Network & Internet
Communications Guide
Business Desktops
Document Part Number: 312968-003
November 2004
This guide provides definitions and instructions for using network
interface controller (NIC) features that are preinstalled on select
models. It also provides information about Internet Service Providers
and solving Internet access problems.

© Copyright 2004 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft
Corporation in the U.S. and other countries.
The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable
for technical or editorial errors or omissions contained herein.
This document contains proprietary information that is protected by copyright.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Hewlett-Packard
Company.
ÅWARNING: Text set off in this manner indicates that failure to follow
directions could result in bodily harm or loss of life.
ÄCAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of information.
Network & Internet Communications Guide
Business Desktops
First Edition (February 2003)
Third Edition (November 2004)
Document Part Number: 312968-003

Network & Internet Communications Guide www.hp.com iii
Contents
1 Network Communications
Ethernet Network Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
NIC-Based Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3
Wake-On-LAN Support (WOL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4
Interpreting the Network Status Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
Disabling 802.3u Auto-Negotiation Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
Installing Network Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
Wireless Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–9
Ad-hoc Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–9
Access Point (Infrastructure) Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–9
Advantages of Wireless Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–10
2 Internet Communications
Choosing an Internet Service Provider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Content Advisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
Restricting Internet Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
Solving Internet Access Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–4

iv www.hp.com Network & Internet Communications Guide
Contents

Network & Internet Communications Guide www.hp.com 1–1
1
Network Communications
The following items are covered in this section:
■Ethernet Network Structure
■Network Interface Controller (NIC)-Based Alerts
■Wake-On-Lan (WOL) Support
■Interpreting the Network Status Lights
■Disabling the Autosensing Capabilities
■Installing Network Drivers
■Wireless Networks
This section provides information about Ethernet networks and the
hardware connectors and software device drivers that allow you to
access an Ethernet network. Access to a computer network
immediately increases your productivity potential. Once the network
connection is active, you can share resources, such as a printer,
exchange information from computer to computer, and run common
software programs.
The computer comes network-ready, which means that it has an
integrated network controller and network device drivers already
loaded onto the computer hard drive. The computer is ready to make
the network connection.

1–2 www.hp.com Network & Internet Communications Guide
Network Communications
Ethernet Network Structure
All Ethernet networks include some combination of the following
elements:
Ethernet Network Structure
Refer to the Hardware Reference Guide on the Documentation CD
for network connector identification.
1Ethernet cable 3Drop cables
2Information packets 4Workstations

Network & Internet Communications Guide www.hp.com 1–3
Network Communications
NIC-Based Alerts
Some NICs feature Alerting Capabilities, which allow a system
administrator to monitor the computer over the network remotely.
The computer can send hardware and operating system alerts over the
network before the operating system is loaded, while the operating
system is loaded, while the computer is in low power states, and when
the computer is powered off. Depending on the NIC model, these
alerts can be monitored in the following states:
■System BIOS hang—On action
■Operating system hang—On action
■Processor missing—On power up
■Operating temperature exceeded—On action
■Chassis intrusion—On power up/or on action if system is running
■Watchdog—On action (same as Operating system hang)
■Heartbeat monitoring—Always
✎NICs featuring Alerting Capabilities comply with Alert Standard
Format (ASF) specification 2.0 and support Remote Management and
Control Protocol (RMCP) based alerts. ASF 1.0 implementations will
not support RMCP due to lack of security in the ASF 1.0
specification.
NIC-Based Alerts are enabled and configured by installing the ASF
2.0 agents for the NIC you are using. These are available at
www.hp.com. ASF alerts can also be enabled and configured using
the Common Information Model (CIM).

1–4 www.hp.com Network & Internet Communications Guide
Network Communications
Wake-On-LAN Support (WOL)
Wake-On-Lan (WOL) can be enabled and disabled in Windows XP
and Windows 2000.
To enable or disable Wake-On-Lan:
Windows XP
1. Select Start > Control Panel.
2. Double-click Network Connections.
3. Double-click Local Area Connection.
4. Click Properties.
5. Click Configure.
6. Click the Power Management tab, then select or clear the check
box to Allow this device to bring the computer out of standby.
Windows 2000
1. Select Start > Settings > Control Panel.
2. Double-click Network and Dial-up Connections.
3. Right-click Local Area Connection.
4. Click Properties.
5. Click Configure.
6. Click the Power Management tab, then select or clear the check
box to Allow this device to bring the computer out of standby.
✎For more information on Wake-On-LAN, refer to the Remote
Management Administrators Guide. The Remote Management
Administrators Guide is included with the Remote Management
Setup Utilities and is available on the Support Software CD or at
www.hp.com.

Network & Internet Communications Guide www.hp.com 1–5
Network Communications
Interpreting the Network Status Lights
Select Ethernet network interface controllers include network status
lights:
■Link light—illuminates when the system is physically connected
to an active network.
■Activity light—illuminates when the computer detects network
activity. When the system is connected to a highly used
network, the activity light will remain on almost constantly.
■Operating Speed light—illuminates during 1000 Mbps or
100 Mbps operation. The color of the light identifies the
operating speed.
Some NICs include only two network status lights where link
(light on) and activity (light blinking) are indicated by one light and
1000-Mbps or 100-Mbps operation is indicated by the second light.
The integrated NIC has two network status lights on the NIC
connector:
■Link/Activity light—Illuminates green when physically linked to
the network and blinks on and off to indicate network activity.
■Operating Speed light—Illuminates green when operating at
1000 Mbps, yellow when operating at 100 Mbps, and is not
illuminated when operating at 10 Mbps.

1–6 www.hp.com Network & Internet Communications Guide
Network Communications
Disabling 802.3u Auto-Negotiation Capabilities
Auto-Negotiation NICs automatically determine the maximum
network operating speed and duplex capabilities of the attached
network and configure themselves on the highest common
combination. The computer begins Auto-Negotiation whenever it
obtains a valid network link, or when the NIC driver is loaded.
In addition to determining the network operating speed, the computer
determines if full-duplex is supported. Full-duplex systems can
transmit and receive information on the network simultaneously.
Half-duplex systems cannot transmit and receive simultaneously.
If necessary, you can disable the Auto-Negotiation capabilities and
force the system to operate in one mode only.
Windows XP
1. Select Start > Control Panel.
2. Double-click Network Connections.
3. Double-click Local Area Connection.
4. Click Properties.
5. Click Configure.
6. Click the Advanced tab.
7. Select Link Speed & Duplex in the Property list box.
8. Change the speed and duplex values to the appropriate values,
depending on the capabilities of the network.
9. Click OK. You may be prompted to restart the computer for the
changes to take effect.
Windows 2000
1. Select Start > Settings > Control Panel.
2. Double-click Network and Dial-up Connections.
3. Right-click Local Area Connection.
4. Click Properties.
5. Click Configure.

Network & Internet Communications Guide www.hp.com 1–7
Network Communications
6. Click the Advanced tab.
7. Select Link Speed/Duplex Mode in the Property list box.
8. Change the speed and duplex values to the appropriate values,
depending on the capabilities of the network.
9. Click OK. You may be prompted to restart the computer for the
changes to take effect.
Refer to the documentation provided with the network controller for
additional information.
✎100Base-TX and 1000Base-TX operation requires the use of CAT5
UTP with RJ-45 connectors.

1–8 www.hp.com Network & Internet Communications Guide
Network Communications
Installing Network Drivers
The device drivers in the network software enable the computer to
communicate with the network. Because HP does not know which
network operating system you’ll be using, the computer comes ready
to work with several different environments.
The device drivers for the network controller enable the drivers to
load correctly in the operating system used, allowing communication
with the network.
✎Device drivers are supplied for the Windows XP Professional,
Windows XP Home, and Windows 2000 operating systems,
depending on the computer model. If you are using another operating
system, device drivers may be installed from media included with
the network operating system or are available from HP. If it ever
becomes necessary to reinstall the operating system, use the
Restore Plus! CD.
Complete instructions for installing the network device drivers are
available as ASCII text files, located in the C:\COMPAQ\NIC
directory. Use the instructions found in the subdirectory that relates to
the network environment.
Install the correct device drivers according to the operating system
you are using, as listed below.
Windows XP
1. Select Start > Control Panel.
2. Double-click Network Connections.
3. Double-click the New Connection Wizard icon and follow the
instructions on the screen.
Windows 2000
Follow the instructions in the ASCII text files located in the
C:\COMPAQ\NIC directory. Use the instructions found in the
subdirectory that relates to the network environment.

Network & Internet Communications Guide www.hp.com 1–9
Network Communications
Wireless Networks
A wireless LAN provides the same functionality of a wired network,
but it eliminates the need to install networking cables and other
networking equipment, making it easier to deploy.
A wireless LAN can be configured for two different modes of
operation. While each method has its advantages, one may be better
suited for your needs. Review the following configuration
information to determine which mode is best for you.
■Ad-hoc Network
■Access Point (Infrastructure) Network
Ad-hoc Network
An Ad-hoc network is the simplest to deploy and is ideal for small
offices. Ad-hoc wireless networks can be comprised of two or more
wireless clients configured to communicate with one another. All
Ad-hoc clients communicate directly with each other without using
an Access Point (AP). As a user on this type of network, you are able
to quickly build up a wireless network in order to share files with
other employees, print to a shared office printer, and access the
Internet through a single shared connection.
Ad-hoc networking is cost effective because no other devices’
components are needed (access points, hubs, or routers) in order to set
up a network. However, with Ad-hoc networking, your computer is
only able to communicate with other nearby wireless clients.
Access Point (Infrastructure) Network
An Access Point network is also referred to as an “Infrastructure”
network. The key difference between a wireless Access Point
network and an Ad-hoc network is the addition of one extra
element—the Access Point. The Access Point serves as the focal
point for all data traffic on your wireless network, optimally
managing all wireless data transactions.
The Access Point extends the range of the wireless LAN. Each
wireless client computer can communicate with other computers
equipped with wireless devices that are within the range of the Access
Point.

1–10 www.hp.com Network & Internet Communications Guide
Network Communications
Additionally, the wireless Infrastructure can provide access to an
existing wired LAN. This link allows computers on the Infrastructure
wireless LAN to access the other wired LAN’s resources and tools,
including Internet access, email delivery, file transfer, and printer
sharing. HP can provide all of the installation services you need to
extend your wired LAN with a wireless LAN.
In addition to the computers that will connect to a wireless network,
you only need two other kinds of equipment to get your Access Point
wireless network up and running:
■Access Points: wireless transmitters that connect every user
within range to the wireless LAN. You can install as many access
points on your network as you need, and add new ones easily as
your network grows, so you can cover an entire suite of offices
with a single wireless LAN. Each access point requires two
connections:
❏A standard outlet for power
❏An Ethernet connection to your existing wired LAN or
incoming Internet connection
■Wireless LAN cards: the wireless equivalent of a network
interface card (NIC) that allow a PC to communicate with the
wireless network. Many HP computers come with built-in
wireless LAN cards so they are ready out of the box to connect to
a wireless network. If your PC doesn't have a wireless card, you
can easily add one. Refer to the Hardware Reference Guide on
the Documentation CD for installation instructions.
Advantages of Wireless Networking
Wireless local area networking (WLAN) brings new levels of
flexibility and accessibility to your business. The many advantages of
wireless networking include:
■There is no need to install labor-intensive and expensive wiring in
a workplace.
■Entire workplaces can be added or moved with minimal
downtime.
■Workers can rearrange their workplaces without being tied to a
wall jack for network access.

Network & Internet Communications Guide www.hp.com 1–11
Network Communications
■A WLAN can often be installed faster and more cost-effectively
than a wired network.
■Additional computers can be added to a WLAN quickly and with
minimal cost.
■WLANs are potentially easier to maintain and manage than wired
networks.
■Wireless local area networks give workers the freedom to access
real-time business information anytime and anywhere within
your office or campus environment.
■Outside the enterprise, public wireless LANs can deliver secure,
high speed connectivity and convenient availability of email,
Internet, and print capabilities.
For more information on wireless networks, go to www.hp.com or
contact your HP representative.

1–12 www.hp.com Network & Internet Communications Guide
Network Communications

Network & Internet Communications Guide www.hp.com 2–1
2
Internet Communications
The following items are covered in this section:
■Choosing an Internet Service Provider
■Content Advisor
■Solving Internet Access Problems
Choosing an Internet Service Provider
An Internet service provider (ISP) provides you with access (dial-up,
cable, DSL, or wireless) and software you need to connect to the
Internet. Most ISPs also offer e-mail, access to newsgroups, space to
create Web pages, and technical support. Some ISPs offer commercial
services, such as domain hosting, to companies and individuals
wanting to do business on the Internet. You can choose from local
and national ISPs.
An online service provider, such as MSN or America Online (AOL),
offers special features, content, and technical support in addition to
providing access to the Internet. An online service provider may
provide a categorized or customizable home page that makes it easy
for you to find some of the most popular and useful sites on the
Internet.
To find the provider that is right for you:
■Look in the Yellow Pages
■Ask a friend or colleague for recommendations
■If you have access to the Internet already, you can use a search
engine, such as Google, to help you locate an ISP or online
service provider.

2–2 www.hp.com Network & Internet Communications Guide
Internet Communications
■ISPs typically offer a variety of service plans for different
customers’ needs. Be sure to review and compare plans, services
offered, and price to find the provider that is right for you and
your needs.
Content Advisor
The Internet provides you with access to a wide variety of
information, but some information may not be suitable for every
viewer.
With Content Advisor, you can:
■Control Internet access
■Set up a password
■Set up a list of Web sites that people who use the computer
cannot view
■Adjust the types of content people who use the computer can
view with or without your permission
Restricting Internet Content
Windows XP
If you have not previously enabled Content Advisor:
1. Select Start > Control Panel.
2. Double-click Internet Options.
3. Click the Content tab.
4. In the Content Advisor area, click the Enable button. If you have
previously created a password for Internet settings, you will be
prompted for your password now.
5. Click a category in the list, then drag the slider to set the limits
you want to use. Repeat this process for each category you want
to limit.
6. Click OK, then type your password in the Password box. A
dialog box will inform you that Content Advisor has been turned
on. Click OK.

Network & Internet Communications Guide www.hp.com 2–3
Internet Communications
If you have previously enabled Content Advisor:
1. Select Start > Control Panel.
2. Double-click Internet Options.
3. Click the Content tab.
4. To change the settings:
a. Click the Settings button. Type your password and click OK.
b. Click a category in the list, then drag the slider to set the
limits you want to use. Repeat this process for each category
you want to limit.
5. To disable Content Advisor:
a. Click the Disable button. Type your password and click OK.
b. A dialog box will inform you that Content Advisor has been
turned off. Click OK.
Windows 2000
If you have not previously enabled Content Advisor:
1. On the Windows desktop, select Start > Settings >Control
Panel.
2. Double-click Internet Options.
3. Click the Content tab.
4. In the Content Advisor area, click the Enable button.
5. Click a category in the list, then drag the slider to set the limits
you want to use. Repeat this process for each category you want
to limit.
6. Click OK, then type your password in the Password box. A
dialog box will inform you that Content Advisor has been turned
on. Click OK.
If you have previously enabled Content Advisor:
1. Select Start > Settings >Control Panel.
2. Double-click Internet Options.
3. Click the Content tab.

2–4 www.hp.com Network & Internet Communications Guide
Internet Communications
4. To change the settings:
a. Click the Settings button. Type your password and click OK.
b. Click a category in the list, then drag the slider to set the
limits you want to use. Repeat this process for each category
you want to limit.
5. To disable Content Advisor:
a. Click the Disable button. Type your password and click OK.
b. A dialog box will inform you that Content Advisor has been
turned off. Click OK.
Solving Internet Access Problems
If you encounter Internet access problems, consult the ISP or refer to
the common causes and solutions listed in the following table.
Solving Internet Access Problems
Problem Cause Solution
Unable to connect to the
Internet.
Internet Service
Provider (ISP) account is
not set up properly.
Verify Internet settings or contact the
ISP for assistance.
Modem is not set up
properly.
Reconnect the modem. Verify the
connections are correct using the
quick setup documentation.
Web browser is not set
up properly.
Verify that the Web browser is
installed and set up to work with the
ISP.
Cable/DSL modem is
not plugged in.
Plug in cable/DSL modem. You
should see a “power” LED light on
the front of the cable/DSL modem.
Cable/DSL service is
not available or has
been interrupted due to
bad weather.
Try connecting to the Internet at a
later time or contact your ISP. (If the
cable/DSL service is connected, the
“cable” LED light on the front of the
cable/DSL modem will be on.)
