Hoyt 350 SVD User manual

Hoyt Electrical Instrument Works, Inc. www.hoytmeter.com
Phone: [phone]
Fax: [phone]
Email: [e-mail] Page 1 (2)
23 Meter Street
Penacook, NH 03303
Safety Voltage Detector
Model 350 SVD
Attached the detector on
your arm with the elastic
cord for voltage detection

160°
VG
350 SVD has a wider angle for
voltage detection (about 160°)
● Protection class: IP65
● Bright LED visual indication
● Audible indication
● Non-contact voltage detection: 220Vac ~ 132kVac
● Wide angle voltage detection
● Frequency range: 40 ~ 70Hz
● Easy-to-prove method
● Self-test function
● Power source: 9V rechargeable battery
● Non-contact detection by proximity
● Flashlight function
● Operating temperature: 0°C~50°C
● Humidity: 80% RH Max
● Lightweight, robust and compact
● Comply with EN 61326-1
Features
IP65

Hoyt Electrical Instrument Works, Inc. www.hoytmeter.com
Phone: [phone]
Fax: [phone]
Email: [e-mail] Page 2 (2)
23 Meter Street
Penacook, NH 03303
Safety Voltage Detector
Model 350 SVD
Instruction manual
AC adapter
Elastic cord
Bracket
Carry case
Tape (2 pcs)
Accessories
● AC Voltage detection: 220Vac ~ 132kVac
● Frequency range: 40 ~ 70 Hz
● Operating temp.: 0°C ~ 50°C
● Operating humidity: 80% R.H. Max.
● Weight: Approx. 137g ((battery included)
● Dimension: 110(L) × 68(W) × 35(D)mm
● Power source: 9V Rechargeable battery
● Safety standard: EN 61326-1
Specifications
(1) ON/OFF switch
(2) SELF TEST button
(3) Flashlight
(4) Rotatable part for flashlight
3 different angles can be set by rotating this part.
(5) Visual alert LEDs
(6) Buzzer
High noise level buzzer triggered on voltage detection.
(7) CHARGE LED
● When this LED glows "red", which means the
detector is under charging
● When this LED glows "green", which means
the charging process is complete. The 9V
rechargeable battery is fully charged.
(8) Bracket
(9) Battery−charge socket - for AC adapter connection.
(10) Flashlight switch
● Switch to the upper position to turn on the flashlight.
● Switch to the lower position to turn off the flashlight.
(11) Protection cover
For flashlight switch and battery-charge socket.
(12) Elastic cord - for attached into the bracket.
(12)
(9)
(10)
(11)
(8)
(4)
(5)
(6)
(7)
(1)
(2)
(3)
