Hoover VCN6185/1A User manual

REFRIGERATORS
34001122 VCN6185/1A
Service Manual

34001122 VCN6185/1A 0920 (11/05/2009)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
1 Compressor 41015477
1c Run capacitor 97058820
8a Adjustable levelling foot 41025764
22 Control panel frame 41028029
28 Condenser 41027371
30 Clip-clamp 92663442
37c Cover 41025186
42b Compressor fixing plate 92854157
44b Drip evap.tray ZEM 41009011
45a Rear foot 92473404
49n Refrigerator door compl.(Tall end cap) 41026113
50 Freezer door complete 41026115
50z Rod 41025236
51c Plug for handle holes 91620468
51e Handle head-middle piece 41026086
51f Handle head-upper piece 41026088
51g Handle head-lower piece 41026085
51i Handle upper trim 41025159
51m Handle lower trim 41025149
58 Eggs holder 41025178
58g Bottle support 41021534
59 Lower bottles shelf 41025179
59r Bottles rail front piece 41025180
70a Upper Door handle 41025157
70b Lower Door handle 41025146
81 Refrigerator gasket 41030789
82 Freezer gasket 41028816
93 Jars door rail 41025185
93c Jars door rail cover 41025191
93d Shelf with runners 41025182
109b Upper hinge pin 92726447

34001122 VCN6185/1A 0920 (11/05/2009)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
109c Upper hinge 41025160
111c Door safety holder (R/H) 41005685
111d Door safety holder (L/H) 41005690
111e Upper door sleeve for hinge 41010607
112c Middle hinge 91750659
113d Lower hinge 41025108
115 Spacer 92434190
124b 3 ways Dryer Filter 41012883
126 Compress.shock absorber 92607290
127b Freezer evaporator 41025725
128 Defrostin.heating element 41029917
128b Drain hose heating strip 92894609
149 Crisper 41020553
149n Crisper handle/Front piece 41025244
149p Crisper wheel support 41020557
151 Crisper glass shelf 41021312
151a Crisper glass shelf trim 41021168
151q Crisper glass shelf trim air grate 41021926
153b Glass shelf with frame 41025068
160b Middle/upper basket 41022315
161 Lower basket 41020462
161p Roller basket 41014144
162 Basket front piece 41022220
162f Upper basket front piece 41025468
196a R/H Plug 41026241
196b L/H Plug 41026240
201a Hinge hole plug 92678572
201c Plug 92957026
231 Inside separatory 41025183
251 Evaporator cover panel 41008720
251c Evapora.cover-Upper panel 41025622

34001122 VCN6185/1A 0920 (11/05/2009)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
251e Cover gasket (Evaporator/fan support) 41030211
251o Evaporator cover panel trim 41022530
251p Evaporator cover panel (Refrigerator) 41026959
252 Fan motor 41030076
253 Buffer 41030567
255 Rear stirrup 41029470
257 Fan 41030568
258b Self sticking gasket 10x15 92058171
281c Heat fuse thermal protec.(freezer) 41030183
284 Dashboard 41026097
288b Dashboard plate 41027393
288c R/H-Hinge hole cover 41026094
288d L/H-Hinge hole cover 41026095
330 Ice cubes tray 92952449
360 Compressor cross piece 92871789
369 Damper box assy 41025665
391b Glass chiller shelf 41026490
391d Chiller Door 41025245
391e Chiller drawer 41021614
412 Refriger.insulating piece 41026960
422 Dashboard circuit plate 41029902
422z Led circuit plate 41026971
423a Control board barrier 41026961
428f Probe for temper.reading (refrigerator) 41027455
428g Probe for temper.reading (freezer) 41027456
999 Wiring diagram 91101304
