HP Compaq 6005 Pro MT Assembly instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP Compaq 6005 Pro Small Form Factor Desktop PC
Name / Model #2
Name / Model #3
Name / Model #4
Name / Model #5
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity of
items
included in
product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
1
Batteries
All types including standard alkaline and lithium coin
or button style batteries
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
0
Cathode Ray Tubes (CRT)
-
0
Capacitors / condensers (Containing PCB/PCT)
-
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
This project have four vendors as Below:
Acbel ,Chicony , Lite-on ,Delta
EPA
Liteon: 13
API :9
Chicony :12
Delta:TBC
nonEPA:
Liteon :13
API:10
Chicony:14
Delta:TBC
External electrical cables and cords
-
0

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Gas Discharge Lamps
-
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
PSU (Acbel ,Delta , Liteon ) and System fan
containing brominated flame retardants,
Mother board
TBC
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
-
0
Components, parts and materials containing
refractory ceramic fibers
-
0
Components, parts and materials containing
radioactive substances
-
0
1.3 Markings for plastic parts greater than 25 grams
Plastic Part Name
Plastic Part
Description
Weight (grams)
ISO 11469:2000 Plastic
Part Mark
Optional:
Main Bezel
Main bezel of desktop
product
89g
>ABS<
Fan Duct
System fan holder of
desktop product
58.7g
>PC+ABS FR(40)<
Fan Holder
Fan holder of desktop
product
44.9
>PC+ABS FR(40)<
System Fan
Frame_ADDA
System Fan Frame of
desktop product
45g
>PBT-GF30 FR(17)<
System Fan
Frame_DELTA
System Fan Frame of
desktop product
45g
>PBT-GF30-FR(17)<
Chassis Stand
Chassis Stand of
desktop product
78.0g
>ABS<
DC Fan Frame_ADDA
DC Fan Frame of
desktop or tower
product
40g
>PBT-GF30 FR(17)<
DC Fan Frame_DELTA
DC Fan Frame of
desktop or tower
product
40g
>PBT-GF30-FR(17)<
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1 Philips Screw Driver
100mm
Description #2 Diagonal cutting pliers
130mm
Description #3 Long nose pliers
NA
Description #4 Unsolder tool
NA
Description #5 Solder machine
230mm
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
1. Remove the access panel (see figure 1-2)
2. Remove the front bezel (see figure 3-4)
3. Remove Fan duct and heatsink (see firgure 5-11)
4. Remove CPU (see figure 12-13)
5. Remove Memory Module (see figure 14-15)
6. DIsconnect all internal cable from PCA (see figure 16)
7. Remove ODD and rotate ODD cage (see figure 17-18)
8. Remove 1st HDD (see figure 19-20
9. Remove PCA (see figure 22-23)
10. Remove Battery (see figure 24-25)
11. Release PSU case (see figure26-28)
12. Remove PSU PCA and Fan (see figure29-32)
13. Remove electrical capacitors from PCA (see figure33)
14.
15.
16.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 1:Pull Lock
Figure 2:Rise access panck Press front panel clip
Figure 3: Pull 3 retaining clips on the bezel top side
Figure 4: Release the front bezel. Rotate the bezel outward
to remove it from the chassis
Figure 5: Remove all cable from cable clamp
Figure 6: Release Fan duct

EL-MF877-00 Page 5
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 7: Press 2 clip to Remove Fan holder from
front chassis,
Figure 8: Disconnect Fan connector from PCA
header
Figure 9 : Remove fan and fan holder from chassis
Figure 10 : Wresting screw with screw driver release
4 qyt’s screw
Figure 11: Remove Heat sink from PCA
Figure 12: Press CPU chassis lock

EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 13: Remove CPU
Figure 14: Unlock Memory DIMM lock
Figure 15 :Remove Memory DIMM from PCA
Figure 16: Remove all internal cable from PCA
Figure 17: Release ODD from ODD cage
Press ODD latch and push ODD toward PSU.
Figure 18: Rotage ODD cable to vertical

EL-MF877-00 Page 7
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 19: Rotate PSU to Vertical
Figure 20: Release HDD Press HDD latch and push
HDD toward Front side.
Figure21: Remove PSU from Chassis
Figure 22: Release PCA 8 screws by wresting screw
with screw driver
Figure 23: Remove PCA from Chassis
Figure 24: Press Battery holder and Pull battery

EL-MF877-00 Page 8
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 25: Remove Battery
Figure 26: Cut the plastic cable tie from PSU case
Figure 27: Release PSU 7 screws by wrest screw
driveer
Figure 28: Remove PSU the top of case
Figure 29: Cut PSU PCA wire (2) and disconnect Fan
connector
Figure 30: Remove PSU PCS 5 screws

EL-MF877-00 Page 9
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 31 : : Remove PSU FAN
Figure 32: Remove PSU PCA from case
Figure 33 Remove electrical capacitors
