HOTO QWLSD010 User manual

User Manual for HOTO Electric Precision
Screwdriver Set
Original instructions
·15

Scan to follow us on WeChat
Get 1Y+ warranty and new follower benefits

15
01 Product Overview
Thank you for purchasing the HOTO Electric Precision Screwdriver Set.
Please read this manual carefully before use, and retain it for future reference.
6
7
8
9
Type-C charging port
Charging Indicator
Forward/Reverse rotation button
Bit Holder
1
2
3
4
Storage box cover
Magnetizing area
Bit
Electric Precision screwdriver
Storage box base
5
89
7
6
5
1
4
3
2

16
02 How to Use
Press the ∨end to turn in or tighten screws.
Press the ∧end to loosen or remove screws.
Forward/Reverse rotation button
Bits are stored in the base magnetically. The
screwdriver bit is removed from a storage box, and
the bit is inserted into the bit holder.
After the bit is inserted into the bit holder, it is
magnetized in the middle magnetizing area.
Magnetic force can be generated, and most screws
can be attached by the magnetic force.
How to Use the Screwdriver
When the bit magnetism is insucient, the bit can be
magnetized in time by placing the bit top at the
magnet of the receiving tank for 5S. The magnetic
force of the bit will decrease when stored for a long
time, so the bit should be regularly magnetized.
Magnetizing
If the battery level is below 20% when the screwdriver is in use,
the indicator will blink red quickly for 5 seconds, and it will turn o
when the button is released. Please charge the battery in time.
When charging, the indicator will slowly blink red.
When the battery is fully charged, the indicator will stay white.
Indicator status

17
03 Storage
Bits are stored in the base magnetically.
Put the bit in the bit slot after use, it will be
attached automatically.
Bit Storage
Insert the tip of the screwdriver bit
holder into the circular hole and press it
for storage, as shown in the gure.
Storage of electric screwdriver
Turn the storage box cover upward to the natural
open position (the maximum open angle is
115°), please do not turn it forcibly.
Turn the storage box cover downward to zero
degree, and the storage box will be closed.
Opening/Closing the Cover
This screwdriver is equipped with a Type-C charging port, and a USB
charging cable is included.
Illustrations of the product, accessories, and user interface in the user
manual are for reference purposes only.
Due to product updates and upgrades, the actual product may be slightly
dierent from the schematic. Please refer to the actual product.

18
A part of the nger may be clipped if the
storage box cover is being turned upward
too fast. Don’ t insert your nger into the
position indicated in the gure during
opening and closing.
Please make sure the power of the live
equipment has been cut o before
using this product.
This product is not a toy and should
not be used by children. The
screwdriver should only be operated
by persons aged 16 years or older.
This product is intended for precision
maintenance. Please use the bit
matching with the screw during
operation. During manual operation,
please avoid excessive force to protect
the screw or bit from unnecessary
damage.
The torque indicated in the product
parameters is the torque of the
screwdriver, not the torque of the bit.
Precautions
Mind your hands during
opening/closing.

04 General Power Tool Safety Warnings
19
WARNING! Read all safety warnings, instructions, illustrations and specications provided
with this power tool. Failure to follow all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
Keep children and bystanders away while operating a powertool. Distractions can
cause you to lose control.
Work Area Safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
Electrical safety

20
When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the inuence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
Use personal protective equipment. Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the o-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energising power tools that
have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
Personal Safety

21
Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing
away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce
dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe
injury within a fraction of a second.
Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn it on and o. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the battery pack, if
detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
Power Tool Use And Care

22
Recharge only with the charger specied by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of re when used with another
battery pack.
Use power tools only with specically designated battery packs. Use of any other
battery packs may create a risk of injury and re.
When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together
may cause burns or a re.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
Battery tool use and care
Maintain power tools and accessories. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may aect the power tool's
operation. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations dierent from those intended could
result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool
in unexpected situations.

23
Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Never service damaged battery packs. Service of battery packs should only be
performed by the manufacturer or authorized service providers.
Service
Do not use a battery pack or tool that is damaged or modied. Damaged or modied
batteries may exhibit unpredictable behavior resulting in re, explosion or risk of
injury.
Do not expose a battery pack or tool to re or excessive temperature.
Exposure to re or temperature above 130°C may cause explosion.
Follow all charging instructions and do not charge the battery pack or tool outside
the temperature range specied in the instructions.
Charging improperly or at
temperatures outside the specied range may damage the battery and increase the
risk of re.
Hold the power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory or fasteners may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed metal parts of the power tool
“live” and could give the operator an electric shock.
Safety instructions for all operations

24
Never operate at higher speed than the maximum speed rating of the drill bit. At
higher speeds, the bit is likely to bend if allowed to rotate freely without contacting
the workpiece, resulting in personal injury.
Always start drilling at low speed and with the bit tip in contact with the workpiece.
At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting
the workpiece, resulting in personal injury.
Apply pressure only in direct line with the bit and do not apply excessive pressure.
Bits can bend causing breakage or loss of control, resulting in personal injury.
Safety instructions when using long drill bits
Secure the workpiece. A workpiece clamped with clamping devices
or in a vice is held more secure than by hand.
Always wait until the power tool has come to a complete stop before placing it down.
The application tool can jam and cause you to lose control of the power tool.
Switch the power tool o immediately if the application tool becomes blocked. Be
prepared for high torque reactions which cause kickback. The application tool
becomes blocked when it becomes jammed in the workpiece or when the power
tool becomes overloaded.
Use suitable detectors to determine if there are hidden supply lines or contact the
local utility company for assistance. Contact with electric cables can cause re and
electrical shock. Damaging gas lines can lead to explosion. Breaking water pipes causes
property damage.
Additional safety information

25
Hold the power tool securely. When tightening and loosening screws be prepared for
temporarily high torque reactions.
In case of damage and improper use of the battery, vapours may be emitted. The
battery can set alight or explode. Ensure the area is well ventilated and seek medical
attention should you experience any adverse eects. The vapours may irritate the
respiratory system.
Do not open the battery. There is a risk of short-circuiting.
The battery can be damaged by pointed objects such as nails or screwdrivers or by
force applied externally. An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
Only use the battery with products from the manufacturer. This is the only way in
which you can protect the battery against dangerous overload.
Protect the battery against heat, e.g. against continuous intense sunlight, re, dirt,
water and moisture. There is a risk of explosion and short-circuiting.
Power Adapter Output: 5V 0.14A Max.
Ambient Temperature while Charging: 1 to 40°C
All products bearing this symbol are waste electrical and electronic equipment
(WEEE as in directive 2012/19/EU) which should not be mixed with unsorted
household waste. Instead, you should protect human health and the
environment by handing over your waste equipment to a designated collection point for
the recycling of waste electrical and electronic equipment, appointed by the
government or local authorities. Correct disposal and recycling will help prevent
potential negative consequences to the environment and human health. Please
contact the installer or local authorities for more information about the location as
well as terms and conditions of such collection points.

26
We Shanghai HOTO Technology Co., Ltd., hereby, declares that this
equipment is in compliance with the applicable Directives and European Norms,
and amendments.
This supplier’s declaration of conformity is hereby for
We declare that the above mentioned device has been tested
and found in compliance with CFR 47 Part 15 Regulation.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Product: HOTO Electric Screwdriver Set
Model Number(s): QWLSD010
Brand/Trade: HOTO
Federal Communications Commission Supplier’s
Declaration of Conformity

27
Representative of Responsible Party for SDoC
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Company: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Putuo District, Shanghai, China
Country: China
Telephone No.: 400-021-8696

28
Troubleshooting
Fault
Bit cannot be
installed
Use an bit in C4
specications
Bit size doesn't match the
size of the bit holder
Battery won't
charge
The USB cable isn't
plugged in properly or
specied charging
voltage isn't being used
Check whether the
charging indicator is on,
insert the USB cable, and
use the charging voltage
specied in product
parameters.
Cause Solution
Maximum electric
torque 0.2N·m
Manually tighten/loosen
it (maximum manual
torque: 3N·m)
Screwdriver
Not work Low battery power Please charge the
equipment in time.
Rust on the surface
of bit
High moisture in
storage environment
Storage it in dry
environment, and apply
anticorrosive oil on the
surface of bit
Cannot loosen
the screws or
screw loose

Screwdriver Bit Parameters
Screwdriver
Bit specication: C4×L28 mm
Cross Head: PH000/PH00/PH0/PH1/PH2
Hex: H0.7/H0.9/H1.5/H2.0
Flat Head: SL1.5/SL2.0
Torx: T2/T3/T4
Torx with holes: T5H/T6H/T8H/T9H/T10H
Bit material: S2 alloy steel
Pentalobular: P2/P5
W Type: W1.5
Y Type: Y0.6
TW Type: TW1
Tri: 2.3
Maximum electric torque: 0.2 N.m
Maximum manual torque: 3 N.m
Input: 5 V 0.14 A
Rated Voltage: 3.7 V
Battery Type: Lithium-ion battery
Battery Capacity: 350 mAh
Rotation per Minute (Unloaded): 170 /min
Model: QWLSD010
Color: Dark Gray
Item Dimensions: Approx. 182×71.3×26.1 mm
Net Weight: Approx. 314 g
Screwdriver Dimensions: Approx. 159×Φ17 mm
Screwdriver NetWeight: Approx. 60 g
ChargingTime: 160-200 min
Declaration of the noise emission values according to EN 62841
(considered uncertainty 5 dB(A))
Sound pressure level: 46.0 dB(A)
Sound power level: 35.0 dB(A)
Declaration of the vibration emission according to EN 62841
(considered uncertainty 1.5 m/s²): 0.043 m/s²
05 Specications
29

Manufacturer: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No. 50, Moganshan Road, Shanghai,China
Information:
The declared vibration total value(s) and the declared noise emission value(s) have
been measured in accordance with a standard test method and may be used for
comparing one tool with another;
The declared vibration total value(s) and the declared noise emission value(s) may
also be used in a preliminary assessment of exposure.
Warning:
The vibration and noise emissions during actual use of the power tool can dier
from the declared values depending on the ways in which the tool is used especially
what kind of workpiece is processed; and
It is necessary to identify safety measures to protect the operator that are based on
an estimation of exposure in the actual conditions of use (taking account of all parts
of the operating cycle such as the times when the tool is switched o and when it is
running idle in addition to the trigger time).
The battery is not replaceable.
30

DECLARATION OF CONFORMITY
EU Declaration of Conformity
We
Shanghai HOTO Technology Co., Ltd.
Declare that the product:
HOTO Electric Precision Screwdriver Set / QWLSD010
Complies with the essential health and safety requirements of the following directives:
2014/30/EU Electromagnetic Compatibility directive References to the following harmonized
standard were made:
EN55014-1: 2017 + A11:2020
EN55014-2: 2015
EN IEC 61000-3-2:2019
EN 61000-3-3:2013+ A11:2019
20011/65/EU+ (EU) 2015/863 Restrictions of the Use of Certain Hazardous Substances in
Electrical and Electronic Equipment
Authorised signatory and technical le holder:
Shanghai HOTO Technology Co., Ltd.
Building 45, No.50 Moganshan Road, Shanghai, China
31
