Household Essentials Sunline 1710 User manual
5/2018
Outdoor
Umbrella Dryer
1710
©2017 HOUSEHOLD ESSENTIALS, LLC
Hazelwood, MO 63042
www.householdessential.com
Not happy?
Happy?
Thank you for your order!
Wonderful! We are very glad.
Please share your experience with
us and others. It helps us know
what you like best!
Please give our St. Louis
customer service a call at
1-800-922-5524.
We are here to help.
Customer Service
1-800-922-5524 | 1-314-428-5657
Open Mon-Fri at 8:30 am CT.
Closed all national holidays.
We appreciate your business. Additional information on your product
may be available on our website.
• Review this product at
www.householdessential.com.
Search the item # from the home
page to find the product. Leave your
review under the review tab on the
product’s page!
• Follow us on Facebook and
Instagram!
• Missing parts?
• Having trouble with assembly?
8"
20"
How to Use the Ground Sleeve
Installing Ground Sleeve
Concrete the ground sleeve into the ground instead of the dryer’s post!
Dig a tapered hole (wider at the bottom than at the
top) that is 8”- 10” wide and approx. 20” deep.
Fill the bottom of the hole approx. 3” deep with
small-medium sized rocks.
STEP 4
STEP 3
STEP 2
STEP 1
(A) Fill the hole with approx. 6” of concrete, up to the
base of the ground sleeve. (Clothesline will be 6’ above
ground level. Adjust sleeve depth as needed.)
(B) Place the ground sleeve and
fill in around the ground sleeve
with concrete up to within 1” of
ground level (remaining space
can be filled with topsoil after
concrete sets).
Insert the dryer pole into the ground sleeve and use a
level to align the pole vertically.
Remove the pole carefully (WITHOUT shifting the
ground sleeve).
Run a small tube or stick down through the center of
the ground sleeve, through the concrete, and to the
rock base (to allow draining).
Remove tube/stick and allow concrete to set.
FIRST TIME USE:
1. (BEST WITH 2 PEOPLE)
Lay umbrella on its side.
Depress buttons on both slides
at the same time and push
center pole down and flush
with top.
2. Insert lower pole into center pole.
3. Place in ground sleeve.
4. Open the dryer and tighten lines as needed.
Tightening Lines: Only tighten lines when dryer is open. Never over-tighten because
some slack is needed to open and close the dryer. Expect to tighten 2-3 times during first
months of use.
Opening the Dryer: Make sure lines are not tangled and not too tight. Both can make it
hard to open the dryer!
Taking the Dryer Down: Always take down during inclement weather. First, close the
dryer and tie lines together on either side of the center pole (you'll have 2 ties). Then,
remove the dryer from the ground sleeve and take it inside.
HEIGHT ADJUST:
1. Set the height of the
dryer with the top slide:
press the button and
slide the sleeve up or
down as desired.
2. Use the bottom slide
to open and close the
dryer.
GENERAL USE:
1. Only open the dryer
after it is securely set
up in the ground sleeve.
2. Press and hold the
button on the bottom
slide to open and close
the dryer.
3. Grasp the arms of the
dryer to spin the dryer.
4. Tighten lines as
needed. Always close
dryer after use and take
inside during inclement
weather.
Dryer Care & Use
Special Tips and Troubleshooting!
AB
CLOTHESLINE HEIGHT: The clotheslines will be 6 feet above
ground level when installed as instructed. To lower lines, please
bury the ground sleeve deeper in the concrete during step 2A.
Button
Center Pole
