HP Brio BA200 User manual

www.hp.com/go/briosupport
Brio Guide
Business PCs
HP
Setting Up
Getting Started
Fixing Problems
Adding Components ...
BrioGuide.book Page 1 Wednesday, September 1, 1999 1:24 PM

Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and fitness for
a particular purpose. Hewlett-Packard shall not be liable for errors contained herein
or for incidental or consequential damages in connection with the furnishing,
performance, or use of this material.
This document contains proprietary information that is protected by copyright. All
rights are reserved. No part of this document may be photocopied, reproduced, or
translated into another language without the prior written consent of
Hewlett-Packard Company.
Adobe™ and Acrobat™ are trademarks of Adobe Systems Incorporated.
Microsoft®, MS-DOS®, Windows® and Windows NT® are U.S. registered trademarks
of Microsoft Corporation.
Celeron™ is a trademark and Pentium® is a registered trademark of Intel
Corporation.
Hewlett-Packard France
Business Desktop Division
5, avenue Raymond Chanas - Eybens
38053 Grenoble Cedex 9
France
© 1999 Hewlett-Packard Company
BrioGuide.book Page 2 Wednesday, September 1, 1999 1:24 PM

i
Information on Your PC
Brio Guide
This manual will help you:
• Set up and begin using your HP Brio PC for the first time
• Troubleshoot your PC
• Upgrade and replace components in your PC
• Find out where to get more information.
Where to Find Information
Your PC’s Online Brio Center
HP Brio Center - Use this online information center to access information on using
your PC, using Windows, and fixing problems with your PC. You can also use the HP
Brio Center to access the HP Brio support web site. For more information, refer to
“Easy Access to Information with the Brio Center” on page 12.
HP Brio Internet Center (available in some countries only)- Click on the HP Brio Internet
Center desktop shortcut or click on the button within the HP Brio Center to access a
range of Web-based information and services. For more information, refer to“Get
Connected with the HP Brio Internet Center” on page 13.
Information on the HP Brio Support Web Site
The HP Brio support web site (www.hp.com/go/briosupport) contains a wide
range of information, including:
• downloadable documentation
• service and support options
• the latest versions of drivers and utilities
• BIOS updates
• answers to Frequently Asked Questions.
Manuals for your PC
In the Manuals section of the HP Brio support site
(www.hp.com/go/briosupport), you can download documentation for your
PC. Documents provided are in Adobe Acrobat (PDF) format.
BrioGuide.book Page i Wednesday, September 1, 1999 2:37 PM

ii
Important Safety Information
For your safety, never remove the PC’s cover without first removing the power cord and any
connection to a telecommunications network. Always replace the cover before switching the
PC on again.
For your safety, always connect equipment to a grounded electrical wall outlet. Always use a
power cord with a properly grounded plug, such as the one provided with the equipment, or
one in compliance with your national safety standards. The equipment can be disconnected
from the power by removing the power cord from the power outlet. This means the equipment
must be located close to an easily accessible electrical outlet.
To avoid electrical shock, do not open the power supply. There are no user-serviceable parts
inside.
There is a danger of explosion if the battery is incorrectly installed. For your safety, never
attempt to recharge, disassemble or burn an old battery. Only replace the battery with the
same or equivalent type, as recommended by the manufacturer. The battery in this PC is a
lithium battery that does not contain any heavy metals. Nevertheless, in order to protect the
environment, do not dispose of batteries in household waste. Please return used batteries
either to the shop from which you bought them, or to the dealer from whom you purchased
your PC, or to HP, so that they can either be recycled or disposed of in the correct way.
Returned used batteries will be accepted free of charge.
Do not attempt to connect this product to the phone line during a lightning storm. Never
install telephone jacks in wet locations unless the telephone line has been disconnected at the
network interface. Never touch uninsulated telephone wires or terminals unless the telephone
line has been disconnected at the network interface. Use caution when installing or modifying
telephone lines. Avoid using a telephone (other than a cordless type) during a lightning storm.
There may be a risk from lightning. Do not use the telephone to report a gas leak in the vicinity
of the leak. Never touch or remove the communications board without first removing the
connection to the telephone network.
BrioGuide.book Page ii Wednesday, September 1, 1999 2:37 PM

Contents
iii
Contents
1 Setting Up Your Brio ................................................................. 1
Unpacking the Computer and the Monitor .....................................................2
Choosing a Comfortable Workspace .................................................................2
Connecting a Mouse, Keyboard, Power Cords and Monitor ..................3
Connecting Other Equipment to Your PC ...................................................... 4
Starting Up the PC ..................................................................................................... 6
Setting Up Windows for the First Time .............................................................. 6
The HP Brio Center .....................................................................................................7
2 Getting Started with Brio......................................................... 9
Using Your PC’s Desktop ...................................................................................... 10
Easy Access to Information with the Brio Center ........................................12
Using Your Software .................................................................................................16
3 If You Have a Problem............................................................ 17
What to Do First ..........................................................................................................18
Troubleshooting Quick Reference ....................................................................19
HP Hardware Diagnostics (DiagTools) .......................................................... 20
Brio Assist CD-ROM ............................................................................................... 20
Your PC’s BIOS ..........................................................................................................22
HP Setup Program ...................................................................................................22
Troubleshooting Help Zone ...............................................................................24
Support and Information Services ....................................................................41
4 Upgrading and Replacing Brio Hardware ......................... 43
Important - Before You Start .............................................................................. 44
Inside the Computer ...............................................................................................45
Removing and Replacing the Cover .............................................................. 46
Accessing or Replacing the System Board ..................................................48
Cables and Connectors in Your PC ..................................................................51
Replacing a Processor ..........................................................................................52
BrioGuide.book Page iii Wednesday, September 1, 1999 2:37 PM

Contents
iv
Replacing the Floppy Drive .................................................................................53
Replacing the Hard Drive ......................................................................................55
Installing an Expansion Bay Drive ....................................................................57
Installing a Memory Module ..............................................................................60
Installing an Expansion Card .............................................................................. 61
Replacing the Power Supply Unit .................................................................... 62
Replacing the Battery ............................................................................................ 63
5 Working in Comfort................................................................ 65
About Repetitive Strain Injury ............................................................................66
Preparing Your Work Environment ...................................................................67
Setting Up Your HP Computing Equipment ...............................................70
Comfort and Safety Checklist ........................................................................... 74
6 Technical Information............................................................. 77
Technical Characteristics .......................................................................................78
Clearing Your PC’s CMOS (BIOS) Settings .................................................. 79
Regulatory and Software License Information .................81
Regulatory Information ........................................................................................ 82
HP Software License Agreement ....................................................................... 85
Index .......................................................................................... 87
BrioGuide.book Page iv Wednesday, September 1, 1999 2:37 PM

Setting Up Your Brio
Setting Up Your Brio
This chapter describes how to set up and begin working with your
HP Brio PC.
Unpacking the Computer and the Monitor ........................ page 2
Choosing a Comfortable Workspace ................................ page 2
Connecting a Mouse, Keyboard, Power Cords and Monitor .. page 3
Connecting Other Equipment to Your PC ......................... page 4
Setting Up Windows for the First Time .............................. page 6
The HP Brio Center ....................................................... page 7
1
BrioGuide.book Page 1 Wednesday, September 1, 1999 2:37 PM

2
Unpacking the Computer and the Monitor
Unpacking the Computer and the Monitor
Remove the computer and the monitor from their boxes. When you have finished
unpacking the boxes, you will find the items shown here. Your monitor or keyboard
may be different from the ones shown here.
Choosing a Comfortable Workspace
Choose a workspace for your computer near a grounded electrical wall outlet.
If your monitor has a tilt-swivel base, attach it to the monitor as described in the
monitor manual. Position the monitor on your desk.
Position the computer to allow proper ventilation and access to the cables.
Warning If you are in any doubt that you can lift the equipment safely, do not try to move it
without help.
Monitor
Monitor cable Power cord
Brio Guide
Mouse
Keyboard
Brio Assist CD-ROM
BrioGuide.book Page 2 Wednesday, September 1, 1999 2:37 PM

3
Connecting a Mouse, Keyboard, Power Cords and Monitor
Connecting a Mouse, Keyboard, Power Cords
and Monitor
Before starting up the PC, connect devices and power cords to the rear of the PC as
shown below:
Caution Check that the correct power supply voltage is selected for your country (the voltage is
set during manufacturing and should already be correct).
Note
* If you have installed an expansion video card you must connect your monitor to the
connector on the video card and not to the monitor connector shown above.
All connectors can go in one way only.
Power connector
Keyboard
Monitor*
Mouse
Voltage selector
BrioGuide.book Page 3 Wednesday, September 1, 1999 2:37 PM

4
Connecting Other Equipment to Your PC
Connecting Other Equipment to Your PC
To use external devices such as a printer, scanner, digital camera or modem, connect
device cables to the rear of your PC as shown below:
Microphone
Line In
Headphones
modem
2 USB devices
Serial devices
P
PP
Pa
aa
ar
rr
ra
aa
all
llll
lle
ee
el
lll c cc
co
oo
on
nn
nn
nn
ne
ee
ec
cc
ct
ttto oo
or
rr
r
(for a printer or
scanner)
BrioGuide.book Page 4 Wednesday, September 1, 1999 2:37 PM

5
Connecting Other Equipment to Your PC
Warning
If your PC is a multimedia model, or if you have installed a sound card in your PC,
always turn the volume down before connecting headphones or speakers to avoid
discomfort from unexpected noise or static. Listening to loud sounds for prolonged
periods of time may permanently damage your hearing. Before putting on
headphones, place them around your neck and turn the volume down. When you put
the headphones on, slowly increase the volume until you find a comfortable listening
level. When you are able to hear comfortably and clearly, without distortion, leave the
volume in that position.
If you have a modem:
Do not attempt to connect this product to the telephone line during a lightning storm.
Never install telephone jacks in wet locations unless the telephone line has been
disconnected at the network interface. Never touch uninsulated telephone wires or
terminals unless the telephone line has been disconnected at the network interface.
Use caution when installing or modifying telephone lines.
Avoid using a telephone (other than a cordless type) during a lightning storm. There
may be a risk from lightning. Do not use the telephone to report a gas leak in the
vicinity of the leak. All inputs and outputs are extra-safety low-voltage circuits, except
the telephone and line connectors, which are telecommunications network voltage
circuits. Always disconnect the host computer from any analog telephone circuits
before removing any covers. Never touch or remove the communications card without
first removing the connection to the telephone network.
BrioGuide.book Page 5 Wednesday, September 1, 1999 2:37 PM

6
Starting Up the PC
Starting Up the PC
To start the PC, press the On/Off button.
Setting Up Windows for the First Time
When your PC starts up for the first time, you will have to enter the unique Product
ID provided with Windows.
When prompted, simply type in the Product ID printed on the Microsoft Certificate of
Authenticity (provided with your Windows documentation).
On/Off
Button
Power On Status
Light
Hard Drive
Activity Light
BrioGuide.book Page 6 Wednesday, September 1, 1999 2:37 PM

7
The HP Brio Center
The HP Brio Center
When your Brio starts up it launches the HP Brio Center. This online application
contains the following links:
•HP Brio Internet Center (only available in some countries) - use to set up an Internet
connection, monitor Internet usage, create your own Web site and online store, or
access Web-based information of interest to the small business.
•Using your HP Brio PC - use to get advice on using your mouse, DVD and CD-RW
drives, if fitted. Also provides advice on working comfortably with your PC, and
allows you to access the Windows tour.
•Fix a Problem - use to troubleshoot your HP Brio PC.
•Register Now! - this allows you to register your PC electronically for support if your
PC has an Internet connection.
For more information on using the HP Brio Center, refer to page 12.
BrioGuide.book Page 7 Wednesday, September 1, 1999 2:37 PM

8
The HP Brio Center
BrioGuide.book Page 8 Wednesday, September 1, 1999 2:37 PM

Getting Started with Brio
2
This chapter describes how to use your PC’s desktop and the online HP Brio
Center preinstalled on your PC.
Using Your PC’s Desktop ................................................. page 10
Easy Access to Information with the Brio Center ................. page 12
Using Your Software ...................................................... page 16
Getting Started with
Brio
BrioGuide.book Page 9 Wednesday, September 1, 1999 2:37 PM

10
Using Your PC’s Desktop
Using Your PC’s Desktop
The Desktop
The desktop is where you can place various things — folders, files and shortcuts to
programs you use regularly. It is also the place where program windows are displayed,
such as the HP Brio Center window.
The Recycle Bin
This is a temporary storage place for files you have deleted. It fills up with all the
files you have deleted until you decide to empty it. You can use it to find things
you might have deleted by mistake.
Note
All the features described in this section are standard to Windows. For further details on
any of these features, together with details on general Windows functionality, please
refer to the relevant Windows documentation, or the Windows Help system.
Recycle
bin
Various
icons
Start
button
HP Brio
Center
Minimize Window
Maximize Window
Close Window
Desktop
Taskbar
Taskbar button Notification area
BrioGuide.book Page 10 Wednesday, September 1, 1999 2:37 PM

11
Using Your PC’s Desktop
Icons
Icons are small graphical objects that represent a particular feature,
area or application (program) on your computer. Double-clicking on
them opens that feature. They can be dragged around the desktop or placed in the
recycle bin.
The Taskbar
The taskbar is at the bottom of your window by default. It shows you which
applications are running — represented by a taskbar button (the taskbar below shows
that the HP Brio Center window is open).
The Start Button
Click on the Start button and a pop-up menu appears from which you can
perform many different tasks — start programs, open documents, find help,
search for things on your computer, and change settings within your computer.
Taskbar Buttons
Every time you open a program, a button for that program
appears on the taskbar. To switch between programs, simply
click on the taskbar button for the program you want.
Notification Area
Depending on what you are working on with your HP Brio PC,
small indicators may appear in the notification area (to the left of
the clock). If you are printing, for example, appears. Double-clicking on any of
these indicators brings up a window where you can change some of the settings. For
example, try double-clicking on and change your volume settings.
You can find out more about your Windows desktop by following the Windows Tour
(click on Using Your HP Brio PC - Windows Tour in the HP Brio Center) or by referring to
the Windows documentation supplied with your computer.
BrioGuide.book Page 11 Wednesday, September 1, 1999 2:37 PM

12
Easy Access to Information with the Brio Center
Easy Access to Information with the Brio Center
The Brio Center window is displayed when you first start up your PC. To stop the Brio
Center appearing every time, click on the check box in the Brio Center window. You
can then access the HP Brio Center by:
• double-clicking on the HP Brio Center shortcut on your PC’s Desktop, or
• selecting HP Brio Center in the Start menu.
The HP Brio Center helps you get the most out of your PC, quickly and efficiently —
letting you concentrate on your work, while at the same time being your first point of
reference for all questions you might have.
From the HP Brio Center you can access:
•HP Brio Internet Center (only available in some countries). Click on to connect to
the Internet and access Internet-based services tailored to the needs of the small
business. See ”Get Connected with the HP Brio Internet Center” on page 13 for
more details.
•Using Your HP Brio PC - Click on to learn how to use your HP Brio PC. See ”Using
Your Brio” on page 14 for details.
•Fix a Problem - Click on to learn how to fix detailed problems with your HP Brio
PC. See ”Fix a Problem” on page 15 for details. You can find more troubleshooting
information in chapter 3 of this manual.
•Register Now - register your HP Brio PC electronically — only if you have a direct
connection to the Internet. See ”Registering Your PC” below for details.
Example screen: exact
features depend on your
country
BrioGuide.book Page 12 Wednesday, September 1, 1999 2:37 PM

13
Easy Access to Information with the Brio Center
Registering Your PC
By registering your HP Brio PC, HP gets a clearer view of your needs and can serve
you much better. When you register your HP Brio PC, you are automatically entered
in a prize draw where you could win another HP product.
Electronic Registration
Registering electronically could not be simpler — simply click on the Register Now!
button on the HP Brio Center (if you have an Internet connection).
Non-electronic Registration
If your HP Brio PC is not fitted with a modem or you are in a region where electronic
registration is not possible, please return the registration card (when provided with
your PC).
Get Connected with the HP Brio Internet Center
You can access the Internet Center by:
• clicking on from within the HP Brio Center, or
• double-clicking on the Brio Internet Center shortcut on your Desktop, or
• selecting HP Brio Internet Center in the Start menu
Note The HP Brio Internet Center is only available in some countries.
Example screen: Internet
Center features depend
on your country
BrioGuide.book Page 13 Wednesday, September 1, 1999 2:37 PM

14
Easy Access to Information with the Brio Center
The Internet Center provides access to a series of Internet-based services allowing you
to:
•Connect for the first time - click on to sign up with an Internet service provider.
•Get Business Information - click on to access the HP and favored Internet
partners’ small business Web site (available in some regions only).
•Create a Web Site - click on to set up your own Web site offline and post it on the
Web.
•Create an Online Store - click on to set up an online store to sell your products
over the Web (available in some regions only).
•Control Your Costs - monitor the costs of your Internet connection (available in some
regions only).
Using Your Brio
The Using Your Brio window provides the following links:
•Getting Started - click on for tips on using the mouse, and, if fitted, CD-RW and
DVD drives.
•Windows Tour- click on for a guided tour of Windows.
•Working Comfortably- click on for tips on how to set up your HP Brio PC to
maximize your comfort and productivity.
Example screen: exact
features depend on your
country
BrioGuide.book Page 14 Wednesday, September 1, 1999 2:37 PM
