Hovr Bracket System User manual
Using the Hovr Bracket System
QUICK INSTALLATION GUIDE
Cut male bracket to size needed. Male bracket should be 1"shorter than female bracket. Determine where the
studs are, mark them on male bracket. Take the 3/16" drill bit (included) and drill holes on top and bottom of
male bracket along die line.
Install female bracket to shelf using the 1"#10 Pan Head screws (please refer to the suggested installation
guide). Once the female bracket is installed into the shelf, take the 17/64"drill bit and make holes where you
want the set screws to be. On a 24 inch shelf we recommend 2 set screws, 3 inches in from each side.
Next take the tapping bit and tap (making threads). Any shelf longer
than 24 inches we recommend 3 set screws, 50 inches 4 set screws and
so on.
Now attach the male bracket level to the wall using the 2 1/2"#10 pan
head screws (4x). Click the shelf (female bracket) onto the wall bracket
(male).
Insert the set screws and tighten using the provided alan key. If you do
not want to use set screws you may opt to glue the female bracket to
the male bracket. You can use the E6000 or any other 2 component
metal epoxy, dap or silicone. Each of these has different holding strength.
This is a permanent installation and is hard to undo.
TOP
BOTTOM
Please Remember: One can compare it with a closed door. As long as you do not push the handle, the door will
not open. Using the set screw has the effect of locking the door. You can push as hard as you want, even push-
ing the door handle, it will not open. In this case of the shelf, pushing upwards is pushing the door handle.
We provided some E-Z Load drywall anchors, just in case you do not find 2 studs.
However the maximum load capacity will now be diminished.
If you install the male bracket only in drywall we recommend using an anchor every 3-4 inches.
If you need to install the male bracket to the wall encountering galvanized steel studs, please only use “1shot”
steel anchor (available on our website) in connection with the E-Z Load drywall anchors.
FURTHER QUESTIONS?
Consult our ‘Suggested Installation Guide’ or Contact Us (options on reverse page)
Accessory & Hardware Included for Aluminum Brackets
WHAT IS INCLUDED
What is included with your FIRST shipment:
1 x 17/64"HSS Steel Drill Bit
1 x 5/16"#18 HSS H3 BTM Tap Bit
1 x 3/16"Cobalt Drill Bit M35 High Speed Steel
x x 5/16"#18 SSS CP 3/4"Long Set Screws
(receive 1 per sq ft ordered)
1 x Corresponding Alan Key
1 x 1 Page Quick Installation Guide
1 x 1"#10 Pan Head Course Threaded Wood
Screws (Robertson/Zinc)
4 x 2 1/2"#10 Pan Head Normal Threaded Wood
Screws (Robertson/Zinc)
4 x EZ Load Anchor #8 Twist-N-Lock w/ screw
(75 lbs)
Since we do not know how you will cut your ordered length, the position of your studs, or the size of the
shelves you will make, we included the above mentioned screws. You can buy additional screws at any hard-
ware store or you can find them on our website.
For ordering the “1shot” steel stud anchor or some epoxy, please email us and we will send you some at a
small cost (plus shipping and handling). Alternatively, you can buy more set screws, or other parts, by visiting
the parts section on our website.
What is included with your SECOND/SUBSEQUENT shipments:
x x Male/Female Bracket (desired length)
x x 5/16"#18 SSS CP 3/4"Long Set Screws
(receive 1 per sq ft ordered)
1 x 1 1/4"Pan Head #8 Wood Screws
6 x 2 1/2"Pan Head #8 Wood Screws
These are included for you to get started and to know exactly what screws we recommend. You can buy this
hardware through our website or at any hardware store.
CONTACT INFO
#115 – 30600 Progressive Way, Abbotsford, BC, V2T 6Z2
Toll Free CAN/USA: (844) 574 2307 B.C. & Prairies: (604) 200 7736
Ontario & Maritime: (647) 493 2553 Quebec (French & English): (450) 499 2028
contact@hovrsolutions.com www.hovrsolutions.com
Thank you,
Hovr Strong Solutions inc.
