HP 2510p - Notebook PC User manual

HP recommends
Windows Vista
®
Business
1. Volume mute button with LED indicator 13. Optical drive (select models)
2. Volume scroll zone with up/down LED indicators 14. USB 2.0 Port (powered on select models)
3. Pointstick 15. RJ-11/modem port
4. HP Fingerprint Sensor 16. Power connector
5. Speaker 17. Power button with LED
6. Touchpad buttons 18. HP Info / HP QuickLook button with LED indicator
7. Touchpad with scroll zone 19. Integrated microphone
8. Pointstick buttons 20. Wireless on/off button with LED indicator
9. Hard drive / optical drive activity / HP 3D DriveGuard LED 21. Ambient Light Sensor
10. Battery charging LED 22. HP Presentation button with LED indicator
11. Power/standby LED 23. Touchpad on/off button
QuickSpecs
HP Compaq 2510p Notebook PC
Overview
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 1

12. Wireless on/off LED 24. Two WLAN/WWAN combo antennas
1. PC Card eject button 6. Stereo microphone in
2. PC Card slot (or smart card reader on select models) 7. USB 2.0 port
3. Secure Digital (SD) slot 8. VGA/external monitor connector
4. IEEE 1394 port 9. Docking connector
5. Stereo headphone/line out 10. Kensington Lock slot
11. RJ-45/Ethernet port
At A Glance
Genuine Windows Vista Business*,
Genuine Windows Vista Home Basic,
Genuine Windows XP Professional, or
FreeDOS
Starting at 2.8 lb/1.29 kg and less than 1 inch thin
Integrated optical drive support on select models
Flexible wireless connectivity options:
Integrated HP ev2210 1xEVDO-A or HP hs2300 HSDPA Broadband Wireless module
Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module
Bluetooth®
12.1-inch Illumi-LiteWXGA display with Ambient Light Sensor and HP Privacy Filter support
3-, 6-, and 9-cell battery options
Intel® Centrino® with vPro™ processor capable, with Intel Core™2 Duo ULV and LV processors
Full magnesium alloy enclosure, magnesium alloy support structure, and HP DuraFinish
Enhanced security features including HP Fingerprint Sensor, TPM 1.2**, optional Smart Card Reader,
and Drive Encryption for HP ProtectTools
HP QuickLook on Windows Vista models for instant access to email, calendar, and contact information
Up to 120-GB 5400 rpm, user-removable hard drive protected by HP 3D DriveGuard or 64-GB Solid State Drive
Up to 4 GB of 667-MHz DDR2 SDRAM (runs at 533-MHz); one memory slot
Full-size keyboard with HP DuraKeys
Touch-sensitive controls
Dual pointing devices (touchpad with scroll zone and pointstick)
Connector for HP 2400/2500 Ultra-Light Docking Station
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
QuickSpecs
HP Compaq 2510p Notebook PC
Overview
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 2

Secure Digital (SD) slot
* At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will be deleted.
** TPM module disabled where use is restricted by law; for example, Russia and China.
QuickSpecs
HP Compaq 2510p Notebook PC
Overview
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 3

Processors Intel Core 2 Duo ULV Processor U7500 (1.06 GHz, 2 MB L2 cache, 533 MHz FSB)
Intel Core 2 Duo ULV Processor U7600 (1.20 GHz, 2 MB L2 cache, 533 MHz FSB)
Intel Core 2 Duo ULV Processor U7700 (1.33 GHz, 2 MB L2 cache, 533 MHz FSB)
Operating System Preinstalled Genuine Windows Vista Business
†
*
Genuine Windows Vista Home Basic*
Genuine Windows XP Professional
FreeDOS
Supported Genuine Windows Vista Enterprise*
Genuine Windows 2000
Certified SuSE Linux Enterprise Desktop 10
†
At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will
be deleted.
* Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit http://www.windowsvista.com/upgradeadvisor .
Chipset Mobile Intel GM965
Intel Centrino with vPro
technology capable
Intel Centrino with vPro technology is a selectable feature that is available on units configured with an
Intel Wireless WiFi Link 4965AGN or 4965AG. It provides advances in remote manageability, security,
energy efficient performance, and wireless connectivity. Intel Active Management Technology (AMT)
offers built-in manageability and proactive security for networked notebook PCs, even when they are
powered off* or when the operating system is inoperable. It can help identify threats before they reach the
operating system, isolate infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source,
and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of Intel Centrino Pro and vPro technology, such as Intel Active Management
technology and Intel Virtualization technology, requires additional 3rd party software in order to run.
Availability of future "virtual appliances" applications for Centrino Pro and vPro technology is dependant
on 3rd party software providers. Compatibility with future "virtual appliances" and Microsoft Windows
Vista operating system is yet to be determined.
Graphics Mobile Intel GMA X3100, up to 384 MB of shared system memory
Microsoft DirectX9 capable
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 4

Display Internal 12.1-inch diagonal Illumi-Lite WXGA anti-glare (1280 × 800 resolution)
Ambient light sensor
HP Privacy Filter support
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard 512-MB, 1024-MB, 2048-MB, or 4096 667-MHz* DDR2 SDRAM;
one SODIMM slot
* Operates at a maximum of 533-MHz with 667-MHz memory.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux.
With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system
resource requirements.
Communications Integrated Intel Gigabit Network Connection (10/100/1000 NIC)*
56K V.92 modem**
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Wireless LAN is factory configurable or available as an option to be
added later. Broadband Wireless (WWAN) requires Windows Vista Business or Windows XP Professional
and is available in select countries as a standard, factory configurable feature or as an option to be added
later. Integrated Bluetooth is also available (factory configurable only) and can be combined with any of
the supported wireless LAN and wireless WAN options.
HP ev2210 1xEVDO-A
Broadband Wireless
Module
Integrated WWAN module connects to the Verizon Wireless BroadbandAccess
and NationalAccess networks (US only)
Supports CDMA 1xEVDO-A, 1xRTT connections at 800 and 1900 MHz.
NOTE: Separately purchased Verizon Wireless service is required. For details,
go to http://www.hp.com/go/broadbandwireless .
Upgradeable design and two 850/900/1800/1900/2100-MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies
HP hs2300 HSDPA
Broadband Wireless
Module
Integrated WWAN module that provides connection to GSM, GPRS, EDGE,
UMTS, and HSDPA mobile networks in many countries. Currently supported
networks are the Cingular network in the U.S., Vodafone networks in select
countries, and roaming on Cingular and Vodafone partner networks in more
than 100 countries.
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 5

NOTE: Separately purchased mobile network operator service is required.
Upgradeable design and two 850/900/1800/1900/2100-MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies.
All 802.11a/b/g
integrated wireless LAN
options
Wi-Fi certified
Cisco Compatible Extensions support (Version 4.0) with Microsoft Windows XP
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Three antennas integrated in the display enclosure
Intel Wireless WiFi Link
4965ABGN
Integrated support for 802.11a, b, g, and draft-n
Up to 300-mbps data rate
Intel Wireless WiFi Link
4965ABG
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Intel PRO/Wireless
3945BG Network
Connection
Integrated support for 802.11 b and g
Up to 54-mbps data rate
Broadcom 4321AGN
802.11a/b/g/draft-n Wi-
Fi Adapter
Integrated support for 802.11a, b, g, and draft-n
Up to 300-mbps data rate
Broadcom 4311AG
802.11a/b/g
WiFi Adapter
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Broadcom 4311BG
802.11b/g
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54-mbps data rate
HP Integrated Module
with Bluetooth Wireless
Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.0-mm stroke, and comfort-dished
keycaps.
HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish and the
printed characters on the keys.
HP DuraFinish helps protect the finish on the keyboard deck, graphics, and icons from normal wear and
tear.
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 6

Touch-sensitive controls Touch-sensitive controls provide easy access to the following features: HP Info Center, HP QuickLook,
wireless on/off, HP Presentation button, touchpad on/off, volume up, volume down, and mute
Pointing device Enhanced dual pointing devices:
Touchpad with scroll zone, two pick buttons
and
Pointstick, two pick buttons
Expansion card slots 1 Type I/II PC Card slot Supports 32-bit CardBus and 16-bit PC Cards
or
Optional Integrated
Smart Card Reader
(replaces PC Card slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Secure Digital slot Supports SD (Secure Digital), MultiMediaCard
Storage Internal Storage Device 120-GB 5400 rpm 1.8" PATA Hard Drive
60/80/100/120-GB 4200 rpm 1.8" PATA Hard Drive
64-GB Solid State Drive
NOTE: Hard drives are customer removable and will withstand multiple insertion/removal cycles. Up to 10
GB is reserved for the system recovery software.
HP 3D DriveGuard The hard drive is mounted to the notebook frame, reducing the transmission
of shock away from the hard drive. Uses three-axis digital motion detection
with intelligent sensitivity to help protect the hard drive during normal use
from shock and vibration. The digital accelerometer temporarily halts all data
transfer and parks the hard drive when abrupt motion is detected.
Optical drives
(9.5mm PATA)
DVD-ROM Drive
DVD/CD-RW Combo Drive
DVD+/-RW SuperMulti DL Drive
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 7

Interfaces PC Card slot One Type I/II PC Card slot
Smart Card Reader Optional (replaces PC Card slot)
External monitor One – VGA
1394a One
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
USB 2.0 Two (including one powered USB 2.0 port to support HP External MultiBay II on
units without an integrated optical drive)
Docking connector For HP 2400/2500 Ultra-Light Docking Station
LED status indicators Seventeen
Audio High Definition Audio support w/24-bit DAC
Integrated mono speaker
Integrated microphone
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in
Software Preinstalled software
with Windows Vista or
Windows XP
PDF Complete
HP Backup and Recovery Manager
HP Help and Support Center
HP QuickLook (Windows Vista only)
HP OpenView Radia Management Agent
HP Universal Print Driver
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
Embedded Security for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition
(select models)
Roxio Creator 9 (for optional DVD+/-RW and DVD/CDRW drives)
Symantec Norton Internet Security with complimentary 60-day live update
Intervideo WinDVD – DVD Player
Additional software
available from the web
HP Client Manager
Java Card Security for HP ProtectTools
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 8

HP Backup and Recovery
Manager
Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide
data and system file protection for HP business PCs to enable fast recovery if the system becomes
corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can
perform scheduled or manual backups of the entire drive or individual files and folders. Up to 10 GB of the
hard drive is reserved for the system recovery software. HP Backup and Recovery Manager can also create
software recovery CDs or DVDs (requires optional CD-RW or DVD+/-RW hardware).
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools Security
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
Embedded Security for HP ProtectTools
Java Card Security for HP ProtectTools
Security Standard Features HP ProtectTools Security Manager
HP Fingerprint Sensor
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
TPM 1.2 Embedded Security Chip*
TPM Enhanced DriveLock*
HP Disk Sanitizer
HP 3D DriveGuard
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased separately)
Optional Features Smart Card Reader
(replaces Type I/II PC Card
slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor
*TPM module disabled where use is restricted by law; for example, Russia and China.
For more information on HP security solutions refer to http://www.hp.com/go/security .
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 9

Power Supply External 65-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge*
*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge
Technology does not apply to 9 cell primary batteries.
Battery Primary Battery 3-cell (28 WHr) high capacity Lithium-Ion
6-cell (55 WHr) high capacity Lithium-Ion
9-cell (83 WHr) high capacity Lithium-Ion
Battery Fuel Gauge LEDs 6-cell high capacity and 9-cell high capacity
Battery Life 3-cell Primary Battery Up to 4 hours
6-cell Primary Battery Up to 8 hours
9-cell Primary Battery Up to 12 hours
NOTE: The listed battery life measurements were taken on models running Microsoft Windows XP
Professional. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time Up to 1 week
Power Conservation Supports enhanced Intel SpeedStep technology with Intel Core 2 Duo ULV processors (allows Battery
Optimized Mode, Maximum Performance Mode, or Automatic mode)
Intel Display Power Saving technology
Hibernation
Standby
ACPI compliance
Docking (optional) HP 2400/2500 Ultra-Light Docking Station
Service and Support HP Services offers limited 3- year, 1-year and 90-day warranty options depending on country;
1-year limited warranty on primary battery. On-site service and warranty upgrades are also available. For
HP Care Pack services see http://www.hp.com/go/lookuptool .
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
Select Model(s)
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 10

2510p
GM651AW#xxx (may vary
based on local regulatory
requirements)
Processor Intel Core 2 Duo ULV Processor U7600 (1.20-GHz, 533-MHz, 2-MB L2 cache)
Intel Centrino with vPro
technology
Enabled
Operating System Genuine Windows Vista Business*
System Memory 1024 MB 667-MHz** DDR2 (1 DIMM)
Hard Drive 80-GB 4200rpm 1.8" SMART PATA
Display 12.1-inch diagonal Illumi-Lite WXGA anti-glare
Graphics Mobile Intel GMA X3100
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Optical Drive DVD+/-RW SuperMulti DL Drive
Communications Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem
Integrated Wireless Intel Wireless WiFi Link 4965AG
Integrated Security Drive Encryption for HP ProtectTools
HP Fingerprint Sensor
TPM 1.2***
Pointing Device Enhanced dual pointing devices (touchpad with scroll zone and pointstick)
Battery 6-cell (44 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will
be deleted.
** System runs at a maximum of 533-MHz.
*** TPM module disabled where use is restricted by law; for example, Russia.
QuickSpecs
HP Compaq 2510p Notebook PC
Standard Features
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 11

Memory HP 512-MB (DDR2 667 MHz) SODIMM EM993AA
HP 1-GB (DDR2 667 MHz) SODIMM EM994AA
HP 2-GB (DDR2 667 MHz) SODIMM EM995AA
HP 4-GB (DDR2 667 MHz) SODIMM KX034AV
MultiBay II Storage
(9.5-mm)
NOTE: Requires HP
External MultiBay II
HP MultiBay II DVD-ROM Drive PA849A
HP MultiBay II DVD/CD-RW Combo Drive PA850A
HP MultiBay II DVD+/-RW SuperMulti DL Drive PA851A
HP 80-GB 5400rpm MultiBay II Hard Drive PH357A
Other Storage HP Notebooks USB Diskette Drive DC361B
Communications Intel Wireless WiFi Link 4965AGN option kit RT081AA#xxx
HP ev2210 1xEVDO-A Broadband Wireless Module (Verizon) (available Sept. 2007) GM763AA#ABA
HP ev2210 1xEVDO-A Broadband Wireless Module (Sprint) (available Oct. 2007) GM764AA#ABA
HP hs2300 HSDPA Broadband Wireless Module (AT&T) (available Sept. 2007) GG589AA#ABA
HP hs2300 HSDPA Broadband Wireless Module (Generic) (available Oct. 2007) GG590AA#xxx
Expansion Solutions HP 2400/2500 Ultra-Light Docking Station EQ773AA#xxx
HP Standard Monitor Stand PA507A
HP Adjustable Notebook Stand PA508A
HP External MultiBay II PA509A#xxx
Power HP 2-Bay Battery Charging Station (North America only) DT533A#xxx
HP 2-Bay Battery Charging Station (rest of world) EW424AA#xxx
HP 10-Bay Battery Charging Station (North America only) DT534A#ABA
HP HP 2400/2500 Battery Adapter Kit EH769AA
HP 65W Smart AC Adapter ED494AA#xxx
HP 90W Smart Auto Adapter ED493AA
HP 65W AC/Auto/Air Combo Smart Adapter ED993AA#xxx
HP 3-Cell Li-Ion Primary Battery RW556AA
HP 6-Cell Li-Ion Primary Battery EH767AA
HP 9-Cell Li-Ion Primary Battery EH768AA
QuickSpecs
HP Compaq 2510p Notebook PC
Options
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 12

Carrying Cases HP Value Nylon Case RR314AA
HP Universal Nylon Case RR315AA
HP Executive Leather Case RR316AA
HP Deluxe Nylon Backpack RR317AA
HP Universal Messenger Bag GD404AA
HP Deluxe Roller Case GD405AA
Security HP PC Card Smart Card Reader with Java Card EL347AA
HP ProtectTools Java Card – 10 units EL348AA
HP/Kensington MicroSaver Security Lock PC766A
HP Notebook Productivity Bundle GC832AA
Input/Output Devices HP USB Keyboard & Mouse Bundle RC465AA#xxx
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP USB Optical Travel Mouse RH304AA
HP USB Optical Travel Mouse RJ316AA
QuickSpecs
HP Compaq 2510p Notebook PC
Options
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 13

667-MHz* DDR2 SDRAM
One DIMM slot
DIMM sizes supported: 512 MB, 1024 MB, 2048, 4096 MB
Standard Memory 512 MB (512 MB x 1)
1024 MB (1024 MB x 1)
2048 MB (2048 MB x 1)
Optional Memory
Upgrades
Support for up to 4096 MB of memory with the installation of optional DDR2 SDRAM memory kits. Please
refer to the Hardware and Software Guide for installation procedures. Memory slot is user-accessible.
HP 512-MB (DDR2 667 MHz) SODIMM* EM993AA
HP 1024-MB (DDR2 667 MHz) SODIMM* EM994AA
HP 2048-MB (DDR2 667 MHz) SODIMM* EM995AA
HP 4096-MB (DDR2 667 MHz) SODIMM* KX034AV
* System runs at a maximum of 533-MHz.
NOTE: Availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux. With
Windows 32-bit operating systems, memory above 3 GB may not all be available due to system resource
requirements.
QuickSpecs
HP Compaq 2510p Notebook PC
Memory
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 14

Optical Drive Support
Fixed optical drives (95mm PATA) Quantity Supported Drive Bay
DVD-ROM Drive One Fixed optical drive bay
DVD/CD-RW Combo Drive One Fixed optical drive bay
DVD+/-RW SuperMulti DL Drive One Fixed optical drive bay
Internal Storage Device
Hard Drives (1.8” SMART PATA) Quantity Supported Drive Bay
60-GB 4200 rpm One Dedicated hard drive bay
80-GB 4200 rpm One Dedicated hard drive bay
100-GB 4200 rpm One Dedicated hard drive bay
120-GB 4200 rpm One Dedicated hard drive bay
120-GB 5400 rpm One Dedicated hard drive bay
Solid State Drive
64-GB Solid State Drive One Dedicated hard drive bay
QuickSpecs
HP Compaq 2510p Notebook PC
Storage
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 15

System Unit Dimensions (HxWxD) 0.97 in (at front) x 11.11 in x 8.38 in
24.7 mm (at front) x 282.3 mm x 212.8 mm
Weight Starting from 2.8 lb (1.29 kg)
NOTE: Height varies depending upon where on the notebook the measurement is made. Starting weight
includes 3-cell battery, hard drive, 512-MB memory, 802.11 wireless communications module. Weight
varies by configuration and components.
Stand-Alone Power
Requirements
(AC Power)
Nominal Operating Voltage 18.5 V
Average Operating Power 12.5 W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating –50 to 10,000 ft (–15.24 to 3,048 m)
Non-operating –50 to 40,000 ft (–15.24 to 12,192 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR
®
4.0 Yes
ICES Yes
GS Yes
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
MIC Yes
BSMI Yes
CE Marking Compliance Yes
BNCI or BELLIS Yes
CIT Yes
GOST Yes
Saudi Arabian Compliance
(ICCP)
Yes
SABS Yes
UKRSERTCOMPUTER Yes
QuickSpecs
HP Compaq 2510p Notebook PC
Technical Specifications
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 16

For accessibility information on HP products, please visit http://www.hp.com/accessibility .
HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals –
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF – over 200,000 hours at 25°C ambient condition.
9-Cell (83WHr) Lithium-
Ion battery
Dimensions (H x W x L) 1.6 x 2.3 x 8.1 in (4.1 x 5.9 x 20.6 cm)
Weight 1.07 lb (0.488 kg)
Cells/Type 9-cell Lithium-Ion
Energy Watt-hour Capacity 83Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
3 to 4 hours
System ON 4 to 5 hours (depending on system power
consumption)
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
QuickSpecs
HP Compaq 2510p Notebook PC
Technical Specifications
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 17

6-Cell (55WHr) Lithium-
Ion battery
Dimensions (H x W x L) 0.8 x 2.3 x 8.1 in (2.1 x 5.9 x 20.6 cm)
Weight 0.73 lb (0.332 kg)
Cells/Type 6-cell Lithium-Ion
Energy Watt-hour Capacity 55Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
3-Cell (28WHr) Lithium-on
battery
Dimensions (H x W x L) 0.8 x 1.5 x 8.1 in (2.1 x 3.9 x 20.6 cm)
Weight 0.39 lb (0.176 kg)
Cells/Type 3-cell Lithium-Ion
Energy Watt-hour Capacity 28.8Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Charges the battery up to 90% within 90 minutes
when system is OFF
QuickSpecs
HP Compaq 2510p Notebook PC
Technical Specifications
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 18

12.1-inch Illumi-Lite
WXGA anti-glare
Active Area (W x H) 10.3 x 6.4 in (26.1 x 16.3 cm)
Diagonal Size 12.1 in (30.7 cm)
Surface Treatment Anti-glare
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Pitch 0.204 mm
Format 1280 x 800
Configuration RGB Stripe
Backlight LED
PPI 125
Viewing Angle ±30° Horizontal, ±10° Vertical (minimum)
Hard Drives
120-GB 5400 rpm
1.8" PATA
Drive Weight 0.13 lb (59 g)
Capacity 120 GB
Height 0.31 in (8 mm)
Width 2.12 in (54 mm)
Interface ATA-6
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 15 ms
Maximum 26 ms
Rotational Speed 5400 rpm
Logical Blocks 234,441,648
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP Compaq 2510p Notebook PC
Technical Specifications
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 19

120-GB 4200 rpm
1.8" PATA
Drive Weight 0.13 lb (59 g)
Capacity 120 GB
Height 0.31 in (8 mm)
Width 2.12 in (54 mm)
Interface ATA-6
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 15 ms
Maximum 26 ms
Rotational Speed 4200 rpm
Logical Blocks 234,441,648
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
100-GB 4200 rpm
1.8" PATA
Drive Weight 0.13 lb (59 g)
Capacity 100 GB
Height 0.31 in (8 mm)
Width 2.12 in (54 mm)
Interface ATA-6
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 15 ms
Maximum 26 ms
Rotational Speed 4200 rpm
Logical Blocks 195,371,568
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP Compaq 2510p Notebook PC
Technical Specifications
DA - 12717 Worldwide — Version 22 — August 25, 2008 Page 20
