HP CHROMEBOOK 11-2201na User manual

User Guide

© Copyright 2015 Hewlett-Packard
Development Company, L.P.
Intel is a trademark of Intel Corporation in
the U.S. and other countries and is used
under license.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: May 2015
Document Part Number: 826302-001
Product notice
This guide describes features that are
common to most models. Some features
may not be available on your computer.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to
be bound by the terms of the HP End User
License Agreement (EULA). If you do not
accept these license terms, your sole
remedy is to return the entire unused
product (hardware and software) within 14
days for a refund subject to the refund
policy of your place of purchase.
For any further information or to request a
full refund of the computer, please contact
your local point of sale (the seller).

Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation.
The computer and the AC adapter comply with the user-accessible surface temperature limits defined
by the International Standard for Safety of Information Technology Equipment (IEC 60950).
iii

iv Safety warning notice

Processor configuration setting (select models only)
IMPORTANT: Select computer models are configured with an Intel® Pentium® N35xx/N37xx series
or a Celeron® N28xx/N29xx/N30xx/N31xx series processor and a Windows® operating system. If
your computer is configured as described, do not change the processor configuration setting in
msconfig.exe from 4 or 2 processors to 1 processor. If you do so, your computer will not restart. You
will have to perform a factory reset to restore the original settings.
v

vi Processor configuration setting (select models only)

Table of contents
1 Getting to know your computer ......................................................................................................................... 1
Right side ............................................................................................................................................. 1
Left side ................................................................................................................................................ 2
Display .................................................................................................................................................. 3
Top ....................................................................................................................................................... 4
TouchPad ............................................................................................................................ 4
Buttons ................................................................................................................................. 5
Bottom .................................................................................................................................................. 6
Labels ................................................................................................................................................... 7
2 Using TouchPad gestures ................................................................................................................................. 8
Using TouchPad gestures .................................................................................................................... 8
Tapping ................................................................................................................................ 8
Scrolling ............................................................................................................................. 10
3 Using the action keys ...................................................................................................................................... 12
Using the action keys ......................................................................................................................... 12
4 Power and Battery .......................................................................................................................................... 13
Factory-sealed battery ........................................................................................................................ 13
Charging the Battery .......................................................................................................... 13
5 More HP resources ......................................................................................................................................... 14
More HP resources ............................................................................................................................ 14
6 Electrostatic Discharge ................................................................................................................................... 15
Index ................................................................................................................................................................... 16
vii

viii

1 Getting to know your computer
Right side
Component Description
(1) Power light ●White: Computer is on.
●Blinking white: Computer is in Sleep mode.
●Off: The computer is off.
(2) Audio-out (headphone)/Audio-in
(microphone) jack
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also
connects an optional headset microphone. This jack does
not support optional microphone-only devices.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a
headset.
NOTE: When a device is connected to the jack, the
computer speakers are disabled.
NOTE: Be sure that the device cable has 4-conductor
connector that supports both audio-out (headphone) and
audio-in (microphone).
(3) USB 2.0 port Connects optional USB devices, such as a keyboard,
mouse, external drive, printer, scanner or USB hub.
(4) USB 3.0 charging (powered) port Connects an optional USB device, such as a keyboard,
mouse, external drive, printer, scanner or USB hub.
Standard USB ports will not charge all USB devices or will
charge using a low current. Some USB devices require
power and require you to use a powered port.
NOTE: USB charging ports can also charge select cell
phones and MP3 players, even when the computer is off.
(5) HDMI port Connects an optional video or audio device, such as a high-
definition television, any compatible digital or audio
component, or a high-speed High-Definition Multimedia
Interface (HDMI) device.
Right side 1

Left side
Component Description
(1) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
(2) Power connector Connects an AC adapter.
(3) AC adapter light ●White: The AC adapter is connected and the battery
is charged.
●Amber: The AC adapter is connected and the
battery is charging.
●Off: The computer is using battery power.
(4) SIM slot (select models only) Supports a wireless subscriber identity module (SIM).
(5) Memory card reader Reads optional memory cards that store, manage, share,
or access information.
To insert a card:
▲Hold the card label-side up, with connectors facing
the slot, insert the card into the slot, and then push
in on the card until it is firmly seated.
To remove a card:
▲Press in on the card it until it pops out.
2 Chapter 1 Getting to know your computer
