Volume Two 3-65
Presario 5200
System Board Assembly Spare Part Config. Codes System
Processor Board,
FP, N/NIC 352728-101 480075-001 CD94, CD95, CD96, CFD4,
CGP2, CGP4,
CGP6, CGP7,
CJDL
5202, 03,
04, 20, 21,
22, 25, 40,
86
Processor Board,
FP, N/NIC 320446-101 320645-001 CFD2, CFD5, CFD7, CFDC,
CFDG, CFDH,
CFDJ, CGP3,
CJ62, CJD2,
CJD3, CJDC,
CJDK
5201, 23,
35, 40, 41,
42, 43, 45,
48, 50, 53,
82, 83, 84,
85
Processor Board,
FP/BX 352727-101 480077-001 CFF4, CFG7, CGC3, CJ68 5210, 30, 60, 70, 96
Processor Board,
FP NIC/BX 352727-102 480078-001 5260, 60, 70, 80
586/100 System
Board w/o MPEG
or Processor
005490-101 234707-001 HVG2, HVH2 5220, 26
Jumper Settings
Jumper Function Pins Description
P1 CMOS Clear 1-2 (default) Secure CMOS Power
Open Remove jumper for 10
seconds. Reinstall to clear
CMOS
P2 CPU Clock
Multiplier A1-A2 B1-B2 1.5x
A2-A3
B1-B2 2.0x
A2-A3
B2-B3 2.5x
A1-A2
B2-B3 3.0x
P3 Bus Speed
Select 1-2 50 MHz CPU Ext. Bus Freq.
2-3 40 MHz CPU Ext. Bus Freq.
3-4 60 MHz CPU Ext. Bus Freq.
4-5 66 MHz CPU Ext. Bus Freq.

3-66 Volume Two
Presario 5200
Configuration
Code Assembly System Board Spare Part Model
CD94 320446-101 480075-001 5204
CD96 320446-101 480075-001 5202
CFB2 352727-102 480078-001 5206
CFC2 352727-101 480077-001 5210
CFD2 320446-101 320645-001 5253
CFD5 320446-101 320645-001 5248
CFD7 320446-101 320645-001 5250
CFDB 320446-101 320645-001 5230
CFDC 320446-101 320645-001 5245
CFDG 320446-101 320645-001 5242
CFDH 320446-101 320645-001 5240
CFDJ 320446-101 320645-001 5241
CFF3 352727-101
352727-102 480077-001 480078-001 5260
CFF4 352727-101
352727-102 480077-001 480078-001 5260
CFF5 352727-101
352727-102 480077-001 480078-001 5260
CFG2 352727-101
352727-102 480077-001 480078-001 5270
CFG3 352727-101
352727-102 480077-001 480078-001 5270
CFG4 352727-101
352727-102 480078-001 5270
CGC3 352727-101 480077-001 5210
CGP2 352728-101 480075-001 5221
CGP3 320446-101 320645-001 5223
CGP4 320446-101 480075-001 5225
CGP5 352728-101 480075-001 5220
CGP6 320446-101 480075-001 5222
CGP7 352728-101 480075-001 5220
CJ62 320446-101 320645-001 5201
CJ68 352727-101 480077-001 5230
CJD2 320446-101 320645-001 5283
CJD3 320446-101 320645-001 5282
CJD4 320446-101 320645-001 5280
GVG3 005490-101 234707-001 5220
GVG4 005490-101 234707-001 5220
GVG8 005490-101 234707-001 5220
GVG9 005490-101 234707-001 5220
GVH3 005490-101 234707-001 5226
HVG2 005490-101 234707-001 5220
HVH2 005490-101 234707-001 5226

Volume Two 3-67
Presario 5200
Memory Assembly Spare Part System
Video Memory, 1 MB 004827-001 213859-001 5220, 26 Option
Video Memory, 4 MB 320821-002 400431-001 5221, 40, 42, 43, 45,
80, 82
(Option – 5202, 04,
20, 22, 25, 40, 42,
45, 48, 50, 70, 80)
Video Memory, 4 MB 341749-001 400431-001 5260
32 MB DIMM, 100 MHz 320767-101 319326-001 5235, 41, 45, 60
64 MB DIMM, 100 MHz 320768-101 320670-001 5201, 02, 04, 10, 20,
21, 22, 23, 25, 30,
35, 40, 41, 42, 43,
45, 48, 53, 60
128 MB DIMM, 100 MHz 381320-101 387073-001 5206, 42, 50, 70, 80,
82, 83
Microprocessors Assembly Spare Part System
K6II, 333 320471-003 337364-001 5201
K6II, 350 320471-005 328966-001 5202, 04, 40
K6II, 380 330631-003 400446-001 5220, 21, 22, 23, 25
K6II, 400/70 330631-001 320668-001 5230, 35, 40, 41, 42,
43, 45, 48, 50, 53
K6II, 400/60 387488-001 320668-001 5230, 35, 40, 42, 43,
45, 50, 53,
K6II, 450 329074-003 400432-001 5280, 82, 83
PII, 400 278309-002 327584-001 5206, 60, 70
PII, 450 278309-003 327585-001 5270
P54C/100 w/o Heat Sink 172915-023 213113-001 5220, 26
Miscellaneous Internal Assembly Spare Part System
Monitor Assembly, NA,
POL* 214136-001 214137-001 5220, 26
Monitor Assembly, S/H 214136-003 214137-003 5220, 26
Monitor Assembly, N/H,
MPR 214136-004 214137-004 5220, 26
MEPG Controller 004821-001 213857-001 5220, 26
Wave Table Controller 004824-001 213858-001 5220, 26
Speaker Assembly 214156-001 214345-001 5220, 26
Logo Kit, N. America 320672-001 5202, 04, 20, 22, 24,
25, 26, 40, 42, 45,
48, 50, 70, 80, 82
Logo Kit, EMEA 214338-002 5220, 22, 24, 26
Logo Kit, APD 214338-003 5220, 22, 24, 26
Logo Kit, Latin America 214338-004 5220, 22, 24, 26
Logo Kit, Japan 214338-005 5220, 22, 24, 26
Button Board w/ Bracket 308882-002 320664-001 5201, 02, 04, 06, 10,
20, 21, 22, 23, 25,
30, 35, 40, 41, 42,
43, 45, 48, 50, 53,
60, 70, 80, 82, 83
*POL = Polished Glass

3-68 Volume Two
Presario 5200
Hard Drives Assembly Spare Part System
840 MB 214124-001 214211-001 5220, 26
1.05 GB 214123-001 214213-001 5220, 26
4.0 GB, IDE 286118-001 286248-001 5201, 02, 04
6.0 GB, IDE 352743-001 480079-001 5210, 21
8.0 GB, IDE 352744-001 400030-001 5220, 22, 40
8.0 GB, IDE 334180-002 334719-001 5260
10.0 GB, IDE 356039-001 387614-001 5223, 25, 30, 40, 41,
42, 53, 60, 70
12.0 GB, IDE 352745-001 480080-001 5225, 35, 43, 45, 48,
50, 80
13.5 GB, IDE 178546-001 334807-001 5206, 70
19.2 GB, IDE 320880-001 334788-001 5270, 82, 83
CD-ROM Drives Assembly Spare Part System
CD-ROM, IDE, 4 Speed 184778-301 172864-301 5220, 26
CD-ROM, IDE, 32X 310185-001 317212-001 5201, 02, 04, 10, 20,
21, 22, 25, 40, 45
CD-ROM, IDE, 40X 386704-003 400028-001 5223, 30, 35, 40, 48,
53, 80
DVD4 320716-401 327446-001 5206, 41, 42, 43, 50,
60, 70, 80, 82, 83
DVD5 5282
Diskette Drives Assembly Spare Part System
1.44 MB 304235-001 5201, 02, 04, 20, 21,
23, 40, 42, 43, 45,
48, 50, 53, 80, 82,
83
1.44 MB 141087-406 239612-401 5202, 04, 06, 10, 25,
45, 50, 60, 70
1.44 MB (Three-mode) 141087-305 160788-301 5220, 26
Zip 270928-003 328934-001 5206, 43, 70, 83
120 MB/1.44 MB SuperDis
k
184932-402 400430-001 5220, 22, 30, 35, 40,
41, 42, 48, 80, 82
19.2/14.4k-bps Modem+TAM ISA
Country Assembly Spare Part Cable Spare Part System
Australia 176550-012 217810-011 165224-011 5220, 5226
Austria 176550-342 217810-341 165224-341 5220, 5226
Belgium 176550-182 217810-181 165224-181 5220, 5226
Denmark 176550-082 217810-081 165224-081 5220, 5226
Finland 176550-352 217810-351 165224-351 5220, 5226
France 176550-052 217810-051 165224-051 5220, 5226
Germany 176550-042 217810-041 165224-041 5220, 5226
Italy 176550-062 217810-061 165224-061 5220, 5226
Korea 176550-AD2 217810-AD1 165224-AD1 5220, 5226
Netherlands 176550-332 217810-331 165224-331 5220, 5226
New Zealand 176550-AP2 217810-AP1 165224-AP1 5220, 5226
Norway 176550-092 217810-091 165224-091 5220, 5226
Portugal 176550-132 217810-131 165224-131 5220, 5226
Sng/Mai/Thi 176550-AF2 217810-AF1 165224-AF1 5220, 5226
Spain 176550-072 217810-071 165224-071 5220, 5226
Sweden 176550-102 217810-101 165224-101 5220, 5226
Switzerland 176550-112 217810-111 165224-111 5220, 5226
U Kingdom 176550-032 217810-031 165224-031 5220, 5226
W/VoiceView 225150-001 225152-001 127949-001 5220, 5226

Volume Two 3-69
Presario 5200
28.8/14.4k-bps Modem
Country Assembly Spare Part Cable Spare part System
Japan 004860-191 212901-191 137256-001 5220, 5226
56 Kb/s Modem KAT
Country Assembly Spare Part System
Belgium, Denmark, Finland,
France, Germany, Italy,
Netherlands, Norway, Portugal,
Spain, Sweden, Switzerland, UK
334790-021 334808-021 5260
56 Kb/s Modem K-PCI
Country Assembly Spare Part System
Asia 352374-001 387518-001 5270
Australia 352374-001 387518-001 5210, 20, 40, 60
Japan 352374-001 387518-001 5260
New Zealand 352374-001 387518-001 5210, 20, 40, 60
PRC 352374-001 387518-001 5204, 70
Taiwan 352374-001 387518-001 5270
Z-56 Kb/s Modem
Country Assembly Spare Part Cable Spare Part System
Brazil 337550-001 337559-001 5223, 43, 53
Canada 337550-001 337559-001 5204, 20, 30,
40, 48, 50, 70
Caribbean 337550-001 337559-001 5243, 83
Japan 337550-001 337559-001 5201, 04, 40,
60, 70
Latin America 337550-001 337559-001 5243, 83
LA
Spanish/Brazil 337550-001 337559-001 5223, 43, 53
Puerto Rico 337550-001 337559-001 5220, 30, 43
US Retail 337550-001 337559-001 137256-001 5202, 04, 20,
22, 25, 30, 35,
40, 41, 42, 45,
80, 82
UDSL/ITU 56K
Country Assembly Spare Part Cable Spare Part System
US Retail 339566-001 339573-001 137256-001 5250, 70, 82
Cable Information Spare Part System
Diskette Data/Power Cables 177071-001 5220, 22, 24, 26
HD/CD ROM Power, Data, Audio Cables 214335-001 5220, 22, 24, 26
Cable Kit 320663-001 5201, 02, 04,
06, 10, 20, 21,
22, 23, 25, 30,
35, 40, 41, 42,
43, 45, 48, 50,
53, 60, 70, 80,
82, 83

3-70 Volume Two
Presario 5200
System ROM Spare Part System
System ROMPaq 148218-001 5220, 22, 24, 26
Miscellaneous External Spare Part System
Keyboard, US 340869-003 5202, 04, 06, 20, 22,
25, 30, 35, 40, 41,
42, 45, 50, 70, 80,
82
Mouse, Ivory 196694-301 5220, 22, 24, 26
Mouse, Ivory 337416-001 5202, 04, 20, 21, 22,
23, 25, 30, 35, 40,
41, 42, 43, 45, 48,
50, 53, 70, 80, 82,
83
Mouse, Scroll/Ivory 334689-001 5201, 60
Mouse, Ivory 199181-401 5206, 10, 60
Power Supply/Battery Assembly Spare Part System
110W 319239-002 319235-001 5201, 02, 04, 06, 10,
20, 21, 22, 23, 25,
30, 35, 40, 41, 42,
43, 45, 48, 50, 53,
60, 70, 80, 82, 83
Real-Time Clock Battery,
4.5 Volts, 600 mA 160274-001 5220, 22, 24, 26

Volume Two 3-71
Presario 5200
Memory Upgrade Chart
586 SYSTEM BOARD
004794, 004797
( 8 MB)
ADD ANY COMBINATION OF MEMORY MODULES UP TO 72 MEGABYTES
TOTAL SYSTEM MEMORY. MUST BE UPGRADED IN IDENTICAL PAIRS
USING INDUSTRY STANDARD 70ns SIMMS WITH TIN/LEAD CONTACTS ONLY.
MEMORY MODULES NOT AVAILABLE

3-72 Volume Two
Presario 5200
Memory Upgrade Chart
A MAXIMUM OF 384 MB TOTAL MEMORY
PROCESSOR BOARD
320645-101, 480075-001
32-MB 100MHz SDRAM DIMMs - OPTION PN 308875-001
64-MB 100MHz SDRAM DIMMs - OPTION PN 308877-001
128-MB 100MHz SDRAM DIMMs - OPTION PN 308878-001

Volume Two 3-73
Presario 5200
Memory Upgrade Chart
A MAXIMUM OF 384 MB TOTAL MEMORY
PROCESSOR BOARD
320446--101
MEMORY OPTIONS ARE NOT AVAILABLE
