Hotpoint RGB790DERWW User guide

RGB790DERWW – Hotpoint 30" Free-Standing Gas Range
Dimensions (in inches) 30" Gas Range Installation Information (in inches)
30
46-1/8
26-1/4*
46-3/8
36-1/4
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common area
for gas outlet and electrical outlet
*Depth from wall
to front of closed
oven door.
Installation Information: Before
installing, consult installation
instructions packed with product
for current dimensional data.
Optional gas range
accessory drip pans:
(Available at additional cost)
To order these accessory drip pans,
call toll-free 800-626-2002.
30
46-1/8
26-1/4*
46-3/8
36-1/4
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common area
for gas outlet and electrical outlet
*Depth from wall
to front of closed
oven door.
CERTIFIED
Specification Created 5/11
430171
All Hotpoint ranges are equipped
with an Anti-Tip device. The
installation of this device is an
important, required step in the
installation of the range.

RGB790DERWW – Hotpoint 30" Free-Standing Gas Range
Features and Benefits
•Self-cleanoven-Self-cleanallowsyoutospareyourselffromthetroubleandeffortit
takes to scrub the oven interior
•Extra-largeovencapacity-Enoughroomtocookanentiremealatonce
•Sealedcooktopburners-Burnerelementsaresealedtothecooktoptokeepfoodsand
liquid contained on the cooktop, making cleaning painless
•Performanceplusburner-This13,000BTUburnerelementprovidesthehighheatidealfor
frying or sautéing and fast heat-up
•Simmersetting-Simmersettingallowsforlow,evenheatdistributionfordelicatefoods
and sauces
•Allpurposeburners-All-purposeburnerdeliverstwolevelsofBTUoutputto
accommodate virtually all your cooking needs
•Twoovenracks-Includestwoovenracksthataresturdyandreliable
•Porcelainupsweptcooktop-Raisededgesandporcelain-enameledsurfacemakescleaning
incredibly easy
•ModelRGB790DERWW–Whiteinwhite
Specification Created 5/11
430171
RGB790DERWW
BROIL
SELF
CLEAN
OVEN
LIGHT
CLOCK
OVENCONTROLS TrueTemp
ON
TEMP
NORMAL
HI LO OFF
KITCHEN
TIMER
ON OFF
BAKE START
ON
CLEAR
OFF
TIMECONTROLS
COOKING
TIME
ON OFF
AUTOMATICOVEN
START
TIME
ON OFF
