HP VISUALIZE B Class and C Class UNIX®
Workstations
Parts Replacement Guide
Manufacturing Part Number: A4985-90036
Edition E0100
© Copyright 1999 by Hewlett-Packard

2
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not
furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright. All rights reserved. No part of
this document may be photocopied, reproduced or translated to another language without the prior written
consent of Hewlett-Packard Company.
Hewlett-Packard Warranty Statement
Refer to Warranty & Support for your HP Workstation for warranty terms applicable to your Hewlett-Packard
product and replacement parts.
Restricted Rights Legend
Use, duplication, or disclosure by the U.S. Government Department of Defense is subject to restrictions as set
forth in paragraph (b)(3)(ii) of the Rights in Technical Data and Software clause in DFARS 252.227.7013.
UNIX is a registered trademark in the United States of America and other countries, licensed exclusively
through X/Open Company Limited.
This software and documentation is based in part on the Fourth Berkeley Software Distribution under license
from the Regents of University of California.
© Copyright 1999 Hewlett-Packard Company. All Rights Reserved.
© Copyright 1980, 1984 AT&T, Inc.
© Copyright 1979, 1980, 1983 The Regents of the University of California.

Contents
3
1. Getting Started
Safety Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Electrostatic Discharge (ESD) Precautions . . . . . . . . . . . . . . . . . . . . . .5
Replacement Part Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Safely Powering Down the B Class and C Class Workstation . . . . . . . . .7
Product Exploded Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2. Parts Removal and Replacement
Terminators and Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Removing the Terminators and Cables. . . . . . . . . . . . . . . . . . . . . . . . .10
Replacing the Terminators and Cables. . . . . . . . . . . . . . . . . . . . . . . . .11
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Removing the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Replacing the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Left Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Removing the Left Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Replacing the Left Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Removing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Replacing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Memory Card(s) DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Removing and Replacing DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
PCI I/O Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Removing PCI I/O Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Replacing PCI I/O Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CD ROM Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

4
Contents
Removing the CD ROM Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Replacing the CD ROM Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Removing the Front-Panel Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Replacing the Front-Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Floppy Disk Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Removing the Floppy Disk Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Hard Disk Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Removing the Hard Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Putting a Disk Drive into its Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Replacing the Hard Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
I/O Fan and Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing the I/O Fan and Speaker. . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing and Replacing the Fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Removing and Replacing the Speaker . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replacing the Fan and Speaker Bracket . . . . . . . . . . . . . . . . . . . . . . . 37
Removing and Replacing the System Board. . . . . . . . . . . . . . . . . . . . . . 38
Disconnecting the Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Removing the old System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Replacing the System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Real Time Clock (RTC) Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Removing the Real Time Clock (RTC) Module . . . . . . . . . . . . . . . . . . 42
Replacing the Real Time (RTC) Module . . . . . . . . . . . . . . . . . . . . . . . 43
Removing and Replacing the System Board Cooling Fans . . . . . . . . . . 44
Replacing the System Board Cooling Fans . . . . . . . . . . . . . . . . . . . . . 45
3. Wrapping Up
Verifying System Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Returning the Defective Exchange Assembly . . . . . . . . . . . . . . . . . . . 47

5
1Getting Started
The following important information must be adhered to for proper removal and
replacement of all Hewlett-Packard parts.
Safety Warnings
WARNING Removing the device cover may expose sharp edges in the equipment
chassis. To avoid injury, use care when installing customer add-on
devices.
NOTE Before performing removal/replacement procedures, position the workstation
on a cushioned flat, stable surface, such as a table top or workbench.
NOTE Installing the recommended HP replacement part in your B Class and C
Class workstation does not affect the regulatory and safety classifications or
approvals listed in the original owner’s guide.
Electrostatic Discharge (ESD) Precautions
To prevent damage to the B Class and C Class workstation, observe all of the following
ESD precautions while performing removal and replacement procedures:
• Remove all ESD-generating materials from the work area in which you will remove and
replace the workstation field replaceable unit(s).
• Open the ESD materials provided with the replacement part kit. Unfold the black
conductive sheeting (antistatic mat) and place it under a corner of the workstation.
• Wear a static strap to ensure that any accumulated electrostatic charge is discharged
from your body to ground. Attach the static-grounding wrist strap by following the
instructions on the package. Attach the sticky end of the wrist strap to bare metal on
the rear panel of the workstation.
• Connect all equipment together, including the static-free mat, static strap, clips
attached to the wrist strap, nodes, and peripheral units.
• Keep uninstalled printed circuit boards in their protective antistatic bags.
• Once you have removed printed circuit boards from their protective antistatic bags,
handle the printed circuit boards by their edges only.

6Chapter1
Getting Started
Replacement Part Kit Contents
Replacement Part Kit Contents
Take a moment to verify that your kit contains the following contents:
• The replacement part.
• Part Number: A3024-80004, Electrostatic Discharge (ESD) materials
• Removal/Replacement Instructions
If you are missing any part or any documentation, please call your designated service
representative.
Required Tools
You will need the following tools for removal/replacement procedures:
• T-10 and/or T-15 Torx drivers
• Light-duty flat-blade screwdriver with a 150mm (6-inch) blade
• Needle-nosed pliers
• ESD materials

Chapter 1 7
Getting Started
Safely Powering Down the B Class and C Class Workstation
Safely Powering Down the B Class and C Class Workstation
You must complete the following steps before performing any of the removal and
replacement procedures:
NOTE Remove any accessory bag(s) and their black tab screws, if present, from the
rear of the workstation.
1. Shut down the workstation by executing “shutdown -h” as user root. This ensures
that all programs are terminated and all data is saved before switching the power off.
Power down the workstation by simply pressing the power switch on the front panel.
Power off the monitor and any attached peripheral devices.
2. After 30 seconds, unplug the workstation’s power cord and all peripheral devices from
AC power outlets. Before attempting to move the workstation to a disassembly area,
disconnect all peripherals from the back of the system.
3. Place the workstation on a flat, stable surface, such as a tabletop or floor. To protect
against scratches, remove miscellaneous debris from the work surface.

8Chapter1
Getting Started
Product Exploded Diagram
Product Exploded Diagram
Refer to the figure below for a basic parts overview of the B Class and C Class workstation.
Figure 1-1. Exploded View
Chassis
Front-Panel Display
Hard Disk Tray
CD Drive Tray
Floppy Drive Tray
System Board
DIMMs (Memory)
Memory Fan
Side Panel
Power
System-Board Fans
I/O Fan/Speaker Bracket
Air Divider
I/O Card
Speaker
I/O Fan
Supply
Retainer Clip

9
2Parts Removal and Replacement
This chapter describes how to remove and replace the various parts in the B Class and C
Class workstations.

10 Chapter2
Parts Removal and Replacement
Terminators and Cables
Terminators and Cables
This section describes how to remove and replace the Terminators and Cables
Removing the Terminators and Cables
1. After powering down the workstation as described in the “Getting Started” chapter,
unplug the power cable from the back of the workstation. To avoid ESD damage to
components, carefully follow the ESD procedures (also described in the “Getting
Started” chapter).
2. Remove the two SCSI terminators from the back of the machine, as shown below. Or, if
you have already replaced either or both of the terminators with cables to external
peripheral devices, remove those cables., LAN cable, USB cables, and any other cables
from the back of the workstation.
Figure 2-1. Removing all Terminators and Cables
1. Remove the cables from the USB Clip from the back of the Workstation.
SCSI Terminators
Audio In/Out Ports
Parallel Port
LAN Port
USB Ports
Serial Ports
Power Plug

Chapter 2 11
Parts Removal and Replacement
Terminators and Cables
Figure 2-2. Opening the USB Clip
Replacing the Terminators and Cables
1. Replace the two SCSI terminators from the back of the machine, as shown below. Or, if
you have already replaced either or both of the terminators with cables to external
peripheral devices, replace those cables., LAN cable, USB cables, and any other cables
from the back of the workstation.Refer to Figure 2-1 for location.
2. Rethread the keyboard and mouse cables through the USB clip. Close the USB clip.
Insert a fingernail under the
locking lever of the USB clip .
Lift up.
Keyboard and
Mouse connectors.

12 Chapter2
Parts Removal and Replacement
Front Panel
Front Panel
This section describes how to remove and replace the Front Panel.
NOTE Prior to removing the Front Panel, the Terminators and Cables need to be
removed from the back of the workstation. See the appropriate section(s) for
the steps on how to remove this component.
Removing the Front Panel
1. Facing the front of the workstation, unlock the front panel if necessary, and open it by
pressing the two latch buttons located on the right side of the panel, as shown below.
Figure 2-3. Opening and Removing the Front Panel
2. Swing the panel to the left until it unhinges, and then lift it away from the workstation.
Set it aside.
Front-Panel
Latch Buttons

Chapter 2 13
Parts Removal and Replacement
Front Panel
Replacing the Front Panel
1. Facing the front of the workstation, align the top and bottom hinge hooks on the left
edge of the front panel with their respective holes in the chassis. Insert the hinge hooks
into the holes.
Figure 2-4. Replacing the Front Panel
2. Swing the panel to the right until it closes, and the two latch buttons click into place to
hold it shut. Relock if desired.
Front-Panel
Latch Buttons

14 Chapter2
Parts Removal and Replacement
Left Side Panel
Left Side Panel
This section describes how to remove and replace the Left Side Panel.
NOTE Prior to removing the Left Side Panel, the Terminators and Cables need to be
removed from the back of the workstation. See the appropriate section(s) for
the steps on how to remove this component.
NOTE Only the left side panel is removed. The left side panel is the one on the left
when facing the front of the workstation.
Removing the Left Side Panel
1. Remove the two T-15 Torx thumbscrews located in the top and bottom right edge of the
back side of the workstation, as shown below.
Figure 2-5. Opened Side Panel
2. Remove the left side panel by grasping the back edge of the panel and rotating the
panel outward as shown above. Unhinge the panel and pull it away from the
workstation. Set the panel and its screws aside.
Safety Interlock Pin
Safety
Side-Panel Thumbscrew
Side-Panel Hook
Interlock Switch
1
2
Hinge Slots

Chapter 2 15
Parts Removal and Replacement
Left Side Panel
Replacing the Left Side Panel
1. Replace the left side panel by holding it at an angle and inserting its top and bottom
hinge hooks with their respective slots in the chassis. Swing the back edge of the panel
toward the back of the workstation and press the panel firmly into place.
Figure 2-6. Opened Side Panel
2. Replace the two T-15 Torx thumbscrews that secure the left side panel to the chassis.
3. For each of the two SCSI connectors on the rear wall of the chassis, replace either the
external SCSI devices (if you had any such devices attached previously) or the
appropriate terminator (if you didn’t have any external devices attached). One or the
other must be in place.
Safety Interlock Pin
Safety
Side-Panel Thumbscrew
Side-Panel Hook
Interlock Switch
1
2
Hinge Slots

16 Chapter2
Parts Removal and Replacement
Power Supply
Power Supply
This section describes how to remove and replace the power supply.
NOTE Prior to removing the Power Supply, the Front Panel and the Left Side Panel
need to be removed. See the appropriate section(s) for the steps to remove and
replace these components.
Removing the Power Supply
1. Position the workstation on its side. Use a cushioned surface to protect the exterior of
the system from damage.
2. Position the conductive sheeting so that an inch of one edge is under the workstation
and the rest is flat against the work area to lay system components on after you remove
them. Also ensure that your static-grounding strap is securely attached to your wrist
and to bare metal on the workstation.
Figure 2-7. Power Supply Screws and Handles
3. Alternately loosen the two T-15 Torx screws from the corners of the power supply as
shown above.
4. Using the handle, lift up the power supply and place the bail in the bail lock to hold the
power supply upright.
T15 Torx
Power Supply
Thumbscrew
Handle
T15 Torx
Thumbscrew

Chapter 2 17
Parts Removal and Replacement
Power Supply
Figure 2-8. Tipping Up the Power Supply
5. Disconnect the four cables shown below: three system power cables and the SCA hard
disk backplane cable.
Figure 2-9. Location of Power Cables
6. Remove the power supply from the workstation:
a. Holding the power supply handle, remove the bail from the bail lock.
b. Slide the spring hinge lever toward the front of the workstation and rotate it
downward to lock it in place.
c. Slide the power supply toward the back of the workstation to disengage it from the
right hinge pin, remove the power supply and set it aside.
Replacing the Power Supply
1. To install the power supply:
Right-side Hinge Pin
Bail
Spring Hinge
Bail
Lock
Power Cables

18 Chapter2
Parts Removal and Replacement
Power Supply
a. Pick up the power supply by the handle and position its right-side hinge pin into the
right side hinge bracket, as shown below.
b. Align the shaft of the spring hinge (on the left side) with its hole in the hinge
bracket, release the spring-hinge lever, and let it snap left into the hole.
Figure 2-10. Reinstalling the Power Supply
2. Connect the four power cables.
• Three system power cables
• SCA hard-disk backplane power cable
Figure 2-11. Location of Power Cables
3. Lift the handle edge of the power supply enough to allow the bail lock to be disengaged
from the bail, fold the bail lock down, and the lower the power supply back into place.
4. Alternately tighten the two captive T-15 Torx screws in the corners of the power supply.
Right-side Hinge Pin
Bail
Spring Hinge
Bail
Lock
Power Cables

Chapter 2 19
Parts Removal and Replacement
Power Supply
Figure 2-12. Power Supply Screws and Handles
5. Carefully tip the workstation back to the upright position.
T15 Torx
Power Supply
Thumbscrew
Handle
T15 Torx
Thumbscrew

20 Chapter2
Parts Removal and Replacement
Memory Card(s) DIMMs
Memory Card(s) DIMMs
This section describes how to remove and replace DIMMs (Dual In-line Memory Modules)
for the B Class and C Class workstations.
NOTE Prior to removing the memory, the Left Side Panel, the Power Supply, and the
Hard Disk Fan need to be removed. See the appropriate section(s) for the
steps to remove and replace these components.
Removing and Replacing DIMMs
1. For each DIMM to be removed, press down firmly on the DIMM-removal tabs. The
DIMM will come out of its socket.
Figure 2-13. Removing a DIMM
2. Align the replacement DIMM with the socket, making sure it is keyed to the socket; i.e.,
the slots in the DIMM match the dividers in the DIMM socket. This ensures that the
DIMM cannot be inserted incorrectly.
