HP EliteBook 8770w Mobile Workstation
HP’s most powerful mobile workstation oers the highest-performing professional graphics,
extreme processing power, a 17.3-inch diagonal display and a chiseled design.
Power to perform.
Create masterful designs and jaw-dropping animations with
workstation-caliber graphics by either AMD or NVIDIA. The HP
EliteBook 8770w is ISV-certied so your mobile workstation runs
smoothly and reliably.
Keep up with large les and critical projects with the incredible
performance and responsiveness of an Intel® Core™ i7 quad-core
or i7 or i5 dual-core processor.1 Run demanding applications with up
to four SODIMMS2 and up to three hard disk drives3for improved
performance and speed. This mobile workstation supports best-in-
class, professional graphics with up to 4 GB of video memory.
View projects on the 17.3-inch diagonal HD4 display. Expand your view
to see multiple screens at once or enlarge your content across ve
additional displays for ne-tuning designs.5
Control color attributes across various devices throughout your
development environments with HP DreamColor Technology.3
Creativity with business acumen.
Save time by quickly accessing your favorite les with Intel Smart
Response Technology.6 You’ll also gain fast response times for system
boot and application startup.
Engage in video conferences,7 web-based trainings8 or streaming
videos with smooth audio quality. SRS Premium Sound PRO also allows
you to share crisp, powerful sound directly from your workstation.
Forget the extra speakers during your presentations.
Access the Internet and email in more places than ever with various
wireless technologies9 that keep you connected—from Wi-Fi
CERTIFIED™ WLAN9 to HP Mobile Broadband featuring 3G and 4G3,10
and optional Bluetooth connectivity.3
Business on the run.
Work eciently in dimly lit rooms or on red eye ights, thanks to
the full-size, backlit keyboard.3 When you invest in a computer
this powerful, you want it to last. The HP EliteBook 8770w meets
tough military standards (MIL-STD-810G) for drop, vibration, dust,
temperature and altitude.11
hp.com/zworkstations

EliteBook 8770w Mobile Workstation HP recommends Windows® 7.
Form Factor Mobile
Operating system Preinstalled:
Genuine® Windows 7 Professional 3212
Genuine Windows 7 Professional 6412,13
Genuine Windows 7 Home Premium 6412,13 (select countries)
FreeDOS
Supported:
Genuine Windows XP Professional 3212
Genuine Windows XP Professional 6412,13
Genuine Windows 7 Enterprise 3212
Genuine Windows 7 Enterprise 6412,13
Genuine Windows 7 Ultimate 3212
Genuine Windows 7 Ultimate 6412,13
SUSE Linux Enterprise Desktop
Red Hat Enterprise Linux (RHEL)
Certied:
SUSE Linux Enterprise Desktop
Red Hat Enterprise Linux (RHEL)
Processor 3rd Generation Intel®CoreTM i7 Quad-Core1 with Turbo Boost Technology;14 3rd Generation Intel®CoreTM i7 and i5 Dual-Core1 with Turbo Boost
Technology14
Chipset Mobile Intel® QM77 Express Chipset (vPro™ support15)
Memory DDR3 SDRAM, 1600 MHz, dual-core processors support 2 memory slots and quad-core processors support 4 memory slots, 2/4/8 GB16
SODIMMs, up to 32 GB total2
Internal Storage17 Primary Storage: 320/500/750 GB 7200 rpm SMART SATA II HDD, 500 GB 7200 rpm SED (Self Encrypting Drive), or SATA 6 Gb/s, 128/180 GB SSD, SATA
6 Gb/s, 256 GB SED SSD 2nd Primary Storage: 320/500/750 GB 7200 rpm SMART SATA II HDD, 500 GB 7200 rpm SED (Self Encrypting Drive), or SATA 6 Gb/s,
128/180 GB SSD, SATA 6 Gb/s, 256 GB SED SSD, RAID 0, 1, 5 support;18 HP 3D DriveGuard19
Flash Cache Optional Intel® 24 GB SLC mSATA cache module support Intel Smart Response Technology (available with non-SED HDD only)3
Upgrade Bay 12.7 mm SATA optical drive or hard drive: Blu-ray R/RE DVD+/-RW SuperMulti DL Drive,3,20 Blu-ray ROM DVD+/-RW SuperMulti DL Drive,3,20 DVD+/–RW
SuperMulti DL Drive,3,20 DVD-ROM Drive,3 500 GB 7200 rpm HDD;3,17 or Weight saver
Display 17.3" diagonal LED-backlit WVA anti-glare, HD+4 (1600 x 900); 17.3" diagonal LED-backlit WVA anti-glare, FHD4 (1920 x 1080);
17.3" diagonal LED-backlit UWVA, anti-glare, FHD4 DreamColor (1920 x 1080)21
Graphics AMD FireProTM M4000, with 1 GB dedicated GDDR5 video memory (AMD Eyenity Technology for advanced multi-monitor support),22
NVIDIA Quadro K3000M, with 2 GB dedicated GDDR5 video memory, NVIDIA Quadro K4000M, with 4 GB dedicated GDDR5 video memory, NVIDIA Quadro
K5000M, with 4 GB dedicated GDDR5 video memory. NVIDIA Quadro mobile professional graphics support multiple monitors22
Audio/Visual High Denition Audio (SRS Premier Sound PRO), integrated stereo speakers, stereo headphone/line out, stereo microphone in, optional 720p HD4
Webcam,3 integrated dual-microphone array
Wireless Support3,9,10 Optional HP hs2350 HSPA+ Mobile Broadband;3 Optional HP un2430 EV-DO/HSPA Mobile Broadband3 Broadcom 802.11a/b/g/n 2x2; Intel®Centrino
Advanced-N 6205 802.11 a/b/g/n 2x2; Intel® Centrino Ultimate-N 6300, 802.11a/b/g/n 3x3; HP Integrated Module with Bluetooth® v4.0 Wireless
Technology; HP Connection Manager
Communications Integrated Intel® 82579LM Gigabit Network Connection (vPro™ support15), 56K v.92 modem3
Ports and Connectors 2 USB 3.0 ports, 2 USB 2.0 ports (1 charging),1 eSATA/USB 2.0 combo port,1 VGA,1 DisplayPort 1.2, 1 stereo microphone in, 1 stereo
headphone/line out, 1 1394a, 1 power connector, 1 RJ-11(optional modem3), 1 RJ-45(Ethernet), 1 docking connector, 1 secondary battery
connector, security lock slot
Expansion Slots 1 ExpressCard/54 slot, SD/MMC Media card slot – Supports SD, SDHC, SDXC, MMC, MMC+; Integrated Smart Card Reader
Input Devices Full-sized spill-resistant keyboard with numeric keypad, drains, backlit keyboard (optional, with two brightness settings), Image Sensor touchpad
with scroll and gestures support; point stick, 4 discrete launch buttons ( WLAN on/o, mute, Web braowser, calculator)
Software (Windows OS only) HP Power Assistant,23 HP Recovery Manager, HP Support Assistant, Microsoft® Oce 2010 Starter Preloaded (select models); Purchase Key,24 Corel
WinDVD (select models), Roxio Secure Burn25 (select models), Roxio MyDVDE Business 2010 (select models), Performance Advisor
Custom Integration Services provides tailor-made, turnkey solutions for Business Ready PCs.
Security Standard: HP ProtectTools,19 TPM Embedded Security Chip 1.2, HP Fingerprint Sensor, Pre-Boot Security, HP SpareKey (requires initial user setup), HP Disk
Sanitizer,26 Drive Encryption for HP ProtectTools, Credential Manager for HP ProtectTools, Face Recognition for HP ProtectTools,27 File Sanitizer for
HP ProtectTools,26 Smart Card Reader, Security lock slot Optional: Computrace,3,28 Central Management for HP ProtectTools3,29
Dimensions (w x d x h) 16.4 x 10.7 x 1.47 in (at front); 41.7 x 27.3 x 3.7 cm (at front)
Weight Starting at 7.66 lb ( 3.47 kg) with SSD and weight saver (weight will vary by conguration)
Power23 8-cell (83 WHr) Lithium-Ion battery, 8-cell (75 WHr) HP Long Life Battery (3-year),30 optional HP ST09 Extended Life Notebook Battery
(73 WHr), Optional HP BB09 Ultra Extended Life Notebook Battery (100 WHr), 200W HP Slim Smart AC Adapter, 230W HP Slim Smart AC Adapter,
HP Fast Charge31
Expansion Solutions3HP 230W Docking Station, HP 230W Advanced Docking Station, HP USB 2.0 Docking Station, HP Essential USB 2.0 Port Replicator, HP Dual Hinge Note-
book Stand, HP Display & Notebook Stand, HP Adjustable Display Stand, HP Adjustable Dual Display Stand
Warranty Limited 3-year and 1-year warranty options available, depending on country, 1-year limited warranty on primary battery. Optional HP Care Pack
Services3,32 are extended service contracts which go beyond your standard warranties.
For more details visit: hp.com/go/lookuptool.
