Agitator brush roll
shut.off
The agitator brush roll shuts off auto-
matically for tool use, when the
cleaner is in the upright position,
To manually shut off the agitator
brush roll for cleaning hard floors,
step on the pedal (E), The indicator
(F) will show red in the "brush roll
off" window, To turn the agitator
brush roll on, step on the pedal
again, The indicator will show red in
the "brush roll on" window,
Cleaning lightweight
flexible rugs
Stand on one end of rug and move
cleaner toward other end or edge,
Before reaching edge, push down
on handle, This will lift up the nozzle
(front of cleaner) as shown and will
prevent rug from clinging to cleaner,
Continue to lift up nozzle so that
when you have reached the edge, it
is completely off the rug, Move
cleaner back to start again, lower
nozzle, and use only forward
strokes,
Cleaning tools
Tools allow for cleaning surfaces
above the floor and for reaching
hard to clean areas,
The cleaner is ready for tool use
when handle is in upright
position,
The agitator brush roll will not
rotate when the cleaner is in the
upright position or the if the agi-
tator brush roll shut off indicator
is in the OFF position when the
handle is lowered.
How to clean tools
To clean the hose and powered
hand tool, wipe off dirt with a cloth
dampened in a mild detergent,
Rinse with a damp cloth, DO NOT
submerge powered hand tool in
water,
Cleaning tools may be washed in
warm water with a detergent, Rinse
and air dry before using,
Removing hose
When using cleaning tools, place
cleaner handle in the upright posi-
tion. The agitator brush roll will
not rotate when the cleaner is in
the upright position. Also, turn
cleaner OFF before disconnecting
and connecting hose to hose tube
(G).
To use hose, lift hose end (H) as
shown,
When you are finished cleaning with
the tools, reposition hose end into
tube,
..........._ j K
L
IN: )
)
Select proper tool
I. Combination tool use with brush
for carved furniture, table tops,
books, lamps, lighting fixtures,
venetian blinds, baseboards, shut-
ters, and registers,
Remove brush (Fig, 2-1 5) to clean
upholstered furniture, draperies,
mattresses, clothing, and carpeted
stairs,
J. Powered hand tool may be used
for upholstered furniture, draperies,
mattresses, clothing, automobile
interiors, and carpeted stairs,
K. Crevice tool may be used in
tight spaces, corners and along
edges in such places as dresser
drawers, upholstered furniture,
stairs and baseboards,
L. Wands are used to give extra
length to your hose, Use them with
any of the above tools,
Combination tool
Slide brush to remove,
To replace brushes, align bottom of
brush with grooves (M) on tool, Slide
brush into place,
Continued -_ 7
