HP Compaq Presario Manual

1-84 Volume Two
Presario 1000
System Boards Spare Part System
System Board, 16 MB, 2 MB VRAM, w/o
Cache, w/o MDM (SPGA) 261822-001 1010, 60, 60ES
System Board, 16 MB, 2 MB VRAM, w/o
Cache, w/ MDM (SPGA) 261823-001 1020, 30, 60, 60ES, 65
System Board, 16 MB, w/o L2 Cache, w/o
MDM (TCP) 282740-001 1060, 60ES, 65
System Board, 16 MB, w/ L2 Cache, w/o
MDM (TCP) 282770-001 1072, 82, 84
System Board, 32 MB, w/ L2 Cache, w/
MDM (TCP) 282785-001 1072, 80, 84
System Board, 16 MB, w/o L2 Cache, w/
MDM (TCP) 282786-001 1070, 75, 1090ES
Configuration
Code/Model System Board Spare Part Model
HZD4 261822-001 1010
HZD5 261823-001 1020
HZD6 261823-001 1020
HZE2 261823-001 1030
BMSB 282740-001 1065
BMS2 282786-001 1070
BMR4 282740-001 1060, 1060ES
BMR4 261823-001 1060
BMT2 282770-001 1072
BMV2 282785-001 1080
BMV4 282770-001 1082
BMV5 282770-001 1084
BPF2 282786-001 1075
BQGN 282786-001 1090ES
Microprocessors Spare Part System
120 MHz, SPGA 261824-001 1010, 20, 1060,
1060ES
120 MHz , TCP 282769-001 1060, 60ES,
1090ES
133 MHz, SPGA 261825-001 1030, 1065
133 MHz, TCP 282736-001 1065, 70, 72
150 MHz, MMX, TCP 282831-001 1075
166 MHz, MMX, TCP 282743-001 1080, 82, 84
686/150 296993 1090ES
Processor Fan Assembly w/ Heat Sink 261859-001 1060, 60ES, 65
Processor Fan Assembly w/ Heat Sink, TCP 282739-001 All
Memory Modules/Boards Spare Part System
16 MB System Memory, Internal 261827-001 All except 1072, 84
32 MB System Memory, Internal 282767-001 1072, 84
16 MB System Memory, External 261829-001 All
32 MB System Memory, External 261830-001 All

Volume Two 1-85
Presario 1000
PC Cards Spare Part System
SpeedPaq 192 Fax Modem 187123-001 All
192 Fax Modem 188512-001 All
288 Fax Modem 189661-001 All
SpeedPaq 288 Telephony PC Card 212028-001 All
SpeedPaq 33.6 Telephony 266203-001 All
33.6 Fax Modem 261864-001 1090ES
Hard Drives Min ROM Spare Part System
810 MB System 261834-001 1010
1.0 GB System 261835-001 1060, 60ES, 65, 70, 72
1.44 GB System 261836-001
282766-001 1020, 30, 1090ES, 1075, 80, 82, 84
Diskette Drives Spare Part System
3.5” 3-Mode 261848-001 All
CD-ROM Spare Part System
4X CD-ROM 261832-001 1010
6X CD-ROM 261833-001 1020, 30, 60, 60ES, 65
10X CD-ROM 282738-001 1070, 72, 80, 82, 84
12X CD-ROM 282797-001 1075, 1090ES
10 CD-ROM Adapter 282799-001 1090ES
Cables Spare Part System
Miscellaneous Cables 261849-001 All
Miscellaneous Internal Spare Part System
LCD Interface Board 261844-001 All
Modem, 33.6 Kb/s, Fax [phone], 30, 65, 70, 72,
75, 80, 84
Modem, 56.0 Kb/s 282834-001 1075
Speaker Assembly 261847-001 All
Regulator Module 261831-001 All
Miscellaneous External Spare Part System
Battery, NiMH 261842-001 1010, 20, 60, 60ES
Battery, Li-Ion 261843-001 All except 1010, 20,
60, 60ES
AC Adapter 261867-001 All
Keyboard, US/Can 261837-001 All
Port Replicator 261845-001 All
Palm Rest w/ Touchpad 261838-001 All

1-86 Volume Two
Presario 1000
Video Spare Part System
Display Assy, DSTN, 11.3” w/ Clutches, Logos,
Plastics 261826-001 1010, 20, 60, 60ES, 1090ES
Display Assy, CTFT, 11.3” w/ Clutches, Logos,
Plastics 261865-001 1030
Display Assy, 12.1” DSTN 282737-001 1065, 70, 75
Display Assy, 12.1” CTFT 282741-001 1072, 80, 82, 84
Display, LCD Status 261839-001 All
ROM Information Spare Part System
ROMPaq 261922-001 All
Power Supply/Battery Spare Part System
Clock/Battery 117099-001 All

Volume Two 1-87
Presario 1000
Memory Upgrade Chart
ADD ANY ONE OF THE FOLLOWING
MEMORY MODULES:
16MB Memory Module, Option # 261806-001
32MB Memory Module, Option # 282789-001
Maximum Memory, Models 1072, 84 = 64MB
Maximum Memory, All Models except 1072, 84 = 32MB
