HP Compaq d220 MT Manual

System Unit
1 Front bezel (1 solid carbonite and 1 solid silver)
with diskette drive bezel. (See Miscellaneous parts
for kit contents) for d220 and d230 models
337555-001
2 Front bezel (carbonite and silver) with diskette drive
bezel and 2- 5.25” bezel blanks for d228 models 356602-001
3 Power supply, PFC 335183-001
*Power supply, non-PFC 335182-001
4 Access panel used on all models (left or right side)
(See Miscellaneous parts for kit contents 337555-001
5 Chassis not spared
* Not shown
Mass Storage Devices
1 Diskette drive, 3.5-inch 336218-001
240-GB\5400 RPM hard drive 335176-001
*40-GB\7200 RPM hard drive 335392-001
*80-GB\5400 RPM hard drive 335177-001
*80-GB\7200 RPM hard drive 337027-001
348X CD-ROM drive 335389-001
* CD RW drive, 48X/24X 335391-001
* 16X DVD drive 335390-000
* 48X/24X/48X+16X CD-RW/DVD-ROM drive 336783-001
*Not shown
Cables
1 Diskette drive cable 335190-001
2 Hard drive cable, primary ATA (2 devices) 335188-001
* Optical drive cable, secondary ATA (2 devices) 335189-001
3 Audio cable 335191-001
*Not shown
Keyboards (not illustrated)
Keyboard, PS2 335192-xxx
Brazil -201 Latin American Spanish -161
French Canadian -121 Peoples Republic of China -AA1
International -B31 Taiwanese -AB1
Japanese -291 Thai -281
Korean -AD1 U.S. -001
Standard and Optional Boards
Memory modules
1 128 MB/266 MHz FSB 285648-001
* 256 MB/266 MHz FSB 285649-001
* 512 MB/266 MHz FSB 285650-001
* 128 MB/333 MHz FSB 314795-001
* 256 MB/333 MHz FSB 314793-001
* 512 MB/2333 MHz FSB 314796-001
Intel Processors with alcohol pad and thermal grease
2 Celeron 1.8 GHz processor 288692-001
* Celeron 2.0 GHz processor 309578-001
* Pentium 1.8 GHz processor 306779-001
* Pentium 2.4 GHz processor 288689-001
* Pentium 2.66 GHz processor 305579-001
* Pentium 2.8 GHz processor 333487-001
* Pentium 2.66 GHz processor, C1 (VID) 333486-001
* Pentium 2.8 GHz processor, C1 stepping 305051-001
3 Front I/O PCA with cable 342725-001
System board with alcohol pad and thermal grease
* System board with AGP socket 335187-001
4 System board without AGP socket 355186-001
Other boards
* Lucent 56K PCI Win modem 239411-001
* Not shown
#Spared with alcohol wipe and thermal grease
Miscellaneous Parts
Miscellaneous Parts kit, (1 solid carbonite and 1 solid sil-
ver) for d220, d228, and d230 models. Includes: 337555-001
1 Front bezel (1 solid carbonite and 1 solid silver) for
use on d220 and d230 models only
5 5.25” drive bezel blank with metal shield for
d220, d228, and d230 models
6 Diskette drive bezel for d220, d228, and d230
models
7 3.5” drive bezel blank with metal shield for
d220, d228, and d230 models
* Side access panel (see item 4in System unit) for
d220, d228, and d230 models
2 Power switch/LED with switch mounting bracket 342724-001
3 Front bezel (carbonite and silver) with diskette drive
bezel and 2- 5.25” bezel blanks for d228 models 356602-001
4 Heatsink with alcohol pad and thermal grease 335184-001
* Air baffle (2 piece) with mounting screws 337553-001
* Rear I/O shield 337554-001
* Mouse, PS2, scroll type 335181-001
* Mouse, PS2, scroll type 323614-001
* Mouse, optical 323617-001
* Battery, real-time clock 153099-001
* Internal speaker 180809-001
Miscellaneous screw kit, includes: 337552-001
*#6-32 x 0.25 lg pan head (262508-001) (6 ea)
*#6-32 x 0.187 lg hi top (262508-003) (6 ea)
* M3 x 5mm lg pan head (263585-001) (8 ea)
* M3 x 6.5mm lg pan head (263585-002) (8 ea)
*Not shown
© 2003 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
Development Company, L.P.
Intel and Celeron are US registered trademarks of Intel
Corporation. All other product names mentioned herein
may be trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided “as is” without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
warranty.
December 2003
Document Part Number 332825-003
HP Compaq Business Desktop
d220/d228/d230 Microtower
Models
Illustrated Parts Map
Celeron and Pentium Processors

System Board Connectors and Jumpers (position of some untitled components may vary in location)
BAT1 Real-time-clock battery J25 Secondary IDE connector
CMOS CMOS Reset button J27 Power/LED switch
DIMM1 Memory socket 1 J28 Primary IDE connector
DIMM2 Memory socket 2 J29 ATX Main power
J11 Aux in audio J31 Diskette drive connector
J12 CD in audio J35 Chassis fan
J13 Wake on LAN JP1# Processor safe mode
J17 System fan JP2# Boot Block
J20 Front side USB U13 Processor socket
J21 CPU fan
#See table below
AGP socket not shown in this drawing
JP1 JP2
Status Jumper
Setting Notes Status Jumper Setting Notes
Normal 1-2 Default Lock 1-2
Safe 2-3 Unlock 2-3 Default
Recovery Open
System Hardware Interrupts
IRQ System Function IRQ System Function
0Timer Interrupt 8 Real-Time Clock
1Keyboard 9 Unused
2Interrupt Controller Cascade 10 Unused, available for PCI
3Serial Port (COM B) 11 Unused, available for PCI
4Serial Port (COM A) 12 Mouse
5Unused, available for PCI 13 Coprocessor
6Diskette Drive 14 Primary ATA (IDE) Controller
7Parallel Port (LPT 1) 15 Secondary ATA (IDE) Controller
Establishing a Password
1. Turn on or restart the computer. If you are in Windows, click Start > Shut Down >
Restart the computer.
2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to
bypass the title screen, if necessary. If you do not press F10 when prompted, a restart will be necessary.
3. Select Password Option, then select Change Supervisor Password and follow the instructions on the screen. You
may also want to establish the Password check at this time. This will allow you to specify when the password will
be required.
4. Before exiting, click Save Settings and Exit.
Changing a Password
1. Turn on or restart the computer. If you are in Windows, click Start > Shut Down > Restart the Computer. To change
the setup password, run Computer Setup.
2. When the key icon appears, type your current password, a slash (/) or alternate de-limiter character, your new
password, another slash (/) or alternate delimiter character, and your new password again as shown:
current password/new password/new password.
NOTE: Type the new password carefully since the actual characters do not appear on the screen.
3. Press the enter key.
4. The new password will take effect the next time the computer is restarted.
Deleting a Password
1. Turn on or restart the computer. If you are in Windows, click Start > Shut Down > Restart the Computer. To delete
the setup password, run Computer Setup (F10).
2. When the key icon appears, type your current password followed by a slash (/) or alternate delimiter character as
shown. Example: currentpassword/
3. Press the Enter key.
Clearing CMOS*
The computer's configuration (CMOS) may occasionally be corrupted. If it is, it is necessary to clear the CMOS
memory using by performing the following procedure:
ÄCAUTION: The power cord must be disconnected from the power source before changing the jumper
setting. (NOTE: All LEDs on the board should be OFF). Failure to do so may damage the system board
1. Turn off the computer and any external devices, then disconnect the power cord from the power outlet.
2. Remove the access panel.
3. Locate the switch CMOS and press the button, holding it down for 5 seconds.
4. Replace the access panel.
5. Connect the power cord to the power outlet.
6. Turn on the computer, allow it to start.
NOTE: Clearing CMOS clears all passwords.
Diagnostic LEDs
LED Color LED Activity State/Message
Power Green On (S0) Computer on
Power Green 1 blink every 2 seconds (S1) Normal Suspend Mode
Power Green 1 blink every 2 seconds (S3) Suspend to RAM
Power Clear Off (S4) Suspend to Disk (if applicable)
Power Clear Off (S5) Computer off
Power Red/Green Red when flashing ROM;
Green 1 blink every second
when user can restart
Boot block recovery w/Embedded Video
Power Red 1 blink every second for 2
seconds CPU thermal shutdown
Power Red 1 blink every second for 5
seconds, then 2 second pause.
5 beeps.
No memory installed
Power Red 1 blink every second for 6 sec-
onds, then 2 second pause.
6 beeps.
Graphics card error
Power Red 1 blink every second for 7
seconds, then 2 second pause.
7 beeps.
System board failure
Hard Drive Green Blinking Hard drive activity
Computer Setup (F10) Utility Features (not all features may be available)
System
Information
System S/N
Product Name
System Chipset Type
BIOS Version
BIOS Release Date
Processor Type
Processor Speed
CPU ID
L1 Cache Size
L2 Cache Size
Memory Bank 0
Memory Bank 1
Total Memory
Standard
CMOS Setup
Set Time
Set Date
Set Floppy size and capacity
Auto Detect Primary IDE Master drive
Auto Detect Primary IDE Slave drive
Auto Detect Secondary IDE Master drive
Auto Detect Secondary IDE Slave drive
Advanced
CMOS Setup
Boot Device Priority
Try Other Boot Device
POST Delay Time (in seconds)
System Keyboard
APIC ACPI SCI IRQ
Hyper-Threading Technology
Internal Graphics Mode Select
Power
Management
Setup
ACPI Standby State
Reset on AC/Power Loss
Resume on Ring
Resume on LAN
Resume on PME
Peripheral
Setup
OnBoard LAN
OnBoard LAN Chip Boot ROM
Init. Graphics Adapter Priority
USB Controller
USB 1.1 Device Legacy Support
OnBoard Serial Port
OnBoard Parallel Port
Hardware
Monitor
CPU Ratio Selection
CPU Warning Temperature
CPU Shutdown Temperature
System Warning Temperature
System Shutdown Temperature
CPU Temperature
System Temperature
CPU FAN Speed
Chassis FAN Speed
CPU VID
Vccp
+1.5V
+2.5V
+3.3V
+5.0V
+12.0V
Password
Option
Change Supervisor Password
Password Status
Password Check
Load Default
Settings
Save Settings
and Exit
Exit Without
Saving
Note: See Computer Setup (F10) Utility Guide on the Documentation Library CD.
