Hotpoint RB792SRSA User instructions

26-3/8*
46-3/8
29-7/8
46-7/8
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
*Depth from wall
to front of closed
oven door.
Dimensions (in inches)
Listed by
Underwriters
Laboratories
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Note: 30" Electric Ranges conform to U.L. requirements for
0" spacing from walls below countertops. Allow 1-1/2" spacing
from the side of the range to adjacent vertical walls above the
cooktop surface.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against rear wall.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
*Dimension from wall to front of closed oven door.
Dimension from wall to the front of closed oven
door handle is 28-1/2".
†The range may be placed with
0" clearance (flush) at the back
wall and side walls if the range
side trims extend beyond the
cabinet fronts at least 1/4".
Self-Clean models only
Amp Rating
240V 10.5
208V 7.9
Breaker Size
40 Amps†
All Hotpoint ranges are equipped
with an Anti-Tip device. The
installation of this device is an
important, required step in the
installation of the range.
26-3/8*
46-3/8
1/4†
29-7/8
46-1/2
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
RB792SR– Hotpoint 30" Free-Standing Electric Range
Specification Revised 1/11
420416

Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing
• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning quick and easy
• 6 "/9"Dual Elements (2) – Choose a 6"or 9"heating element to accommodate the size
of your pan
• Fifth Element Warming Zone - Simplify meals by keeping foods fresh from the oven warm
and ready to serve
• Super-Large Oven Capacity - Provides an impressively large oven interior for cooking
more dishes and large meals at one time
• Electronic Oven Controls - One-touch electronic pads are easy-to-use and allow
for simple oven operation
• Hidden Bake Oven Interior - Conceals the lower oven bake element to eliminate hard-to-reach
areas that collect food and spills for easy cleaning
• Hot Surface Indicator Lights - Cooktop lights let you know when the surface is hot
• Model RB792SRSA – Silver metallic
RB792SR– Hotpoint 30" Free-Standing Electric Range
Specification Revised 1/11
420416
RB792DR
MED
Warming Zone
BurnerOn
BurnerOn
