The HP Ethernet 1Gb 4-port 331FLR Adapter for select HP ProLiant Gen8 rack servers features the next generation of Ethernet
integration, offering a single-chip solution in a FlexibleLOM form factor, which offers the option for future upgrades to 10GbE
networking speeds. It delivers full line-rate performance across all ports with low power consumption.
The HP 331FLR is ideal for virtualization, security, server consolidation, network segmentation, and other applications requiring
maximum throughput and port density. The total aggregate throughput of 4Gb meets the needs of customers desiring high bandwidth.
The HP 331FLR supports advanced features such as Large Send and Receive offload capability, TCP checksum and segmentation, VLAN
tagging, MSI-X, jumbo frames, IEEE 1588, HP Sea of Sensors 3D and virtualization features such as VMware NetQueue and Microsoft
VMQ.
Support for HP Sea of Sensors 3D Technology enhances server performance while reducing energy use and expense.
Models
HP Ethernet 1Gb 4-port 331FLR Adapter 629135-B21
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Overview
DA - 14214 North America — Version 9 — September 10, 2013 Page 1

Kit Contents HP 331FLR FlexibleLOM adapter
Quick install card
Product warranty statement
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Overview
DA - 14214 North America — Version 9 — September 10, 2013 Page 2

Servers ProLiant DL (rack-optimized) :
HP ProLiant DL160 Gen8
HP ProLiant DL360p Gen8
HP ProLiant DL380p Gen8
HP ProLiant DL385p Gen8
HP ProLiant DL560 Gen8
ProLiant SL (scalable) :
HP ProLiant SL210t Gen8
HP ProLiant SL230s Gen8
HP ProLiant SL250s Gen8
HP ProLiant SL270s Gen8
NOTE: This is a list of supported servers. Some servers may be discontinued.
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Compatibility
DA - 14214 North America — Version 9 — September 10, 2013 Page 3

Performance
Product Features FlexibleLOM for select HP Gen8 Rack servers
Industry-leading hardware integration for low power
Quad-port 1GbE provides up to 8Gb/s full duplex throughput per adapter
Energy Efficient Ethernet (EEE) support
Optimized for virtual servers
Improved small packet performance
Support for Preboot eXecution Environment (PXE)
Quad-port 1 Gigabit
Ethernet Throughput
The HP 331FLR adapter provides 2,000 Mbps full duplex Ethernet transfer rate per port (8 Gbps aggregate
full duplex) delivers outstanding network performance that improves response time and removes
bottlenecks. With a theoretical throughput of 1 Gbps each direction, the x4 PCI Express bus is more than
capable of supporting the 331FLR's four gigabit ports. Four ports on a single adapter are ideal for high
density, I/O slot constrained servers, virtualization and security, applications, server consolidation, and
increased network segmentation. The total aggregate throughput of 4Gbps also meets the needs for
customers desiring high bandwidth but are not yet ready to move to 10 Gigabit Ethernet.
NOTE: Port enumeration on the 331FLR is from the bottom up, i.e. the port closest to the gold teeth is port
#1 and the port near the top of the adapter is port #4
Jumbo Frames The HP 331FLR FlexibleLOM supports jumbo frames, permits up to a 9K byte (KB) transmission unit (MTU)
when running Ethernet, which is over five times the size of standard 1500-byte Ethernet frame. Jumbo
frames can help achieve higher throughput and better CPU utilization and are particularly useful for
database transfer and tape backup operations.
MSI and MSI-X Up to 17 Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by
load balancing interrupts between CPUs/cores.
802.1Q VLANs IEEE 802.1Q virtual local area network (VLAN) protocol allows each physical port of the HP 331FLR to be
separated into multiple virtual NICs for added network segmentation and enhanced security and
performance. VLANs increase security by isolating traffic between users. Limiting the broadcast traffic to
within the same VLAN domain also improves performance.
TCP/IP Stateless
Offloading
For overall improved system response, the HP 331FLR supports TCP, IP, UDP checksum offload, Large
Send Offload (LSO), TCP, and Segmentation Offload (TSO). These features optimize host efficiency, leaving
the CPU available for other duties
Time synchronization
(IEEE 1588)
Hardware assist for IEEE 1588 and IEEE 802.1AS time synchronization implementations for time sensitive
applications.
Optimized for
Virtualization
I/O Virtualization support for VMware NetQueue and Microsoft VMQ help meet the performance demands
of consolidated virtual workloads.
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Standard Features
DA - 14214 North America — Version 9 — September 10, 2013 Page 4

SR-IOV The HP 331FLR does not support SR-IOV ( Single Root - Input Output Virtualization)
Energy Efficient Ethernet Compliant with IEEE 802.3az, featuring advanced power savings features throttles power usage with
network load activity.
HP Sea of Sensors 3D Support for HP Sea of Sensors 3D which is a collection of 32 sensors that automatically track thermal
activity - heat - across the server. When temperatures get too high, sensors can kick on fans and make
other adjustments to reduce energy usage. What makes it better is the upgrade from all six fans kicking on
at one time to a new system where only one kicks on - the one in proximity of the area that started heating
up - thus reducing the amount of energy used for cooling.
Versatility
10/100/1000T Twisted
Pair Networks
In addition to Gigabit Ethernet, the 331FLR adapter supports both 10Mbps and 100Mbps providing
compatibility with Ethernet and Fast Ethernet twisted pair networks.
FlexibleLOM slot
Compatibility
The HP 331FLR is compatible only with HP FlexibleLOM slot available on select HP ProLiant Gen8 Rack
servers
PCI Express Compatibility The PCI Express interface on the 331FLR is mechanically compatible with x8 and x16 PCI Express slots but
has a different connector pin out than a standard PCI Express slot. When installed in a x8 or x16 slot, the
adapter will operate at the x4 speed.
High Availability
Network Adapter Teaming ProLiant Network Adapter Teaming provides fault tolerance and load balancing across a team of two or
more network adapters. The team of adapters works together as a single virtual adapter. The HP 331FLR
FlexibleLOM provides Support for several different types of teaming.
The teaming options offer IT professionals an easy, efficient, and cost-effective way to provide network
fault tolerance and increased network bandwidth. For more information, refer to the ProLiant Network
Adapter Teaming Whitepaper available at:
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c01415139/c01415139.pdf
Network Management
Auto-negotiation The HP 331FLR automatically senses the speed of the device to which it is attached. It also automatically
configures for full duplex, depending on the duplex mode of the switch, hub, or router connected to the
adapter.
Management Support Like all HP server adapters, the HP 331FLR ships with drivers and agents that can be managed from HP
Systems Insight Manager, as well as using any other management application that supports SNMP. HP
Systems Insight Manager can recognize the 331FLR individually or in teams, and can collect and report
SNMP statistics on the adapter events.
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Standard Features
DA - 14214 North America — Version 9 — September 10, 2013 Page 5

Server Integration The HP 331FLR is a completely integrated, tested, and qualified solution that is optimized for HP servers.
HP validates a wide variety of major operating systems drivers with the network drivers plus provides
central interface to simplify network management.
Configuration Utilities Each HP 331FLR ships with a suite of operating system-tailored configuration utilities that allow the user
to enable initial diagnostics and configure adapter teaming. This includes a patented teaming GUI for
Microsoft Windows operating systems. Additionally, support for scripted installations of teams in a
Microsoft Windows environment allow for unattended OS installations.
LED Indicators Per port LED indicators show link integrity, network activity, and network speed for easy troubleshooting.
Colored LEDs on each port of the HP 331FLR adapter indicate network activity, and network link speed.
Green link LED indicates 10/100/1000Mb speed.
PXE Support for pre-boot execution environment (PXE) enables automatic deployment of computing resources
remotely from anywhere. It allows a new or existing server to boot over the network and download
software, including the operating system, from a management/ deployment server at another location on
the network. Additionally, PXE enables decentralized software distribution and remote troubleshooting
and repairs.
Warranty
Warranty Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Standard Features
DA - 14214 North America — Version 9 — September 10, 2013 Page 6

Service and Support HP Technology Services
HP Technology Services offers you consultants and support experts to solve your most complex
infrastructure problems. We help keep your business running, boost availability, and avoid downtime.
Protect your business beyond warranty with HP Care Pack Services
When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care
Pack services provide total care and support expertise with committed response choices designed to meet
your IT and business need.
HP Foundation Care services deliver scalable support-packages for HP industry-standard servers and
software. You can choose the type and level of service that is most suitable for your business needs. New
to this portfolio is HP Collaborative Support. If you are running business critical environments, HP offers
Proactive Care or Critical Advantage. These services help you deliver high levels of application availability
through proactive service management and advanced technical response.
Here is the support service recommendation from the Foundation Care and Proactive Care portfolio. For
customized support service solution, HP can work with you to tailor a service solution for your unique
support requirements using broader services portfolio of Foundation Care and Proactive Care.
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended Services 3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an HP authorized representative who will arrive on
site any time and day of the year to begin hardware maintenance service within 4 hours of the service
request being logged.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
OR
3-Year HP 24x7 4 hour Response, HP Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution, and
basic software problem diagnosis, fault isolation, and resolution if available to HP. If the problem is with
HP HW, the representative will arrive on site any time and day of the year to begin hardware maintenance
service within 4 hours of the service request being logged. In case, the issue is with HP or supported third-
party software product and cannot be resolved by applying known fixes, HP will contact the third-party
vendor and create a problem incident on your behalf.
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Service and Support
DA - 14214 North America — Version 9 — September 10, 2013 Page 7

Related HP Care Pack Services to enhance your HP product experience
Related Services 3-Year HP 24x7 4 hour Response, Proactive Care or Critical Advantage
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue
end to end until resolved, delivering a single point of contact for you
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-2140ENW.pdf
OR
3-Year HP 6-hour Onsite Call-to-Repair, HP Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to
return the hardware in operating condition within 6 hours of the initial service request to the HP Global
Solution Center, and basic software problem diagnosis, fault isolation, and resolution if available to HP. In
case, the issue is with HP or supported third-party software product and cannot be resolved by applying
known fixes, HP will contact the third-party vendor and create a problem incident on your behalf.
HP Proactive Select Service
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next
12 months. http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN.pdf
Insight Remote Support Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App * allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
*HP' Support Center Mobile App is subject to local availability
Parts and materials HP will provide HP-supported replacement parts and materials necessary to maintain the covered
hardware product in operating condition, including parts and materials for available and recommended
engineering improvements. Supplies and consumable parts will not be provided as part of this service;
standard warranty terms and conditions apply. Parts and components that have exceeded their maximum
supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating
manual or the technical product data sheet will not be provided, repaired or replaced as part of this service.
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Service and Support
DA - 14214 North America — Version 9 — September 10, 2013 Page 8

Warranty / Service
Coverage
For ProLiant servers and storage systems, this service covers HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have
not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on services for HP ESSN Options, please contact your HP sales representative or HP
Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant or
www.hp.com/services/bladesystem
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Service and Support
DA - 14214 North America — Version 9 — September 10, 2013 Page 9

Gigabit Server Adapters HP NC112T PCI Express Gigabit Server Adapter 503746-B21
HP NC360T PCI-E Dual Port Gigabit Server Adapter 412648-B21
HP NC364T PCI-E Quad Port Gigabit Server Adapter 435508-B21
HP NC365T 4-port Ethernet Server Adapter 593722-B21
HP NC373T PCI-E Multifunction Gigabit Server Adapter 394791-B21
HP NC373F PCI-E Multifunction 1000SX Gigabit Svr Adapter 394793-B21
HP NC375T PCI Express Quad Port Gigabit Server Adapter 538696-B21
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter 458492-B21
HP Ethernet 1Gb 4-port 331T Adapter 647594-B21
HP Ethernet 1Gb 2-port 332T Adapter 615732-B21
HP Ethernet 1Gb 2-port 361T Adapter 652497-B21
10 Gigabit Server
Adapters
NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
adapter.
HP NC522SFP Dual Port 10GbE Gigabit Server Adapter 468332-B21
HP NC523SFP 10Gb 2-port Server Adapter 593717-B21
HP NC524SFP Dual Port 10GbE Module
NOTE: NC524SFP is available only on DL370 G6, ML370 G6, DL580 G7, DL585 G7, and
DL980 G7.
489892-B21
HP NC550SFP Dual Port 10GbE Server Adapter 581201-B21
HP NC552SFP 10Gb 2-port Ethernet Server Adapter 614203-B21
HP Ethernet 10Gb 2-port 530SFP Adapter 652503-B21
HP Ethernet 10Gb 2-port 530T Adapter 656596-B21
HP Ethernet 10Gb 2-port 560SFP+ Adapter 665249-B21
HP Ethernet 10Gb 2-port 561T Adapter 716591-B21
HP Ethernet 10Gb 2-port 570SFP+ Adapter 718904-B21
FlexibleLOM Adapters NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
adapter.
Ethernet Adapters
HP Ethernet 1Gb 4-port 366FLR Adapter 665240-B21
HP Ethernet 10Gb 2-port 530FLR-SFP+ Adapter 647581-B21
HP Ethernet 10Gb 2-port 560FLR-SFP+ Adapter 665243-B21
HP Ethernet 10Gb 2-port 561FLR-T Adapter 700699-B21
HP Ethernet 10Gb 2-port 570FLR-SFP+ Adapter 717491-B21
FlexFabric Adapters
HP FlexFabric 10Gb 2-port 526FLR SFP+ Adapter 629138-B21
HP FlexFabric 10Gb 2-port 533FLR-T Adapter 700759-B21
HP FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter 700751-B21
HP FlexFabric 10Gb 2-port 554FLR-SFP+ Adapter 629142-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information: www.hp.com/go/ProLiantNICs
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Related Options
DA - 14214 North America — Version 9 — September 10, 2013 Page 10

General Specifications Network Processor Broadcom BCM5719 chipset
Data rate Four 1GbE ports, each at 2 Gbps full duplex; 8 Gbps aggregate full duplex
theoretical bandwidth. 10/100/1000 Mbps, Full-duplex
Data path Four lane (x4) PCI Express, mechanically compatible with x8, and x16 PCI
Express slots
On-board buffer memory 276 MB
Bus type PCI Express v2.0 (Gen 2 x4) (FlexibleLOM slot)
Interrupt levels Automatically configured
Connector RJ-45 (Four)
Cable distance Up to 328 ft (100 m)
Wiring Category 5 (CAT-5) or better twisted-pair cabling
Dimensions 11.75 cm x 7.62 cm [4.626 in x 3.0 in (L x W)] (without bracket)
IEEE Compliance 802.3, 802.3ab, 802.3u, 802.3x, 802.3ad, 802.1q, 802.3az, 1588, 802.1as
Form factor FlexibleLOM
Power and Environmental
Specifications
Operating Temperature 32° to 131° F (0° to 55° C)
Humidity 10% to 90% non-condensing
Non-operating Temperature -85° to 185° F (-65° to 85° C)
Humidity 5% to 95% non-condensing
Power requirement 5.5W Maximum
Emissions classification Class B
Agency approvals USA FCC Part 15 Class B
Canada ICES=--3, Issue 4
Japan VCCI V3 (2010.04) Class B
Korea KN22 Class B, KN24
Australia EN55022:2006+A12007 class B
International EN55022:2006 + A1:2007 Class B
EN55024:1998+A1:2011+A2; EN61000-3-2:2006,
EN61000-3-3:2008
RoHS Compliance 6 of 6
Safety UL Mark (USA and Canada)
CE Mark
EN 60590-1
Operating System
Support
Microsoft Windows Server 2008 (32/64), Enterprise, Web, Embedded, and R2
Microsoft Windows HPC Server 2008
Microsoft certified miniport and teaming drivers
Microsoft Windows 2008 Standard (32 and x64)
Microsoft Windows 2008 Enterprise (32 and x64)
Microsoft Windows Small Business Server 2011 (SBS V7) - base
Microsoft Windows Small Business Server 2011 Essentials
RHEL 5.7 x86 and AMD 64 & EM 64T
RHEL 6.1 x86 and AMD 64 & EM 64T
SLES10: x86 and AMD 64 & EM 64T
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Technical Specifications
DA - 14214 North America — Version 9 — September 10, 2013 Page 11

SLES 11: x86 and AMD 64 & EM64T
Solaris 10
VMware ESX/ESXi 4.1, ESXi 5.0 and ESXi 5.1
Citrix
HyperV (Windows Server 2008 32 and 64)
NOTE: For more Linux OS support & certification information, please visit the ProLiant & Bladesystem
Server Linux matrix: http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html
Environment-friendly
Products and Approach
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to:
http://www.hp.com/go/green . To recycle your product, please go to:
http://www.hp.com/go/green or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/green . These instructions may be
used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2013 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Windows is a US registered trademark of Microsoft Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP Ethernet 1Gb 4-port 331FLR Adapter
Technical Specifications
DA - 14214 North America — Version 9 — September 10, 2013 Page 12
