
■■
■■
■PGHW5-3000 ■■
■■
■PGHW5-3500
PGHW

Model Number ______________________________
Serial Number ______________________________
Date of Purchase ____________________________
The model and serial numbers will be found on a decal attached to
the pressure washer. You should record both serial number and
date of purchase and keep in a safe place for future reference.
CONTENTS
3
PGHW Manual •Form #96-6031 •Revised 7/03
Introduction ................................................................................................................................... 4
Important Safety Information ..................................................................................................... 4, 6
Component Identification .............................................................................................................. 5
Pre-Operation Check .................................................................................................................... 6
Set-Up Procedures ....................................................................................................................6-7
Operating Instructions ................................................................................................................... 7
General Washing Techniques ........................................................................................................ 7
Shut Down Procedures ................................................................................................................. 7
How To Use The Detergent Injector .............................................................................................. 8
Preventative Maintenance ............................................................................................................. 9
Maintenance and Service ........................................................................................................ 9-11
Exploded View, Left Side............................................................................................................. 12
Exploded View, Right Side .......................................................................................................... 13
Parts List................................................................................................................................ 14-16
Float Tank Assembly, Exploded View and Parts List ................................................................... 17
Control Panel, Exploded View ..................................................................................................... 18
Control Panel, Parts List ............................................................................................................. 19
Hose and Spray Gun Assembly .................................................................................................. 20
Burner Specifications .................................................................................................................. 21
Pump/Engine Specifications ..................................................................................................22-23
Troubleshooting ..................................................................................................................... 24-27
Oil Change Record ..................................................................................................................... 28
Maintenance Chart ..................................................................................................................... 28
Warranty ..................................................................................................................................... 29

4 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
INTRODUCTION
Thank you for purchasing a Landa Pressure Washer.
This manual covers the operation and main-
tenance of the PGHW4-3000E, PGHW4-4000E,
PGHW5-3000E and PGHW5-3500E washers. All infor-
mation in this manual is based on the latest product in-
formation available at the time of printing.
Landa, Inc. reserves the right to make changes at any
time without incurring any obligation.
The PGHW Series was designed for maximum
use of 8 hours per day, 5 days per week.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this Landa pressure washer.Warning infor-
mation should be emphasized and understood. If the op-
erator is not fluent in English, the manufacturer’s instruc-
tions and warnings shall be read to and discussed with
the operator in the operator’s native language by the
purchaser/owner, making sure that the operator com-
prehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number.
IMPORTANT SAFETY
INFORMATION
WARNING: When using this product basic precau-
tions should always be followed, including the fol-
lowing:
CAUTION: To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Read the owner’s manual thor-
oughly. Failure to follow instruc-
tions could cause a malfunction
of the machine and result in
death, serious bodily injury and/
or property damage.
2. Know how to stop the machine and bleed pressures
quickly. Be thoroughly familiar with the controls.
3. Stay alert — watch what you are doing.
4. All installations must comply with local codes. Con-
tact your electrician, plumber, utility company or the
selling distributor for specific details.
WARNING: Risk of asphyxiation.
Use this product only in a well
ventilated area.
5. Avoid installing machines in
small areas or near exhaust
fans. Exhaust contains poison-
ous carbon monoxide gas; ex-
posure may cause loss of con-
sciousness and may lead to
death. It also contains chemi-
cals known in certain quantities, to cause cancer,
birth defects, or other reproductive harm.
WARNING: Flammable liquids can
create fumes which can ignite,
causing property damage or se-
vere injury.
CAUTION: Risk of fire. Do not add
fuel when the product is operat-
ing.
6. Allow engine to cool for 2 min-
utes before refueling. If any fuel
is spilled, make sure the area is dry before testing
the spark plug or starting the engine. (Fire and/or
explosion may occur if this is not done.)
Gasoline engines on mobile or portable equipment
shall be refueled:
(a) outdoors;
(b) with the engine on the equipment stopped;
(c ) with no source of ignition, within 10 feet of the
dispensing point; and
(d ) with an allowance made for expansion of the fuel
should the equipment be exposed to a higher
ambient temperature.
In an overfilling situation, additional precautions are
necessary to ensure that the situation is handled in
an safe manner.
WARNING: Risk of explosion –do not spray flam-
mable liquids.
7. Do not place machine near flammable objects as
the engine is hot.
WARNING: Risk of injection or se-
vere injury to persons - Keep clear
of nozzle - Do not touch or direct
discharge stream at persons.This
machine is to be used only by
trained operators.
RISK OF EXPLOSION:
DO NOT USE WITH
FLAMMABLE
LIQUIDS.
WARNING
WARNING
RISK OF
ASPHYXIATION.
USE THIS PRODUCT
ONLY IN A WELL
VENTILATED AREA.
WARNING
HIGH PRESSURE
STREAM CAN
PIERCE SKIN AND
TISSUES.
WARNING
READ OPERATOR’S
MANUAL
THOROUGHLY
PRIOR TO USE.
CAUTION

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
5
LANDA PGHW •96-6031 • REV. 7/03
COMPONENT IDENTIFICATION
Battery Box
(battery not
included)
Detergent
Pick Up Tube
Water Supply
Hose (not
included)
Detergent
Bucket (not
included)
High
Pressure
Hose
Fuel Oil
Tank
Variable
Pressure
Control
Wand Handle
Variable Pressure
Control Wand
Nozzle
Quick
Coupler
Steam
Valve
Engine
Switch
Hour
Meter
Spray
Gun
Nozzle
Quick
Coupler
Collar
Swivel
Connector
Discharge
Nipple
Rupture
Disk
Gasoline
Tank
Pressure
Nozzles
Detergent
Valve
Burner
Switch
Trigger

6 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
CAUTION: Hot discharge fluid. Do not touch or di-
rect discharge stream at persons.
8. High pressure developed by these machines will
cause personal injury or equipment damage. Use
caution when operating. Do not direct discharge
stream at people, or severe injury or death will re-
sult.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne and
fly at high speeds.
9. Eye safety devices, safety
clothing and foot protection
must be worn when using this
equipment.
10. Never make adjustments on
machine while it is in operation.
WARNING: Spray gun kicks back. Hold with both
hands.
11. Grip cleaning wand securely with both hands before
starting the cleaner. Failure to do this could result in
injury from a whipping wand.
12. Machines with spray gun should not be operated with
the spray gun in the off position for extensive peri-
ods of time as this may cause damage to the pump.
13. The best insurance against an accident is precau-
tion and knowledge of the machine.
14. Landa will not be liable for any changes made to our
standard machines, or any components not pur-
chased from Landa.
WARNING: Keep wand, hose and
water spray away from electric
wiring or fatal electric shock may
result.
15. Read engine safety instructions
provided.
16. Never run pump dry or leave
spray gun closed longer than 5
minutes.
17. Inlet water must be cold and clean fresh water.
18. Use No. 1 or No. 2 Heating Oil (ASTM D306) only.
NEVER use gasoline in your fuel oil tank. Gasoline
is more combustible than fuel oil and could result in
a serious explosion. NEVER use crankcase or waste
oil in your burner. Fuel unit malfunction could result
from contamination.
19. Do not confuse gasoline and fuel oil tanks. Keep
proper fuel in proper tank.
20. Protect machine from freezing.
21. Be certain all quick coupler fittings are secured be-
fore using pressure washer.
22. Do not allow acids, caustic, or abrasive fluids to pass
through the pump.
23. To reduce the risk of injury, close supervision is nec-
essary when a product is used near children. Do not
allow children to operate the pressure washer. This
machine must be attended during operation.
24. Do not operate this product when fatigued or under
the influence of alcohol or drugs. Keep operating area
clear of all persons.
25. Protect discharge hose from vehicle traffic and sharp
objects. Inspect condition of high pressure hose be-
fore using or bodily injury may result.
26. Before disconnecting discharge hose from water out-
let, turn burner off and open spray gun to allow wa-
ter to cool below 100°F before stopping the machine.
Then open the spray gun to relieve pressure. Failure
to properly cool down or maintain the heating coil
may result in a steam explosion.
27. Landa will not be liable for any changes made to our
standard machines or any components not pur-
chased from Landa.
28. Do not overreach or stand on unstable support. Keep
good footing and balance at all times.
29. This machine must be attended during operation.
30. CAUTION: Risk of injury. Disconnect battery
ground terminal before servicing.
PRE-OPERATION CHECK
❑Pump oil (SAE 30W non-detergent oil, General)
❑Cold water supply (6 gpm • 58" • 20 psi)
❑Hose, wand, nozzle (nozzle size per serial plate)
❑Water filter (intact, non restrictive)
❑Engine fuel (unleaded 86 or higher octane)
❑Engine oil (SAE 10W30)
❑Burner fuel (No. 1 home heating fuel or diesel)
SET-UP PROCEDURES
This machine is intended for outdoor use only.
Machine must be stored indoors when not in use.
1. Attach a 5/8" water supply hose to inlet connector.
Minimum flow should be 6 or 10 gpm depending on
model of machine.
2. Attach high pressure hose to discharge nipple using
quick coupler. Lock coupler securely into place by
pulling back coupler collar and inserting it into dis-
charge nipple, then pushing collar forward to lock in
place.
3. Attach variable pressure control wand to spray gun
using teflon tape on threads to prevent leakage.
WARNING
USE PROTECTIVE
EYE WEAR
AND CLOTHING
WHEN OPERATING
THIS EQUIPMENT.
WARNING
KEEP WATER
SPRAY AWAY FROM
ELECTRICAL WIRING.

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
7
LANDA PGHW •96-6031 • REV. 7/03
4. Attach swivel connector on discharge hose to spray
gun using teflon tape on threads.
5. Check engine and pump oil level by removing oil dip-
stick, making sure oil is on proper indicator marking.
Oil should be visible one half way up sight glass (SAE
30W non-detergent).
6. Fill red gasoline tank.
7. Fill green fuel tank. Do not confuse gasoline and fuel
oil (diesel) tanks. Keep proper fuel in proper tank.
8. Install proper battery making sure that the red cable
is attached to the positive terminal. Use a 12V Group
24 battery on all models except 4-40321 and
5-35321E. These models use a U1 30 amp garden
tractor style battery.
OPERATING INSTRUCTIONS
1. Read engine warning and operating instructions.
2. Turn on water at faucet. Check for water leaks; tighten
as needed.
3. Pull wand coupler collar back and insert desired pres-
sure nozzle into wand coupler then secure by push-
ing coupler collar forward.
NOTE: Variable pressure control wand handle must
be turned clockwise to enable water to flow out of
the high pressure nozzle.
4. Pull spray gun trigger to relieve pressure. Read en-
gine manual provided and pull choke. Turn engine
switch to the START position and hold it there until
the engine starts. NOTE: Do not engage electric
starter for more than five (5) seconds at a time. If
engine fails to start, release the switch, pull spray
gun trigger to relieve pressure and wait ten seconds
before operating the start again. When the engine
starts, allow the engine switch to return to the ON
position. If the engine is to be started without the
battery, turn switch to start position and pull starter
grip to start. Turn off choke.
CAUTION: Small engines may kick back. Do not hold
starter grip tightly in hand.
5. With the spray nozzle pointed away from you or any-
body else, press the trigger on the spray gun to ob-
tain pressurized cold water spray.
6. For hot water, turn the burner switch to ON when a
steady stream of water flows out of the spray gun.
Burner will now light automatically.
NOTE: Do not start machine with burner switch on.
7. To apply detergent, place detergent pick-up tube into
a container of detergent and turn the detergent valve
counterclockwise (see page 8).
8. For steam, open the steam valve counterclockwise
which will lower the pressure and raise the tempera-
ture.
GENERAL WASHING
TECHNIQUES
1. Hold spray nozzle approximately one foot from the
surface being cleaned. Spray at an angle to get un-
der the material and lift it off.
2. When detergent is required for cleaning, start wash-
ing from the bottom and work up. Better detergent
economy and faster results will be obtained by al-
lowing the chemical to set 5-10 minutes. After wash-
ing, rinse from the top down.
3. Cleaning heavy dirt or material away with a hard
stream of clear water is recommended before using
a cleaning agent.
SHUT DOWN PROCEDURES
1. Rinse all detergent lines with clean water, to remove
any soap residue.
2. Turn burner switch off and continue spraying, allow-
ing the water to cool to below 100°F.
3. Turn engine key switch off.
4. Turn off water supply.
5. Squeeze trigger on spray gun to relieve remaining
pressure.
6. Remove water supply hose.
7. In freezing conditions, disconnect water, drain float
tank and add a 50/50 mixture of anti-freeze. Start
the machine and squeeze trigger on spray gun to
allow the mixture to flow out of the wand. Now turn
off the engine. See Winterizing Procedures under
Maintenance and Service.
CAUTION: Do not allow pump to run longer than 5
minutes without water. Disconnect all hoses to al-
low water to drain.
With machine off, open spray gun to release pres-
sure before removing discharge hose.

8 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
HOW TO USE THE OPTIONAL
DETERGENT INJECTOR
WARNING: Some detergents may
be harmful if inhaled or ingested,
causing severe nausea, fainting
or poisoning. The harmful ele-
ments may cause property dam-
age or severe injury.
The machine can siphon and mix
detergents with the use of Landa's
detergent injector kit.
1. Pull injector quick coupler collar back and secure on
discharge nipple. Injector valve body arrow should
point in direction of flow.
2. Connect high pressure hose to injector discharge
nipple securing quick coupler.
3. Start machine as outlined in Operating Instructions.
4. Place detergent pick-up tube into container of deter-
gent.
5. Turn pressure control handle counterclockwise on
the variable pressure wand. This lowers the pres-
sure by directing the water flow through the soap
nozzle and allows the detergent injector to siphon
soap.
6. Open spray gun. Water detergent ratio is approxi-
mately 15 to 1.
7. When you finish washing, rinse by simply turning
the variable pressure wand control handle clockwise
to increase pressure.
NOTE: The detergent injector will not siphon deter-
gent with the water flowing through the high pres-
sure nozzle at the end of the wand.
8. For clean up, place detergent pick-up tube into con-
tainer of clear water and follow steps 4 and 5 to pre-
vent detergent deposits from damaging the injector.
WARNING
RISK OF
ASPHYXIATION.
USE THIS PRODUCT
ONLY IN A WELL
VENTILATED AREA.
Detergent Injector
Discharge
Nipple
Quick
Coupler
High Pressure
Nozzle
Variable Pressure
Control Wand Handle
Spray Gun
Detergent
Bucket
(Not Included)
Detergent
Pickup Tube
Soap Nozzle

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
9
LANDA PGHW •96-6031 • REV. 7/03
PREVENTATIVE MAINTENANCE
1. Check to see that water pump is properly lubricated.
2. Follow winterizing instructions to prevent freeze dam-
age to pump and coils.
3. Always neutralize and flush detergent from system
after use.
4. If water is known to be high in mineral content, use a
water softener on your water system, or de-scale as
needed.
5. Do not allow acidic, caustic or abrasive fluids to be
pumped through system.
6. Always use high grade quality cleaning products.
7. Never run pump dry for extended periods of time.
8. Use clean fuel-kerosene, No. 1 fuel oil, or die-
sel. Clean or replace fuel filter every 100 hours of
operation. Avoid water contaminated fuel as it will
damage the fuel pump.
9. If machine is operated with smoky or eye burning
exhaust, coils will soot up, not letting water reach
maximum operating temperature.
10. Never allow water to be sprayed on or near the en-
gine or burner assembly or any electrical compo-
nent.
11. Periodically delime coils as per instructions.
12. Check to see that engine is properly lubricated.
It is advisable, periodically, to visually inspect the burner.
Check air inlet to make sure it is not clogged or blocked.
Wipe off any oil spills and keep equipment clean and
dry.
The flow of combustion and ventilating air to the burner
must not be blocked or obstructed in any manner.
The area around the Landa washer should be kept clean
and free of combustible materials, gasoline and other
flammable vapors and liquids.
MAINTENANCE AND SERVICE
Unloader Valves:
Unloader valves are preset and tested at the factory be-
fore shipping.Occasional adjustment of the unloader may
be necessary to maintain correct pressure.
Winterizing Procedure:
Damage due to freezing is not covered by warranty. Ad-
here to the following cold weather procedures whenever
the washer must be stored or operated outdoors under
freezing conditions.
During winter months, when temperatures drop below
32°F, protecting your machine against freezing is nec-
essary. Store the machine in a heated room. If this is not
possible then mix a 50/50 solution of anti-freeze and
water in the float tank. Turn the engine on to siphon the
anti-freeze mixture through the machine. If compressed
air is available, an air fitting can be screwed into the float
tank by removing the float tank strainer and fitting. Then
inject the compressed air. Water will be blown out of the
machine when the trigger on the spray gun is opened.
High Limit Hot Water Thermostat:
For safety, each machine is equipped with a tempera-
ture sensitive high limit control switch. In the event that
the water should exceed its operating temperature, the
high limit control will turn the burner off until the water
cools then automatically reset itself.The thermostat sen-
sor is located on the discharge side of the heating coil.
The thermostat control dial is located on the control panel.
Pumps:
Use only SAE 30 weight non-detergent oil. Change oil
after first 50 hours of use. Thereafter, change oil every
three months or at 500 hour intervals. Oil level should be
checked through use of dipstick found on top of pump,
or the red dot visible through the oil gauge window. Oil
should be maintained at that level.
Cleaning of Coils:
In alkaline water areas, lime deposits can accumulate
rapidly inside the heating coil. This growth is increased
by the extreme heat build up in the coil.The best preven-
tative for liming conditions is to use high quality cleaning
detergents. In areas where alkaline water is an extreme
problem, periodic use of Landa Deliming Powder (Landa
Part #9-028008) will remove lime and other deposits
before coil becomes plugged. (See Deliming instructions
for use of Landa Deliming Powder.)
Deliming Coils:
Periodic flushing of coils or optional float tank is recom-
mended.
Step 1 Fill a container with 4 gallons of water, then add
1 lb. of deliming powder. Mix thoroughly. Pour
mixture into float tank.
Step 2 Remove wand assembly from spray gun and put
spray gun into float tank. Secure the trigger on
the spray gun into the open position.
Step 3 Turn engine on, allowing solution to be pumped
through coils back into the float tank. The solu-
tion should be allowed to circulate 2-4 hours or
until the color changes.
Step 4 After circulating solution, flush the entire sys-
tem with fresh water. Clean out float tank and
then reinstall wand assembly to spray gun.

10 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
Removal of Soot and Heating Coil:
In the heating process, fuel residue in the form of soot
deposits may develop between the heating coil pipe and
block air flow which will affect burner combustion. When
soot has been detected on visual observation, the soot
on the coil must be washed off after following the coil
removal steps (See Coil Removal on page 11).
Rupture Disk:
If pressure from pump or thermal expansion should ex-
ceed safe limits, the rupture disk will burst allowing high
pressure to be discharged through hose to ground.When
disk ruptures it will need to be replaced. Torque new rup-
ture disk to 35 ft. lbs.
Fuel:
Use clean fuel oil that is not contaminated with water
and debris. Replace fuel filter and drain tank every 100
hours of operation.
Use No.1 or No. 2 Heating Oil (ASTM D306) only. NEVER
use gasoline in your burner fuel tank. Gasoline is more
combustible than fuel oil and could result in a serious ex-
plosion. NEVER use crankcase or waste oil in your burner.
Fuel unit malfunction could result from contamination.
Fuel Control System:
This machine utilizes a fuel solenoid valve located on the
fuel pump to control the flow of fuel to the combustion cham-
ber.The solenoid, which is normally closed, is activated by
a flow switch when water flows through it.When the opera-
tor releases the trigger on the spray gun, the flow of water
through the flow switch stops, turning off the electrical cur-
rent to the fuel solenoid.
The solenoid then closes, shutting off the supply of fuel to
the combustion chamber.Controlling the flow of fuel in this
way gives an instantaneous burn-or-no-burn situation,
thereby eliminating high and low water temperatures and
the combustion smoke normally associated with machines
incorporating a spray gun. Periodic inspection, to insure
that the fuel solenoid valve functions properly, is recom-
mended. This can be done by operating the machine and
checking to see that the burner is not firing when the spray
gun is in the OFF position.
Fuel Pressure Adjustment:
To control water temperature, adjust fuel pressure by turn-
ing the regulating pressure adjusting screw clockwise to
increase, counterclockwise to decrease. Do not exceed
200 psi. NOTE: When changing fuel pump, a bypass plug
must be installed in return port or fuel pump will not prime.
Burner Nozzle:
Keep the tip free of surface deposits by wiping it with a
clean, solvent saturated cloth, being careful not to plug
or enlarge the nozzle. For maximum efficiency, replace
the nozzle each season.
Electrodes Setting: Wayne
(See Illustration Below)
Electrodes Setting: Beckett
(See Illustration Below)
Air Adjustment:
Machines are preset and performance tested at the fac-
tory - elevation 100'. A one-time initial correction for your
location will pay off in economy, performance, and ex-
tended service life. If a smoky or eye-burning exhaust is
being emitted from the stack, two things should be
checked. First, check the fuel to be certain that kero-
sene or No. 1 home heating fuel is being used. Next,
check the air adjustment on the burner.
Gap
1/8"
1/8"
3/8"
1/2"
3/16"
Top View Side View
Nozzle
Adapter
2-7/8"
Periodically Check Wiring Connections. If Necessary
To Adjust Electrodes, Use Diagram.
Electrodes
1/16"
5/32" Gap
Nozzle
7/16"
Electrode
Top View Side View

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
11
LANDA PGHW •96-6031 • REV. 7/03
To adjust: Start machine and turn burner ON. Loosen
two locking screws found in the air shutter openings (re-
fer to illustration) and close air shutter until black smoke
appears from burner exhaust vent. Note air band posi-
tion. Next, slowly open the air shutter until white smoke
just starts to appear. Turn air shutter halfway back to the
black smoke position previously noted. Tighten locking
screws.
If the desired position cannot be obtained using only the
air shutter, lock the air shutter in as close a position as
can be obtained, then repeat the above procedure on
the air band setting.
Air Shutter
Locking Screw
Air Shutter
Locking Screw
Air
Shutter
Air Band
Locking Screw
Air Band
Coil Removal:
Removal of coil because of freeze breakage, or to clean
soot from it can be done quickly and easily.
1. Disconnect hose from pump to inlet side of the coil.
2. Carefully disconnect the thermostat sensor making
sure you do not crimp the capillary tube.
3. Remove burner assembly from combustion chamber.
4. Remove the 3-3/8" bolts from each side of coil and
tank assembly (these bolts are used to fasten tank
to chassis).
5. Remove fittings connected to the 1/2" pipe nipples
from inlet and discharge sides of coil.
6. Remove top tank wrap, bend back insulation tabs
and fold back blanket.
7. Remove bolts that hold down coil to bottom wrap.
8. Remove coil.
9. Replace or repair any insulation found to be torn or
broken.
10. Remove insulation retainer plates.
Coil Reinstallation:
Reinstall new or cleaned coil reversing Steps 9 through 1.

12 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
EXPLODED VIEW
LEFT SIDE
1
2
35 73
38
21 20
19
18
95
25
24
22, 95, 96
108
122
117
109
110
89
112
90
8
50
111 52
51
43
121
120
44
116
67
58
118 57
56
55
49
32
31
87
30
26
46 28
29
27
16
17
34
13 14
15
11
12
6
7
22
23
9
94

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
13
LANDA PGHW •96-6031 • REV. 7/03
EXPLODED VIEW
RIGHT SIDE 66
81
80
83
95
78
79
68
85
84
93
10
82
70
69
58
86 91
88
45
33
75
50
9
114
119
115
117
117
PGHW
4-3000E
For
Detail See
Control
Panel Illus
For
Detail See
FloatTank
Illus
41
64
63
104
106
102
103
104
5
69
70
68
53 3
101
39
48
47
98
97
75
4
92
61
59
58
54
60
100
40
72
56
55
55
71
9
77
76
36
37
96
42
74
62
99
123
125
124
107
65
105
PGHW4-3000E
127
126
128

14 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
ITEM PART NO. DESCRIPTION QTY
1 95-07121014S Top Wrap, SS, PHW Series II 1
2 2-01104 Trim, 1/16" Black 3 ft.
3 90-1006 Bolt, 5/16" x 3/4" 4
90-4008 ▲Washer, 5/16", Lock,
Split Ring 4
4 2-0031 Elbow, 3/8" Street 1
5 90-1016 Bolt, 3/8" x 1", NC HH 12
6 7-01484 Insulation/Blanket - Die Cut
28" x 24" 1
7 7-01430 Insulation Blanket - No Foil,
24" x 57" 1
8 10-02011 Label, Use Only Gasoline (All
Models Except 13HP Honda) 1
9 10-02025A Label, Hot/Caliente 2
10 10-02028 Label, Warning-
Exposed Pulleys 2
11 7-0141 Insulation, Burner Head, w/Hole1
12 95-07121212 Coil Replacement Schedule 80
W/Aluminum Steel Wrap 1
13 95-07121015 Wrap, Bottom, Stainless Steel 1
14 7-0140 Insulation, Front Head, No Hole 1
15 7-12484 Gasket, Standard - Large 1
16 7-0144 Gasket, Burner Plate 2
17 95-07121113 PHW/VNG Insulation
Retainer Plate 2
18 Burner Assembly, See Burner Specifications
Page 21
19 2-1022 Elbow, 1/4" Street 1
20 2-1002 Nipple, 1/4" Close 1
21 2-9905 Filter, Fuel/Oil H20 Separator 1
22 90-1019 Bolt, 3/8" x 1-3/4" Tap 5
23 2-9040 Clamp, Hose, 1/4" 6
24 4-02100000 Hose, 1/4", Push-on (All Models
Except 13HP Honda) 10"
25 2-1085 Hose Barb, 1/4" Barb x 1/4"
ML Pipe 1
26 2-00120 Nipple, 1/2" x 5" 1
2-00123 Nipple, 1/2" x 5" Black Pipe
(4-4000) 1
27 2-00091 Nipple, 1/2" x 3", Galv. 1
2-00122 Nipple, 1/2" x 4" Black Pipe
(4-4000) 1
28 2-00241 Coupling, 1/2" x 3/8" Reducing 1
ITEM PART NO. DESCRIPTION QTY
29 2-2007 Nipple, 3/8" x 3/8" NPT St Mal 1
30 2-0032 Elbow, 1/2" Street 1
31 2-90041 Clamp Screw #16 1
32 4-05088 Thermostat, General, 302° 1
33 4-02047725 Hose, 25" x 3/8", 100R2,
Pres Loop 1
34 4-02047716 Hose, 16" x 3/8", 100R2
Pres Loop 1
35 90-19959 Screw, 3/8" x 1" HX Wash 6
36 90-2001 Nut, 5/16" ESNA 4
90-2002 Nut, 3/8" ESNA
(20 HP Honda only) 4
37 90-4001 Washer, 5/16" Flat SAE 8
90-4002 Washer, 3/8" SAE, Flat
(20 Honda only) 4
38 2-1089 Hose Barb, 1/4" Barb x 1/4"
Pipe, 90° 3
39 2-1037 Tee, 1/4" Branch Male 1
40 2-1076 Bushing, 1/2" x 1/4" Pipe 1
41 2-11080 Push-on 1/2"MPT x 3/4" Barb 1
42 4-02120000 Hose, 3/4", Push-on 1.5 ft.
43 5-3208 Unloader, AR, AL607 1
44 2-00101 Nipple, 1/2" x 4" Gal Sch 80 1
2-00122 Nipple, 1/2" X 4" Black Pipe
(4-4000 only) 1
45 95-071410273 Belt Guard, End Support,
Pump End (all models) 1
46 95-07101226 Discharge Block, 1/2" 1
47 90-1020 Bolt, 3/8" x 2", NC HH 2
48 95-07101216/B Block, Unloader, 3/8" x 3/8" Brass 1
49 4-02130050 Hose, Conduit 7/8" 1.75 ft.
50 10-02029 Label, Danger Cool Engine 1
51 2-0079 Swivel, 1/2" JIC x 3/8" Male 1
52 2-0051 Nipple, 1/2" JIC x 3/8" Pipe 1
53 90-1010 Bolt, 5/16" x 1-3/4", NC HH (All
Models Except 20HP Honda) 4
90-1020 Bolt, 3/8" x 2" NC HH (20HP
Honda) 4
54 2-10630 Elbow, 3/4" JIC x 1/2", 90° 1
55 2-1105 Swivel, 1/2" JIC Fem, Push-on (All
Models Except 13HP Honda) 4
(13HP Honda) 2
56 4-02110000 Hose, 1/2" Push-on 1.5 ft.
EXPLODED VIEW
PARTS LIST

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
15
LANDA PGHW •96-6031 • REV. 7/03
ITEM PART NO. DESCRIPTION QTY
57 2-1062 Elbow, 1/2" JIC x 1/2" 90° 1
58 2-0053 Elbow, 1/2" JIC, 3/8" 90° 3
59 2-1035 Cross, 1/2" Female, Pipe 1
60 2-30082 Pump Protector, 1/2" PTP 1
61 2-1007 Nipple, 1/2" Hex 1
62 4-02100030 Inlet Hose, Supply Water 30"
63 4-02100013 Inlet Hose, Supply Water 13"
64 2-10712 Tee, 1/2" x 1/2" JIC 51# 1
65 2-1024 Elbow, 1/2" Street, Brass 1
66 6-060150 Generator, Winco, 50HZ, 220V 1
6-0107 ▲Cord, Molded, Royal, K1426,
14-3 1
67 2-0006 Nipple, 3/8" Hex 1
68 95-07121112 Rail, Pump or Generator
Combo (PHW/Skid) 2
69 95-07141110 Retainer, Pump Take Up, Plated 2
70 90-10220 Bolt, 3/8" x 3-1/2", Tap 4
90-2007 ▲▲
▲▲
▲Nut, 3/8", HEXNC 4
71 2-0053 Elbow, 1/2" JIC, 3/8", 90°, LBG
(All Models Except 13HP
Honda) 1
2-1101 ▲▲
▲▲
▲Adaptor, 3/8" x 1/4" (20 HP
Honda only) 1
72 2-1050 Plug, 1/2" JIC, Flare (All
Models Except 13HP Honda) 1
73 10-99087 Label, Warning 1
74 2-11050 Swivel, 3/4" JIC FEM, Push-on 1
75 Engine, See Engine Specifications Page 23
76 76-807964 Muffler, Exhaust Skid,
16 HP Van. 1
76-808597 ▲Muffler, Van. 21 HP 1
77-VHLM4 ▲Muffler, (20 HP Honda) 1
77 95-07101149 Guard, Muffler, Van. 16 HP 1
95-07101153 Guard, Van. 21 HP 1
95-071011491 ▲Brace, Van. Muff. Bracket
(16HP Vanguard) 2
78 Bushing, Generator, See Specifications Page 23
79 Pulley, Generator, See Specifications Page 23
80 Belt, Generator, See Specifications Page 23
81 Bushing, Engine, See Specifications Page 23
82 Pulley, Engine, See Specifications Page 23
83 Belt, Pump/Engine, See Specifications
Pages 22 & 23
ITEM PART NO. DESCRIPTION QTY
84 Pulley, Pump, See Specifications Page 22
85 Bushing, Pump, See Specifications Page 22
86 95-071410294 Belt Guard, Cover, (4-3000) 1
95-071410293 Belt Guard, Cover,
(4-4000, 5-3000, 5-3500) 1
87 2-3408 Rupture Disk Assy, 8000 PSI 1
2-3480 Rupture Disk Replacement Only,
8000 PSI 1
88 95-071410274 Belt Guard, End Support,
Gen End
(16, 20, 21 HP Engines) 1
95-071410230 Belt Guard, End Support,
Gen End (13 HP Engines) 1
89 2-010064 Diptube, Plastic, w/Elbow (All
Models Except 13HP Honda) 2
90 2-010061 Bushing, Rubber, Nitrile (All
Models Except 13HP Honda) 2
91 95-071410292 Face Plate, Belt Guard 1
92 Pump, See Pump Specifications Page 22
93 90-1996 Bolt, 3/8" x 3/4", NC HH, Whiz 5
90-2020 ▲▲
▲▲
▲Nut, Cage, 3/8" x 12 GA 5
94 4-02100000 Hose, 1/4" Push-On (All Models
Except 13HP Honda) 7"
95 90-2002 Nut, 3/8" ESNA, NC 35
96 90-4002 Washer, 3/8", SAE, Flat 50
97 2-0115 Box, Battery, M-100 (All Models
Except 20HP Honda) 1
2-0117 Box, Battery (20HP Honda) 1
2-011500 ▲Plate, Battery Box, Large,
Polypro (All Models Except 20HP
Honda) 1
2-011700 ▲Plate, Battery Box, Small
Polypro (20HP Honda) 1
6-051030 Cable, Battery, Red (All Models
Except 20HP Honda) 1
6-05104 Cable, Battery, Black Molded (All
Models Except 20HP Honda) 1
6-0117 ▲Wire, 6 Ga. Red (20HP
Honda) 1.5 ft
6-0503 ▲Terminal Ring (20HP Honda) 1
6-0118 ▲Wire, 6 Ga. Black (20HP
Honda) 1.5 ft.
6-05030 ▲Terminal Ring (20HP Honda) 3
EXPLODED VIEW
PARTS LIST (continued)

16 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
ITEM PART NO. DESCRIPTION QTY
98 90-10051 Bolt, 5/16" x 1/2", Button Head 4
99 95-07141057 ▲Heat Shield (20 HP Honda,
21 HP Vanguard Only) 1
100 90-4011 Washer, 5/16" Star 4
101 2-01011 Isolator, 5/16", F x F, 1" 4
102 95-07141043 Power Platform, PGHW 1
103 90-4007 Washer, 3/8" x 1-1/2", Fender,
SAE 8
104 2-0108 Bumper Pad, Engine 16
105 95-07141004 Cage, PGHW 1
106 2-01041 Pad, Soft Rubber, 50 Duro 8
107 2-10942 Swivel, 1/2" MP x 3/4" GHF
W/Strainer 1
108 95-07164010 Strap, MHP Fuel Tank W/Hole 6
109 2-01167 Cap, Fuel Tank, Plastic (All
Models Except 13HP Honda) 2
110 2-011501 Tank, Fuel, 10 Gallon Poly,
Diesel, Green (4-4000, 5-3000,
5-3500) 1
111 2-011502 Tank, Fuel, 5 Gallon Poly,
Gasoline, Red (4-4000, 5-3000,
5-3500) 1
112 2-010066 Elbow, Fuel Tank (All Models
Except 13HP Honda) 1
2-010061 ▲ Bushing, Rubber (All Models
Except 13HP Honda) 1
114 2-01157 Cap, 14" w/Fuel Gauge, (13HP
Honda) 1
115 2-1088 Hose Barb 1/4" Barb x 1/8"
ML Pipe 90° (13HP Honda) 2
EXPLODED VIEW
PARTS LIST (continued)
ITEM PART NO. DESCRIPTION QTY
116 6-021730 Switch, Flow MV60 1
117 10-020110 Label, Use Only Kerosene 2
118 2-1060 Elbow 1/2" JIC x 3/8", 90° 1
119 95-07141045 Tank, Fuel, PGHW (13HP
Honda) 1
90-1008 ▲ Bolt, 5/16" x 1-1/4" (13HP
Honda) 2
90-4007 ▲ Washer, 3/8" x 1-1/2", Fender
(13HP Honda) 4
90-2001 ▲ Nut, 5/16", ESNA (13HP
Honda) 2
120 2-0083 Adapter, 1/2" JIC x 1/2" Fem. 1
121 6-021740 Switch, Reed Replacement
MV60 1
122 2-4019 Gasket, Fuel Tank (All Models
Except 13HP Honda) 1.75 ft.
123 90-19959 Screw, 3/8" x 1" HX Wash (13HP
Honda) 2
124 77-31620-ZG5-003
REG/REC Honda
(20 HP Honda Only) 1
125 77-32105-ZJ1-800
Harness, Honda 20 AMP
(20 HP Honda Only) 1
126 4-02110000 Hose, 1/2" Push-On .75 ft.
127 4-02100000 Hose, 1/4" Push-On, 34" (13HP
Honda) 2
128 4-02100000 Hose, 1/4" Push-On (All Models
Except 13HP Honda) 44"
▲ Not Shown

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
17
LANDA PGHW •96-6031 • REV. 7/03
PGHW FLOAT TANK ASSEMBLY
EXPLODED VIEW
ITEM PART NO. DESCRIPTION QTY
1 2-01164 Tank, Plastic Universal 1
2 2-1906 Strainer, 1/2" Basket 1
3 2-0151 Plug, Float Tank (Items 3 - 6) 1
4-02100000 Hose, 1/4" Push-on 1
4 90-4030 Screw, 5/16" - 18 x 1-1/2" SS,
Button Socket 1
5 90-4032 Washer, 5/16", SS 1
6 90-4031 Nut, 5/16" - 18, Wing, SS 1
7 2-1062 Elbow, 1/2" JIC x 1/2", 90° 1
8 2-11041 Connector, 1/2" Anchor 1
9 4-02100013 Inlet Hose, 13" Supply Water 1
10 4-02100030 Inlet Hose, 30" Supply Water 1
11 95-07121207 Lid and Hinges 1
12 2-3014 Valve, Fluidmaster 400A Float 2
13 2-10942 Swivel, 1/2" MP x 3/4" GHF
W/Strainer 1
14 2-1902 Strainer, Inlet Garden Hose 1
15 2-1024 Elbow, 1/2" Street, Brass 1
16 2-10712 Tee, 1/2" x 1/2" JIC #51 1
17 90-300210 Screw, #14 x 1", Tek, Blk 3
18 90-40002 Washer, 1/4", SAE, Blk 3
19 2-11080 Push-on, 3/4" x 1/2" Male 1
20 90-19980 Screw, 1/4" x 1" 2
21 90-20231 Nut, Cage, 1/4" x 12 GA 2
22 10-99079 Label, Landa Stripe 1
11
17
18
12
1
2
7
4
3
5
6
10
9
15
13
14
16
19
To Pump
Inlet
8
18
20
21
22

18 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
PGHW CONTROL PANEL
EXPLODED VIEW
11
3
9
12
1
2
17
13
5
5
8
7
5
6
14
15
10
16
To Pump
Assembly
To Detergent
Supply
15
4
8
6
18

PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
19
LANDA PGHW •96-6031 • REV. 7/03
PGHW CONTROL PANEL
EXPLODED VIEW
ITEM PART NO. DESCRIPTION QTY
1 10-07998 Label, PGHW Control Panel 1
2 2-0103 Grommet, 1/8" Rubber 4
3 90-19942 Screw, 10/32" x 3/4" 2
4 2-00220 Elbow, 1/4" Street, 45° 1
5 2-1089 Hose Barb, 1/4" Barb x
1/4" Pipe 3
6 2-3015 Valve/Control, Metering
(Detergent) 1
90-4005 ▲ Washer, 5/8" SAE Flat Zinc 1
90-40073 ▲ Washer, 5/8" Internal
Star-Zinc 1
7 2-9040 Clamp, Hose 1/4" 5
8 2-30151 Valve, Flow Control w/Meter
(Steam) 1
90-4005 ▲Washer, 5/8" SAE, Flat, Zinc
90-40073 ▲ Washer, 5/8", Star, Zinc 1
9 4-050822 Hour Meter, ENM, 115Vac
50/60 Hz 1
10 4-02021226 Hose, Pressure Loop, 100R2,
26" x 1/4" 1
11 95-071410460 Control Panel, PGHW 1
12 6-020251 Switch, Curvette 120V and
220V 1
13 2-0030 Elbow, 1/4" Steel 1
14 4-02080000 Tube, 1/4" X 1/2" Clr Vinyl 8 ft.
15 4-02100000 Hose, 1/4" x 34" 2
16 4-05088 Thermostat, General 302° 1
ITEM PART NO. DESCRIPTION QTY
17 4-12804000 Nozzle, 0004, Red
(4-3000, 4-4000) 1
4-12804015 Nozzle, 1504, Yellow
(4-3000, 4-4000) 1
4-12804025 Nozzle, 2504, Green
(4-3000, 4-4000) 1
4-12804040 Nozzle, 4004, White
(4-3000, 4-4000) 1
4-12805500 Nozzle, 0005.5, Red (5-3000) 1
4-12805515 Nozzle, 1505.5, Yellow (5-3000) 1
4-12805525 Nozzle, 2505.5, Green (5-3000)1
4-12805540 Nozzle, 4005.5, White (5-3000) 1
4-12805000 Nozzle, 0005, Red (5-3500) 1
4-12805015 Nozzle, 1505, Yellow (5-3500) 1
4-12805025 Nozzle, 2505, Green (5-3500) 1
4-12805040 Nozzle, 4005, White (5-3500) 1
18 90-1994 ▲Screw, 10/32" x 1-1/4"
(Ground) 1
90-017 ▲Nut, 10/32" 4
11-1042 ▲Label, Ground 1
▲Not Shown

20 PGHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PGHW •96-6031 • REV. 7/03
ITEM PART NO. DESCRIPTION QTY
1 2-2002 Coupler, 3/8" Female 1
2-0121 ▲ O-Ring, 3/8",
Replacement Only 1
2 4-02043450C Hose, 50' x 3/8" 100R2 1
3 4-01212 Spray Gun, Shut-Off Series
2000 1
4 4-011143A VP Wand SS (AL344) W/Coupler,
Soap Nozzle 1
PGHW HOSE & SPRAY GUN ASSEMBLY
ALL MODELS
5
4
3
1
2
ITEM PART NO. DESCRIPTION QTY
4 83-SSVPKIT ▲ Repair Kit, AL Stainless Seat 1
5 2-2001 Coupler, 1/4" Male 1
2-0119 ▲O-Ring, Replacement Only 1
6 4-06540 ▲ Nozzle, Soap, 1/8" Brass 1
▲ Not Shown
6
