HP Vectra VEi 8 Manual

Medium-Profile
Desktop Vectras HP Vectra VEi 8 PC 16-1
16
16
HP Vectra VEi 8 PC
Models and Accessories
Product
Number Hard Drive Video Controller Std. RAM Multi-media LAN OS1
Vectra VEi 8 PC
Models with Intel Pentium II Processor,
100 MHz System Bus Speed, and 512 KB Level 2 Cache Memory
HP Vectra VEi 8 PC 400 (CPL: 04/99 )
D8151A/T 4.3 GB
IDE Integrated Matrox
MGA-G200 AGP
(8 MB SGRAM
fitted, not
upgradeable)
32 MB
SDRAM
100 MHz
no no W95
D8152N/T 64 MB
SDRAM
100 MHz
3COM
3C905B-
TX
NT
4.0
WS
D8153A/T 8.4 GB
IDE 32 ✕Max IDE CD-ROM no W95
D8155A 4.3 GB
IDE 32 MB SDRAM
100 MHz
no W95
+
Word
Vectra VEi 8 PC
Models with Intel Pentium III Processor,
100 MHz System Bus Speed, and 512 KB Level 2 Cache Memory
HP Vectra VEi 8 PC 450 (CPL: 04/99 )
D8171A/T 4.3 GB
IDE Integrated Matrox
MGA-G200 AGP
(8 MB SGRAM
fitted, not
upgradeable)
32 MB
SDRAM
100 MHz
no no W95
D8172N/T 64 MB
SDRAM
100 MHz
3COM
3C905B-
TX
NT
4.0
WS
D8173A/T 8.4 GB
IDE 32 ✕Max IDE CD-ROM no W95
D8174A W98
D8175T NT
4.0
WS

HP Vectra VEi 8 PC
16-2 HP Vectra VEi 8 PC Medium-Profile
Desktop Vectras
16 Note
All models have an integrated full-duplex PCI audio controller.
Supported Accessories
1. Operating system preloaded on these models, as indicated in the table.
2. Channel Assembly Program (CAP) models: Processor speed, hard disk size, and memory is
user defined.
HP Vectra VEi 8 PC 500 (CPL: 04/99 )
D8183A 8.4 GB
IDE Integrated Matrox
MGA-G200 AGP
(8 MB SGRAM
fitted, not
upgradeable)
64 MB
SDRAM
100 MHz
32 ✕Max IDE
CD-ROM no W95
Vectra VEi 8 PC
Models with User Defined Processor, Main Memory, and Hard Disk
HP Vectra VEi 8 PC xxx2(CPL: 04/99 )
D8160E User
defined Integrated Matrox
MGA-G200 AGP
(8 MB SGRAM
fitted, not
upgradeable)
User
defined User defined User defined None
32-MB kit 32-bit SDRAM, 100 MHz non-ECC main memory module D6501A/T
32-MB kit 32-bit SDRAM, 100 MHz non-ECC main memory module
(pack of 20) D6504A/T
64-MB kit 32-bit SDRAM, 100 MHz non-ECC main memory module D6502A/T
64-MB kit 32-bit SDRAM, 100 MHz non-ECC main memory module
(pack of 20) D6505A/T
128-MB, 32-bit SDRAM, 100 MHz non-ECC main memory module D6503A/T
256-MB, 32-bit SDRAM, 100 MHz ECC main memory module D6743A/T
Documentation
User’s Guide Manual Kit D8110A
Product
Number Hard Drive Video Controller Std. RAM Multi-media LAN OS1

HP Vectra VEi 8 PC
Medium-Profile
Desktop Vectras HP Vectra VEi 8 PC 16-3
16
Input Devices
HP Standard Keyboard C4735A
HP Standard Mouse C3751A
HP Scrolling Mouse C4736A
Video Displays
All current HP Displays (see the HP Vectra Accessory Service Handbook)
Mass Storage
4.3-GB IDE hard disk D8371A
6.4-GB IDE hard disk D8372A
8.4-GB IDE hard disk D8373A
HP 100 MB Atapi II Iomega ZIP drive D6650A
HP 100 MB Atapi II Iomega ZIP drive (pack of 10) D6651A
Multimedia
32✕Max IDE CD-ROM drive (pack of 10) D6656A
32✕Max IDE CD-ROM drive D4384A
Multimedia sound accessory kit (16-bit audio board, cables, and software) -
pack of 10 D5183A
Multimedia sound accessory kit (32✕Max CD-ROM drive, 16-bit audio
board, headphones, cables, and software) D6657A
Data Communications and LAN Adapter Boards
HP 56K V90 PCI Fax Modem D7808A
HP 10/100 3Com 3C905B-TX, 10/100BT Ethernet card D7504A
HP 10/100 3Com 3C905B-TX, 10/100BT Ethernet card (pack of 10) D7505A
HP 10/100 Intel PRO/100+, 10/100BT Management adapter D7506A
HP 10/100 Intel PRO/100+, 10/100BT Management adapter (pack of 10) D7507A
Security
HP Master Pass Key System Kit D6655A
HP Master Pass Key D6658A
HP Locks for Master Pass Key System (pack of 50) D6659A
I/O Interfaces
HP Adaptec 2940 UW SCSI board D6951A
HP Serial interface card D8388A

HP Vectra VEi 8 PC
16-4 HP Vectra VEi 8 PC Medium-Profile
Desktop Vectras
16
System Board, BIOS, and Memory
Processor: Pentium II
or Pentium III SECC2
package with integrated
heatsink and level-2
cache memory.
Main Memory:
Two DIMM sockets which support
up to a maximum of 512 MB.
Install 32 MB, 64 MB, 128 MB or 256
MB 100 MHz SDRAM modules.
System Board Jumpers:
See the diagram on the next page.

HP Vectra VEi 8 PC
Medium-Profile
Desktop Vectras HP Vectra VEi 8 PC 16-5
16
System Board Jumpers
BIOS History
For the latest BIOS, the flasher utility program, and the BIOS history refer to the
HP World Wide Web site.
http://www.hp.com/go/vectrasupport/
Clear CMOS jumper
Defaultposition
Clear CMOS
Clear Password jumper
Defaultposition
Clear Passwords
 






 

 

Processor Frequency jumper.
Youneedtoinstallthejumper
only if a new processor is
supplied with one. To install
the jumper, simply place it
over the jumper block. It can
only go on one way.

HP Vectra VEi 8 PC
16-6 HP Vectra VEi 8 PC Medium-Profile
Desktop Vectras
16
Part Numbers
1
4
a
b
23
6
7
8
9
10
11
12
13
14
16
15
17
5

HP Vectra VEi 8 PC
Medium-Profile
Desktop Vectras HP Vectra VEi 8 PC 16-7
16
1. Includes front bezel, two 5.25 inch fillers, one 3.5 inch filler and name plate.
2. For optional disk drive information, see the Accessory Service Handbook.
3. Where “xx” is the code for your national keyboard (see the Accessory Service Handbook).
Parts List for HP Vectra VEi 7 PC
Item Description Repl.
Part Number Exchange Part Number
1Chassisassembly:
a Top cover assembly
b Rear bezel
5064-9121
5064-9140
5064-7437
—
2 Status panel assembly 5064-9150 —
3 Front bezel assembly15064-9116 —
4 Power supply 0950-3423 —
5 FDD filler kit (RFI plate +filler) 5064-9142 —
6 HDD and FDD cable kit 5064-9141 —
7 CD-ROM cable 5183-8063 —
8 Floppy disk drive (bezel-less) D2035-60391 —
9IDE hard disk drive 2
4.3 GB
8.4 GB —
—D7528-69001 D7530-69001
10 32 ✕Max IDE CD-ROM drive —D4385-69001
11 CD-ROM to audio connector cable 5182-1857 —
12 Headphones 5182-3552 —
13 Standard mouse C3751-60201 —
Standard keyboard C4739-601xx3—
14 Battery type CR2032 1420-0356 —
15 3COM Wake on LAN Cable 5183-2769 —
16 3Com 3C905B-TX LAN board 5064-6787 —
or Intel PRO/100+ LAN board 5064-7434 —
17 System board See PC’s system board parts list

HP Vectra VEi 8 PC
16-8 HP Vectra VEi 8 PC Medium-Profile
Desktop Vectras
16 Notes:
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
1. Electronic file available on HP’s Web site.
System Board Parts List for HP Vectra VEi 8 PC
Description Repl.
Part Number Exchange Part Number
System board:
Vectra VEi 8 system board with Matrox
MGA-G200 video controller — D8155-69001
Processors:
Intel Pentium II 400/100 512KB L2 cache — D7945-69001
Intel Pentium III 450/100 512KB L2 cache — D7946-69001
Intel Pentium III 500/100 512KB L2 cache — D7947-69001
Main memory modules:
1 ✕32-MB, 100 MHz non-ECC SDRAM D6501-63001 —
1 ✕64-MB, 100 MHz non-ECC SDRAM D6502-63001 —
Manuals and Documentation for HP Vectra VEi 8 PC
User’s Guide D8110A
Troubleshooting and Upgrade Guide no number1
Technical Reference Manual: hardware and BIOS no number1

English 23
3 Replacing Hardware Components
Removing and Replacing the Cover and Front Panel
Removing and Replacing the Cover and Front Panel
Removing the Cover Before removing the cover, switch off the monitor and PC, disconnect
all power cords and any telecommunication cables. If necessary, unlock
the cover at the rear of the PC.
1Undo the three thumb screws at the back of the PC and remove the
cover by sliding it towards you by about 2 cm (0.8 inches) and then
lifting it off.
2Ifrequired, remove thefront panel.To removethe panel,lift thetwo
retaining catches, then tilt the panel forwards and lift it off.

3 Replacing Hardware Components
Removing and Replacing the Cover and Front Panel
24 English
Replacing the Cover Before replacing the cover, ensure that all internal cables are properly
connected and safely routed.
1If necessary, replace the front panel. To do this, insert the three
plastic tabs into the holes in the front of the PC chassis and snap the
panel in place.
2Lower the cover and slide it into position.
3Tighten the three thumbscrews at the rear of the PC.
4If required, lock the cover with the key at the rear of the PC.

English 25
3 Replacing Hardware Components
Replacing a Memory Module
Replacing a Memory Module
1Remove the PC’s cover (described in this chapter).
2Open the two tabs and remove the old memory module.
3Insert the new memory module (aligning it) and close the two tabs.
4Replace the cover (described in this chapter).
Location of
Main Memory
(modules can
be installed in
either slot)
VEi 7 models VEi 8 models

3 Replacing Hardware Components
Replacing an Accessory Board
26 English
Replacing an Accessory Board
1Remove the computer’s cover (described in this chapter).
2Remove the screw that holds the old board in place.
3Hold the old board firmly and carefully pull it out.
4Aligning the new board carefully, slide it into position, then press it
firmly into the slot and tighten the retaining screw.
5Replace the cover (described in this chapter).

English 27
3 Replacing Hardware Components
Which Drive Connectors to Use
Which Drive Connectors to Use
Internal drives, such as hard disk drives, DVD drives, and CD-ROM
drives, must be connected to data and/or power cables. When replacing
these drives, ensure you use the correct data and power connectors.
Power Connectors Number in PC Use for
3 Hard disk drives, DVD drives, CD-ROM
drives, Zip drives
1 Floppy disk drive
Master (boot)
Hard Disk Drive
CD-ROM, DVD or Zip Drive Vectra VEi 7
Floppy Disk
Drive
CD-ROM, DVD or Zip Drive
Master (boot)
Hard Disk Drive
Floppy Disk Drive
Vectra VEi 8

3 Replacing Hardware Components
Replacing the Hard Disk Drive
28 English
Replacing the Hard Disk Drive
For information on recovering the contents of your hard disk drive,
refer to the Troubleshooting and Upgrade Guide, available on HP’s
web site at www.hp.com/go/vectrasupport.
1Remove the computer’s cover (described in this chapter).
2Remove the drive’s data and power connectors.
3Remove the four retaining screws and slide the drive out of the tray.
CAUTION Take care when handling the hard disk drive during installation. A one-quarter
inch drop can damage it.
4Slide the new hard drive into the drive tray (with the correct
orientation) and tighten the screws.
5Attach all data and power connectors.
6Replace the cover (described in this chapter).

English 29
3 Replacing Hardware Components
Replacing the CD-ROM Drive (or DVD Drive)
Replacing the CD-ROM Drive (or DVD Drive)
WARNING Toavoidelectricalshockandharmtoyoureyesbylaser,donotopenthelaser
module. The laser module should be serviced by service personnel only. Do
not attempt to make any adjustment to the laser unit. Refer to the label on the
CD-ROM for power requirements and wavelength. This product is a class I
laser product.
1Remove the PC’s cover and front panel (described in this chapter).
2Remove all the drive’s connectors. There may also be an audio cable
(not shown here).
3Remove the screws that secure the old drive and slide the drive out
the front of the PC.
NOTE Some models have a third retaining screw, situated on the other side of
the drive bay. If the drive cannot be slid out after removing the two
screws,take outthefloppy/harddiskdrive bay(describedin“Replacing
the Floppy Drive” ) and remove the third retaining screw.
Optional third
screw

3 Replacing Hardware Components
Replacing the CD-ROM Drive (or DVD Drive)
30 English
4Slide the new drive into the bay and replace the screws.
5Attach all connectors.
6Replace the PC’s front panel and cover (described in this chapter).

English 31
3 Replacing Hardware Components
Replacing the Floppy Drive
Replacing the Floppy Drive
1Remove the PC’s cover (described in this chapter).
2Remove the hard drive’s connectors.
3Remove the floppy drive’s connectors.
4Removethethreeretainingscrewsfromthedrivetray,thenslidethe
tray back (by about 3 cm) until it can be lifted out.

3 Replacing Hardware Components
Replacing the Floppy Drive
32 English
5Undo the three screws on the sides of the drive tray and remove the
old floppy drive.
6Slide the new floppy drive into the drive tray (with the correct
orientation) and tighten the screws.
7Replace the drive tray and tighten the three retaining screws.
8Attach the connectors to the new floppy drive and the hard disk
drive.
9Replace the cover (described in this chapter).

English 33
3 Replacing Hardware Components
Replacing the Celeron Processor (VEi7 models)
Replacing the Celeron Processor (VEi7 models)
NOTE HP does not support processor upgrades. This information is provided
to help you replace a defective unit with a processor provided by HP
support services.
1Remove the computer’s cover (described in this chapter).
2Unclip and remove the heatsink. The retention clip will be of one of
the designs shown below.
3Raise the lever on the socket to unlock the processor and lift it out.
Design 1 Design 2

3 Replacing Hardware Components
Replacing the Celeron Processor (VEi7 models)
34 English
4Position the new processor over the socket, with its corner marker
facing the corner marker on the socket.
5Install the new processor and lower the lever to lock it in place.
6Apply more heat interface if required. Replace the heatsink and
fastenthe clip.The retentionclip willbe ofone ofthe designsshown
above.
NOTE The heat interface that bonds the heatsink to the processor can be
damaged when you change processors. You can order more heat
interface by consulting the Service Handbook, downloadable from the
“Manuals” section of www.hp.com/go/vectrasupport.
7Replace the cover (described in this chapter).
NOTE If you replace your processor or system board, you may need to update
yourBIOS.ThelatestBIOSforyourPCandinstructionsonupdatingthe
BIOS are available from: www.hp.com/go/vectrasupport.
Design 1 Design 2
