HP Compaq dx2250 User manual

Service Reference Guide
HP Compaq dx2250 Business PC

© Copyright 2006 Hewlett-Packard
Development Company, L.P. The
information contained herein is subject to
change without notice.
Microsoft and Windows are trademarks of
Microsoft Corporation in the U.S. and other
countries.
The only warranties for HP products and
services are set forth in the express warranty
statements accompanying such products
and services. Nothing herein should be
construed as constituting an additional
warranty. HP shall not be liable for technical
or editorial errors or omissions contained
herein.
This document contains proprietary
information that is protected by copyright. No
part of this document may be photocopied,
reproduced, or translated to another
language without the prior written consent of
Hewlett-Packard Company.
Service Reference Guide
Business PCs
First Edition (November 2006)
Document Part Number: 440319–001

About This Book
WARNING! Text set off in this manner indicates that failure to follow directions could result in
bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in
damage to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
ENWW iii

iv About This Book ENWW

Table of contents
Index .................................................................................................................................................................153
ENWW v

vi ENWW

1 Install the Operating System
CAUTION: Do not add optional hardware or third-party devices to your computer until the
operating system is successfully installed. Doing so may cause errors and may prevent the
operating system from installing properly. Once the automatic installation has begun, DO NOT
TURN OFF THE COMPUTER UNTIL THE PROCESS IS COMPLETE. Turning off the computer
during the installation process might damage the software that runs the computer or prevent its
proper installation.
NOTE: Be sure there is a 10.2-cm (4-inch) clearance at the back of the unit and above the
monitor to permit the required airflow.
The first time the computer is turned on, the operating system is automatically installed. This takes
approximately 10 minutes, depending on the operating system being installed. Carefully read and follow
the instructions that appear on the screen to complete the installation.
NOTE: If the computer shipped with more than one operating system language on the hard
drive, the installation process could take up to 60 minutes.
If the computer was not shipped with a Microsoft operating system, some portions of this documentation
do not apply. For complete operating system installation and configuring instructions, refer to the
operating system documentation. Additional information is available in online help.
Microsoft security updates are available on the Microsoft Web site.
Installing or Upgrading Device Drivers
When installing optional hardware devices after the operating system installation is complete, you must
also install the drivers for each of the devices.
If prompted for the i386 directory, replace the path specification with C:\i386, or use the Browse button
in the dialog box to locate the i386 folder. This action points the operating system to the appropriate
drivers.
Obtain the latest support software, including support software for the operating system from
http://www.hp.com/support. Select your country and language, select Download drivers and
software, enter the model number of the computer, and press Enter.
Transferring Files and Settings
Use the Microsoft Windows XP Professional/Home Files and Settings Transfer Wizard to move files and
settings from the old computer to the new one. Click Start > All Programs > Accessories > System
ENWW Installing or Upgrading Device Drivers 1

Tools > Files and Settings Transfer Wizard. Follow the wizard's instructions to transfer files and
settings to the new computer.
HP Backup and Recovery Manager
The HP Backup and Recovery Manager is an easy-to-use, versatile application that is pre-loaded on
each system and allows you to:
●create Recovery Points to back up the entire system incrementally
●back up the entire system in a single hard archive
●back up individual files
Backups can be scheduled to occur automatically at designated intervals, or they can be initiated
manually. Recovery can be performed from the Recovery Partition on the hard drive or the Recovery
Disc Set. The Recovery Disc Set includes the Restore Plus! CD, the Microsoft Operating System, and
any Supplemental Software CDs.
NOTE: HP highly recommends that you create a Recovery Disc Set immediately before using
the computer and schedule regular automatic Recovery Point backups.
To create the Recovery Disc Set:
1. Click Start > HP Backup and Recovery > HP Backup and Recovery Manager to open the
Backup and Recovery Wizard, then click Next.
2. Select Create factory software recovery CDs or DVDs to recover the system.
3. Follow the instructions in the wizard.
The HP Backup and Recovery Manager provides two basic recovery methods. The first, recovery of
files and folders, operates in Windows. The second, PC Recovery, requires a reboot to the Recovery
Partition or from the Recovery Disc Set. To reboot to the Recovery Partition, press F11 at startup when
you see the message “Press F11 for Emergency Recovery.”
NOTE: For more information on using HP Backup and Recovery Manager, refer to the HP
Backup and Recovery Manager User Guide by selecting Start > HP Backup and Recovery >
HP Backup and Recovery Manager Manual.
You can order a Recovery Disc Set from HP by calling the HP support center. Go to the following
Web site, select your region, and click the Technical support after you buy link under the Call
HP heading to obtain the support center telephone number for your region.
http://welcome.hp.com/country/us/en/wwcontact_us.html
2 Chapter 1 Install the Operating System ENWW

2 Computer Setup (F10) Utility
Computer Setup (F10) Utilities
Use Computer Setup (F10) Utility to do the following:
●Change factory default settings.
●Set the system date and time.
●Set, view, change, or verify the system configuration, including settings for processor, graphics,
memory, audio, storage, communications, and input devices.
●Modify the boot order of bootable devices such as hard drives, diskette drives, optical drives, or
USB flash media devices.
●Restrict a device from booting the unit.
●Run hard drive self-tests.
●View CPU and system temperatures.
●Enter the Asset Tag or property identification number assigned by the company to this computer.
●Establish a supervisor password that controls access to Computer Setup (F10) Utility and the
settings described in this section.
●Secure integrated I/O functionality, including the serial, USB, or parallel ports, audio, or embedded
NIC, so that they cannot be used until they are unsecured.
●Enable or disable removable media boot ability.
●Enable or disable legacy diskette write ability (when supported by hardware).
Using Computer Setup (F10) Utilities
Computer Setup can be accessed only by turning the computer on or restarting the system. To access
the Computer Setup Utilities menu, complete the following steps:
1. Turn on or restart the computer. If you are in Microsoft Windows, click Start > Shut Down >
Restart.
2. As soon as the computer is turned on, press F10 when the monitor light turns green to enter
Computer Setup. Press Enter to bypass the title screen, if necessary.
NOTE: If you do not press F10 at the appropriate time, you must restart the computer and
again press F10 when the monitor light turns green to access the utility.
ENWW Computer Setup (F10) Utilities 3

3. The Computer Setup Utility screen is divided into menu headings and actions.
Eight menu headings appear on the Computer Setup Utility screen:
●System Information
●Standard CMOS Features
●Advanced BIOS Features
●Advanced Chipset Features
●Integrated Peripherals
●Power Management Setup
●PC Health Status
Five action choices are listed on the Computer Setup Utility screen:
●Load Optimized Defaults
●Set Supervisor Password
●Set User Password
●Save & Exit Setup
●Exit Without Saving
Use the arrow keys to select the appropriate heading, then press Enter. Use the arrow (up and
down) keys to select the option you want, then press Enter. To return to the previous screen,
press Esc.
4. To apply and save changes, press F10 or select Save & Exit Setup on the Computer Setup Utility
screen and press Enter.
If you have made changes that you do not want applied, select Exit Without Saving and press
Enter.
CAUTION: Do NOT turn the computer power OFF while the BIOS is saving the Computer Setup
(F10) changes because the CMOS could become corrupted. It is safe to turn off the computer
only after exiting the F10 Setup screen.
Table 2-1 Computer Setup (F10) Utility Main Menu
Heading Table
System Information Table 2-2 Computer Setup—System Information on page 5
Standard CMOS Features Table 2-3 Computer Setup—Standard CMOS Features
on page 6
Advanced BIOS Features Table 2-4 Computer Setup—Advanced BIOS Features
on page 8
Advanced Chipset Features Table 2-5 Computer Setup—Advanced Chipset Features
on page 9
Integrated Peripherals Table 2-6 Computer Setup—Integrated Peripherals
on page 10
4 Chapter 2 Computer Setup (F10) Utility ENWW

Power Management Setup Table 2-7 Computer Setup—Power Management Setup
on page 11
PC Health Status Table 2-8 Computer Setup—PC Health Status on page 12
(Action Choices) Table 2-9 Computer Setup—(Action Choices) on page 12
Computer Setup—System Information
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-2 Computer Setup—System Information
Option Description
Product Name (view only)
SKU Number (view only)
Processor Type (view only)
Processor Speed (view only)
Cache Size (view only)
Memory Size (view only)
System ROM (view only)
Integrated MAC (view only)
UUID (view only)
System Serial # (view only)
Asset Tracking
Number
(view only)
Enter Asset Tag No. Enter asset tag number assigned by the company (maximum 18 characters).
Table 2-1 Computer Setup (F10) Utility Main Menu (continued)
ENWW Computer Setup (F10) Utilities 5

Computer Setup—Standard CMOS Features
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-3 Computer Setup—Standard CMOS Features
Option Description
Date (mm:dd:yy) Allows you to set system date.
Time (hh:mm:ss) Allows you to set system time.
PATA Controller Disables/enables PATA Controller.
PATA Channel 0 Master
PATA Channel 0 Slave
For each, if PATA HDD is used, allows you to:
●run HDD self-test for selected channel:
●SMART Status Check
●HDD Short Self-Test
●HDD Extended Self-Test
●set PATA Ch 0 Master/Slave device details on selected channel to:
●Auto
●Manual
●set access mode on selected channel to:
●CHS (Cylinder-Head-Sector)
●LBA (Logical Block Addressing)
●Large
●Auto
●view:
●Firmware Version
●Capacity
●Cylinder
●Head
●Precomp
●Landing Zone
●Sector
SATA Controller Disables/enables onboard SATA controller.
SATA Mode Allows you to set the onboard SATA mode to:
●Native IDE
●Legacy IDE
6 Chapter 2 Computer Setup (F10) Utility ENWW

SATA Channel 1 Master
SATA Channel 2 Master
For each, allows you to:
●run HDD self-test for selected channel:
●SMART Status Check
●HDD Short Self-Test
●HDD Extended Self-Test
●set extended IDE drive on selected channel to:
●None
●Auto
●set access mode on selected channel to:
●Large
●Auto
●view:
●Firmware Version
●Capacity
●Cylinder
●Head
●Precomp
●Landing Zone
●Sector
Floppy Controller Disables/enables the floppy disk controller.
Drive A Allows you to set Drive A to:
●None
●1.44M, 3.5 in.
Halt On Allows you to set POST error behavior to:
●All Errors
●No Errors
●All but Keyboard
●All but Diskette
●All but Diskette/Keyboard
POST Delay Allows you to set a POST delay to:
●0 seconds
●5 seconds
●10 seconds
Table 2-3 Computer Setup—Standard CMOS Features (continued)
ENWW Computer Setup (F10) Utilities 7

●15 seconds
●30 seconds
Computer Setup—Advanced BIOS Features
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-4 Computer Setup—Advanced BIOS Features
Device Boot Disabling Allows you to restrict a device from booting the unit. You can disable as a bootable device:
●None
●USB
●Internal ODD
●Internal FDD
●USB + ODD + FDD
F9 Boot Menu Disables/enables F9 Boot Menu.
Removable Device
Boot Seq.
Allows you to specify the order of attached removable devices (such as Floppy Discs or USB FDD).
The first drive in the order has priority in the boot sequence and is recognized as drive A.
Hard Disk Boot Seq. Allows you to specify the order of attached hard drive devices (such as USB HDD storage, USB2
Drive Key, or USB flash media). The first drive in the order has priority in the boot sequence and is
recognized as drive C (if any devices are attached).
Optical Drive Boot
Seq.
Allows you to specify the order in which attached optical drives (including USB ODD) are checked
for a bootable operating system image.
Network Boot Seq. Allows you to specify the order in which network devices (including UP NIC cards) are checked for
a bootable operating system image.
First Boot Device
Second Boot Device
Third Boot Device
Fourth Boot Device
Allows you to specify which devices will boot first, second, third, and fourth or to disable any of the
four:
●Removable
●Hard Disk
●CDROM
●Network
●Disabled
NOTE: MS-DOS drive lettering assignments may not apply after a non-MS-DOS operating
system has started.
Boot Up NumLock
Status
Allows you to set the default NumLock status to off or on.
Security Option Allows you to set the security option to Setup or System so that the password is required every time
the system boots or only when entering Computer Setup.
BIOS Write Protect Disables/enables BIOS write Protect function.
AMD NX Function Disables/enables AMD NX Function.
8 Chapter 2 Computer Setup (F10) Utility ENWW

Computer Setup—Advanced Chipset Features
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-5 Computer Setup—Advanced Chipset Features
Option Description
UMA Frame Buffer Select the UMA (Unified Memory Architecture) frame buffer size:
●32MB
●64MB
●128MB
●Recommended (system allocates memory automatically)
Init Display First
(VGA Setting)
Allows you to select the primary display device:
●PCI Slot
●OnChipVGA
●PCIEx
SURROUNDVIEW
(VGA Setting)
Disables/enables SURROUNDVIEW (available when an ATI PCIEx video card is installed).
Auto Detect PCI Clk
(VGA Setting)
Disables/enables PCI clock auto-detection.
Spread Spectrum
(VGA Setting)
Disables/enables Spread Spectrum.
ENWW Computer Setup (F10) Utilities 9

Computer Setup—Integrated Peripherals
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-6 Computer Setup—Integrated Peripherals
Option Heading
Onboard HD Audio Disables/enables onboard HD audio.
OnChip USB
Controller
Disables/enables USB controller.
USB Legacy Support Disables/enables USB legacy support function (USB keyboard, USB mouse, and USB flash media).
Onboard LAN Disables/enables onboard LAN controller.
Onboard LAN Boot
ROM
Disables/enables the boot ROM of the onboard LAN chip.
Onboard Serial Port Allows you to select a setting for the onboard serial port:
●Disabled
●3F8/IRQ4
●2F8/IRQ3
●3E8/IRQ4
●2E8/IRQ3
Onboard Parallel Port Allows you to select a setting for the onboard parallel port:
●Disabled
●378/IRQ7
●278/IRQ5
●3BC/IRQ7
Parallel Port Mode Allows you to select parallel port mode:
●SPP
●EPP
●ECP
●ECP+EPP
●Normal
10 Chapter 2 Computer Setup (F10) Utility ENWW

Computer Setup—Power Management Setup
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-7 Computer Setup—Power Management Setup
Option Heading
After AC Power Loss Allows you to select system power loss behavior:
●On
●Off
●Last State
External Modem S5
Wake-Up
Disables/enables wake-up modem from S5.
Wake on PCI Device
from S5
Disables/enables PCI S5 on power on.
AMD Cool'n'Quiet Disables/enables the AMD Cool'n'Quiet feature.
RTC Alarm Resume Disables/enables RTC (real-time clock) alarm.
Date (of Month) If RTC Alarm Resume is enabled, allows you to select the day of the month for resumption of RTC
alarm. (Set to 0 for every day.)
Resume Time
(hh:mm:ss)
If RTC Alarm Resume is enabled, allows you to select what time the RTC alarm will resume.
ENWW Computer Setup (F10) Utilities 11

Computer Setup—PC Health Status
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-8 Computer Setup—PC Health Status
Option Description
System Fan Fail Check Disables/enables system fan detection during POST.
Smart Fan Function Disables/enables smart fan functionality.
Current CPU
Temperature
(view only)
Current System
Temperature
(view only)
Current CPU Fan
Speed
(view only)
Current System Fan
Speed
(view only)
Vcore (view only)
+12V (view only)
VCC5 (view only)
+3.3V (view only)
VBAT (V) (view only)
3VSB (V) (view only)
Computer Setup—(Action Choices)
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 2-9 Computer Setup—(Action Choices)
Option Description
Load Optimized
Defaults
Allows you to reset Computer Setup to factory defaults.
Set Supervisor
Password
Allows you to establish a password to control access to Computer Setup.
Set User Password Allows you to establish a password to control access to the computer. (Supervisor password must
be set before you can set a User password.)
Save & Exit Setup Allows you to save current settings and exit Computer Setup.
Exit Without Saving Allows you to exit Computer Setup without saving changes.
12 Chapter 2 Computer Setup (F10) Utility ENWW

Recovering the Configuration Settings
Recovering the configuration settings established in the Computer Setup (F10) Utility requires that you
first back up the settings before a recovery is needed.
The CMOS Save/Load utility can be found at http://www.hp.com under the Software & Driver Downloads
for your specific model. Download the firmware files into a folder on a removable storage device. It is
recommended that you save any modified computer configuration settings to a diskette, a USB flash
media device, or a diskette-like device (a storage device set to emulate a diskette drive) and save the
diskette or device for possible future use.
Backing Up the CMOS
1. Make sure the computer to be backed up is turned on. Connect the removable storage to the
computer.
2. Boot to DOS.
3. Type N:\folder\BIOS.exe SAVE:ABC001.DAT (where Nis the drive letter of the removable
storage) to save the CMOS setting to the removable storage device.
Restoring the CMOS
1. Make sure the target computer is turned on. Connect the removable storage to the target computer.
2. Boot to DOS.
3. Type N:\folder\BIOS.exe LOAD:ABC001.DAT (where Nis the drive letter of the removable
storage) to load the custom CMOS setting onto the target system.
ENWW Recovering the Configuration Settings 13

14 Chapter 2 Computer Setup (F10) Utility ENWW
