HP Compaq Presario Manual

3-118 Volume Two
Presario 9500
System Boards
(w/o Processor) Assembly Spare Part Config Codes System
P54C System Board,
75/90 MHz, 8 MB, w/
MPEG
004810-101 214524-001 HSB
GRZ
GRZ
Note 1
P54C System Board,
75/90 MHz, 8 MB,
w/o MPEG
004813-101 214525-001 GRE
HRZ Note 2
P54C System Board,
100/133 MHz, 8 MB,
w/ MPEG
004814-101 214414-001 HSA
HSA
HTG
Note 3
P54C System Board,
100/133 MHz, 8MB,
w/o cache, w/ MPEG
005491-101 214079-001 HSA Note 4
1Presario 9534, 9536, 9538. 2Presario 9520, 9530, 9532, 9536.
3Presario 9542, 9544, 9548, 9564. 4Presario 9546.
Configuration Jumper Settings (004810, 004813, 004814, 005491)
Jumper Function Setting Description
P1 CMOS Power 1 - 2
Open Secure CMOS Power (Default) Remove jumper 10 sec, then reinstall to
clear CMOS
P2 Clock Multiplier Setting Multiplier
A1-A2 1.5X
B1-B2
A2-A3 2.0X
B1-B2
A2-A3 2.5X
B2-B3
A1-A2 3.0X
B2-B3
P3 Bus Speed Select 1 - 2
2 - 3
3 - 4
4 - 5
50MHz CPU External Bus Frequency
40MHz CPU External Bus Frequency
60MHz CPU External Bus Frequency
66MHz CPU External Bus Frequency
Microprocessors Spare Part System
P54C/75 172760-003 Note 1
P54C/90 172760-002 Note 2
P54C/100 213113-001 Note 3
P54C/133 223311-001 Note 4
1Presario 9520. 2Presario 9530, 9534, 9536, 9538.
3Presario 9542, 9544, 9546, 9548. 4Presario 9564.
Memory Assembly Spare Part System
4 MB SIMM, 60ns, Tin/Lead
Contacts. U.S. Only. 214531-001 214049-001 9548, 9564
1 MB Video Memory 004827-001 213859-001 Option

Volume Two 3-119
Presario 9500
Miscellaneous Assembly Spare Part System
Backplane, 5x5 004818-001 213856-001 All
Keyboard, U.S./Canadian 160650-001 160648-301 All
Mouse, Ivory 141189-301 All
Controller Boards Assembly Spare Part System
MPEG Module 004821-001 213857-001 Option
WaveTable Module 004824-001 213858-001 Note 1
1Presario 9542, 9546, 9548, 9564.
Hard Drives Type Cable Select Spare Part System
630 MB, IDE 65 Yes 214209-001 Note 1
840 MB, IDE 65 Yes 214211-001 Note 2
1.05 GB, IDE 65 Yes 214213-001 Note 3
1.6 GB, IDE 65 Yes 213990-001 Note 4
1Presario 9520, 9530. 2Presario 9534, 9542.
3Presario 9536, 9538, 9544, 9546. 4Presario 9548, 9564.
CD-ROM Drive Assembly Spare Part System
CD-ROM, IDE, 4-spd, Ivory 172854-301 172864-301 All
Diskette Drives Spare Part System
1.44 MB, 3.5” 160788-301 All
28.8K bps Modem, N/A
Country Assembly Spare Part System
U.S. 004860-001 212901-003* 9548, 9564
* Inactive. Replaced by 212901-001. Plug and play compatible.
19.2/14.4k-bps Modem+FDSP+TAM ISA
Country Assembly Spare Part Cable Spare Part System
Australia 176550-011 176561-011 165224-011 9530, 9534,
9544
Belgium 176550-181 176561-181 165224-181 9520, 9538
Denmark 176550-081 176561-081 165224-081 9520, 9538
Finland 176550-351 176561-351 165224-351 9520, 9538
France 176550-051 176561-051 165224-051 9520, 9538
Germany 176550-041 176561-041 165224-041 9520, 9538
Italy 176550-061 176561-061 165224-061 9520, 9538
Japan 004706-191 213006-191 137256-001 9542
Netherlands 176550-331 176561-331 165224-331 9520, 9538
New Zealand 176550-361 176561-361 165224-API 9530, 9534,
9544
N/S America
19.2 K bps 004706-001 213006-001 127949-001 9536, 9546
Norway 176550-091 176561-091 165224-091 9520, 9538
Portugal 176550-131 176561-131 165224-071 9520, 9538
Sweden 176550-101 176561-101 165224-101 9520, 9538
Switzerland 176550-111 176561-111 165224-111 9520, 9538
United
Kingdom 176550-031 176561-031 165221-031 9520, 9538

3-120 Volume Two
Presario 9500
Cables Spare Part System
LED Cable, w/ Holder 141346-001 All
Diskette Drive Cable 172480-001 All
Hard Drive Cable/CD ROM Cable, Single 172481-001 All
Telephone Cable, U.S. 127949-001 All
Modem Cable, APD 165224-001 All
Dual Hard Drive Cable 172945-001 All
Audio Cable 176866-001 All
ROM Information Spare Part System
System ROMPaq 148218-001 All
ROM BIOS, Modem, 19.2K bps 213018-001 9536, 9544
ROM BIOS, Modem, 19.2K bps, Japan 213019-001 9542
ROM BIOS, Modem, 19.2/14.4K bps 217808-001 Outside North and
South America
ROM BIOS, Modem, 28.8k bps, NA 212907-001 9548, 9564
Power Supply/Battery Spare Part System
Power Supply, 145W 184737-001 Note 1
Power Supply, 145W PCF (Europe) 184738-001 Note 2
Real-Time Clock Battery (4.5 v alkaline) 160274-001 All
1Presario 9530, 9534, 9536, 9542, 9544, 9546, 9548, 9564.
2Presario 9520, 9538 (Europe Only).

Volume Two 3-121
Presario 9500
MEMORY UPGRADE CHART
SYSTEM BOARDS
4810, 4813, 4814, 5491
(8 MB)
MAXIMUM SYSTEM MEMORY IS 136 MEGABYTES
MEMORY OPTIONS ARE NOT AVAILABLE FOR THE PRESARIO 9500
Memory upgrade SIMMs must be installed in pairs.
Fast Pa
g
e Mode SIMMs are recommended for all s
y
stem boards.
