Hozelock 2550 Operating instructions

How to use the Pulsating Sprinkler (2550)
Setup
Start by pushing the metal spike firmly all the way into the
ground, in the centre of the area to be watered (A), or placed
in the middle of one side (B).
This product is best placed into a lawn or the soil of a garden bed.
A B
Push the sprinkler down, ideally with two
hands, holding on to the bottom parts of
the sprinkler, as shown. Take care not to
push down on the top of the sprinkler.
Next, with the water supply turned o, connect your hose connector.
It is now ready to use and will start spraying water when you turn on the tap.
Please note: This image is not to scale.

Sprinker Controls
1. Diuser Screw
This small red screw works by breaking up the
stream of water.
Turn it anti-clockwise until it is completely out of
the stream and the sprinkler will produce a single
jet of water with maximum distance.
Turn it clockwise until it is in the stream of water
and the sprinkler will produce a wide, dispersed
flow of water with a shorter distance.
2. Deflector Dial
The red dial on the top of the sprinkler adjusts the
angle of the yellow deflector. It is marked with jet
and fan symbols.
Turning the dial towards the jet symbol will allow
the water to travel the full distance uninterrupted.
Use this to water large lawns.
Turning the dial towards the fan symbol will
deflect the water downwards and outwards. Use
this to water nearby flowerbeds.
3. Arc Adjusters & Trip Lever
The two red arc adjustment rings and the small
metal trip lever work together to set the motion of
the spray head.
If you want to water in a continuous 360° circle,
flip the metal trip lever upwards, away from the
red rings. This will allow the spray head to rotate
freely without stopping.
If you want to water only part of a circle, for
example, a semi-circle, flip the metal trip lever
downwards, into the red ring area. Then, slide the
red rings left or right to set the arc area. The arc
adjusters move independently of each other to
set each side of the desired arc.

Troubleshooting
No water coming out
If no water is coming out of the sprinkler, check that your tap is on and that water is
coming through the hose by disconnecting the sprinkler from your hose and attaching
another accessory such as a spray gun.
1. Ensure the sprinkler is pushed all the way into the ground, so that the hose connector is
only just above the ground. If the sprinkler is too high, it will vibrate and these vibrations
can prevent the sprinkler from rotating.
2. This sprinkler also requires good water pressure. Use the shortest possible length of hose
from the tap to the sprinkler. Enure the tap is turned all the way on and is not restricted
by any valves or Y connectors.
Does not rotate/does not rotate reliably
If the sprinkler continues to operate incorrectly, please contact our Consumer Service
team by emailing [email protected].
