HP Omni Pro 110 All-in-One PC Illustrated Parts & Service Map 654195-001 page1
Illustrated Parts & Service Map
HP Omni Pro 110 All-in-One PC
© 2011 Hewlett-Packard Development Company, L.P. The information con-
tained herein is subject to change without notice. HP shall not be liable for
technical or editorial errors or omissions contained herein. Intel, Pentium,
Intel Inside, and the Intel logo are trademarks or registered trademarks of the
Intel Corporation and its subsidiaries in the U. S. and other countries.
Document Number 654195-001. 1st Edition March 2011.
Key Specifications
Spare Parts
Processor Type Intel® Celeron Dual-Core, Intel Pentium Dual-Core, Intel
Core™2 Duo
RAM Type PC3-10600 DDR3 1333-MHz non-ECC SDRAM
Maximum RAM Sup-
ported 4 GB
Display • 20-inch diagonal
• Resolution: 1600 x 900
• Contrast Ratio: 1000:1
• Image brightness: 250 nits
• Typical response time: 5ms
Graphics Adapter Integrated Intel Graphics Media Accelerator X4500
Chipset Intel G41 Express chipset
Expansion Bays:
External: (1) 5.25- Slim Tray drive bay
Internal: (1) 3.5-inch drive bay
Slots:
(1) Mini Socket Slot (Occupied)
I/O Interfaces (6) USB 2.0 ports: (2) left slide, (4) rear; (1) RJ-45, (1) left
side audio headphone, (1) left side microphone, (1) rear
line out
Operating Systems • Windows 7 Professional 32 & 64
• Windows 7 Home Basic 64
• Windows 7 Starter Edition 32
• RedFlag Linux
•FreeDOS
Mass Storage Devices (not illustrated)
8X DVD±RW SuperMulti DL Drive with LightScribe 597927-001
Optical drive bracket (mounts on back of optical drive) 651600-001
1 TB hard drive 621418-001
750 GB hard drive 632938-001
500 GB hard drive 621421-001
320 GB hard drive 621420-001
250 GB hard drive 621419-001
Standard and Optional Boards
System boards with thermal grease, alcohol pad, and CPU socket cover
1 System board 648965-001
2 Power button board 651585-001
3 Inverter board 651601-001
4 Webcam module 651586-001
5 WLAN module (802.11b/g/n) (1x1 mini card) 634906-001
Memory modules (PC3-10600)
*2GB 651609-001
*1GB 651608-001
Intel Core2 Duo processors with thermal material:
E8500, 6-MB cache, 3.16 GHz 466170-001
E8400, 6-MB cache, 3.00 GHz 509554-001
E7600, 3-MB cache, 3.06 GHz 573954-001
E7500, 3-MB cache, 2.93 GHz 586745-001
Intel Pentium processors with thermal material:
E6800, 2-MB cache, 3.20 GHz, 1066-MHz FSB 631758-001
E6700, 2-MB cache, 3.20 GHz, 1066-MHz FSB 617840-001
E5800, 2-MB cache, 3.30 GHz, 800-MHz FSB 646376-001
E5700, 2-MB cache, 3.00 GHz, 800-MHz FSB 631759-001
E5500, 2-MB cache, 2.80 GHz, 800-MHz FSB 613035-001
Intel Celeron processor with thermal material:
E3500, 1-MB cache, 2.70 GHz, 800-MHz FSB 633219-001
* Not shown
Miscellaneous Parts
1 Display panel, 20-inch, non-glare 646794-001
2 Display bezel 651599-001
3 Heat sink (thermal module) 651607-001
4 Speaker, right 651597-001
4 Speaker, left 651598-001
5 Fan 651606-001
* Thermal pad, DIMM, 20mm x 50mm x 2.5mm (mount under PCA) 651595-001
* Thermal pad, VRM, 15mm x 40mm x 4mm (mount under PCA) 651596-001
* AC adapter, 150W, external 651587-001
* Mouse, USB, optical, Portia 621416-001
*Not shown

HP Omni Pro 110 All-in-One PC Illustrated Parts & Service Map 654195-001 page2
System Board
Computer Setup.
Cables
1 WLAN antenna cable 651594-001
2 Inverter cable 651588-001
3 Optical drive cable 651590-001
4 LVDS cable 651589-001
5 Hard drive cable 651592-001
6 Power button/LED cable 651593-001
7 Webcam cable 651591-001
*Not shown
System Board Connectors and Jumpers (component location may vary)
MINI _CARD1 Mini card connector (WLAN) LAN Network connector
LVDS_UMA Display connector DC JACK AC adapter connector
PROCESSOR CPU SPEAKER_L Left speaker connector
BAT2 RTC battery socket
SPEAKER_R Right speaker connector
CHANNELA
_DIMM0 Memory socket 1 SATA_HDD POWER Hard drive power connec- tor
CHANNELB
_DIMM0 Memory socket 2 SATA0 Hard drive connector
1394A 1394 port SATA1 Optical drive connector
USB2 USB connector SATA_ODD
POWER Optical drive power con- nector
USB1 USB connector
SYSTEM FAN System fan connector
MIC Microphone connector PWR_CON1 Power cable connector
HP_OUT Headphone jack WEBCAM Webcam connector
USB3-6 USB connectors INVERTER Inverter board connector
LINE_OUT Headphone connector
Computer Setup Menu
Heading Option / Description
Main System Time Allows you to set system time.
System Date Allows you to set system date.
System IDs (view only) Lists product name, serial number
UUID, SKU number, family name, feature byte,
build ID.
Language Allows you to select the language.
Floppy Diskette A Specifies capacity and physical size, if installed.
1st Drive
2nd Drive Allow you to: enable/disable port configuration, view capacity (HDD only), view transfer mode. Also
allows you to run HDD self-test for selected chan-
nel: SMART status check, SMART short self test,
SMART extended self test.
System Information Allows you to view installed memory, memory
banks 1-2, BIOS revision, core version.
Advanced CPU Type View only.
CPU Speed View only.
Cache RAM View only.
Supervisor Pass-
word Allows you to view the supervisor password.
User Password Allows you to view the user password.
Onboard LAN Disable/enable onboard LAN controller.
Onboard WLAN Disable/enable onboard WLAN controller.
Onboard LAN Boot
ROM Disable/enable the boot ROM of the onboard LAN chip.
Onboard 1394 Allows you to enable/disable all 1394 ports.
Primary Video
Adapter Allows you to select boot display device when more than 2 video options are offered by system:
Integrated (onboard), PCIe.
SATA Controller Allows you to disable/enable the SATA controller.
SATA Controller
Mode If SATA controller is enabled, allows you to set the mode to: IDE, AHCI.
Onboard Audio Auto/disable/enable.
USB Ports Allows you to individually enable/disable available
USB ports.
Change Supervisor
Password Allows you to change the supervisor password.
Power After AC Power
Failure Allows you to select system restart behavior after power loss: Stay off, Power on, Auto.
XD (Execute Dis-
able) Disable/enable XD bit.
Virtualization Tech-
nology Disable/enable.
WOL from S5 Allows you to enable/disable Limited (normal shut-
down) WOL from S5 support.
Boot Boot-time Diagnos-
tic Screen Disable/enable POST diagnostic messages dis- play.
ESC: Boot Menu Enables/disables the ability to press the Esc key to
access the boot menu during boot.
F9: Diagnostics Enables/disables the ability to press the F9 key to
access the Diagnostics menu during boot.
F10: Setup Enables/disables the ability to press the F10 key to
access the Setup menu during boot.
F11: Recovery Enables/disables the ability to press the F11 key to
access the recovery menu during boot.
F12: Boot from LAN Enables/disables the ability to press the F12 key to
boot from LAN.
Boot Device Prior-
ity: 1st Boot Device,
2nd Boot Device,
3rd Boot Device,
4th Boot Device
Allows you to specify which device groups will boot
first, second, third, and fourth or to disable any
of the four: Floppy group, CD-ROM group, Hard
drive group, Network boot group. MS-DOS drive
lettering assignments maybe apply after a non-MS-
DOS operating system has started.
Floppy Group Boot
Priority Specifies boot device priority within removable devices.
CD-ROM Boot Pri-
ority Specifies boot device priority within CD/DVD drives.
Hard Drive Boot Pri-
ority Specifies boot device priority within hard drives.
Network Group
Boot Priority Specifies boot device priority within bootable net- work devices.
Exit Exit Saving
Changes Press Enter to exit saving changes.
Exit Discarding
Changes Press Enter to exit discarding changes.
Load Setup
Defaults Press Enter to load setup defaults.
Discard Changes Press Enter to discard changes.
Save Changes Press Enter to save changes.
