HP Compaq dc5750 Series User instructions

HP recommends
Windows Vista
®
Business
Microtower
1. (2) 5.25" external bays and (2) 3.5" internal bays for optional
removable hard drives
5. (2) full-height PCI slots, (1) full-height PCIe x1 slot, (1) full-
height PCIe x16 slot
2. (1) 3.5" external bay for optional HP 16-in-1 Media Card
Reader, diskette drive, or other 3.5" device
6. Front I/O: (2) USB 2.0, headphone and microphone
3. 300-watt or 300-watt high efficiency 80 PLUS
®
power supply 7. 2-Button Scroll Mouse (PS/2), Optical Scroll Mouse (PS/2 or
USB), or USB Laser Mouse
4. Rear I/O: (6) USB 2.0, (1) standard serial port, (1) optional serial
port, (1) parallel port, (2) PS/2, (1) RJ-45, (1) VGA, (1) DVI-D,
audio in/out
8. HP Standard Keyboard (PS/2 or USB) or HP USB Smartcard
Keyboard
9. Monitor (sold separately)
QuickSpecs
HP Compaq dc5750 Business PC
Overview
DA - 12546 North America — Version 39 — October 29, 2008 Page 1

Small Form Factor
1. (1) 3.5" external bay for optional HP 16-in-1 Media Card
Reader, diskette drive, or other 3.5" device;
(1) 3.5" internal bay
6. Front I/O: (2) USB 2.0, headphone and microphone
2. (1) 5.25" external bay for optional optical drive, or other 5.25"
device (bay tilts up for device removal and insertion)
7. 2-Button Scroll Mouse (PS/2), Optical Scroll Mouse (PS/2 or
USB), or USB Laser Mouse
3. 240-watt or 240-watt high efficiency 80 PLUS power supply 8. HP Standard Keyboard (PS/2 or USB) or HP USB Smartcard
Keyboard
4. Rear I/O: (6) USB 2.0, (1) standard serial port, (1) optional serial
port, (1) parallel port, (2) PS/2, (1) RJ-45, (1) VGA, (1) DVI-D,
audio in/out
9. Monitor (sold separately)
5. (2) low profile PCI slots, (1) low profile PCIe x1 slot,
(1) low profile PCIe x16 slot
QuickSpecs
HP Compaq dc5750 Business PC
Overview
DA - 12546 North America — Version 39 — October 29, 2008 Page 2

At A Glance
Designed to meet the needs of customers, across all market segments, looking for a stable solution to cover mainstream
business needs.
Created using industry leading Design for Environment standards. Upgradeable, recyclable and energy efficient.
AMD Athlon™ 64 X2 Dual-Core, Athlon 64, and Sempron™ processors with HyperTransport™ technology
Support for AMD Enhanced Virus Protection™ and AMD Cool 'n Quiet™ technologies
ATI Radeon Express 1150 Chipset with integrated X300 graphics
Dual monitor support standard
RAID 0/1 support
Embedded TPM1.2 compliant security module* (Vista Bit-Locker ready)
Support for SMART III 3.0Gb/s Serial ATA hard drives
Value-added software available pre-installed on select models:
HP ProtectTools Security Software Suite (purchased separately), including Credential Manager, Smart Card Manager, and
BIOS Configuration
HP Software Agent
Altiris Deployment Solution Agent
McAfee Anti-Virus with 60 day Live Update Subscription
HP Backup and Recovery Manager
Microsoft Office 2007
Value-added software available for free download from the Web ( http://www.hp.com/go/easydeploy )
HP Client Configuration Manager, Basic Edition
HP Client Manager for Altiris
Altiris Out-of-Band Management Solution
HP SoftPaq Download Manager
HP System Software Manager
HP Client Catalog for Microsoft SMS
Verdiem Surveyor remote power management agent
Fully compatible software OS image across all models (Microtower, Small Form Factor)
HP BIOS for security, manageability and software image stability
Standard 3-years parts, 3-years labor and 3-years on-site warranty services
(terms and conditions vary by country; certain restrictions and exclusions apply)
HP Insight Diagnostics software
Selected configurations with global availability easily set up and ordered through HP.com Business to Business portals
( http://h10019.www1.hp.com/business-site/index.html )
Tailored HP Factory Express deployment and lifecycle services available
( http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx )
* TPM module disabled where use is restricted by law; for example, Russia.
QuickSpecs
HP Compaq dc5750 Business PC
Overview
DA - 12546 North America — Version 39 — October 29, 2008 Page 3

Model Key and Example
NOTE: This diagram is an example that illustrates how to read the model number. It is not intended to give every available
configuration choice specified in the body of this document and may include references to modules that are out of date and no longer
available.
QuickSpecs
HP Compaq dc5750 Business PC
Configurable Components - Select Models (localized by Regions)
DA - 12546 North America — Version 39 — October 29, 2008 Page 4

Operating System –
One of the following
Preinstalled Genuine Windows Vista Business 32*
Genuine Windows Vista Business 64*
Genuine Windows XP Professional SP2
FreeDOS
†
Supported Genuine Windows 2000
* Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit http://www.windowsvista.com/upgradeadvisor .
†
The following features are not supported by Linux:
1.2 TPM Embedded Security Chip integrated with Broadcom NIC
HP 16-in-1 Media Card Reader
HP Wireless A+G PCI Card
HP BT450 USB Bluetooth Wireless Printer and PC Adapter
Broadcom NetXtreme Gigabit Ethernet PCIe NIC Card
2006 Agere PCI 56K International SoftModem
ATI Radeon X1300 (256MB SH) PCIe x16 Graphics Card
ATI Radeon X1300 Pro (256MB DH) PCIe x16 Graphics Card
ATI Radeon X1600XT (256MB DH FH) PCIe x16 Graphics Card
ATI Radeon HD 2400XT (256MB DH) PCIe x16 Graphics Card
HP USB Smartcard Keyboard
HP 2nd Serial Port adapter
HP FireWire / IEEE 1394 PCI Card
Value-added Software (on
select models; not included
with FreeDOS)
HP Backup and Recovery Manager Microsoft Office 2007 Small Business*
HP Insight Diagnostics Microsoft Office Ready 2007*
Computer Setup Utility Microsoft Works*
McAfee Anti-Virus with 60 day Live Update
Subscription
Microsoft Internet Explorer with AOL Toolbar
PDF Complete*
Intervideo WinDVD (supplied with DVD-ROM drive) HP Software Agent
Microsoft Office 2007 Basic* Altiris Deployment Solution Agent
Microsoft Office 2007 Professional* Smart Desktop Management Service (SDMS) Trial
(XP Professional only)
NOTE :* optional purchase
Value-added Software
(available for free
download from the Web
http://www.hp.com/
go/easydeploy )
HP Client Configuration Manager, Basic Edition HP Systems Software Manager
HP Client Manager for Altiris HP Client Catalog for Microsoft SMS
Altiris Out-of-Band Management Solution Verdiem Surveyor agent
HP SoftPaq Download Manager
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 5

Value-added Services and
Features
HP Stable Platform Program with Product Change
Notification
Factory Express Deployment and Lifecycle Services
Business-to-Business Portals TPM 1.2* Vista Bit-Locker Ready
HP Global Series Services Tool-less Serviceability
* TPM module disabled where use is restricted by law; for example, Russia.
Service and Support On-site Warranty and Service
Note 1
: This three-year (3-3-3), limited warranty and service offering delivers
three years of parts, labor and on-site repair. Response time is next business-day
Note 2
and includes free
telephone support
Note 3
24 x 7. Global coverage
Note 2
ensures that any product purchased in one
country and transferred to another non-restricted country will remain fully covered under the original
warranty and service offering. Some countries/regions do not offer one year onsite and labor.
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
NOTE 3 : Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
Microtower Small Form Factor
Chassis Dimensions
(H x W x D)
14.85 x 6.95 x 16.85 in
(377 x 177 x 428 mm)
4.5 x 15.5 x 13.5 in
(114 x 394 x 343 mm)
System weight* 23.44 lb (10.63 kg) 17.86 lb (8.10 kg)
System volume 1739 cu in (28,497.1 cu cm) 941.63 cu in (15,430.6 cu cm)
Shipping weight* 32.12 lb (14.57 kg) 26.70 lb (12.11 kg)
Shipping box dimensions
(H x W x D)
12.0 x 19.76 x 23.62 in
(305 x 502 x 600 mm)
9.72 x 19.68 x 22.67 in
(247 x 500 x 576 mm)
* Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.
Power Supply 300W power supply –
passive PFC
240W power supply –
passive PFC
80 PLUS Power Supply 300W 80 PLUS* power supply – active PFC 240W 80 PLUS* power supply – active PFC
* This alternate 80% efficient power supply is a requirement for ENERGY STAR compliance in conjunction with a select range of
processors and modules.
Ports
USB 2.0 8 (2 front, 6 rear) 8 (2 front, 6 rear)
Serial 1 standard with 2
nd
optional 1 standard with 2
nd
optional
Parallel 1 1
PS/2 1 keyboard, 1 mouse 1 keyboard, 1 mouse
Video analog for integrated graphics analog for integrated graphics
DVI-D output Integrated DVI-D output Integrated DVI-D output
Support for Multi-Monitor yes yes
Audio Front – mic and headphone
Rear* – line in, line out
Front – mic and headphone
Rear* – line in, line out
NIC (RJ-45) Integrated Broadcom 5755 Gigabit Ethernet Integrated Broadcom 5755 Gigabit Ethernet
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 6

NOTE :* Rear audio ports are re-taskable as Line-in, Line-out, or Microphone-in.
MT SFF
Chipset ATI Express 1150 Chipset X X
Processor and Speed
One of the following
AMD Sempron Processors with HyperTransport Technology:
AMD Sempron 3400+ Processor (1.8-GHz, 256K L2 cache, 1600-MHz FSB) X X
AMD Sempron 3600+ Processor (2.0-GHz, 256K L2 cache, 1600-MHz FSB) X X
AMD Sempron LE-1250 Processor (2.2-GHz, 512K L2 cache, 800-MHz FSB) X X
AMD Athlon 64 Processors with HyperTransport Technology:
Athlon 64 3500+ Processor (2.2-GHz, 512K L2 cache, 2000-MHz FSB) X X
Athlon 64 3800+ Processor (2.4-GHz, 512K L2 cache, 2000-MHz FSB) X X
AMD Athlon Single-Core Processors with HyperTransport Technology:
AMD Athlon LE-1640B Processor (2.7-GHz, 512K L2 cache, HT bus 2.0) X X
AMD Athlon X2 Dual-Core Processors with HyperTransport Technology:
Athlon X2 BE-2350 Processor (2.1-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
AMD Athlon 64 X2 Dual-Core Processors with HyperTransport Technology:
Athlon 64 X2 Dual-Core 3800+ Processor (2.0-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
Athlon 64 X2 Dual-Core 3800+ Processor 35-Watt (2.0-GHz, 2x512K L2 cache, 2000-
MHz FSB)
X X
Athlon 64 X2 Dual-Core 4000+ Processor (2.1-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
Athlon 64 X2 Dual-Core 4200+ Processor (2.2-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
Athlon 64 X2 Dual-Core 4400+ Processor (2.3-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
AMD Athlon X2 4450B Processor (2.3-GHz, 1MB L2 cache, HT bus 2.0) X X
Athlon 64 X2 Dual-Core 4600+ Processor (2.4-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
Athlon 64 X2 Dual-Core 4800+ Processor (2.5-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
Athlon 64 X2 Dual-Core 5000+ Processor (2.6-GHz, 2x512K L2 cache, 2000-MHz FSB) X X
AMD Athlon X2 5000B Processor (2.6-GHz, 1MB L2 cache, HT bus 2.0) X X
Athlon 64 X2 Dual-Core 5200+ Processor (2.6-GHz, 2x1MB L2 cache, 2000-MHz FSB) X X
AMD Athlon X2 5200B Processor (2.7-GHz, 1MB L2 cache, HT bus 2.0) X X
AMD Athlon X2 5400B Processor (2.8-GHz, 1MB L2 cache, HT bus 2.0) X X
Athlon 64 X2 Dual-Core 5600+ Processor (2.8-GHz, 2x1MB L2 cache, 2000 MHz FSB) X X
Athlon 64 X2 Dual-Core 6000+ Processor (3.0-GHz, 2x1MB L2 cache, 2000 MHz FSB) X X
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 7

Memory DDR2 SYNCH DRAM NON-ECC MEMORY
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This
chart does not represent all possible memory configurations. Memory DIMMS must be populated
beginning with DIMM slot 4 (Channel B) or DIMM slot 3 (Channel A). Slot 4 must be populated before slot 2,
and slot 3 must be populated before slot 1.
HP recommends dual-channel configurations for maximum performance.
For best performance, place matching DIMMs in black memory slots 4 and 3 (and in white memory slots 2
and 1 if used). Matching DIMMs have the same size, speed, and number of memory chips. If the slot pairs
are not matched, all the memory is still used, but the system will operate in single-channel mode. If
speeds are mixed, speed will default to the slowest DIMM.
Microtower and Small Form Factor
Maximum Memory Supports up to 8 GB of DDR2 Synch DRAM. Not all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory
may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-
bit operating system.
DIMM Size Slot
WHITE BLACK
1 (Channel A) 2 (Channel B) 3 (Channel A) 4 (Channel B)
512-MB 512-MB
512-MB
(dual-channel)
256-MB 256-MB
1-GB 1-GB
1-GB
(dual-channel)
512-MB 512-MB
2-GB
(dual-channel)
512-MB 512-MB 512-MB 512-MB
4-GB
(dual-channel)
1-GB 1-GB 1-GB 1-GB
8-GB
(dual-channel)
2-GB 2-GB 2-GB 2-GB
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 8

MT SFF
Memory Configurations
One of the following
512-MB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 512) X X
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 1GB) X X
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 512) X X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 1GB) X X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 2GB) X X
4-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 2GB) X X
8-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 2GB) X X
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 512) X X
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 256) X X
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 512) X X
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 1GB) X X
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 512) X X
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 1GB) X X
4-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 1GB) X X
Expandability Microtower Small Form Factor
PCI slots 2 Full Length 5V 32 bit PCI slots 2 LP 5V 32 bit PCI slots
Max power per slot 25W 25W
PCIe x1 slot 1 1
Max power per slot 10W 10W
PCIe X16 slot 1 Full Height card 1 LP profile card
Max power per slot 75W 25W
External Bays
3.5” 1 1
5.25” 2 1
IDE
Internal 3.5” HDD Bays 2 1
Hard Drive Controller
(SATA) Supported
SATA SATA
Hard Drive Interfaces
Supported
SATA 3.0Gb/s SATA 3.0Gb/s
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 9

Microtower Small Form Factor
Drive Support
Microtower Small Form Factor
Media Card
Reader or
Diskette Drive
(optional)
5.25” Serial ATA
Devices
3.5” Serial ATA
Devices
Media Card
Reader or
Diskette Drive
(optional)
5.25” Serial ATA
Devices
3.5” Serial ATA
Devices
Quantity Supported 122112
Position Supported
, , , ,
Controller USB/Diskette SATA SATA USB/Diskette SATA SATA
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 10

MT SFF
Hard Drive
One or two of the following
80-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
160-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
250-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
80-GB SATA 3.0-Gb/s NCQ Hard Drive (10,000 rpm) X
160-GB SATA 3.0-Gb/s NCQ Hard Drive (10,000 rpm) X
RAID 80-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
RAID 160-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
RAID 250-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
2nd hard drive, 80-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
2nd hard drive, 160-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
2nd hard drive, 250-GB SATA 3.0-Gb/s Hard Drive (7200 rpm) X X
SATA HDD2 Cable – Microtower X
SATA HDD2 Cable – Small Form Factor X
Removable Storage –
One or more of the
following depending on
form factor (see Storage –
Drive Support section
above)
Diskette Drives
1.44-MB Diskette Drive X X
Media Reader
HP 16-in-1 Media Reader (USB connection on the system board) X X
Optical Drives
SATA CD-ROM Drive 1st Drive X X
SATA DVD-ROM Drive 1st Drive X X
SATA CD-RW/DVD-ROM Combo Drive 1st Drive X X
SATA DVD+/-RW (DL/DF) LightScribe Drive 1st Drive X X
SATA 16X DVD+/-RW LightScribe 1st Drive* X X
SATA 48X/32X Combo 1st Drive* X X
SATA CD-ROM Drive 2nd Drive X X
SATA DVD-ROM Drive 2nd Drive X X
SATA CD-RW/DVD-ROM Combo Drive 2nd Drive X X
SATA DVD+/-RW (DL/DF) LightScribe Drive 2nd Drive X X
SATA 16X DVD+/-RW LightScribe 2nd Drive* X X
SATA 48X/32X Combo 2nd Drive* X X
*Work with Windows Vista.
Removable Hard Drives*
Removable 3.5" 80GB SATA 3.0 Gb/s (7200 rpm) X X
Removable 3.5" 160GB SATA 3.0 Gb/s (7200 rpm) X X
Removable 3.5" 250GB SATA 3.0 Gb/s (7200 rpm) X X
*Removable Hard Drive replaces Optical Drive in Bay 1.
Flash Module
1GB Flash Module for ReadyBoost™ X X
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 11

Security 1.2 TPM Embedded Security Chip* integrated with Broadcom NIC X X
HP ProtectTools Security Software Suite with BIOS Configuration (Serial, Parallel, USB
Enable/Disable), Credential Manager, Smart Card Manager
X X
HP Desktop Security lock kit (lock and cable) X X
Security cable with Kensington lock X X
* TPM module disabled where use is restricted by law; for example, Russia.
NIC Broadcom 5755 Gigabit Ethernet integrated on system board X X
Wireless Wireless A+G PCI Card (full height bracket) X
Wireless A+G PCI Card (low profile bracket) X
Modem 2006 Agere PCI 56K International SoftModem (full height) X
2006 Agere PCI 56K International SoftModem (low profile) X
Graphics Integrated ATI Radeon X300 graphics with VGA and DVI-D X X
ATI Radeon X1300 (256MB SH) PCIe x16 Graphics Card X X
ATI Radeon X1300 Pro (256MB DH) PCIe x16 Graphics Card X X
ATI Radeon X1600XT (256MB DH FH) PCIe x16 Graphics Card X
ATI Radeon HD 2400XT (256MB DH) PCIe x16 Graphics Card X X
ATI Radeon HD 3650 (512MB DH) PCIe x16 Graphics Card X X
Audio Integrated High Definition audio with Realtek 2 channel ALC260 codec (all ports are
stereo)
X X
Microphone and Headphone front ports X X
Line-out and Line-In rear ports* X X
Aux Input connection on system board X X
Internal Speaker X X
* Rear audio ports are re-taskable as Line-in, Line-out, or Microphone-in. External speakers must be
powered externally.
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 12

Input Devices Keyboard – One of the following
HP PS/2 Standard Keyboard X X
HP USB Standard Keyboard X X
HP USB Smartcard Keyboard X X
Mouse – One of the following
USB 2-Button Laser Mouse X X
HP PS/2 2-Button Scroll Mouse X X
HP PS/2 2-Button Optical Scroll Mouse X X
HP USB 2-Button Optical Scroll Mouse X X
Miscellaneous HP FireWire / IEEE 1394 PCI Card (full height) X
HP FireWire / IEEE 1394 PCI Card (low profile) X
2nd serial port adapter X
2nd serial port adapter (low profile) X
Thermal Kit – Microtower X
Thermal Kit – Small Form Factor X
Tower stand X
XP Pro System Recovery CD US X X
Vista Business System Recovery DVD Kit X X
1-GB Flash Module for ReadyBoost X X
QuickSpecs
HP Compaq dc5750 Business PC
Standard Features and Configurable Components
DA - 12546 North America — Version 39 — October 29, 2008 Page 13

MT SFF Part Number
Communications Wireless LAN
HP Wireless A+G PCI Card (North America only) X X EA118AA
bt450 Bluetooth Wireless Printer and PC Adapter (IPG) X X Q6398A#ABA
NICs
Intel Pro 1000 PT Gb Ethernet PCIe NIC X X EH352AA
Broadcom NetXtreme Gigabit Ethernet PCIe NIC Card X X EA833AA
Modem
Agere 2006 PCI 56K International Modem X X EK694AA
Connectivty
Bundle Connectivity Starter Kit – Surge Protector/LAN cable/Printer
cable
X X RT174AA
Office 2007 Media-less
License Kits (MLKs)
MS Office Basic Edition 2007 – Media-less License Kit X X RZ361A#ABA
MS Office Small Business Edition 2007 – Media-less License Kit X X RZ365A#ABA
MS Office Professional Edition 2007 – Media-less License Kit X X RZ363A#ABA
Graphics Single head solutions
NVIDIA GeForce 256MB Single Head PCIe x16, low profile Graphics
Card
X X
GJ119AA
Multi head solutions
ATI RADEON X1300 Pro (256MB DH) PCIe Graphics Card X X AH050AA
ATI HD 2400 XT 256MB Dual Head PCIe x16, low profile Graphics Card X X KD060AA
HP DMS59 DVI Dual-head Connector Cable X X DL139A
ATI Radeon HD 3650, 512MB Dual Head PCIe x16, full height Graphics
Card
X
KS505AA
Hard Drives HP 80-GB SATA 3.0-Gb/s Hard Drive X X PY276AA
HP 160-GB SATA 3.0-Gb/s Hard Drive X X PY277AA
HP 250-GB SATA 3.0-Gb/s Hard Drive X X PY278AA
QuickSpecs
HP Compaq dc5750 Business PC
After-Market Options
DA - 12546 North America — Version 39 — October 29, 2008 Page 14

Input/Output Devices HP PS/2 Standard Keyboard X X DT527A#ABA
HP USB Standard Keyboard X X DT528A#ABA
HP USB BG1650 Standard Keyboard X X DT529A#ABA
HP USB Smartcard Keyboard X X ED707AA#ABA
HP USB 2-Button Laser Mouse X X GW405AA
HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver) X X DC172B
PS/2 2-Button Optical Scroll Mouse EY703AA
Memory (DIMMs) PC2-6400 (DDR2 800 MHz) DIMMs
HP 2-GB PC2-6400 (DDR2 800 MHz) DIMM X X AH060AA
HP 1-GB PC2-6400 (DDR2 800 MHz) DIMM X X AH058AA
HP 512-MB PC2-6400 (DDR2 800 MHz) DIMM X X AH056AA
Monitors CRTs 3PO Offering
Business LCD Monitors
HP L1506 15-inch LCD Monitor PX848AA#ABA
HP w17e 17-inch LCD Monitor (offering 1/1/1 warranty) GV537AA#ABA
HP L1710 17-inch LCD Monitor GS917AA#ABA
HP L1750 17-inch LCD Monitor GF904AA#ABA
HP L1745 17-inch LCD Monitor GE178AA#ABA
HP L1910 19-inch LCD Monitor GS918AA#ABA
HP L1950 19-inch LCD Monitor (disco 8.31.08 - transition to L1950g) GG458AA#ABA
HP L1950g 19-inch LCD Monitor (launching 8.4.08) KR145AA#ABA
HP LP1965 19-inch LCD Monitor RA373AA#ABA
HP LP2065 20-inch LCD Monitor EF227A4#ABA
Business Widescreen LCD Monitors GX007AA#ABA
HP L1908w 19-inch Widescreen LCD Monitor GP536AA#ABA
HP L1945w 19-inch Widescreen LCD Monitor KD286AA#ABA
HP L2045w 20-inch Widescreen LCD Monitor RD125AA#ABA
HP L2208w 22-inch Widescreen LCD Monitor GX007AA#ABA
HP L2245w 22-inch Widescreen LCD Monitor (disco 8.31.08 - transition to L2245wg) GX008AA#ABA
HP L2245wg 22-inch Widescreen LCD Monitor (launching 8.4.08) FL472AA#ABA
HP LP2275w 22-inch Widescreen LCD Monitor (launching 8.4.08) KE289A4#ABA
HP L2445w 24-inch Widescreen LCD Monitor (launching 9.2.08) KT931AA#ABA
HP LP2465 24-inch Widescreen LCD Monitor (disco 10.31.08 - transition to LP2475w EF224A4#ABA
HP LP2465 24-inch Widescreen LCD Monitor (launching 9.2.08) KD911A4#ABA
HP LP3065 30-inch Widescreen LCD Monitor EZ320A4#ABA
Business Widescreen LCD Monitor with Integrated Speakers
HP L1908wm 19-inch Widescreen LCD Monitor with Built in Integrated Speakers KA214AA#ABA
Business GSA Monitors
QuickSpecs
HP Compaq dc5750 Business PC
After-Market Options
DA - 12546 North America — Version 39 — October 29, 2008 Page 15

HP L1750 17-inch TAA LCD Monitor GF904A2#ABA
HP L1950 19-inch TAA LCD Monitor (disco 8.31.08 - transition to L1950g) GG458A2#ABA
HP L1950g 19-inch TAA LCD Monitor (launching 8.4.08) KR145A2#ABA
Business Touchscreen LCD Monitor
HP L5006tm 15-inch Touch Screen LCD Monitor RB146AA#ABA
Business LCD Monitor with Integrated Work Stand
HP L1908wi 19-inch Widescreen LCD Monitor plus Integrated Work Stand GP537AA#ABA
HP L1910i 19-inch LCD Monitor plus Integrated Work Stand GS581AA#ABA
Options
HP Flat Panel Speaker Bar EE418AA
HP Quick Release Kit EM870AA
HP Integrated Work Stand (stand alone) GN783AA
HP DreamColor Advanced Profiling Solution (aka Puck) KZ300AA
HP LCD Hood Kit KZ301AA
3M 17-in Privacy Screen Filter KM218AA
3M 19-in Privacy Screen Filter KZ310AA
Multimedia Thin USB Powered Speakers X X KK912AA
Flat Panel Speaker Bar X X EE418AA
Optical Drives DVD-ROM Drive
HP SATA DVD-ROM Drive X X AH047AA
Combo Drive
HP SATA CD-RW/DVD-ROM Combo Drive X X AH046AA
DVD+/-RW Drive
HP SATA DVD+/-RW (DL/DF) SuperMulti LightScribe Drive X X GF343AA
Removable Storage Diskette and Digital Drives
HP 1.44-MB Internal Diskette Drive X X AH053AA
HP 1.44 USB Floppy Drive – External X X DC141B
Removable Hard Drive
HP Removable SATA Hard Drive Enclosure (Frame & Carrier) X X RY102AA
HP Removable SATA Hard Drive Enclosure (Carrier Only) X X RY103AA
Multimedia
HP 16-in-1 Media Card Reader X X EM718AA
QuickSpecs
HP Compaq dc5750 Business PC
After-Market Options
DA - 12546 North America — Version 39 — October 29, 2008 Page 16

Security Kensington lock X X PC766A
HP Business PC Security Lock X X PV606AA
HP USB Smartcard Keyboard X X ED707AA#ABA
Protect Tools (version3.0) X X KN780AA
HP Smart Data Protection Service X X BB731UT
Manageability HP Client Configuration Manager, Premium Edition X X T3488AA
(use T3489AA for
1000 licenses)
Altiris Client Management Suite Level 1
Includes:
Altiris Deployment Solution
Altiris Inventory Solution
Altiris Application Metering Solution
Altiris Carbon Copy Solution
Altiris Software Delivery Solution
Altiris Application Management Solution
Altiris Patch Management Solution
X X DR605A
(use DR606A for
1000+ licenses)
Miscellaneous
Accessories
HP 2nd Serial Port adapter X X PA716A
Belken USB to Serial Adapter X X EM449AA
HP FireWire / IEEE 1394 PCI Card X X PA997A
Tower Stand-Carbonite X RG048AA
5.25" Blank Bezel Kit (Carbonite 50/Bulk Pack) X X DC177B
DVI to DVI Cable X X DC198A
Local Area Network (LAN) cable X X AH122AA
Firewire (1394) Cable X X AH123AA
7-outlet Surge Protector X X AG290AA#ABA
HP 1TB Media Vault Pro MV5140 X X GX667AA#ABA
HP 1.5TB Media Vault Pro MV5150 X X GX668AA#ABA
QuickSpecs
HP Compaq dc5750 Business PC
After-Market Options
DA - 12546 North America — Version 39 — October 29, 2008 Page 17

Unit Environment and Operating
Conditions
Microtower Small Form Factor
General Unit Operating Guidelines (Need this updated for dc5750)
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is
operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are subject to each other's re-
circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure,
and the same operating guidelines listed above will still apply.
Temperature Range Operating: 50° to 95° F (10° to 35° C)*
Non-operating: -22° to 140° F(-30° to 60° C)
Relative Humidity Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude (unpressurized) Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
* NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained
sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Microtower Small Form Factor
Power Supply 300-watt BTX power
supply – Passive PFC
115v/230v line switch
300-watt 80 PLUS* BTX
power supply – Active
PFC
240-watt BTX power
supply – Passive PFC
115v/230v line switch
240-watt 80 PLUS* BTX
power supply – Active
PFC
Operating Voltage Range 90 to 132VAC, or 180 to
264VAC
90 to 264VAC 90 to 132VAC, or 180 to
264VAC
90 to 264VAC
Rated Voltage Range 100 to 127VAC, or 200
to 240VAC
100 to 240VAC 100 to 127VAC, or 200
to 240VAC
100 to 240VAC
Rated Line Frequency 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency Range 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz
Rated Input Current 8A/4A 5A/2.5A 6A/3A 3.5A/1.75
Heat Dissipation Typical 315 btu/hr
(79 kg-cal/hr)
Maximum 1575 btu/hr
(397 kg-cal/hr)
Typical 270 btu/hr
(68 kg-cal/hr)
Maximum 1280 btu/hr
(322 kg-cal/hr)
Typical 315 btu/hr
(79 kg-cal/hr)
Maximum
1260 btu/hr
(317 kg-cal/hr)
Typical 270 btu/hr
(68 kg-cal/hr)
Maximum 1025 btu/hr
(258 kg-cal/hr)
Power Supply Fan Variable speed fan Variable speed fan Variable speed fan Variable speed fan
ENERGY STAR Compliant X X
FEMP Standby Power Compliant
(<2W in S5 – Power Off)**
XXXX
QuickSpecs
HP Compaq dc5750 Business PC
Technical Specifications
DA - 12546 North America — Version 39 — October 29, 2008 Page 18

Power Consumption in ES Mode –
Suspend to RAM (S3)
(Instantly Available PC)
<4W <3W <4W <3W
NOTES :
* This 80% efficient power supply is a requirement for ENERGY STAR compliance in conjunction with a select range of processors and
modules.
** Power consumption in the Off/Apparent Off mode is measured and reported with the network interface controller "Wake on LAN"
feature disabled in F10 Setup (default is "enabled").
ROM BIOS Information
Key features of the HP BIOS in the dc5750 include:
Deployment and manageability – HP BIOS provides several technologies that help integrate the HP Business desktop computer
into the enterprise, such as PXE, remote configuration, remote control, and F10 Setup support for 12 languages.
Stability – HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced
change notification.
Security – HP BIOS offers a robust and flexible set of security features to help the system administrator secure their systems
from removal of sensitive data, and help prevent access by unauthorized users, subversion of OS security policies, removal of
hardware, flash of rogue BIOS images, and attacks on BIOS settings.
Thermal and power management – The HP BIOS provides and enables thermal and power management technologies to assist in
operating the HP Business Desktop computer in any enterprise environment.
Serviceability – HP BIOS provides diagnostic and detailed service information.
Upgrades and recovery – HP BIOS provides numerous ways to upgrade HP Business Desktop computers, including BIOS updates
from within DOS (Flashlite), BIOS updates from within Windows (HPQFlash, SSM), HP Client Manager, and fail-safe recovery. In
addition, the HP Business Desktop BIOS Utilities tool enables replicated BIOS setup throughout the Enterprise; it is available
from within the BIOS software and from the support website.
Additional HP BIOS Features
Administrator password – Also known as the setup password, this helps prevent unauthorized changes to the system
configuration. If the administrator password is not known, the BIOS version cannot be changed and changes cannot be made to
BIOS settings using F10 setup or under the OS.
Advanced Configuration and Power Interface (ACPI) – Represents a significant innovation in power and configuration
management, allowing operating systems and applications to manage power based on activity and usage. HP Compaq dc5750
models use ACPI to provide power conservation features under Windows XP.
Other Features Description
ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards
and peripherals in a low-power or powered-off state without affecting other
elements of the system.
SMBIOS Ver. 2.4 System Management BIOS, previously known as DMI BIOS, for system management
information
AMD Cool 'n Quiet A setting in F10 Setup allows the system to automatically adjust the CPU speed, voltage
and power combination to match the instantaneous user performance need. The AMD
driver for this feature requires Windows XP SP2.
Dual-State Power Button Power button acts as both an on/off button and suspend-to-sleep button
QuickSpecs
HP Compaq dc5750 Business PC
Technical Specifications
DA - 12546 North America — Version 39 — October 29, 2008 Page 19

Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM Flash ROM CMOS Battery Holder for easy
Replacement
Flash Recovery with Video 5 Aux Power LED on System PCA Processor ZIF Socket for easy Upgrade
Over-Temp Warning on Screen
(Requires IM Agents)
Clear Password Jumper DIMM Connectors for easy Upgrade
Restore CD Clear CMOS Button NIC LEDs (integrated) (Green & Amber)
Serviceability Features of Chassis
Dual Color Power and HD LED – To
Indicate Normal Operations and
Fault Conditions
Color coordinated cables and
connectors
Tool-less Hood Removal
Front power switch System memory can be upgraded
without removing the system board or
any internal components
Tool-less Hard Drive, CD & Diskette
Removal
Feature Description
ASF 2.0 support (Alert Standard Format) Industry-standard specification for network alerting and remote control in operating system-
absent environments
Towerable Product can be oriented as a tower (in addition to desktop orientation)
Drive Self Tests (DPS) Drive Protection System
A diagnostic hard drive self test. It scans critical physical components and every sector
of the hard drive for physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem and
needs to be replaced.
The system expands on the Self-Monitoring, Analysis, and Reporting Technology
(SMART), a continuously running systems diagnostic that alerts the user to certain
types of failures.
DPS Access through F10 Setup during
Boot
SMART Technology*
(Self-Monitoring, Analysis and Reporting
Technology)
Allows hard drives to monitor their own health and to raise flags if imminent failures were
predicted
Predicts failures before they occur. Tracks fault prediction and failure indication
parameters such as re-allocated sector count, spin retry count, calibration retry count
By avoiding actual hard drive failures, SMART hard drives act as "insurance" against
unplanned user downtime and potential data loss from hard drive failure
SMART I – Drive Failure Prediction
SMART II – Off-Line Data Collection
SMART III – Off-Line Read Scanning with
Defect Reallocation
QuickSpecs
HP Compaq dc5750 Business PC
Technical Specifications
DA - 12546 North America — Version 39 — October 29, 2008 Page 20
