HP Compaq dx6100 ST Manual

System Unit
1 Computer cover assy with front bezel and no inserts 370503-001
2 Power supply, PFC 350030-001
3 Chassis assembly not spared
Cables
1SATA hard drive cable, 24” (326965-007) 368388-001
1SATA hard drive cable, 18” (326965-002) 346142-005
2Power switch/LED cable - use switch holder
(370857-001) 368387-001
3Audio cable (CD to system board) (387527-001) 149806-005
4Front I/O device with cable 368386-001
* Diskette drive cable (168999-006) 370499-001
*UATA data cable, 8.6” (108950-054) 368389-001
* Flying serial port with cable 370500-001
*Not shown
Standard and Optional Boards
1System board with alcohol pad and thermal grease 361682-001
Memory Modules
* 128 MB/400 MHz FSB 335697-005
* 256 MB/400 MHz FSB 335698-005
* 512 MB/400 MHz FSB 335699-005
* 1.0 GB/400 MHZ FSB 335700-005
Intel Pentium 4 Processors with alcohol pad and thermal grease
* 2.8 GHz\800 MHz FSB, 1MB cache 367594-001
* 3.0 GHz\800 MHz FSB, 1MB cache 366643-001
* 3.2 GHz\800 MHz FSB, 1MB cache 366644-001
* 3.4 GHz\800 MHz FSB, 1MB cache 367415-001
* 3.6 GHz\800 MHz FSB, 1MB cache 367416-001
Other Cards
* PCI Modem, International, LP bracket 361287-021
PC MCIA Reader with PCI card 331589-001
* Intel Pro 10/100/1000 MT NIC, LP bracket 338154-005
* FireWire 1394 card, 2 ext/1 int port, LP bracket 361551-001
Wireless LAN adapters (802.11b)
* 13 channel, LP bracket - use cable 333365-005 354900-005
Graphics Solutions
* 4 Layer ADD2 Graphics, LP bracket 361264-001
* ATI RV370 VGA graphics, 64M, LP bracket 364833-001
* ATI RV370 VGA graphics, 128M, LP bracket 364834-001
*Not shown
LP= Low profile mouinting bracket
FH = Full height mounting bracket
© 2004 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
Development Company, L.P.
All other product names mentioned herein may be
trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided “as is” without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
warranty.
August 2004
Document Number
361289-001
HP Compaq Business Desktop
dx6100 Series Personal Computer
Illustrated Parts Map
Slim Tower Chassis
See next page for keyboard spares
Mass Storage Devices (not illustrated)
40 GB\7200 RPM SATA hard drive 365555-001
80 GB\7200 RPM SATA hard drive 345713-005
120 GB\7200 RPM SATA hard drive 365556-001
160 GB\7200 RPM SATA hard drive 345712-005
Diskette drive with mounting screws 333505-005
48X CD-ROM drive with mounting screws 326773-005
52X CD-ROM drive 333969-005
48X/32X/48X CD-RW 346788-005
48X/32X/48X +16X DVD/CD-RW 359493-005
8X DVD+R/RW 358688-005
16/40X DVD ROM Drive 325313-005
Zip 250 Drive with mounting bracket 333504-005
Zip 250 drive without mounting bracket 326772-005
Miscellaneous Parts
1 Front bezel assembly with no inserts 368083-001
* 5.25” Bay bezel blank (carbonite) 335937-005
2 CD drive bezel with diskette drive 370501-001
3 CD drive bezel without diskette drive 367852-001
4 CD drive bezel with Zip drive 370504-001
5# Speaker with alcohol pad and thermal grease 368084-001
6 Active heatsink with thermal grease and alcohol pad 367857-001
7 Chassis fan 366641-001
* Heatsink duct baffle 375514-001
8 Heatsink retention plate with thumbscrew 370709-001
9 Power switch holder with LED holders (use with
368387-001 switch) 370857-001
* Mouse, 2-Button, PS/2 with scroll wheel 323614-005
* Mouse, 2-Button, USB, optical with scroll wheel 323615-005
* Mouse, 2-Button, USB, with scroll wheel 323617-005
* Drive Key, 16 MB 324780-005
* Drive Key, 128 MB 349988-005
* Drive Key, 256 MB 344249-005
* Real-time-clock battery 153099-001
* Expansion card retainer kit 377661-001
* Port control cover 367856-001
* Rubber foot (4 each) 370708-001
* Kensington lock 370856-001
*Not shown
#The heatsink must be removed before removing the speaker. Make sure
the mating surfaces between the heatsink and the processor have been
cleaned with the alcohol pad provided and fresh thermal grease has been
applied when reinstalling the heatsink.
Miscellaneous Screw Kit (not illustrated)
Miscellaneous screw kit 337237-005
M3 x 5mm, hitop (263585-001) 4 ea
#6-32 x .250, hitop (262508-001) 8 ea
#6-32 x .250, pan head (101517-067) 3 ea
#6-32 x .312, hitop (262508-002) 4 ea
#6-19 x .312, pan head (101346-068) 2 ea
#6-19 x .315, T15 head (331310-001) 2 ea

Keyboards (not illustrated)
PS/2, Basic
USB, Basic
USB, Basic (Blue Angel)
USB, Modular
355630-xxx
355631-xxx
355632-xxx
355102-xxx
Arabic [1] -175 Greek [1] -155 Portuguese [1, 3] -135
Belgian -185 Hebrew [1, 2] -BB5 Russian [1] -255
BHCSY[1, 2] -B45 Hungarian [1] -215 Slovakian [1] -235
Czech [1] -225 International [1, 4] -B35 Spanish [1, 3] -075
Danish [3] -085 Italian [3] -065 Swedish [2, 3] -105
Dutch [1] -335 Japanese [1] -295 Swiss [3] -115
Europe [5] -025 Kazak [1, 2] -DF5 Taiwanese [1] -AB5
Finnish [1] -355 Korean (Hanguel) [1, 2] -KD5 Thai [1] -285
French [3] -055 Norwegian [1, 3] -095 Turkish [1, 3] -145
French Arabic [1, 2] -DE5 PRC [1] -AA5 U.K. [1, 3] -035
German [3] -045 Polish [1] -245
[1]Not for 355632-xxx
[2]Not for 355630-xxx [3]Not for 355631-xxx
[4]Not for 355102-xxx [5]Only for 355102-xxx
System Board Connectors and Jumpers (position of some untitled components may vary in location)
CR1 5V Aux power P24 USB connector, front panel
E14 Boot block P27 Multi Bay
E49 Password jumper P29 SCSI LED connector
J20 PCI slot 1 P52 Serial port “B”
J21 PCI slot 2 P54 Serial Port “A”
J31 PCI Express x1 P60 Primary Serial ATA (SATA) Port
J41 PCI Express x16 P61 Secondary Serial ATA (SATA) Port
P1 Main power (24 pin) P124 Hood lock
P3 Processor VccP Power 12V (6 pin) P125 Hood sensor
P5 Main power switch/LED SW50 CMOS button
P6 Internal chassis speaker XBT1 Battery
P7 CD audio in XMM1 Memory socket
P8 Primary chassis fan XMM2 Memory socket
P9 Secondary chassis fan XMM3 Memory socket
P10 Diskette drive XMM4 Memory socket
P11 Aux audio in XU1 Microprocessor
P20 IDE XU100 Security
P23 Front audio
System Hardware Interrupts
IRQ System Function IRQ System Function
0Timer Interrupt 8 Real-Time Clock
1Keyboard 9 Unused
2Interrupt Controller Cascade 10 Unused, available for PCI
3Serial Port (COM B) 11 Unused, available for PCI
4Serial Port (COM A) 12 Mouse
5Unused, available for PCI 13 Coprocessor
6Diskette Drive 14 Primary ATA (IDE) Controller
7Parallel Port (LPT 1)
Computer Diagnostic LEDs (on front of computer)
LED Color LED/Beep Activity State/Message
Power Green On (S0) Computer on
Power Green 1 blink every 2 seconds (S1) Suspend Mode
Power Green 1 blink every 2 seconds (S3) Suspend to RAM
Power Clear Off (S4) Hibernation
Power Clear Off (S5) Computer off
Power Red* 2 blinks 1 second apart CPU thermal shutdown
Power Red* 3 blinks 1 second apart CPU not installed
Power Red* 4 blinks 1 second apart Power supply overload (crow bar)
Power Red* 5 blinks 1 second apart Defective or missing memory
Power Red* 6 blinks 1 second apart Defective or missing graphics
Power Red* 7 blinks 1 second apart System board failure (detected prior to video)
Power Red* 8 blinks 1 second apart Invalid ROM based on bad checksum
Power Red* 9 blinks 1 second apart System not fetching code
Power Red* 10 blinks 1 second apart System hang while loading an option ROM
Hard Drive Green Blinking Hard drive activity
*Blinking codes are repeated after a 2 second pause. Beeps stop after fifth iteration but LEDs continue until problem is
resolved.
Keyboard Diagnostic LEDs, PS/2 Keyboards Only
LED Color LED Activity State/Message
Num, Caps,
Scroll Lock Green On (Rising Tone) ROM reflashed successfully
Num Lock Green On ROMPaq diskette not present, is bad, or drive
not ready.*
Caps Lock Green On Enter password.
Num, Caps,
Scroll Lock Green Blink On in sequence, one at a time - N, C, SL Keyboard locked in network mode
* Insert valid ROMPaq diskette in drive A. Turn power switch off, then on to reflash ROM. If ROM flash is successful, all
three keyboard LEDs will light up, and you will hear a rising tone series of beeps. Remove diskette and turn power off,
then on to restart the computer. For more information about flashing the ROM, refer to the Troubleshooting guide.
Clearing CMOS
The computer's configuration (CMOS) may occasionally be corrupted. If it is, it is necessary to clear the CMOS
memory using switch SW50.
To clear and reset the configuration, perform the following procedure:
1. Prepare the computer for disassembly.
ÄCAUTION: The power cord must be disconnected from the power source before pushing the Clear CMOS
Button (NOTE: All LEDs on the board should be OFF). Failure to do so may damage the system board
2. Remove the access panel.
3. Press the CMOS button located on the system board and keep it depressed for 5 seconds.
4. Replace the access panel.
5. Turn the computer on and run F10 Computer Setup (Setup-utility) to reconfigure the system.
Disabling or Clearing the Power-On and Setup Passwords
1. Turn off the computer and any external devices, and disconnect the power cord from the power outlet.
2. Remove the access panel.
3. Locate the header and jumper labeled E49.
4. Remove the jumper from pins 1 and 2. Place the jumper over pin 2 only, in order to avoid losing it.
5. Replace the access panel.
6. Plug in the computer and turn on power. Allow the operating system to start.
NOTE: Placing the jumper on pin 2 clears the current passwords and disables the password features.
7. To re-enable the password features, repeat steps 1-3, then replace the jumper on pins 1 and 2.
8. Repeat steps 5-6, then establish new passwords.
Refer to the Computer Setup (F10 Setup) instructions to establish new passwords.
Computer Setup (F10) Utility Features (not all features may be available)
File System Information About
Set Time and date
Replicated Setup
Default Setup
Apply Defaults and Exit
Ignore Changes and Exit
Save Changes and Exit
Storage Device Configuration
Storage Options DPS Self-Test Boot Order
Security
Setup Password
Power-On Password
Password Options
Smart Cover
Embedded Security
Drivelock Security
Data Execution Prevention
Master Boot Record Security
Save Master Boot Record
Restore Master Boot Record
Device Security
Network Service Boot
System IDs
Power OS Power Management Hardware Power Management Thermal
Advanced Power-On Options BIOS Power On
Onboard devices
PCI Devices
Bus Options Device Options PCI VGA Configuration
