HP ProBook 4535s User instructions

1. WWAN antennas (select models) 14. Touchpad
2. WLAN antennas 15. Touchpad pick buttons
3. Dual-microphone array 16. Touchpad on/off button with LED indicator
4. Webcam LED indicator (with webcam) 17. Stereo microphone in
5. 720p HD webcam 18. Stereo headphone/line out
6. Stereo speakers 19. Media Card Reader
7. HP QuickWeb button with LED indicator 20. Hard drive activity LED indicator
8. Wireless on/off button with LED indicator 21. Power button with LED indicator
9. Optical drive (select models) 22. HP Power Assistant function key
10. Numeric keypad 23. Volume mute function key
11. Optional RJ-11/modem port 24. Volume down function key
12. (2) USB 2.0 ports 25. Volume up function key
13. Optional HP Fingerprint Sensor
QuickSpecs
HP ProBook 4535s Notebook PC
Overview
DA - 14044 North America — Version 12 — August 2, 2012 Page 1

1. Battery charging LED indicator 6. RJ-45/Ethernet port
2. HDMI 1.4a port 7. VGA/external monitor connector
3. USB 2.0 port 8. Vent
4. USB 2.0 port 9. Power connector
5. ExpressCard/34 slot 10. Security lock slot
1. Battery and access cover release latches 4. Vents
2. Battery bay 5. Hard drive bay
3. SIM card slot (select units, located inside battery bay)
QuickSpecs
HP ProBook 4535s Notebook PC
Overview
DA - 14044 North America — Version 12 — August 2, 2012 Page 2

At A Glance
Genuine Windows 7 versions, SUSE Linux, or FreeDOS
Thin, lightweight design with metallic gray brushed aluminum finish for durability and style; wear-resistant HP DuraFinish
Full-sized spill-resistant keyboard with full separate numeric keypad
HP 3D DriveGuard to protect hard drive against impact, bumps or drops
Larger Touchpad with gestures support, on/off button with LED indicator
Enhanced security features including HP ProtectTools, HP Face Recognition, HP Fingerprint Sensor, and optional HP Privacy
Filter
SRS Premium Sound optimized for high fidelity audio
HDMI port for connecting to high-resolution displays
ArcSoft TotalMedia Suite for playing, creating, and editing video and audio files
HD webcam with dual-microphone array for video conferencing
15.6-inch diagonal LED-backlit HD anti-glare display with 16:9 aspect ratio
Accelerated Processing Unit and graphics powered by VISION Pro Technology from AMD
HP QuickWeb for convenient online access without the standard boot-up time
Flexible wireless connectivity options controlled by HP Connection Manager:
Integrated HP Mobile Broadband Module
Integrated 802.11 b/g/n wireless LAN module
Integrated 802.11 a/b/g/n or b/g/n with Bluetooth 3.0 High Speed (HS) combo card *
HP DayStarter for calendar display during startup
HP Power Assistant to conserve power, increase battery run-time, monitor power needs, report workforce power consumption
BFR/PVC-free, ** ENERGY STAR® qualified, *** and EPEAT® Gold registered in the U.S. EPEAT status varies by country—please
see epeat.net .
* Available on select models.
** This notebook is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free) on notebooks that are non-WWAN; meeting
the evolving definition of 'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics
(BFR/CFR/PVC-Free)'". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and < 1000 ppm (0.1%) of
chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. Power supply and power cords are not BFR/PVC-free. Service parts
after purchase may not be BFR/PVC-free.
*** Microsoft® Windows® required for ENERGY STAR qualification.
QuickSpecs
HP ProBook 4535s Notebook PC
Overview
DA - 14044 North America — Version 12 — August 2, 2012 Page 3

Accelerated Processing
Unit (APU)
VISION Technology from AMD
AMD Quad-Core A6-3400M with Radeon HD 6520G Graphics
(2.3 GHz/1.4 GHz, 4 MB L2 cache, 35W)
AMD Dual-Core A4-3300M with Radeon HD 6480G Graphics
(2.5 GHz/1.9 GHz, 2 MB L2 cache, 35W)
NOTE: APU speed denotes maximum performance mode; APUs will run at lower speeds in battery
optimization mode.
Operating System Preinstalled Genuine Windows 7 Professional 32 *
Genuine Windows 7 Professional 64 *
Genuine Windows 7 Home Premium 32 *
Genuine Windows 7 Home Premium 64 *
Genuine Windows 7 Home Basic 32 * (select countries)
SUSE Linux Enterprise Desktop 11
FreeDOS
Supported Genuine Vista Home Basic
Genuine Windows XP Professional 32
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality.
See: http://www.microsoft.com/windows/windows-7/ for details.
Fusion Controller Hub
(Chipset)
AMD A70M FCH
Graphics
included with Accelerated
Processing Unit (APU)
AMD Radeon HD 6520G Graphics (with AMD Quad-Core A6-3400M APU)
AMD Radeon HD 6480G Graphics (with AMD Dual-Core A4-3300M APU)
Display Internal 15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Optional HP Privacy Filter
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz.
HDMI port supports direct connection to high-definition displays with up to
1920 x 1080 resolution and 7-channel audio with one convenient cable (not
included).
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 4

Memory Standard DDR3 PC3-10600 SDRAM (1333 MHz)
Two SODIMM slots supporting dual-channel memory
2 GB, 3 GB, and 4 GB SODIMMs
Maximum Upgradeable to 8 GB with 4 GB SODIMMs
in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
Communications Realtek Ethernet (10/100/1000 NIC) *
Optional 56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless options featuring support for the latest industry
standards.
Mobile Broadband
options
Mobile Broadband (WWAN) requires a Windows operating system and is
available in select countries as a factory configurable feature for the HP
ProBook 4535s. Two 850/900/1575/1700/1800/ 1900/2100 MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies.
NOTE: Separately purchased mobile network operator service is required.
HP hs2340 HSPA+ Mobile
Broadband Module
Integrated mobile broadband module that provides connectivity to both HSPA
and HSPA+ (UMTS) networks. It also provides standalone, Internet and
network assisted GPS functionality for various mapping applications and
security applications such as Computrace Pro for HP ProtectTools.
HP un2430 EV-DO/HSPA
Mobile Broadband Module
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA)
networks. It also provides GPS functionality for various mapping applications
and security applications such as Computrace Pro for HP ProtectTools.
802.11 integrated
wireless LAN options
Wi-Fi certified *
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 5

Realtek 8188GN 802.11
b/g/n 1x1 WiFi Adapter
Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Ralink 5390GN 802.11
b/g/n 1x1 WiFi Adapter
Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Ralink 3592BC8 802.11
a/b/g/n 2x2 WiFi and
Bluetooth 3.0+HS Combo
Adapter *
Integrated support for 802.11 a, b, g, and n
Up to 300 mbps data rate
Bluetooth Specification 3.0 High Speed (HS) * and 2.1 compliant
Works with a wide range of Bluetooth devices
Atheros 9285GN
802.11 b/g/n
1x1 WiFi and 3011
Bluetooth 3.0+HS Combo
Adapter *
Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Bluetooth Specification 3.0 High Speed (HS) * and 2.1 compliant
Works with a wide range of Bluetooth devices
Realtek 8188BC8 802.11
b/g/n 2x2 WiFi and
Bluetooth 3.0+HS Combo
Adapter *
Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Bluetooth Specification 3.0 High Speed (HS) * and 2.1 compliant
Works with a wide range of Bluetooth devices
* Bluetooth 3.0+HS support requires a Windows operating system.
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain
system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage
to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key
layout with desktop keyboard features, such as editing keys, both left and right control and alt keys,
function keys, and an integrated numeric keypad. US and International key layouts are available.
Launch Buttons and
Function Keys
Separate launch buttons provide easy access to wireless on/off and HP QuickWeb. Function keys provide
control of features including: standby mode, display brightness, external display, HP Power Assistant,
volume mute, volume down, volume up, and media control.
Pointing device Touchpad with gestures support, on/off button with LED indicator, two-way scroll, two pick buttons
Expansion card slots ExpressCard/34 slot Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes
Media Card Reader Supports High Speed SD 3.0 (Secure Digital), MultiMediaCard, Memory Stick,
Memory Stick Pro, Memory Stick Pro Duo * , SD Micro, MultiMediaCard Micro
* Memory Stick Pro Duo Adapters are required and sold separately. Inserting a Memory Stick Pro Duo Card
directly into your notebook could damage the memory card and/or notebook.
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 6

Internal Storage Hard drives 320/500/750 GB 7200 rpm SMART SATA II
320 GB 5400 rpm SMART SATA II
NOTE: Up to 15 GB is reserved for the system recovery software.
HP 3D DriveGuard
(Windows models only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Removable Storage Fixed optical drives Blu-ray ROMDVD+/-RW SuperMulti DL Drive
DVD+/-RW SuperMulti DL Drive
DVD-ROM Drive
Interfaces VGA One
HDMI 1.4a One
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem (optional) One
RJ-45/Ethernet One
USB 3.0 One
USB 2.0 Three
Audio/Visual SRS Premium Sound™
Integrated stereo speakers
Integrated microphone (dual-microphone array)
Function keys for volume mute, volume up, volume down; play, rewind, and fast-forward of video and
audio files
Stereo headphone/line out
Stereo microphone/line in
HD webcam
HD format (widescreen)
Supports web casting and still image capture
High-quality fixed focus lens
M-JPEG compression supports higher frame rates for video capture and web casting
Improved low light sensitivity
Improved dynamic range
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 7

Software Preinstalled software
with Windows Operating
System
HP Recovery Manager
HP Support Assistant
HP ProtectTools Security Manager
HP ProtectTools for Central Management
HP Face Recognition
HP Hotkey Support
HP QuickWeb
HP Power Assistant
HP Connection Manager
HP DayStarter
Microsoft Office 2010 preloaded (purchase of a Product
Key required to activate a full Office 2010 suite) *
Norton Internet Security 2011 **
PDF Complete Special Edition ***
ArcSoft Total Media Suite
HP Webcam Software (select models)
Skype
ArcSoft Total Media Suite
Additional software
available from the web
HP SoftPaq Download Manager
* Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel. Purchase of
Product Key required to activate full Office 2010 suite available at participating resellers/retailers and
www.office.com .
** Norton Internet Security 2011 includes 60 days of complimentary live updates; subscription required for
live updates thereafter. Internet access required to receive updates.
*** PDF Complete Special Edition 60 day trial; purchase license afterwards for full functionality.
HP Recovery Manager Models shipped with Windows 7 include HP Recovery Manager. HP Recovery Manager enables fast
recovery of the factory preinstalled image if the system becomes corrupted or if important system files
are accidentally deleted. Up to 20 GB of the hard drive is reserved for the system recovery software.
Security Standard Features HP ProtectTools Security Manager (standard modules include)
Credential Manager
Computrace * Pro
Device Access Manager
Drive Encryption
Face Recognition (webcam configurations only)
File Sanitizer
Privacy Manager
HP Fingerprint Sensor
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Security lock slot
Optional Features HP Privacy Filter
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 8

* The Computrace agent is shipped turned off, and must be activated by customers when they purchase a
subscription with terms ranging from one to five years. For more information on HP security solutions
refer to: www.hp.com/products/security .
HP ProtectTools Security
Manager with Central
Management
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The ProtectTools modules are available on the hard drive
(also downloadable from the web) and can be configured in Software Setup.
HP ProtectTools is centrally manageable with the capability to manage notebooks from a single point. HP
ProtectTools is management ready out of the box, in partnership with Digital Persona. Features address
requirements that customers expect from a centrally managed security solution such as user provisioning,
credential reset, and credential revocation.
HP ProtectTools provides two separate management solutions, targeted at the enterprise and the SMB:
Digital Persona Pro AD: Designed for the enterprise customer. Integrates with Active Directory and
gives IT Managers the ability to provision users, create login policies based on passwords,
biometrics or smartcards. Management features also include remote credential recovery in case the
user forgets the password, loses the smartcard or cannot use the fingerprint reader for any reason.
In addition, advanced auditing capabilities are also built in. Digital Persona Pro AD is available now.
Digital Persona Pro Workgroup: Designed for the small business customer. Provides features
similar to the Active Directory version, but for workgroups. Workgroup activation is built into HP
ProtectTools, and activation of up to 5 seats is completely free.
For more information on Central Management for HP ProtectTools, refer to:
www.hp.com/products/security .
Power Supply External 65-watt Smart AC adapter
6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet (3.66 meter)
HP Fast Charge *
* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast
Charge does not apply to the HP 9-cell battery.
Battery Primary battery HP 9-cell (93 WHr) Li-Ion battery
HP 6-cell (47 WHr) Li-Ion battery
Battery Life 9-cell battery 93 WHr Up to 11 hours and 15 Minutes
6-cell battery 47 WHr Up to 6 hours
NOTE: Battery life will vary depending on the product model, configuration, loaded applications, features,
use, wireless functionality and power management settings. The maximum capacity of the battery will
naturally decrease with time and usage. See MobileMark07 battery benchmark
www.bapco.com/products/mobilemark2007 for additional details.
System Standby Time Up to 1 week
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 9

Power Conservation Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance
Mode, or Automatic mode)
ATI PowerPlay technology
Hibernation
Standby
ACPI compliance
Service and Support HP Services offers limited 3-year and 1-year warranty options depending on country; 1-year limited
warranty on primary battery. Warranty upgrades are also available. HP Care Pack Services extend service
contracts beyond the standard warranties. To choose the right level of service for your HP product, use the
HP Care Pack Services Lookup Tool at: www.hp.com/go/lookuptool . Additional HP Care Pack Services
information by product is available at: www.hp.com/services/carepack .
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
QuickSpecs
HP ProBook 4535s Notebook PC
Standard Features (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 10

NOTE: Options/capabilities listed in the QuickSpecs represent those capabilities available through Base Units or Build to Order
configurations. The various product features and capabilities will vary in terms of configurable vs. aftermarket options (AMOs). There
may be options and capabilities available through CTO that are not available as AMOs.
Memory HP 1 GB (DDR3 1333 MHz) SODIMM AT911AA#xxx
HP 2 GB (DDR3 1333 MHz) SODIMM AT912AA#xxx
HP 2 GB PC3-12800 (DDR3 1600 MHz) SODIMM H2P63AA
HP 4 GB PC3-12800 (DDR3 1600 MHz) SODIMM H2P64AA
NOTE: Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux. With Windows 32-bit operating
systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available
due to system resource requirements. Due to system limitations, DDR3-1600 MHz memory will only be supported at DDR3-1333 MHz.
Storage HP 250 GB Pocket Media Drive FE477AA
HP Mobile USB DVD XQ543AA
HP Mobile USB DVDRW BU516AA
Power HP 65W Slim Adapter AX727AA#xxx
Carrying Cases HP Basic Carrying Case AJ078AA
HP Business Nylon Case BP848AA
HP Professional Slim Top Load Case AY530AA
Security HP Notebook Combo Lock AY475AA#xxx
HP Keyed Cable Lock BV411AA
HP 15.6-inch Display Privacy Filter AU103AA#xxx
Input/Output Devices HP USB Optical Travel Mouse RH304AA
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP USB Keyboard & Mouse Bundle RC465AA#xxx
QuickSpecs
HP ProBook 4535s Notebook PC
Options (availability may vary by country)
DA - 14044 North America — Version 12 — August 2, 2012 Page 11

System Unit Dimensions (HxWxD) 1.13 in (at front) x 14.76 in x 10.09 in
2.87 cm (at front) x 37.50 cm x 25.62 cm
Weight Starting at 5.14 lb (2.33 kg) without optical drive
or 5.45 lb (2.47 kg) with optical drive
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by
configuration and components.
Stand-Alone Power
Requirements
(AC Power)
Nominal Operating Voltage 18.5 V
Average Operating Power with integrated graphics: TBD W
with discrete graphics: TBD W
Max Operating Power < 90 W or < 65W
Temperature Operating * 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating -50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating -50 to 40,000 ft (-15.24 to 12,192 m)
Planned
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR® Select models *
EPEAT® Registered Gold in United States **
ICES Yes
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
KCC Yes
BSMI Yes
CE Marking Compliance Yes
* Configurations of the HP ProBook 4535s that are ENERGY STAR qualified are identified as HP ProBook
4535s ENERGY STAR on HP websites and on www.energystar.gov . Microsoft Windows required for
ENERGY STAR qualification.
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 12

** EPEAT registration varies by country. See www.epeat.net for registration status by country. EPEAT
status listed above applies to U.S.
NOTE: For accessibility information on HP products, please visit: www.hp.com/accessibility .
Audio SRS Premium Sound
Hardware Implementation IDT 92HD87 High Definition CODEC
Touch-Sensitive Volume
Controls
Volume up, volume down, and mute
Full Duplex Yes
Microphone In Stereo
Headphone/Line Out Stereo
Integrated Microphone Yes, dual digital microphone array when equipped with webcam
Audio Output Quality Frequency Response 20 Hz – 20 kHz
Signal to Noise Ratio >85 dB
Total Harmonic Distortion 0.01%
Noise Floor –110 dB
Play/Record Sampling
Rate (s)
8 kHz – 48kHz
DAC 16, 20 or 24-bit
ADC 16 or 20-bit
Integrated Stereo
Speakers
Power Rating 2 Watts
Impedance 4 Ohms
Power
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 13

HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 87% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
NOTE: Unless otherwise noted, temperature limits listed in the following component specifications relate to the internal temperatures
of these components and not to the environment in which the PC is operating.
9-Cell (93 WHr) Lithium-
Ion battery
Dimensions (H x W x L) 0.8 x 2.9 x 8.3 in (2.0 x 7.3 x 21.0 cm)
Weight 1.07 lb (0.488 kg)
Cells/Type 9-cell Lithium-Ion
Energy Watt-hour Capacity 93 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
3 to 4 hours
System ON 4 to 6 hours (depending on system power
consumption)
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 14

6-Cell (47 WHr) Lithium-
Ion battery
Dimensions (H x W x L) 0.8 x 1.8 x 10.4 in (2 x 4.5 x 26.5cm)
Weight (max) .70lb, (.312kg)
Cells/Type Lithium-Ion
Energy Voltage 10.8V
Amp-hour capacity 4.4Ah
Watt-hour capacity 47Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
2.5 hours
System ON 3 to 5 hours
Fuel Gauge LED No
Warranty 1 year
Optional Travel Battery
Available
No
Displays
15.6-inch LED HD (1366 x
768)
anti-glare
Dimensions (W x H) 13.54 x 7.59 in (34.4 x 19.4 cm)
Diagonal Size 15.6 in (39.6cm)
Surface Treatment Anti-glare
Contrast Ratio 400:1 (min)
Refresh Rate 60 Hz
Brightness 210 nit (typical)
Pixel Resolution Pitch 0.252 mm
Format 1366 x 768
Configuration RGB Stripe
Backlight LED
PPI 101 ppi
Viewing Angle ±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
Internal Storage
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 15

750 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 750 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 1,465,149,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
500 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 500 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 976,773,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 16

320 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115 g)
Capacity 320 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 625,142,448
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
320 GB 5400 rpm SATA
Hard Drive
Drive Weight 0.22 lb (101 g)
Capacity 320 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 625,142,448
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
Optical Drives
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 17

DVD-ROM Drive Access Times Random < 140 ms CD (typical)
< 160 ms DVD (typical)
Max Data Transfer Rate 24X CD-ROM
8X-DVD
Transfer Mode UDMA Mode 5
Interface Gen 1 SATA
Supported Media (read) CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW, DVD-RAM
Supported Media (write) None
Max Media Capacity (read) 8.5GB
Transport Tray Loading
DVD+/-RW SuperMulti DL
Drive
Access Times Random <140ms CD (typical)
< 160 ms DVD (typical)
Max Data Transfer Rate 24X CD-ROM
8X DVD
24X CD-R
24X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
6X - DVD+R Dual Layer
6X - DVD-R Dual Layer
5X DVD-RAM
Transfer Mode UDMA Mode 5
Interface Gen 1 SATA
Supported Media (read) CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW, DVD-RAM
Supported Media (write) CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM, DVD+R DL, DVD-R
DL
Max Media Capacity (read) 8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport Tray Loading
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 18

Blu-ray ROM DVD+/-RW
SuperMulti DL Drive
Access Times Random <190 ms CD-ROM (typical)
< 180ms DVD-ROM (typical)
<230 ms BD-ROM (typical)
Max Data Transfer Rate 24X CD-ROM
8X DVD-ROM
24X CD-R
16X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
4X - DVD+R Dual Layer
4X - DVD-R Dual Layer
5X DVD-RAM
6X BD-ROM
Transfer Mode UDMA Mode 5
Interface Gen 1 SATA
Supported Media (read) CD-DA, , CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW. DVD-RAM, BD-ROM, BD-R, BD-RE
Supported Media (write) CD-R, CD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW, DVD-
RAM
Max Media Capacity (read) 50.0 GB
Max Media Capacity
(write)
8.5GB
Transport Tray Loading
Security
HP Fingerprint Sensor Mobile Voltage Operation 3.0V–3.6V single supply
Operating Temperature 32° – 158°F (0° – 70°C)
Current Consumption @
3.3V
Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management
High-Rate Image Capture Up to 240 image frames /sec
ESD Resistance IEC 61000-4-2 Level 4 (±15KV)
Detection Matrix 192 x 16 Pixels
9.7 mm x 0.81 mm
500 ppi High-Resolution Images
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 19

Communications
V.92 56K Data/Fax Modem Form Factor MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class
B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other
Countries
Data Mode Capabilities V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates :
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates :
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
T.31
Command Set V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
QuickSpecs
HP ProBook 4535s Notebook PC
Technical Specifications
DA - 14044 North America — Version 12 — August 2, 2012 Page 20
