QuickSpecs HP Compaq dx2250 Microtower Business PC
Overview
DA –12605 EMEA •Version 1 • March 14, 2007 Page 1
HP Compaq dx2250 Microtower Business PC HP recommends
Windows Vista™ Business
Microtower
1.Monitor (sold separately) 6.(2) full-height PCI 2.3 slots, (1) PCI-E x1 slot,
(1) PCI-E x16 slot
2.PS/2 Scroll Mouse 7.(4) USB 2.0 ports, (1) serial port, (1) parallel port, (2)
PS/2, (1) RJ-45, (1) VGA, (1) audio in –(1) audio out –
(1) MIC
3.HP Standard Keyboard 8.250-watt max power supply
4.(2) USB 2.0 ports, audio ports 9.(2) external 5.25" drive bays for optional optical drives;
(1) external 3.5" drive bay for optional media reader or
diskette drive
5.(2) internal 3.5" drive bays
At A Glance
•AMD Athlon™ 64 X2 Dual-Core, Athlon 64, and Sempron™ processors with HyperTransport™ technology
•ATI Radeon Xpress 1150 chipset
•Built-in ATI graphics processor
•PCI Express I/O bus
•Integrated SATA 3.0-Gb/s controller
•
•Integrated Fast Ethernet 10/100 Network Connection
•Choice of hard drives and optical drives
•DDR2 SDRAM system memory
•Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
NOTE: All models and features may not be available in all countries.

QuickSpecs HP Compaq dx2250 Microtower Business PC
Available Technology and Features
DA –12605 EMEA •Version 1 • March 14, 2007 Page 2
AMD Sempron Processors with HyperTransport Technology:
AMD Sempron 3400+ Processor (1.8-GHz, 256K L2 cache, 1600-MHz FSB)
AMD Sempron 3600+ Processor (2.0-GHz, 256K L2 cache, 1600-MHz FSB)
AMD Athlon 64 Processors with HyperTransport Technology:
Athlon 64 3800+ Processor (2.4-GHz, 512K L2 cache, 2000-MHz FSB)
AMD Athlon 64 X2 Dual-Core Processors with HyperTransport Technology:
Athlon 64 X2 3800+ Processor (2.0-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 4000+ Processor (2.1-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 4200+ Processor (2.2-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 4400+ Processor (2.3-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 4600+ Processor (2.4-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 4800+ Processor (2.5-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 5000+ Processor (2.6-GHz, 1MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 5200+ Processor (2.6-GHz, 2MB L2 cache, 2000-MHz FSB)
Athlon 64 X2 5400+ Processor (2.8-GHz, 1MB L2 cache, 2000-MHz FSB)
Processor and Speed
One of the following
Athlon 64 X2 5600+ Processor (2.8-GHz, 2MB L2 cache, 2000-MHz FSB)
Preinstalled Genuine Windows Vista Business 32*
Genuine Windows XP Professional SP2
Genuine Windows XP Home SP2
Red Flag Linux (China Only)
Free DOS (not available in China)
* Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your
computer. To download the tool, visit http://www.windowsvista.com/upgradeadvisor.
NOTE: Drivers for Windows Vista are continually being made available for download from
http://www.hp.com. Windows Vista support for all hardware and software features of this
product is planned by April 1, 2007.
Operating Systems
Microsoft Office 2007 Basic
Microsoft Office 2007 SBE
Microsoft Office 2007 Professional
Microsoft Works
Application Software
(availability varies by
region)
Roxio DigitalMedia Plus (by SONIC)*
Intervideo WinDVD*
Symantec Antivirus 2005 with 60 day Live Update Subscription (availability varies by region)
Sun Java Runtime Environment
Google Toolbar

QuickSpecs HP Compaq dx2250 Microtower Business PC
Available Technology and Features
DA –12605 EMEA •Version 1 • March 14, 2007 Page 3
* Supporting software available with certain optical drive configurations
80-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
160-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
Hard Drives
250-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
512-MB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 512-MB)
512-MB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 256-MB)
System Memory
1-GB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 1-GB)
1-GB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 512-MB)
2-GB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 1-GB)
Diskette Drive
1.44-MB Diskette Drive
Media Reader
HP 16-in-1 Media Reader and additional USB 2.0 port
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
Storage –
One or more of the
following (see Storage
section below)
SATA DVD+/-RW (DL/DF) LightScribe Drive
Keyboard –
One of the following HP PS/2 Standard Keyboard
HP USB Standard Keyboard
PS/2 2-Button Scroll Mouse
PS/2 2-Button Optical Scroll Mouse
USB 2-Button Optical Scroll Mouse
Mouse –
One of the following
Realtek ALC861 High Definition audio codec
3D audio compliant with AC'97 Rev. 2.3 and HD Audio compatible
Audio
Internal PC speaker
Integrated Realtek 8100C Fast Ethernet Network Connection
Intel PRO/1000 PT PCIe Gigabit NIC Card
Communication
Agere 56K PCI Modem
Integrated ATI graphics processor
Graphics ATI RADEON X1300 (256MB DH) PCIe Graphics Card
ATI RADEON X1300 (256MB SH) PCIe Graphics Card

QuickSpecs HP Compaq dx2250 Microtower Business PC
Available Technology and Features
DA –12605 EMEA •Version 1 • March 14, 2007 Page 4
Miscellaneous HP Firewire / IEEE 1394 PCI Card (full height)

QuickSpecs HP Compaq dx2250 Microtower Business PC
System Details
DA –12605 EMEA •Version 1 • March 14, 2007 Page 5
Base Unit •Micro ATX microtower chassis, including power supply and front bezel
•Five (5) drive bays and four expansion slots
•Microsoft operating system CD
•Active type heatsink
•92 x 92 x 25 mm chassis fan
•System board with ATI Radeon Xpress 1150 chipset, integrated Realtek 8100C Fast
Ethernet 10/100 Network Connection, integrated graphics and audio, 2PCI slots, 1
PCI
Express x1 slot, 1 PCI Express x16 slot, 2 DDR2 DIMM memory slots
•(4) Serial ATA data connectors
•(2) Serial ATA data cables
•Product documentation on CD
•Power cord
PCI Two (2) full-height PCI 2.3 slots on PCA
One (1) full-height PCI Express x1 slot on PCA
One (1) full-height PCI Express x16 slot on PCA (for graphic cards)
Slots
Memory Expansion Two (2) DIMM slots (2 GB maximum memory support)
Internal Two (2) 3.50" Bays
External Two (2) 5.25”
One (1) 3.50”
EHCI high-speed USB 2.0 controller
USB Support Two (2) front ports; Four (4) rear ports, Two (2) internal ports on motherboard
Interfaces (Legacy) One (1) parallel port
One (1) serial port
One (1) PS/2 keyboard port
One (1) PS/2 mouse port
One (1) analog VGA video port
One (1) line in; one (1) line out; one (1) mic in
One (1) RJ45 network port
Chassis Dimensions
(H x W x D) 13.90 x 6.89 x 16.38 in (353 x 175 x 416 mm)
Packaged
Dimensions
(L x W x H)
22.25 x 19.63 x 16.31 in (565.15 x 498.5 x 414.3 mm) (NA)
21.10 x 19.53 x 15.008 in (536.0 x 496.0 x 383.0 mm) (EMEA)
System Weight 21.16 lb (9.6 kg)
Weight and
Dimensions
Shipping Weight 30.86 lb (14.0 kg)

QuickSpecs HP Compaq dx2250 Microtower Business PC
System Details
DA –12605 EMEA •Version 1 • March 14, 2007 Page 6
Memory Type •PC2-5300 DDR2 SDRAM (667-MHz) non-ECC
•4GB maximum system memory
Technology and
Features
Hard Drive
Interfaces Supported •Serial ATA 3.0-Gb/s hard drives are supported
Front Panel •Power button
•Power On LED
•HDD Activity LED
Cooling Solutions
Supported •Power Supply Fan (variable speed)
•Aluminum active heatsink (variable speed)
•Chassis fan (variable speed)
Slots Supported Four (4) full-height expansion slots
Front I/O Two (2) USB 2.0 ports
Rear I/O Standard Micro ATX I/O connectors, including four (4) USB 2.0 ports
Drive Bays •Two (2) 5-1/4” external
•One (1) 3-1/2” external
•Two (2) 3-1/2” internal
Internal Speaker Standard
Security Padlock loop
Chassis
Power Supply 250-watt ATX Power Supply –PFC/non-PFC with a 115v/230v line
switch (varies by country/region)
General Unit Operating GuidelinesUnit Environment
and Operating
Conditions •Keep the computer away from excessive moisture, direct moisture and the extremes of
heat and cold, to ensure that unit is operated within the specified operating range.
•Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the
required airflow.
•Never restrict airflow into the computer by blocking any vents or air intakes.
•Do not stack computers on top of each other or place computers so near each other that
they are subject to each other's re-circulated or preheated air.
•Occasionally clean the air vents on the front, back, and any other vented side of the
computer. Lint, dust and other foreign matter can block the vents and limit the airflow.
•If the computer is to be operated within a separate enclosure, intake and exhaust
ventilation must be provided on the enclosure, and the same operating guidelines listed
above will still apply.
Temperature Range •Operating: 50° to 95° F (10° to 35° C)
•Non-operating: –22° to 140° F (–30° to 60° C)
Relative Humidity •Operating: 10% to 90% (non-condensing at ambient)

QuickSpecs HP Compaq dx2250 Microtower Business PC
System Details
DA –12605 EMEA •Version 1 • March 14, 2007 Page 7
•Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized) •Operating: 10,000 ft (3048 m) •Non-operating: 30,000 ft (9000 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000
m) above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The
upper limit may be limited by the type and number of options installed.
Processor •Socket AM2 industry standard Micro ATX form factor
•Support single AMD Athlon 64 X2 Dual-Core, Athlon 64, or
Sempron processor
PWM •Intersil 6566 VRM 10.1
Chipset •ATI RS485 (Northbridge), ATI SB600 (Southbridge)
Super I/O •W83627EHG
Front Side Bus
Frequency •533/800 MHz
Memory •DDR2 SDRAM
•2 x DIMM slots
Clock Generator •ICS 951412GLFT
Integrated Graphics •Built-in ATI graphics processor
provided by the ATI Radeon Xpress 1150 chipset
Audio •
Realtek ALC861 HD Audio compatible codec with two channel
audio 3D audio compliant with AC'97 rev. 2.3
LOM •Realtek 8100c Fast Ethernet 10/100
IDE •Support all PIO modes
•1 x IDE ports support up to 2 devices
•Support Ultra ATA 33/66/100
Serial •Four Serial ATA interfaces support data transfer rates up to 3.0
Gb/s
System Board
Expansion Slots •2 x PCI 2.3 slots
•1 x PCI Express x1 slot

QuickSpecs HP Compaq dx2250 Microtower Business PC
System Details
DA –12605 EMEA •Version 1 • March 14, 2007 Page 8
•1 x PCI Express x16 slot
BIOS •LPC EEPROM
Industrial Standard •PCI 2.3 compliant
•USB 2.0
Rear Side I/O Ports •1 x PS/2 keyboard port
•1 x PS/2 mouse port
•4 x USB 2.0 ports
•1 x RJ-45 10/100 port
•1 x serial port
•1 x parallel port
•1 x DB 15 pin analog VGA port
•3 x audio ports
On Board I/O
Interfaces •1 x ATX power connector
•1 x +12V power connector
•1 x Floppy connector
•1 x Front panel connector, Switch, LED (ON/Flash/OFF)
•2 x Fan headers for CPU, chassis, with voltage/fan speed
control
•1 x ATAPI headers-CD IN
•1 x header to support 2 USB 2.0 ports at front side
•1 x header to support USB media reader
Board Size •Micro-ATX, PCB Size: 9.6 x 9.0 in (24.38 x 22.86 cm)
•4-layer PCB with green color
Additional Features •Bootable without keyboard, mouse or monitor
•Keyboard/mouse/USB wake up
•Support S3, S4 and S5
•ACPI status
•Hardware monitor capability
•CPU fan speed control
Integrated Realtek 8100C Fast Ethernet Network Controller
Hardware Highlights •PCI interfaces
Network Interface
Features •10-Mbps and 100-Mbps operation
Intel PRO/1000 PT PCIe Gigabit NIC Card
Hardware Highlights •PCI interfaces

QuickSpecs HP Compaq dx2250 Microtower Business PC
System Details
DA –12605 EMEA •Version 1 • March 14, 2007 Page 9
Features •10-Mbps, 100-Mbps and 1000-Mbps operation
Wireless Wireless A+G PCI Card (full height bracket)
Power Supply •ATX Power Supply –Passive PFC/non-PFC with a 115v/230v line switch
•Passive Power Factor Correction (PFC) –with line switch set to 230V –No PFC in 115V
line switch position
•90 to 140VAC, or 180 to 264VAC operating voltage range
•100 to 127VAC, or 200 to 240VAC rated voltage range
•50–60 Hz rated line frequency
•47–63 Hz operating line frequency range
•250 watt maximum rated power
•80-mm power supply fan –variable speed for optimum acoustics
Power Conservation
‘Energy Saver‘ •Energy Star compliant
•APM 1.2 support
•Screen blanking
•Hard drive 'Idle' mode
•System Idle mode
•~2 watt power consumption in ES mode –suspend to RAM (S3) (instantly available PC)
•Processor/Cache memory power-down (S3)
•Values are subject to change without notification and are for reference only.
•Performance of system, options, and ancillary equipment will vary depending on the
system configuration.
•Levels presented do not account for non-HP/Compaq installed hardware.
Operating 50° to 95°F (10° to 35°C) at sea level with
an altitude de-rating of 1.0°C per every
1000 ft (300 m) above sea level to a
maximum of 8000 ft (2500 m), no direct
sustained sunlight. Maximum rate of change
is 77°F/Hr (25°C/Hr). The upper limit may
be limited by the type and number of options
installed.
Ambient Air
Temperature
Storage –22° to 140°F (–30° to 60°C) –
Maximum rate of change: 410°F/Hr
(210°C/Hr).
System
Environmental Specs
Humidity Operating 10% to 90% relative humidity (Rh), 86°F
(30°C) maximum wet bulb temperature, non-
condensing

QuickSpecs HP Compaq dx2250 Microtower Business PC
System Details
DA –12605 EMEA •Version 1 • March 14, 2007 Page 10
Storage 10% to 95% relative humidity (Rh), 101.66°F
(38.7°C) maximum wet bulb temperature,
non-condensing
Operating 0 to 10,000 feet (0 to 3048 meters) –This
value may be limited by the type and number
of options installed. Maximum allowable
altitude change rate is 1,000 ft/min (304.8
m/min).
Altitude
Non-Operating 0 to 30,000 feet (0 to 9,144 meters) –
Maximum allowable altitude change rate is
1200 ft/min (365.76 m/min).
Listed are the levels of shock the product can withstand with NO
damage being incurred. The values represent peak input acceleration
during an 2~3 ms half-sine shock pulse, 11 ms trapezoidal shock
pulse.
Shock
Non-Operating 40 g (Half-sine Shock)
40 g (Trapezoidal Shock)
Listed are the levels of vibration the product can withstand with NO
damage being incurred. The values represent a flat random vibration
input acceleration profile across the given frequency range.
Operating Random vibration at [email protected]•/Hz,
[email protected]•/Hz, [email protected]•/Hz,
[email protected]•/Hz
5Hz to 300Hz, (0.25G's nominal).
Vibration
Non-Operating Random vibration at 0.008G•/Hz,
10Hz to 500Hz, (2 Grms nominal).
On-site WarrantyNote 1: One-year (1-1-1) limited warranty delivers one year of on-site, next
business-dayNote 2 service for parts and labor and includes free telephone supportNote 3 24 x 7.
Global coverageNote 2 ensures that any product purchased in one country and transferred to
another non-restricted country will remain fully covered under the original warranty and service
offering. One-year onsite and labor are not available in all countries.
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
Other warranty variations may be offered in your region.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an
authorized HP third-party provider, and is not available in certain countries. Global service
response times are based on commercially reasonable best effort and may vary by country.
Service and Support
NOTE 3: Technical telephone support applies only to HP-configured Compaq and third-party HP-
qualified hardware and software. Toll-free calling and 24 x 7 support may not be available in
some countries.

QuickSpecs HP Compaq dx2250 Microtower Business PC
After-Market Options
DA –12605 EMEA •Version 1 • March 14, 2007 Page 11
NICs
Intel PRO/1000 PT PCIe Gigabit NIC Card EH352AA
Wireless LAN
HP Wireless A+G PCI Card (North America only) EA118AA
HP Wireless A+G PCI Card (WW except North America) PZ928AA
Modems
Communications
Agere 2006 PCI High-Speed 56K International SoftModem EK694AA
HP 250-GB SATA 3.0-Gb/s Hard Drive PY278AA
HP 160-GB SATA 3.0-Gb/s Hard Drive PY277AA
Hard Disk Drives
HP 80-GB SATA 3.0-Gb/s Hard Drive PY276AA
Diskette Drive
HP 1.44-MB Internal Diskette Drive AG295AA
HP 1.44-MB USB Diskette Drive –External DC141B
16-in-1 Media Reader EM718AA
USB Drive Key
HP 1-GB Drive Key II Flash Drive AG382AA
Removable Storage
Devices
HP (APJ) 512-MB Drive Key II Flash Drive ED516AA
Keyboards
HP PS/2 Standard Keyboard DT527A
HP USB Standard Keyboard DT528A
Mice
HP PS/2 2-Button Scroll Mouse DD440B
HP PS/2 2-Button Optical Scroll Mouse EY703AA
HP USB 2-Button Scroll Mouse DD441B
Input Devices
HP USB 2-Button Optical Scroll Mouse DC172B
HP 1-GB PC2-5300 (DDR2-667 MHz) DIMM PX976AA
HP 512-MB PC2-5300 (DDR2-667 MHz) DIMM PX975AA
Memory
HP 256-MB PC2-5300 (DDR2-667 MHz) DIMM PX974AA
NOTE: The HP Compaq dx2200 Microtower memory frequency is clocked at 630 MHz.
Audio HP Satellite Speakers ZD929AA
Graphics ATI RADEON X1300 (256MB DH) PCIe Graphics Card AH050AA
ATI RADEON X1300 (256MB SH) PCIe Graphics Card AG392AA

QuickSpecs HP Compaq dx2250 Microtower Business PC
After-Market Options
DA –12605 EMEA •Version 1 • March 14, 2007 Page 12
HP SATA CD-ROM Drive (available in Asia Pacific and Japan only) AH045AA
HP SATA CD-RW/DVD-ROM Combo Drive AH046AA
Optical Drives
HP SATA DVD-ROM Drive AH047AA
HP SATA DVD+/-RW (DL/DF) LightScribe Drive AH048AA
Security HP Business PC Security Lock Kit PV606AA
Miscellaneous
Accessories HP Firewire / IEEE 1394 PCI Card PA997A
CRTs
HP s7540 17" (16.0" vis) CRT Monitor PF997AA#XXX
HP v7650 17" (16.0" vis) Flat-face CRT Monitor PF996AA#XXX
TFTs
HP L1506 15" TFT Flat Panel Monitor –Analog only PX848AA#XXX
HP L1706 17" TFT Flat Panel Monitor –Analog only PX849AA#XXX
HP L1740 17" TFT Flat Panel Display –Analog/Digital PL766AA#XXX
HP L1755 17" TFT Flat Panel Display –Analog/Digital PL777AA#XXX
HP L1906 19" TFT Flat Panel Display –Analog only PX850AA#XXX
HP L1940T 19" TFT Flat Panel Display –Analog/Digital EM869AA#XXX
HP L1955 19" TFT Flat Panel Display –Analog/Digital PD974AA#XXX
HP L2065 20" TFT Flat Panel Display –Analog/Digital EF227A4#XXX
HP LP2465 24" TFT Widescreen Flat Panel Display –Analog/Digital EF224A4#XXX
GSA Monitors
HP L717g 17" GSA Flat Panel Monitor EE191AA#XXX
HP L919g 19" GSA Flat Panel Monitor EE192AA#XXX
Options
HP Flat Panel Speaker Bar EE418AA
Monitors
HP CRT Monitor Multimedia Base PM552AA

QuickSpecs HP Compaq dx2250 Microtower Business PC
Memory
DA –12605 EMEA •Version 1 • March 14, 2007 Page 13
DDR SYNCH DRAM NON-ECC MEMORY
The ATI Radeon Xpress 1150 chipset supports non-ECC DDR2 memory up to PC2-5300 (667-MHz). Memory upgrades are
accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible
memory configurations.
MAXIMUM MEMORY
Supports up to 2-GB of DDR2 SYNCH DRAM. Not all memory configurations possible are represented below.
DIMM Size Slot 1 Slot 2
256-MB 256-MB
512-MB 512-MB
512-MB 256-MB 256-MB
1-GB 1-GB
1-GB 512-MB 512-MB
2-GB 1-GB 1-GB

QuickSpecs HP Compaq dx2250 Microtower Business PC
Storage
DA –12605 EMEA •Version 1 • March 14, 2007 Page 14
HP Compaq dx2250 Microtower Business PC
Maximum Quantity
Supported Position Supported Controller
Drive Support
Diskette Drives 1 3 SIO
Media Reader 1 3 Internal USB 2.0 port
CD-ROM Drives 21, 2 IDE ATAPI
DVD-ROM Drives 21, 2 IDE ATAPI
CD-RW/Combo Drives 21, 2 IDE ATAPI
DVD+/-RW Drives 21, 2 IDE ATAPI
3.5” Serial ATA Hard Drives 24,5 SATA

QuickSpecs HP Compaq dx2250 Microtower Business PC
Technical Specifications -Audio
DA –12605 EMEA •Version 1 • March 14, 2007 Page 15
Type Integrated
HD Audio
compatible codec Yes
Sampling Supports 48/96 KHz
Mic-In
Line-In
Audio Jacks
Line-Out / Headphone Out
Power Support Digital: 3.3V
Analog: 5V
Integrated Realtek
ALC861 Audio
Other Meets performance requirements for audio on PC99/2001 systems
High quality differential CD input

QuickSpecs HP Compaq dx2250 Microtower Business PC
Technical Specifications -Communications
DA –12605 EMEA •Version 1 • March 14, 2007 Page 16
Connector RJ-45
Controller Intel 82572EI Gigabit Ethernet Controller
Memory Integrated Dual 48K configurable transmit receive FIFO Buffers
Data rates
supported 10/100/1000 Mbps
Compliance IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u
compliant, 802.3x flow control
Bus architecture PCI-E 1.0a
Data transfer mode Bus-master DMA
Hardware
certifications FCC, B, CE, TUV-cTUVus Mark Canada and United States, TUV-GS
Mark for European Union
Power requirement Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Boot ROM support Yes
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
Network transfer
rate
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Operating
temperature 32° to 131°F (0° to 55° C)
Environmental
Operating humidity 85% at 131° F (55° C)
Dimensions 6.4 x 2.6 x 0.8 in (16.3 x 6.6 x 1.9 cm)
Operating system
driver support Microsoft Windows 2000 (Service Pack 4 or greater), Windows XP
Home, Windows XP Professional
Intel PRO/1000 PT
PCIe Gigabit NIC
Management
capabilities ASF, WOL, PXE, DMI, WFM 2.0.
Dimensions 4.99 x 2.54 x 0.71 in (126.8 x 64.4 x 18.0 mm)
Weight 0.268 lb (65 g)
Controller
system interface Atheros AR5414X chipset
PCI Spec 2.2
Network standard IEEE 802.11a/b/g
Frequency band 5.1500 to 5.8500 GHz
2.4000 to 2.4835 GHz
2.4465 to 2.4835 GHz (Europe, Middle East, Asia and Asia Pacific –
excluding Japan)
2.4000 to 2.4697 GHz (Japan)
Operating
temperature 32° to 140° F (0° to 60° C), operating
Storage temperature -4° to 176° F (-20° to 80° C), non-operating
HP Wireless A+G PCI
Humidity 10% to 85% non-condensing

QuickSpecs HP Compaq dx2250 Microtower Business PC
Technical Specifications -Communications
DA –12605 EMEA •Version 1 • March 14, 2007 Page 17
Operating voltage 5V ± 5%
Power consumption Tx/Rx peak 560/250mA @ 3.3V (max.)
Output power
(approximately) 15 dBM ±2dB
Receive sensitivity -90dBm at 11 Mbps (typical)
Data transfer rate Standard rates of 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 48, 54 and Super
AG Mode108-Mbps
Spreading DSSS (Direct Sequence Spread Spectrum)
Security 64(40h) bit, 128(104h) bit, WPA, IEEE802.1X, AES-OCB, AES-CCM,
Microsoft PEAP,TKIP, WEP
Antenna External 5dBi antenna
108 Mbps (only with
Belkin 54G or above
router that supports 108
Mbps speed)
200 ft (60.96 m) –Indoor
Throughput
54 Mbps 200 ft (60.96 m) –Indoor
11 Mbps 200 ft (60.96 m) –Indoor
Certifications Wi-Fi certified
North America: United States, Canada
Certifications for use
by country Europe: Austria, Belgium, Cyprus, Denmark, Finland, France,
Germany, Greece, Iceland, Ireland, Italy, Liechtenstein, Luxembourg,
Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, United
Kingdom
Australia
New Zealand
OS support Microsoft Windows XP Professional and Home
Microsoft Windows 2000
56,000 Kbps maximum downstream data
Data Transmission
NOTE: 56 Kbps technology refers to download speeds only and
requires compatible modems at server sites. Other conditions may limit
modem speed. FCC limitations allow a maximum of 53 Kbps during
download transmissions.
Data Speeds (Upload only)
33,600/31,200/28,800/26,400/21,600/19,200/16,800/14,400/
12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell
212A, and Bell 103
Fax Speeds 14,400/12,000/9,600/7,200/4,800/2,400/300 b/s
Fax Mode
Capabilities ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Agere 56K PCI
Modem
Error Correction and
Data Compression V.44, 42bis, V.42 and MNP2-5

QuickSpecs HP Compaq dx2250 Microtower Business PC
Technical Specifications -Communications
DA –12605 EMEA •Version 1 • March 14, 2007 Page 18
Power Management ACPI; PPMI 1.1 and wake support with PME and Vaux; meets PCI 2.3
requirements and PC 2001 requirements
Upgradeability Driver upgradeable for future enhancements
Video ITU-T V.80 video ready interface
TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel
16550a UART-compatible interface
Other
Optional ring wakeup signal
Operating
Temperature 32° to 158° F (0° to 70° C)
Operating Humidity 20% to 90%, non-condensing
Operating System
Support Microsoft Windows XP
OS Driver Support Microsoft Windows XP
Requires a 3.3-V auxiliary power rail on PCI bus
Power Uses only one PCI load (i.e., one grant/request pair), one shared IRQ,
one electrical load
Chipset Agere Systems SV92PL –Integrated PCI interface with 5-V tolerant
buffers and CardBus support
Dimensions (L X H)Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8
cm) and supports high-and low-profile brackets
Connection Single RJ-11 connector
Other Features Digital line protection, call progress monitoring via on-board piezo
device, support for high profile and low profile brackets, PnP ID support
Safety UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950
(TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO,
DEMKO, SEMKO, CE mark
EMC FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A,
EN 61000-4-6, EN 61000-4-8
Telecom FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Health Bare PCB material compliant to 94V-0 or better (marked as such)
OtherPC 2001 compliant, PCI version 2.3, WHQL approved; ACPI compliant

QuickSpecs HP Compaq dx2250 Microtower Business PC
Technical Specifications -Graphics
DA –12605 EMEA •Version 1 • March 14, 2007 Page 19
3D/2D Controller Full Microsoft DirectX® 9 based with Shader 2.0 support, full
precision floating point pixel pipeline, 2x, 4x, or 6x Anti-Aliasing,
hidden surface removal using 16, 24, or 32-bit Z-Buffering, and
support for 12-bit per pixel formats. Support for Microsoft's
DirectDraw, Double Buffering, Virtual Sprites, Transparent Blit, and
Masked Blit.
VGA/DVI Controller Integrated
Bus Type PCI Express™ x16 for optional graphics upgrade
RAMDAC Integrated
Integrated ATI
Radeon X300
graphics
Memory HYPERMEMORY™ technology offers optional dedicated Local Frame
Buffer configuration for a 32-bit or 64-bit interface and up to 128MB
of memory. UMA mode operation uses from 32MB up to 256MB of
shared system memory.
Controller Clock
Speed 400 MHz
Overlay Planes Back end overlay supporting Motion Adaptive De-Interlacing
Maximum Color
Depth 32 bits/pixel
Maximum Vertical
Refresh Rate Supports resolutions up to 2045x1536 @ 32bpp
Multi-display
Support SURROUNDVIEW™ support for up to four monitors with an ATI
discrete graphics card. Up to 2 displays can be supported via the
motherboard's VGA and DVI-D connectors. An additional 2 displays
can be supported via the ATI discrete graphics card. Dual
independent display modes are supported.
Operating Systems Microsoft Windows XP and Windows 2000
Graphics/Video API
Support Microsoft DirectX 9, DirectXVA®, VMR7, VMR9, GDI/GDI+;
OpenGL® 1.4.
Bus type PCI Express (x16 lanes)
Maximum vertical
refresh rate 85 Hz
Display support Integrated 400 MHz RAMDAC
Display max
resolution 2048 x 1536
Board display
options DVI-I + TV
DVI-I supports analog CRT or flat panel or digital flat panel (using DVI-
A, DVI-D or DVI-I connector)
DVI-I supports analog CRT or flat panel (with VGA connector and DVI-I
to VGA dongle)
TV connector is a 4-pin mini-DIN S-video connector
Specification Description
ATI RADEON X1300
PCIe Graphics Card
(256 MB)
Board configuration Graphics Chip RV515

QuickSpecs HP Compaq dx2250 Microtower Business PC
Technical Specifications -Graphics
DA –12605 EMEA •Version 1 • March 14, 2007 Page 20
Core clock 450 MHz
Memory clock 250 MHz
Frame buffer 256 MB DDR2
Languages
supported 24 languages: English, Arabic, Chinese Simplified, Chinese
Traditional, Czechoslovakian, Danish, Dutch, Finnish, French, German,
Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian,
Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish
Operating systems
support Windows 2000, Windows XP, Linux x86 and x86_64 distributions
using XFree86 or X.Org*.
*Linux drivers are available from ATI's website and may be available
in a Linux distribution. Refer to the Open Source and Linux from HP
website (http://www.hp.com/wwsolutions/linux/products/clients/) for
support information.
Core power 25 W (Max board power)
Option kit contents •ATI RADEON X1300 PCIe graphics card with full height
bracket attached
•Low profile bracket
•DVI-to-VGA Adapter
•Software CD with graphics drivers
•Warranty documentation
Compliance
standards EMC Emissions:
a) FCC Part 15, Subpart B –Unintentional Radiators, Class B
Computing Devices for Home & Office Use
b) CISPR22: 1997/EN 55022:1998 –Class B –Limits and methods of
measurement of radio disturbance characteristics of Information
Technology Equipment
c) Canadian Standard ICES-003 is equivalent to CISPR22
d) Taiwanese Standard BSMI
e) Japanese VCCI
f) Australian C-Tick
EMC Immunity:
CISPR 24:1997/EN 55024:1998 –Information Technology Equipment
–Immunity Characteristics –Limits and Methods of Measurement.
Safety:
UL 60950 (USA) & EN 60950 (EU): Safety of Information Technology
Equipment, Including Electrical Business Equipment. All boards meet UL
PCB flammability requirements.
