Hotpoint HTM18GCSSA Manual

Specification Revised 8/07
410334
HTM18GCS – Hotpoint®18.2 Cu. Ft. Top-Freezer Refrigerator
Front View Top View
A
G
E
C
F
'94 TMNF Refer
B
D
H
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
Listed by
Underwriters
Laboratories
Note: Before installing, consult installation instructions packed with product
for current dimensional data.
Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your left and the
hinges are on your right.
All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your right and the
hinges are on your left.
Height to top of hinge (in.) A 67-3/8
Height to top of case (in.) B 66-7/8
Height to mid-freezer (in.) 57
Case depth without door (in.) C 26-3/4
Case depth less door handle (in.) D 30-1/2
Case depth with door handle (in.) E 32-3/8
Depth with fresh food door open 90° (in.) F 56-3/8
Width (in.) G 28
Width with door open 90° with door handle (in.) H 30-3/4
Each side (in.) 3/4
Top (in.) 1
Back (in.) 1
Air Overall
Clearances Dimensions

Specification Revised 8/07
410334
HTM18IBP
Features and Benefits
• Adjustable Glass Shelves - Lets consumers maximize usable storage space
• Upfront Temperature Controls - Are positioned up front, close at hand,
for maximum convenience and ease of use
• Factory-Installed Icemaker - Makes ice automatically ensuring a ready supply
• Vegetable/Fruit Crispers - For easy storage of your fruits and vegetables
• Gallon Door Storage - Makes room for milk and any other gallon size containers
• Square Doors - Classic design that's compatible with any kitchen décor
• NeverClean™Condenser - Condenser coils are encased, so they don't require
cleaning in normal operating environments
• Deluxe Quiet Design - Significantly reduces operating noise
• Model HTM18GCSSA – Silver metallic
HTM18GCS – Hotpoint®18.2 Cu. Ft. Top-Freezer Refrigerator
