HOTO P12 User manual

User Manual for HOTO Cordless
Screwdriver
P12
Scan to follow us on WeChat
Get 1Y+ warranty and new follower benefits

12
01 Product Overview
Start Buon
USB Charging Port
LED Light
Direction Knob
Charging Indicator
Bit Holder
1
2
3
4
5
6
Read this manual carefully before use, and retain it for future reference.
Thank you for using HOTO Cordless Screwdriver.
1
2
4
5
6
3

13
02 How to Use
Start the screwdriver: Press and hold the
start buon, and the LED light will turn on.
Stop the screwdriver: Release the start
buon, and the LED light will turn off.
Start Buon
To illuminate the object you are working
on, press and hold the start buon. Then
the LED light will be on.
LED Light
Turn or tighten screws:Push the knob upward,
press and hold the start buon, screw in or
tighten the screw.
Neutral:Push the knob to the circle in the middle
part.
Loosen or remove screws:Push the knob
downward, press and hold the start buon,
unscrew or loosen the screw.
Direction Knob
This screwdriver is equipped with a USB-C charging
port, and a USB charging cable is included.
Charging: The charging indicator is red.
Fully Charged: The charging indicator is white.
Charging
Turn or tighten screws
Push the
knob upward
Neutral
Push the
knob to the
middle
Loosen or
remove screws
Push the
knob
downward

14
03 General Power Tool Safety Warnings
Warning! Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or baery-operated (cordless) power tool.
Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
Electrical safety
Work Area Safety
Keep work area clean and well lit. Cluered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.

15
moving parts. Damaged or entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inaention while
operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or baery pack, picking up or carrying
the tool. Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key le aached to a rotating part of the power tool may result in
personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables beer control of the power tool in unexpected situations.
Personal Safety

16
Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job beer and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the baery pack,
if detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
Power Tool Use And Care
tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may affect the
power tool's operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.

17
Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not allow for safe handling and control
of the tool in unexpected situations.
Do not use a baery pack or tool that is damaged or modified. Damaged or modified
baeries may exhibit unpredictable behavior resulting in fire, explosion or risk
of injury.
Do not expose a baery pack or tool to fire or excessive temperature. Exposure
to fire or temperature above 130°C may cause explosion.
When baery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the baery terminals together
may cause burns or a fire.
Recharge only with the charger specified by the manufacturer. A charger that
is suitable for one type of baery pack may create a risk of fire when used with
another baery pack.
Use power tools only with specifically designated baery packs. Use of any other
baery packs may create a risk of injury and fire.
Baery tool use and care
Under abusive conditions, liquid may be ejected from the baery; avoid contact.
If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the baery may cause
irritation or burns.

18
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Never service damaged baery packs. Service of baery packs should only be
performed by the manufacturer or authorized service providers.
Service
Follow all charging instructions and do not charge the baery pack or tool
outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage the
baery and increase the risk of fire.
Never operate at higher speed than the maximum speed rating of the drill bit. At
higher speeds, the bit is likely to bend if allowed to rotate freely without
contacting the workpiece, resulting in personal injury.
Always start drilling at low speed and with the bit tip in contact with the
workpiece. At higher speeds, the bit is likely to bend if allowed to rotate freely
without contacting the workpiece, resulting in personal injury.
Apply pressure only in direct line with the bit and do not apply excessive
pressure. Bits can bend causing breakage or loss of control, resulting in personal
injury.
Safety instructions when using long drill bits
Hold the power tool by insulated gripping surfaces, when performing an
operation where the cuing accessory or fasteners may contact hidden wiring.
Cuing accessory contacting a “live” wire may make exposed metal parts of the
power tool “live” and could give the operator an electric shock.
Safety instructions for all operations

19
Always wait until the power tool has come to a complete stop before placing
it down. The application tool can jam and cause you to lose control of the
power tool.
Secure the workpiece. A workpiece clamped with clamping devices or in a vice is
held more secure than by hand.
Additional safety information
Hold the power tool securely. When tightening and loosening screws be
prepared for temporarily high torque reactions.
In case of damage and improper use of the baery, vapours may be emied. The
baery can set alight or explode. Ensure the area is well ventilated and seek
medical aention should you experience any adverse effects. The vapours may
irritate the respiratory system.
Do not open the baery. There is a risk of short-circuiting.
The baery can be damaged by pointed objects such as nails or screwdrivers or
by force applied externally. An internal short circuit may occur, causing the
baery to burn, smoke, explode or overheat.
Only use the baery with products from the manufacturer. This is the only way
in which you can protect the baery against dangerous overload.
Switch the power tool off immediately if the application tool becomes blocked.
Be prepared for high torque reactions which cause kickback. The application
tool becomes blocked when it becomes jammed in the workpiece or when the
power tool becomes overloaded.
Use suitable detectors to determine if there are hidden supply lines or contact
the local utility company for assistance. Contact with electric cables can cause
fire and electrical shock. Damaging gas lines can lead to explosion. Breaking
water pipes causes property damage.

20
Screwdriver stops rotating
during use
Issue
Screwdriver doesn't work
Possible Causes Solution
ChargingLithium baery is depleted
Lithium baery is depleted Charging
Use the appropriate bitBit cannot be installed Bit size does not match
the size of the bit holder
Troubleshooting
Screwdriver does not
work when pressing and
holding the start buon
Adjust the direction
knob according to your
needs
Direction knob is in the
neutral position
Check whether the
charging indicator is on,
and use the included
charging cable
The USB cable is not
plugged in or the
included charging cable
is not being used
Baery cannot be charged
Protect the baery against heat, e.g. against continuous intense sunlight, fire,
dirt, water and moisture. There is a risk of explosion and short-circuiting.

21
04 Specifications
Model: QWLSD008
Max. Torque: 5 N·m
Screwdriver Net Weight: 365 g
Screwdriver Dimensions: 127×130.5×42 mm
Rated Voltage: 3.6 V
Input: 5 V 1 A
Baery Type: Lithium-ion baery
Rated Capacity: 2000 mAh
No Load Rotational Speed: 200 rpm
Charging Time: 120–180 min
Manufactured by: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Putuo District Shanghai,China
Bit Size: C6.3 × 50 mm
Pozidriv: PZ2
Phillips-head: PH1/PH2
Allen: H3/H4/H5
Standard: SL5
Torx: T25
2.3
TW1
