hot-steam HS Series User manual

Operating Manual
HS SERIES ELECTRIC STEAM IRON
Model No.HS-4000
HS-4200
IMPORTANT
•Please read this owner’s manual thoroughly before
installing and operating your iron.
•Please retain this owner’s manual for future reference
after reading it thoroughly.

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
Thank you for purchasing the Hö t-Steam® HSSeries Model No.HS-4000
Electric Steam Iron.Please read this instruction manual carefully before
using the iron to ensure its longest possible life.
Table of Contents
A. General Safety Instructions
B. Installation & Connecting
C. Operation & Use
D. Maintenance
E. Warranty Coverage
A. GENERAL SAFETY INSTRUCTIONS
•Verify if the voltage of the iron corresponds to the power supply source
before connecting.
•Be sure to always place the iron on the iron rest.
•Do not place the iron on its back because it may cause injury to the
operator or damage the iron.
•Wait for the iron to cool down before attempting to troubleshoot the
iron
•Only skilled technicians should attempt to install and/or repair the iron.

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
B. INSTALLATION & CONNECTING
•Power Cord Wiring Specification
Mod.HS4000 Hot-Steam® Electric Steam Iron
(Consult to manufacturer’s manual when connecting a different iron brand)
•4-P Plug Wiring Instructions
Connecting iron (Mod.HS4000) to a steam regulator (Mod.SP3 Hot-Steam® )
(Consult to manufacturer’s manual when connecting a different steam regulator brand)
(Male 4-P Plug)
•Cissell® Lowboy Wiring Instructions
Connecting iron (Mod.HS4000) to Cissell® Lowboy
(Consult to manufacturer’s manual when connecting a different lowboy brand)
(Electric Box Terminal Block)

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
C. INSTALLATION & CONNECTING
•Power Cord Wiring Specification
Mod.HS4000 Hot-Steam® Electric Steam Iron
(Consult to manufacturer’s manual when connecting a different iron brand)
•4-P Plug Wiring Instructions
Connecting iron (Mod.HS4000) to a steam regulator (Mod.SP3 Hot-Steam® )
(Consult to manufacturer’s manual when connecting a different steam regulator brand)
(Male 4-P Plug)
•Cissell® Lowboy Wiring Instructions
Connecting iron (Mod.HS4000) to Cissell® Lowboy
(Consult to manufacturer’s manual when connecting a different lowboy brand)
(Electric Box Terminal Block)

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
D. OPERATION & USE
IMPORTANT
Initially, you may see water leaking out of the iron. This is not an iron
malfunction. It may take few seconds to heat and evaporate the remaining
condensation from previous use.
1) Place the Electric Steam Iron on a Silicon Rest (not included).
2) Refer to the Installation & Connecting instructions and connect the
iron.
After connecting the iron, turn on the boiler and/or open all ball valves
in the steam supply line and wait until boiler has heated thoroughly.
3) Set the Temperature Dial to the desired level.
4) Turn ON the Power Switch and wait until the iron has heated
thoroughly.
5) Make sure that the iron is facing away from the press and any clothes,
and press the Microswitch (Red Thumb Switch) a few times to release
any possible condensation.
6) Start pressing.
a. If the boiler is not hot enough, you may see water leaking out of the
iron. This is not a malfunction. Do not start pressing clothes until the
boiler has heated thoroughly.
b. If you still see water leaking out of the iron, increase the iron
temperature.
IMPORTANT
•Once finished operating the iron, press the Microswitch to release all
the remaining steam inside the iron.
•Prior to the next operation, repeat above-mentioned procedures.
•In the event that you encounter technical difficulties with the iron,
please contact your local Authorized Distributor from whom the
Hö t-Steam® HSSeries Electric Steam Iron was purchased.
•Only skilled technicians should attempt any repairs on an iron.

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
E. MAINTENANCE
•Once finished operating the iron, press the Microswitch to release any
remaining steam inside the iron.
•Be sure to clean the base of the iron regularly. Keep the base clean
of dust and adhered starch-residues.
•If you need to replace parts of the iron, please contact your local
Authorized Dealer or Distributor from whom the Hö t-Steam®
HSSeries Electric Steam Iron was purchased.
•Use genuine Hö t-Steam® parts for optimum results.
F. WARRANTY COVERAGE
Contact your local Authorized Dealer or Distributor from whom the
Hö t-Steam® HSSeries Electric Steam Iron was purchased for
additional assistance on warranty coverage.
For coverage under warranty, following is required:
•Sales Receipt issued by one of our Authorized Dealer or Distributor
from whom the iron was purchased.
•The Sales Receipt must show the serial number and date of
purchase.
•You must obtain a RAN (Return Authorization No.) from
Hö t-Steam® prior to returning the iron. Contact your Dealer or
Distributor for assistance.
•Warranty can be a form of Replacement or Repair Service of the
product.
•Hö t-Steam® is not responsible for any freight charges.
Our TSD (Technical Support Division) will perform thorough
examination on the returned iron to finalize whether the causes
are defects or misuse of the product.
.

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
EXPLODED VIEW

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
PARTS BREAKDOWN
Ref#
Item#
Description
1
HS401
Sole Plate Assembly
2
HS402
Fitting for Sole Plate Assembly
3
HS403
Tap and Threaded Bolt
4
HS404
Lead Wires (Set of 2)
5
HS405
Thermostat
6
HS406
Screw for Thermostat
7
HS407
Screw for Thermostat Wires (Set of 2)
8
HS408
Handle Bracket
9
HS409
Screw & Spring Washer for Handle Support
10
HS410
Metal Cover
11
HS411
Screw & Spring Washer for Metal Cover
12
HS412
Heat Protector & Screw Set
13
HS413
Support Disc for Temperature Dial
14
HS414
Temperature Dial Assembly
15
HS415
Handle Tip Assembly
16
HS416
Urethane Handle
17
HS417
Handle Support Set
18
HS418
Main Switch Cover Assembly
19
HS419
Power Switch
20
HS420
Thermal Fuse
21
HS421
Power Cord
22
HS422
Power Cord Bushing
[Additional Parts]
Ref#
Item#
Description
-
SP3
Steam Regulator (110V or 220V)
-
4PP
Male Plug for Power Cord
-
IR1
Metal Silicon Iron Rest
-
BSH-6
6.5ft Black Silicon Hose
-
IRS66
Iron Shoe

OPERATING MANUAL
Hö t-Steam® HSSeries –Model No. HS4000, HS4200
ELECTRIC DIAGRAM MOD. HS4000
P
ELECTRIC DIAGRAM MOD. HS4200

Limited Warranty
The Hö t-Steam® Electric Steam Iron is tested and inspected before leaving our
factory. We warrant to the original user of this product that it will be free from defects
in material and workmanship for a period of Six (6) months from date of purchase.
With respect to non-durable parts that can wear down to normal wear and tear, there
is a limited warranty of ninety (90) days. The warranty period on each new replacement
part furnished by Hö t-Steam® in fulfillment of the warranty shall be for the unexpired
portion of the original part that was replaced.
In no event will the manufacturer or distributors of the Hö t-Steam® Electric Steam
Iron be responsible for any incidental or consequential damage caused by the iron.
Any liability is limited solely to the repair or replacement of the part or product,
excluding any labor or any other cost to remove or install said part or product, nor any
responsibility for transportation expense which is involved therein.
This warranty is contingent upon installation and use of equipment under normal
operating conditions and periodic maintenance according to its described manual.
This warranty is void on iron and parts that have been subject to misuse, accident,
negligent damage, altered, repaired and operated with other than genuine
Hö t-Steam® parts or which havehad the identificationserial number altered, effaced,
or removed.
No defective iron or part may be returned to Hö t-Steam® for repair or replacement
without prior written authorization from Hö t-Steam® .
For warranty service, contact an Authorized Distributor from whom the
Hö t-Steam® Electric Steam Iron was purchased.
www.hot-steam.com
Copyright© 2019 Hö t-Steam® All rights reserved
