RGB508PEH – Hotpoint 30" Free-Standing Gas Range
All Hotpoint ranges are equipped
with an Anti-Tip device. The
installation of this device is an
important, required step in the
installation of the range.
Installation Information: Before
installing, consult installation
instructions packed with product
for current dimensional data.
Optional gas range
accessory drip pans:
(Available at additional cost)
To order these accessory drip pans,
call toll-free 800-626-2002.
24
30
8
4
92
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common
area for gas outlet and
electrical outlet
CERTIFIED
*Depth from wall to front of
closed oven door
Specification Created 4/03
Dimensions (in inches) 30" Gas Range Installation Information (in inches)
30
39-7/8
26-1/2*
46-3/8
36±1/4

RGB508PEH – Hotpoint 30" Free-Standing Gas Range
Features and Benefits
•Extra-Large Oven Capacity – Provides a large oven interior ideal for cooking more items
at once.
• All Purpose Burners – Deliver a wide range of heat output ideal for most cooking requirements.
• Standard Grates – Provide a sturdy and convenient cookware surface for everyday cooking.
• Lift-Up Cooktop – Cooktop lifts up for easy access to porcelain-enameled subtop.
• Easy Clean Subtop – Porcelain enameled subtop collects spills and messes for easy cleaning.
• Porcelain Oven Door – Offers a scratch-resistant porcelain coating for easy cleaning.
• Two Oven Racks – Feature a durable construction to help accommodate any size
or type of cookware.
•Model RGB508PEHWH – White (white door and black control panel)
•Model RGB508PEHCT – Bisque (bisque door and black control panel)
Specification Created 4/03
