HOTO QWLSD009 User manual

User Manual for HOTO Precision
Screwdriver Set
Scan to follow us on WeChat
Get 1Y+ warranty and new follower benefits

01 Product Overview
Thank you for purchasing the HOTO Precision Screwdriver Set.
Please read this manual carefully before use, and retain it
for future reference.
4
Storage box cover
1
Screwdriver handle
3
Bit
2
Storage box base
4
02 How to Use
Turn the storage box cover upward to the
natural open position (the maximum open
angle is 115°), please do not turn it
forcibly.
Turn the storage box cover downward to zero
degree, and the storage box will be closed.
Opening/Closing the Cover
How to Use the Screwdriver
The bit can be inserted into the screwdriver handle
directly for use.
When the bit is inserted into the screwdriver handle,
magnetic force can be generated, and most screws can be
attached by the magnetic force.
Bits are stored in the base
Put the bit in the bit slot after
use, it will be attached
Bit Storage
4
1
3
2
3
2

5
03 Precautions
Illustrations of the product, accessories, and user interface
in the user manual are for reference purposes only. Due to
product updates and upgrades, the actual product may be
slightly different from the schematic. Please refer to the
Insert the tip of the precision screwdriver into the circular
hole and press it for storage.
Screwdriver Handle Storage
Be careful to
prevent the hands
from being clipped
by this area during
opening/closing.

Follow us:@HOTO
Model：QWLSD009
Net weight：216g
Maximum manual torque：2N·m
Bit material: S2 alloy steel
Bit specification：C4×L28mm
Bit model：Y0.6/TW1/PH000/PH00/PH0/PH1/SL1.5/SL2/SL2.5/SL3/
W1.5/P2/P5/P6/T1/T2/T3/T4/T5H/T6H/T8H/T9H/T10H/H1.5/H2/
H2.5/U2.6 /▲2.3
Dimension of storage box：
149.5×78×19.5mm
Dimension of screwdriver：
126.5×10.1×10.1mm
04 Specifications
Manufactured by: Shanghai Qiwai Culture Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Putuo District,
Shanghai,China
